5. Raise the lock tab and pull the connector (C)
from the base of the bulb to remove the
electrical connector.
6. Remove the bulb retaining nut (E) by turning it
counterclockwise.
7. Remove the bulb (D) and replace it with the
appropriate bulb.
8. Reverse the steps to reinstall the lamp
assembly.
321
ProCarManuals.com

Front Turn Signal, Parking and
Daytime Running Lamps (DRL)
(Coupe)
To change this bulb on a coupe model, do the
following:
1. Open the hood. SeeHood Release on
page 279for more information.
2. Reach behind the headlamp from inside
the hood.
3. Turn the bulb socket counterclockwise to
remove it from the housing.
4. Pull the bulb (A) from the socket (B) and
replace it with the appropriate bulb.
5. Reinstall the bulb socket (B) by turning it
clockwise.
322
ProCarManuals.com

Front Turn Signal, Parking and
Daytime Running Lamps (DRL)
(Sedan)
To change this bulb on a sedan model, do the
following:
1. Follow Steps 1 through 4 to remove the
headlamp assembly. See the headlamp
removal for sedan underHeadlamps (Coupe)
on page 319orHeadlamps (Sedan) on
page 320. This bulb is located next to the
high/low-beam headlamp.
2. Remove the bulb socket (B) by turning it
counterclockwise.
3. Remove the bulb (A) and replace it with the
appropriate bulb.
4. Reverse the steps to reinstall the lamp
assembly.
323
ProCarManuals.com

Center High-Mounted
Stoplamp (CHMSL)
To change a CHMSL bulb, do the following:
1. Remove the CHMSL cover by pulling down on
the cover edges from inside the vehicle.
2. Turn the bulb socket counterclockwise to
remove it.3. Replace with the appropriate bulb.
4. Reinstall the bulb socket by turning it
clockwise.
5. Replace the cover.
Taillamps, Turn Signal, Stoplamps
and Back-up Lamps
To change one of these bulbs, do the following:
1. Open the trunk. SeeTrunk on page 98
for more information.
2. Remove the three retaining screws from the
taillamp assembly.
324
ProCarManuals.com

3. Slide the taillamp assembly back and remove
it from the quarter panel.4. Remove the bulb socket (B) by turning it
counterclockwise.
5. Pull the bulb (A) from the socket and replace
it with the appropriate bulb.
6. Reverse the steps to reinstall the taillamp
assembly.
325
ProCarManuals.com

License Plate Lamp
To replace the license plate lamp bulb, do the
following:
1. Remove the two screws holding the license
plate lamp assembly to the fascia.
2. Turn and pull the license plate lamp forward
through the fascia opening.3. Turn the bulb socket counterclockwise and
pull the bulb straight out of the socket.
4. Install the new bulb.
5. Reverse Steps 1 through 3 to reinstall the
lamp assembly.
Replacement Bulbs
Exterior Lamp Bulb Number
Back-up Lamps 921
CHMSL PC-175
Front Turn Signal/Parking
Lamp/DRL5702KA 1
Headlamps 9007
Stoplamp and
Taillamps (Top)3057K
1 Phillips Only
For replacement bulbs not listed here, contact
your dealer/retailer.
326
ProCarManuals.com

A. Retainer
B. Jack and Wheel Wrench
C. Spare Tire
D. Foam Support
E. Bolt
3. Remove the retainer (A) that holds down the
jack, wheel wrench (B) and spare tire (C).
4. Remove the spare tire by placing your hands
at the four and eight o’clock positions. Gently
pull it up and out of the trunk.
The tools you will be using include the jack (A)
and wheel wrench (B).
354
ProCarManuals.com

You will need to turn the plastic wheel nut
counterclockwise to loosen the wheel wrench from
the jack.Press the button and then pull on the end of the
wheel wrench to extend the handle.
