2007 SUBARU FORESTER specification

12-10 Specifications
Vehicle identification
12
3 4
56
9 8
7
C00112 1) Vehicle identification number
2) Emission control label
3) Vehicle identification number plate
4) Tire inflation pressure plate
5) Certification plate
6) Bar cord label (U.S. only)
7) Model number plate
8) Radio noise label (Canada only)
9) Fuel label

Consumer information and Reporting safety defects 13-7
– CONTINUED –
asymmetrical tire that has a particu-
lar side that must always face out-
ward when mounting on a vehicle.
y Accessory weight
The combined weight (in excess of
those standard items which may be
replaced) of floor mats, leather seats
and cross bars to the extent that these
items are available as factory-in-
stalled equipment (whether installed
or not). y Curb weight
The weight of a motor vehicle with
standard equipment including the
maximum capacity of fuel, oil, and
coolant and air conditioning. y Maximum loaded vehicle weight
The sum of curb weight, accessory
weight, vehicle capacity weight and
production options weight. y Normal occupant weight
150 lbs (68 kg) times the number of
occupants (3 occupants). y Occupant distribution
Distribution of occupants in a vehicle,
2 in front, 1 in rear seat. y Production options weight
The combined weight of those in-
stalled regular production options weighing over 5.1 lbs (2.3 kg) in ex-
cess of those standards items which
they replace, not previously consid-
ered in curb weight or accessory
weight.
y Vehicle capacity weight
The total weight of cargo, luggage
and occupants that can be added to
the vehicle. y Vehicle maximum load on a tire
Load on an individual tire that is deter-
mined by distributing to each axle its
share of the maximum loaded vehicle
weight and dividing by two. y Vehicle normal load on a tire
Load on an individual tire that is deter-
mined by distributing to each axle its
share of the curb weight, accessory
weight, and normal occupant weight
and dividing by two. „ Tire care – maintenance and
safety practices
y Check on a daily basis that the tires
are free from serious damage, nails,
and stones. At the same time, check
the tires for abnormal wear. y Inspect the tire tread regularly and
replace the tires before their tread wear indicators become visible. When
a tire’s tread wear indicator becomes
visible, the tire is worn beyond the ac-
ceptable limit and must be replaced
immediately. With a tire in this condi-
tion, driving at even low speeds in wet
weather can cause the vehicle to hy-
droplane. Possible resulting loss of
vehicle control can lead to an acci-
dent.
y To maximize the life of each tire and
ensure that the tires wear uniformly, it
is best to rotate the tires every 7,500
miles (12,500 km). Rotating the tires
involves switching the front and rear
tires on the right-hand side of the ve-
hicle and similarly switching the front
and rear tires on the left-hand side of
the vehicle. (Each tire must be kept on
its original side of the vehicle.) Re-
place any damaged or unevenly worn
tire at the time of rotation. After tire ro-
tation, adjust the tire pressures and
make sure the wheel nuts are correct-
ly tightened. A tightening torque spec-
ification and a tightening sequence
specification for the wheel nuts can be
found “Flat tires” in Chapter 9.

14-6 Index
ReplacingAir cleaner element .................................................... 11-15
Battery (remote keyless entry) ....................................... 2-8
Bulbs ......................................................................... 11-44
Transmitters ................................................................... 2-9
Rocking the vehicle .......................................................... 8-11
Roof rail and crossbar ...................................................... 8-13 S
Safety
Precautions when driving .................................................. 4
Symbol .............................................................................. 2
Warnings ........................................................................... 2
Seat height adjustment (drivers seat) ................................. 1-4
Seatbelt .................................................................................. 4
Extender ...................................................................... 1-20
Maintenance ................................................................ 1-19
Pretensioners .............................................................. 1-21
Safety tips .................................................................... 1-10
Warning light and chime ....................................... 1-12, 3-9
Seatbelts .......................................................................... 1-10
Seats Fabric .......................................................................... 10-4
Heater ............................................................................ 1-7
Selector lever (AT vehicles) ............................................. 7-11
Self-leveling rear suspension ........................................... 7-25
Shift lock release .............................................................. 7-14
Shift position indicator ...................................................... 3-15
Shopping bag hook .......................................................... 6-14
Snow tires ........................................................................ 8-10
Snowy and icy roads .......................................................... 8-9
Spark plugs .................................................................... 11-17 Specifications ................................................................... 12-2
Speedometer ...................................................................... 3-6 SRS
Airbag system warning light ......................................... 3-10
Frontal airbag ............................................................... 1-40
Side airbag ................................................................... 1-52
SRS airbag (Supplemental Restraint System airbag) ... 4, 1-36
Steering wheel Power ........................................................................... 7-15
Tilt wheel ...................................................................... 3-28
Storage compartments ....................................................... 6-4
Sun visors ........................................................................... 6-3
Supplemental Restraint System airbag ............................ 1-36
Synthetic leather upholstery ............................................. 10-5 T
Tachometer ........................................................................ 3-7
Temperature gauge ............................................................ 3-8
Temperature warning (AT OIL TEMP) .............................. 3-12
Tie-down hooks ................................................................ 9-11
Tilt steering wheel ............................................................. 3-28
Tire Chains .......................................................................... 8-10
Inspection .................................................................. 11-30
Pressures and wear ................................................... 11-31
Replacement .............................................................. 11-34
Rotation ..................................................................... 11-34
Types ......................................................................... 11-30
Top tether anchorages ..................................................... 1-34
Towing .............................................................................. 9-10
All wheels on the ground ............................................. 9-12
Flat-bed truck ............................................................... 9-12

GAS STATION REFERENCE
Fuel: TNon-turbo models
Use only unleaded gasoline with an octane rating of 87 AKI or
higher. T Turbo models
Use premium unleaded gasoline with an octane rating of 91 AKI or
higher. If premium unleaded gasoline is not available, regular un-
leaded gasoline with octane rating of 87 AKI or higher may be tem-
porarily used. For optimum engine performance and driveability, it
is required that you use premium grade unleaded gasoline. „ Fuel octane rating
This octane rating is the average of the Research Octane and Mo-
tor numbers and is commonly referred to as the Anti Knock Index (AKI). Refer to “Fuel” section in this manual.
Fuel capacity:
15.9 US gal (60 liters, 13.2 Imp gal) Engine oil:
Use only API classification SM with the words “ENERGY CON-
SERVING” and the ILSAC certification mark (starburst mark) dis-
played on the container (ILSAC GF-4).
Engine oil capacity:
4.2 US qt (4.0 liters, 3.5 Imp qt)
Cold tire pressure:
NOTE
For the Canada specification non-turbo models, there is a c onventional tire installed under the floor of the cargo area.
Tire sizeP215/60R16 94HP215/55R17 93H
Wheel size16u 6 1
/2 JJ or 16
u 6 1
/2 J17
u 7 JJ
PressureFrontLight load29 psi (200 kPa, 2.0 kgf/cm 2
)32 psi (220 kPa, 2.2 kgf/cm 2
)
Full load29 psi (200 kPa, 2.0 kgf/cm 2
)32 psi (220 kPa, 2.2 kgf/cm 2
)
RearLight load28 psi (190 kPa, 1.9 kgf/cm 2
)30 psi (210 kPa, 2.1 kgf/cm 2
)
Full load36 psi (250 kPa, 2.5 kgf/cm 2
)32 psi (220 kPa, 2.2 kgf/cm 2
)
Trailer towing41 psi (280 kPa, 2.8 kgf/cm 2
)36 psi (250 kPa, 2.5 kgf/cm 2
)
Temporary spare tireSizeT135/80D16
Pressure60 psi (420 kPa, 4.2 kgf/cm 2
)
