Lockout Protection
This feature prevents the driver’s door from being
locked using the power door locks, if the key is
left in the ignition and a door is open.
Press the power door lock switch to lock all the
doors and then unlock the driver’s door.
Press and hold the power door lock switch for
more than three seconds to override this feature.
If the key is removed from the ignition, or if
the manual door lock or the Remote Keyless Entry
(RKE) transmitter is used, the key could still be
locked inside the vehicle. Always remember
to take the key with you.
Trunk
To open the trunk from the outside, press the
trunk release button on the Remote Keyless
Entry (RKE) transmitter.
{CAUTION:
It can be dangerous to drive with the
trunk lid open because carbon monoxide
(CO) gas can come into your vehicle. You
cannot see or smell CO. It can cause
unconsciousness and even death. If you
must drive with the trunk lid open or if
electrical wiring or other cable
connections must pass through the seal
between the body and the trunk lid:
Make sure all other windows are shut.
Turn the fan on your heating or
cooling system to its highest speed
and select the control setting that will
force outside air into your vehicle. See
Climate Control System.
If you have air outlets on or under
the instrument panel, open them all
the way.
SeeEngine Exhaust on page 123.
97

Remote Trunk Release
Press the button located
on the driver’s door
near the map pocket to
open the trunk.
The trunk can only be opened while the vehicle is
in PARK (P).
Emergency Trunk Release Handle
Notice:Do not use the emergency trunk
release handle as a tie-down or anchor point
when securing items in the trunk as it
could damage the handle. The emergency
trunk release handle is only intended to aid a
person trapped in a latched trunk, enabling
them to open the trunk from the inside.
There is a glow-in-the-dark emergency trunk
release handle located inside the trunk on
the trunk latch. This handle glows following
exposure to light. Pull the release handle up to
open the trunk from the inside.
98

Windows
{CAUTION:
Leaving children, helpless adults, or pets
in a vehicle with the windows closed is
dangerous. They can be overcome by the
extreme heat and suffer permanent
injuries or even death from heat stroke.
Never leave a child, a helpless adult, or a
pet alone in a vehicle, especially with the
windows closed in warm or hot weather.
99

Power Windows
The power window
switches are located on
the armrest on the
driver’s door. In
addition, each
passenger door has a
switch for its own
window.
Express-Down Window
The driver’s window has an express-down feature.
This switch is labeled AUTO. Press the front of
the switch part way, and the driver’s window opens
a small amount. If the front of the switch is
pressed all the way down and released, the
window goes all the way down automatically.
To stop the window while it is lowering, pull the
front of the switch momentarily. To raise the
window, pull and hold the front of the switch.
Express-Up Window
Your vehicle may have this feature on the driver’s
window. Pull the switch up to the second
position and release the switch to activate the
express-up feature. To stop the window as
it is raising, pull up or press down briey on the
switch again.
100

Programming the Power Windows
If the battery on your vehicle has been recharged,
disconnected, or is not working, you will need
to reprogram the driver’s power window for
the express-up feature to work. Replace or
recharge the vehicle’s battery before
reprogramming.
To program the driver’s window, follow
these steps:
1. With the ignition in ACC, ON, or when
Retained Accessory Power (RAP) is active,
close all doors.
2. Press and hold the power window switch until
the window is fully open.
3. Pull the power window switch up until the
window is fully closed.
4. Continue holding the switch up for
approximately two seconds after the window
is completely closed.
The window is now reprogrammed.
Express Window Anti-Pinch Feature
If any object is in the path of the window when the
express-up is active, the window stops at the
obstruction and auto-reverse to a preset factory
position. Weather conditions such as severe icing
may also cause the window to auto-reverse.
The window returns to normal operation once the
obstruction or condition is removed.
101

Express Window Anti-Pinch Override
{CAUTION:
If express override is activated, the
window will not reverse automatically.
You or others could be injured and the
window could be damaged. Before you
use express override, make sure that all
people and obstructions are clear of the
window path.
In an emergency, the anti-pinch feature can be
overridden in a supervised mode. Hold the window
switch all the way up to the second position.
The window rises for as long as the switch is held.
Once the switch is released, the express mode
is re-activated.
In this mode, the window can still close on an
object in its path. Use care when using the
override mode.
Window Lockout
The driver’s power window controls also include a
lockout button.
o(Window Lockout):Press the lockout button
to stop the rear passengers from using their
window switches. The driver and front passenger
can still operate all the windows with the lock
on. When the red part of the switch is visible you
have returned to normal window operation.
Sun Visors
To block out glare, you can swing down the
visors. You can also remove them from the center
mount and swing them to the side, to block out
glare from the side.
Your vehicle may have lighted visor vanity mirrors
located on the passenger and driver’s side
visor. When you lift the cover, the light will turn on.
102

Theft-Deterrent Systems
Vehicle theft is big business, especially in some
cities. Although your vehicle has a number of
theft-deterrent features, we know that nothing we
put on it can make it impossible to steal.
Content Theft-Deterrent
Your vehicle may have
a content theft-deterrent
alarm system.
Arming the System
With the ignition off, you can arm the system by
pressing the Remote Keyless Entry (RKE)
transmitter lock button.
The system will arm thirty seconds after all the
doors are closed, or sixty seconds with any
door open.
If you press the lock button on the transmitter a
second time while all the doors are closed, the
system will arm immediately. The system will still
arm in sixty seconds if a door is open. When the
open door is closed, the system will arm.
The security light, located on the instrument panel
cluster, comes on to indicate that arming has been
initiated. Once the system is armed, the security
light will ash once every three seconds.
If the security light is ashing twice per second,
this means that a door is open.
If you do not want to arm the system, lock the car
with the lock levers on the doors.
103

Disarming the System
To disarm the system, do one of the following:
Press the RKE transmitter unlock button.
Turn the ignition to ON.
Once the system is disarmed, the security light will
stop ashing.
How the System Alarm is Activated
To activate the system if it is armed:
Open the driver’s door or trunk. This will
cause a ten second pre-alarm chirp followed
by a thirty second full alarm of horn and lights.
Open any other door. This will immediately
cause a full alarm of horn and lights for
thirty seconds.
Open the hood. If the vehicle has the remote
start feature, it will activate the full alarm.
When an alarm event has nished, the system will
re-arm itself automatically.
How to Turn Off the System Alarm
To turn off the system alarm:
Press the lock button on the RKE transmitter.
The system will then re-arm itself.
Press the unlock button on the RKE
transmitter. This will also disarm the system.
Insert the key in the ignition and turn it on. This
will also disarm the system.
How to Detect a Tamper Condition
If you hear three chirps when the unlock or lock
button is pressed on the RKE transmitter, it means
that the content theft security system alarm was
previously triggered.
