2007 SAAB 9-7X engine coolant

Keys.............................................................. 87
Remote Keyless Entry (RKE) System.......... 89
Remote Keyless Entry (RKE)
System Operation.................................... 90
Doors and Locks.......................................... 92
Door Locks................................................. 92
Power Door Locks....................................... 93
Delayed Locking.......................................... 94
Programmable Automatic Door Locks.......... 94
Rear Door Security Locks........................... 97
Lockout Protection....................................... 97
Liftgate/Liftglass........................................... 98
Windows....................................................... 99
Power Windows........................................ 100
Sun Visors................................................ 101
Theft-Deterrent Systems............................. 101
Content Theft-Deterrent............................. 102
PASS-Key
®III ........................................... 103
PASS-Key®III Operation........................... 104Starting and Operating Your Vehicle......... 106
New Vehicle Break-In................................ 106
Ignition Positions....................................... 107
Retained Accessory Power (RAP)............. 108
Starting the Engine.................................... 108
Adjustable Throttle and Brake Pedal.......... 110
Engine Coolant Heater.............................. 110
Automatic Transmission Operation............. 112
Parking Brake........................................... 116
Shifting Into Park (P) ................................. 117
Shifting Out of Park (P)............................. 118
Parking Over Things That Burn................. 118
Engine Exhaust......................................... 119
Running the Engine While Parked............. 120
Mirrors......................................................... 121
Automatic Dimming Rearview Mirror
with OnStar
®and Compass................... 121
Automatic Dimming Rearview Mirror
with Compass........................................ 123
Outside Power Mirror................................ 123
Section 2 Features and Controls
85
ProCarManuals.com

Adjustable Throttle and Brake Pedal
If your vehicle has this feature, you can change the
position of the throttle and brake pedals. This
feature is designed for shorter drivers, since the
pedals cannot move farther away from the standard
position, but can move closer for better pedal reach.
If your vehicle has this feature, it can be
programmed to work with the memory function. See
Memory Seat, Mirrors, and Pedals on page 11.
The vehicle must be in PARK (P) for this feature
to operate.
The switch used
to adjust the pedals
is located on the
steering column.
Press the switch forward or backward to move the
pedals closer or farther away from you.
Engine Coolant Heater
Your vehicle may have an engine coolant heater.
In very cold weather, 0°F (−18°C) or colder,
the engine coolant heater can help. You will get
easier starting and better fuel economy during
engine warm-up.
Usually, the coolant heater should be plugged in a
minimum of four hours prior to starting your
vehicle. At temperatures above 32°F (0°C), use of
the coolant heater is not required. Your vehicle
may also have an internal thermostat in the
plug end of the cord. This will prevent operation of
the engine coolant heater when the temperature
is at or above 0°F (−18°C) as noted on the cord.
110
ProCarManuals.com

To Use the Engine Coolant Heater
1. Turn off the engine.
2. Open the hood and unwrap the electrical
cord. The cord is located on the driver’s
side of the engine compartment next to the
battery box facing the engine.
3. Plug it into a normal, grounded 110-Volt AC
outlet.
{CAUTION:
Plugging the cord into an ungrounded
outlet could cause an electrical shock.
Also, the wrong kind of extension cord
could overheat and cause a re. You
could be seriously injured. Plug the cord
into a properly grounded three-prong
110-volt AC outlet. If the cord will not
reach, use a heavy-duty three-prong
extension cord rated for at least 15 amps.4. Before starting the engine, be sure to unplug
and store the cord as it was before to keep it
away from moving engine parts. If you do
not, it could be damaged.
How long should you keep the coolant heater
plugged in? The answer depends on the outside
temperature, the kind of oil you have, and some
other things. Instead of trying to list everything here,
we ask that you contact your dealer in the area
where you will be parking your vehicle. The dealer
can give you the best advice for that particular area.
111
ProCarManuals.com

Instrument Panel Overview........................ 148
Hazard Warning Flashers.......................... 150
Other Warning Devices............................. 150
Horn.......................................................... 150
Tilt Wheel.................................................. 151
Turn Signal/Multifunction Lever.................. 151
Turn and Lane-Change Signals................. 152
Headlamp High/Low-Beam Changer.......... 153
Flash-to-Pass............................................ 153
Windshield Wipers..................................... 154
Windshield Washer.................................... 155
Rear Window Wiper/Washer...................... 155
Headlamp Washer..................................... 156
Cruise Control........................................... 156
Headlamps................................................ 160
Headlamps on Reminder........................... 160
Daytime Running Lamps (DRL)................. 161
Automatic Headlamp System..................... 161
Fog Lamps................................................ 162
Instrument Panel Brightness...................... 163
Dome Lamps............................................. 163
Dome Lamp Override................................ 163
Entry Lighting............................................ 164
Exit Lighting.............................................. 164
Reading Lamps......................................... 164Electric Power Management...................... 164
Battery Run-Down Protection..................... 165
Accessory Power Outlet(s)........................ 166
Climate Controls......................................... 167
Dual Automatic Climate Control System....... 167
Outlet Adjustment...................................... 172
Rear Climate Control System.................... 173
Climate Controls Personalization................ 173
Warning Lights, Gages, and Indicators..... 174
Instrument Panel Cluster........................... 175
Speedometer and Odometer...................... 176
Trip Odometer........................................... 176
Tachometer............................................... 176
Safety Belt Reminder Light........................ 177
Passenger Safety Belt Reminder Light....... 177
Airbag Readiness Light............................. 178
Passenger Airbag Status Indicator............. 179
Charging System Light.............................. 182
Voltmeter Gage......................................... 182
Brake System Warning Light..................... 183
Anti-Lock Brake System Warning Light...... 184
StabiliTrak
®Service Light........................... 185
StabiliTrak®Indicator Light......................... 185
Engine Coolant Temperature Gage............ 186
Section 3 Instrument Panel
145
ProCarManuals.com

Engine Coolant Temperature Gage
This gage shows the engine coolant temperature.
If the gage pointer moves into the red area,
the engine coolant has overheated.
If you have been operating your vehicle under
normal driving conditions, you should pull off the
road, stop your vehicle and turn off the engine
as soon as possible.
SeeEngine Overheating on page 347.
Tire Pressure Light
This light will come on
briey when you turn
the ignition to RUN.
This light will also come on when one or more of
your tires are signicantly underinated.
A CHECK TIRE PRESSURE DIC message will
accompany the light, seeDIC Warnings and
Messages on page 199.
Stop and check your tires as soon as it is safe to do
so. If underinated, inate to the proper pressure.
SeeTires on page 380for more information.
This light will ash for approximately 70 seconds
and then turn on solid if a problem is detected with
the Tire Pressure Monitor system.
SeeTire Pressure Monitor System on page 391
for more information.
United StatesCanada
186
ProCarManuals.com

Highbeam On Light
This light comes on
when the high-beam
headlamps are in use.
SeeHeadlamp High/Low-Beam Changer on
page 153.
Service All-Wheel Drive Light
This light should come
on briey when you turn
on the ignition, as a
check to show you it is
working.The service all-wheel drive light comes on to
indicate that there may be a problem with the drive
system and service is required. Malfunctions
can be indicated by the system before any problem
is apparent, which may prevent serious damage
to the vehicle. This system is also designed
to assist your dealer in correctly diagnosing a
malfunction.
Check Gages Warning Light
The check gages light
will come on briey
when you are starting
the engine.
If the light comes on and stays on while you are
driving, check your coolant temperature and
engine oil pressure gages to see if they are in the
warning zones.
192
ProCarManuals.com

CHECK WASHER FLUID
This message displays if the washer uid level is
low. Adding washer uid to the windshield
washer uid reservoir clears this message. See
Windshield Washer Fluid on page 357. This
message clears itself after 10 seconds, or you can
press any of the DIC buttons, or the trip stem,
to acknowledge this message and clear it from the
DIC display.
CURB VIEW ACTIVATED
This message displays when the passenger
outside rearview mirror moves into the curb view
position. SeeOutside Curb View Assist Mirror
on page 124for more information.
DRIVER DOOR AJAR
This message displays and a chime sounds if the
driver’s door is not fully closed. Stop and turn
off the vehicle, check the door for obstructions, and
close the door again. Check to see if the
message still appears on the DIC. Press any of
the DIC buttons, or the trip stem, to acknowledge
this message and clear it from the DIC display.
ENGINE COOLANT HOT/ENGINE
OVERHEATED
Notice:If you drive your vehicle while the
engine is overheating, severe engine damage
may occur. If an overheat warning appears
on the instrument panel cluster and/or
DIC, stop the vehicle as soon as possible.
Do not increase the engine speed above
normal idling speed. SeeEngine Overheating
on page 347for more information.
This message displays and a chime sounds if the
cooling system temperature gets hot. SeeEngine
Overheating on page 347for the proper course of
action. This message clears when the coolant
temperature drops to a safe operating temperature.
FRONT FOG LAMPS OFF
This message displays if the fog lamps are turned
off. The message clears after 10 seconds. If you
turn on the high-beam headlamps, the fog lamps
also turn off and this message appears on the DIC.
The fog lamps turn back on again when you switch
back to low-beam headlamps. SeeFog Lamps on
page 162andTurn Signal/Multifunction Lever on
page 151for more information.
200
ProCarManuals.com

Turn Signals When Towing a Trailer
The arrows on your instrument panel will
ash whenever you signal a turn or lane change.
Properly hooked up, the trailer lamps will also
ash, telling other drivers you’re about to
turn, change lanes or stop.
When towing a trailer, the arrows on your
instrument panel will ash for turns even if the
bulbs on the trailer are burned out. Thus, you may
think drivers behind you are seeing your signal
when they are not. It’s important to check
occasionally to be sure the trailer bulbs are still
working.
Driving On Grades
Reduce speed and shift to a lower gearbefore
you start down a long or steep downgrade. If you
don’t shift down, you might have to use your
brakes so much that they would get hot and no
longer work well.
You can tow in DRIVE (D). You may want to shift
the transmission to THIRD (3) or a lower gear,
under heavy loads or hilly conditions.
When towing at high altitude on steep uphill
grades, consider the following: Engine coolant will
boil at a lower temperature than at normal
altitudes. If you turn your engine off immediately
after towing at high altitude on steep uphill grades,
your vehicle may show signs similar to engine
overheating. To avoid this, let the engine run while
parked (preferably on level ground) with the
automatic transmission in PARK (P) for a few
minutes before turning the engine off. If you do get
the overheat warning, seeEngine Overheating
on page 347.
315
ProCarManuals.com
