2007 SUBARU FORESTER specification

12-2 Specifications
Sp ecificationsSpecifications
These specifications are subject to change without notice. „Dimensions
in (mm)
*1: Measured with vehicle empty
AT: Automatic transmission
MT: Manual transmission
Item2.5-liter non-turbo models2.5-liter turbo models
Drive systemAWD
Transmission typeATMTATMT
Overall length176.6 (4,485)
Overall width68.3 (1,735)
Overall height62.6 (1,590)62.4 (1,585)
Wheel base99.4 (2,525)
TreadFront58.9 (1,495)
Rear58.5 (1,485)
Ground clearance* 18.07 (205)7.87 (200)

Specifications 12-3
–
CONTINUED –
„ Engine
„ Electrical system
Engine modelEJ253 (2.5-liter, SOHC, non-turbo)EJ255 (2.5-liter, DOHC, turbo)
Engine typeHorizontally opposed, liquid cooled 4 cylinder, 4-stroke gasoline engine
Displacement cc (cu-in)2,457 (150)
Bore u Stroke in (mm)3.92 u 3.11 (99.5 u 79.0)
Compression ratio10.0 : 18.4 : 1
Firing order1 – 3 – 2 – 4
Battery type and capacity (5HR)Manual transmission12V-48AH (55D23L)
Automatic transmission12V-52AH (75D23L)
Alternator2.5-liter turbo models12V-110A
2.5-liter non-turbo models12V-90A
Spark plugs2.5-liter non-turbo modelsFR5AP-11 (NGK)
2.5-liter turbo modelsILFR6B (NGK)

12-4 Specifications
„Capacities
AT: Automatic transmission
MT: Manual transmission
Fuel tank15.9 US gal (60 liters, 13.2 Imp gal)
Engine oil4.2 US qt (4.0 liters, 3.5 Imp qt)
Transmission oilMT3.7 US qt (3.5 liters, 3.1 Imp qt)
AT9.8 US qt (9.3 liters, 8.2 Imp qt)
Front differential gear oil (AT)1.3 US qt (1.2 liter, 1.1 Imp qt)
Rear differential gear oil0.8 US qt (0.8 liter, 0.7 Imp qt)
Power steering fluid0.7 US qt (0.7 liter, 0.6 Imp qt)
Engine coolant2.5-liter non-turbo modelsMT7.3 US qt (6.9 liters, 6.1 Imp qt)
AT7.2 US qt (6.8 liters, 6.0 Imp qt)
2.5-liter turbo modelsMT7.8 US qt (7.4 liters, 6.5 Imp qt)
AT7.7 US qt (7.3 liters, 6.4 Imp qt)

Specifications 12-5
„Tires
NOTE
For the Canada specification non-turbo models, there is a conventional tire installed under the floor of the cargo area. „Wheel alignment
Tire sizeP215/60R16 94HP215/55R17 93H
Wheel size16 u 6 1
/2 JJ or 16
u 6 1
/2 J17
u 7 JJ
PressureFrontLight load29 psi (200 kPa, 2.0 kgf/cm 2
)32 psi (220 kPa, 2.2 kgf/cm 2
)
Full load29 psi (200 kPa, 2.0 kgf/cm 2
)32 psi (220 kPa, 2.2 kgf/cm 2
)
RearLight load28 psi (190 kPa, 1.9 kgf/cm 2
)30 psi (210 kPa, 2.1 kgf/cm 2
)
Full load36 psi (250 kPa, 2.5 kgf/cm 2
)32 psi (220 kPa, 2.2 kgf/cm 2
)
Trailer towing41 psi (280 kPa, 2.8 kgf/cm 2
)36 psi (250 kPa, 2.5 kgf/cm 2
)
Temporary spare tireSizeT135/80D16
Pressure60 psi (420 kPa, 4.2 kgf/cm 2
)
Item2.5-liter non-turbo models2.5-liter turbo models
Drive systemAWD
ToeFront0 r 0.12 in (0 r 3 mm)
Rear0.079 r 0.12 in (2 r 3 mm)
CamberFront–0 q25’ r 45’
Rear–0 q50’ r 45’–0 q55’ r 45’

12-6 Specifications
Fuses and circuits „Fuse panel located behind the instrument pan- el
1 234 56
7891 01112
14
13 15 16 17 18 19
20 21 22 23
C00000
Fuse panelFuse ratingCircuit
115AyHeater fan
215AyHeater fan
315AyPower door lock
y Remote keyless entry
415AyPower outlet (front)
y Remote controlled rear view mirrors
510AyTail light
y Parking light
615AySRS airbag
715AyFog light
830AyABS
915AyRadio
1010A

Specifications 12-7
–
CONTINUED –
1530Ay Windshield wiper and washer
1620AyBrake light
1715AyAir conditioner
1815AyBackup light
y Cruise control
1915AyPower outlet (cargo)
2015AyRear window wiper and washer
2115AyIgnition coil (Non-turbo model only)
2215AySeat heater
23Empty
Fuse panelFuse ratingCircuit

12-8 Specifications
„Fuse panel located in the engine compartment
A) FWD socket
B) Main fuse
A 12 4
3 B
5
6 789
10 11 12 13
C00105
14
Fuse panelFuse ratingCircuit
130Ay
Radiator cooling fan (Main)
230AyRadiator cooling fan (Sub)
330AyABS motor
430AyEngine sensor (Non-turbo models only)
520AyRear window defogger
615AyHazard warning flasher
y Horn
715AyTurn signal lights
810AyAutomatic transmission control unit
910AyAlternator
1015AyHeadlight (right side)
1115AyHeadlight (left side)
1220AyLighting switch
1315AyClock
y Interior light
1410AySecondary air combination valve
(Turbo models only)

Specifications 12-9
Bulb chart
Description Wattage Bulb type
Headlight
High beam 12V-60W 9005 (HB3)
Low beamCanada-spec. 2.5XT 12V-35W D2R
All except Canada-
spec. 2.5XT 12V-55W H1
Front fog light 12V-51W 9006 (HB4)
Front turn signal light 12V-21W 1474
Parking light 12V-5W 168
Side marker light (Front) 12V-5W 168
Rear combination light Tail/stop light 12V-21/5W 7443
Turn signal light 12V-21W (Amber) 1474
Tail/stop light 12V-21/5W 7443
Backup light 12V-16W 921
High mount stop light 12V-13W 912
License plate light 12V-5W 168
Cargo area light 12V-15W –
Dome light 12V-8W –
Map light 12V-8W –
