StartingandStoppingEngine
StartingProcedures
Pleaseobservethechapter”IMMOBILIZER”onpage22.
Pleaseobservethechapter”EMISSIONCONTROLSYSTEM”onpage220.
Warning!
Seriouspersonalinjuryordeathmayresultifyouareinvolvedinacollisionwithouthavingfastenedthesafetybelts.
Fastensafetybeltsbeforedrivingaway.
Beforestartingtheengine
Applythefootbrake.
Manualtransmission:Movethegearshiftleverintoneutral.Theclutchpedalmustbedepressedfullybeforethestarterwillengage.
Tiptronic:MovetheselectorlevertoPorN.
Temperaturesensorsontheengineautomaticallyprovidethecorrectfuel/airmixturerequiredforstarting.Therefore,itisnotnecessarytodepresstheacceleratorpedalwhilestartingacoldorawarmengine.
Startingtheengine
Turnignitionkeytoignitionlockposition2.
Assoonastheenginestarts,releasetheignitionkey.
Thefirstoperationofthestarterisendedautomat-icallywhentheenginestarts.Iftheenginedoesnotstart,subsequentstarteroperationswillnotbeendedautomatically.
Iftheenginefailstostartafter10or15secondsofcranking:
Waitabout10secondsbeforeengagingthestarteragain.
Whenstartingtheengine,bereadytodriveimmediately.Drivevehicleatmoderatespeedsandavoidenginespeedsabove4200rpmduringthefirst5minutes.
Donotlettheengineidletowarmup.
Danger!
Engineexhaustfumeshavemanycompo-nentswhichyoucansmell.Theyalsocontaincarbonmonoxide(CO),whichisacolorlessandodorlessgas.Carbonmonoxidecancauseunconsciousnessandevendeathifinhaled.
Neverstartorlettheengineruninanenclosed,unventilatedarea.Itisnotrec-ommendedtositinyourcarforprolongedperiodswiththeengineonandthecarnotmoving.
Danger!
Anunattendedvehiclewitharunningengineispotentiallyhazardous.Ifwarninglightsshouldcomeontoindicateimproperopera-tion,theywouldgounnoticed.
Neverleavetheengineidlingunattended.
Danger!
Dangerofre.
Donotparkoroperatethevehicleinareaswherethehotexhaustsystemmaycomeincontactwithdrygrass,brush,fuelspillorotherflammablematerial.
86Controls,Instruments

InstrumentPanelUSAModels
Overview
AlsorefertothecorrespondingchapterintheOwner’sManual.
1.Speedometerwithanaloguedisplay
2.Tirepressurewarninglight
3.Turnsignalindicatorlightleft
4.Tachometer
5.Highbeamindicatorlight
6.Turnsignalindicatorlightright
7.ABSwarninglight
8.CoolingsystemTemperaturegauge,warninglight
9.FuelLevelgauge,warninglight
10.Adjustingbuttonforinstrumentilluminationandtripcounter
11.Odometeranddailytripmileagedisplay
12.Automaticspeedcontrolindicatorlight
13.Lightsensorforinstrumentillumination
14.Airbagwarninglight
15.Emissioncontrolwarninglight(CheckEngine)
16.Centralwarninglight
17.On-boardcomputerdisplay
18.PorscheStabilityManagement,MultifunctionalPSMlight
19.Brakewarninglight
20.Safetybeltwarninglight
21.Tiptronicindicator
22.Clockandoutsidetemperaturedisplay
23.Adjustmentbuttonforclock
Whentheignitionisswitchedon,thewarninglightslightupforalampcheck.
Note
WarningsthathavebeengivenarestoredintheappropriatecontrolunitmemoryandcanbereadoutatanauthorizedPorschedealer.
Thisinformationcanhelptowarnyouaboutsituationswhichmaybehazardoustoyouoryourcar.
Note
WarningsthathavebeengivenarestoredintheappropriatecontrolunitmemoryandcanbereadoutatanauthorizedPorschedealer.
Thisinformationcanhelptowarnyouaboutsituationswhichmaybehazardoustoyouoryourcar.
88Controls,Instruments

InstrumentPanelCanadaModels
Overview
AlsorefertothecorrespondingchapterintheOwner’sManual.
1.Speedometerwithanaloguedisplay
2.Tirepressurewarninglight
3.Turnsignalindicatorlightleft
4.Tachometer
5.Highbeamindicatorlight
6.Turnsignalindicatorlightright
7.ABSwarninglight
8.CoolingsystemTemperaturegauge,warninglight
9.FuelLevelgauge,warninglight
10.Adjustingbuttonforinstrumentilluminationandtripcounter
11.Odometeranddailytripmileagedisplay
12.Automaticspeedcontrolindicatorlight
13.Lightsensorforinstrumentillumination
14.Airbagwarninglight
15.Emissioncontrolwarninglight(CheckEngine)
16.Centralwarninglight
17.On-boardcomputerdisplay
18.PorscheStabilityManagement,MultifunctionalPSMlight
19.Brakewarninglight
20.Safetybeltwarninglight
21.Tiptronicindicator
22.Clockandoutsidetemperaturedisplay
23.Adjustmentbuttonforclock
Whentheignitionisswitchedon,thewarninglightslightupforalampcheck.
Note
WarningsthathavebeengivenarestoredintheappropriatecontrolunitmemoryandcanbereadoutatanauthorizedPorschedealer.
Thisinformationcanhelptowarnyouaboutsituationswhichmaybehazardoustoyouoryourcar.
Note
WarningsthathavebeengivenarestoredintheappropriatecontrolunitmemoryandcanbereadoutatanauthorizedPorschedealer.
Thisinformationcanhelptowarnyouaboutsituationswhichmaybehazardoustoyouoryourcar.
90Controls,Instruments

InstrumentIllumination
Function
Theilluminationisautomaticallyadjustedtotheambientbrightnessbythelightsensorinthetachometer.
Inaddition,whenthecarlightsareswitchedon,theinstrumentandswitchsymbolbrightnesscanbemanuallyadjusted.
Warning!
Riskoflossofcontroloranaccident,resultinginpersonalinjuryordeath.
Donotreachthroughthesteering-wheelspokeswhiledriving.
Dimminginstrumentillumination
TurnadjustmentbuttonAintheappropriatedirectionandholdituntilthedesiredbright-nesshasbeenreached.Thechosenlevelofbrightnessisindicatedbyabardisplayinthedisplayfieldoftheon-boardcomputer.
Note
Whenthevehiclelightsareswitchedon,thescalelightingforbrightdialsisswitchedonandoffautomaticallydependingontheambientbrightness.
Controls,Instruments93

Whenthetirepressurewarninghasappearedontheon-boardcomputer,stopimmediatelyatasuitablelocation.Checkthetireforsignsofdamage.Ifnecessary,fillintiresealantandsetthecorrecttirepressure.
Thistirepressurewarningappearswhendrivingandcanbeacknowledged.Thetirepressurewarninglightintheinstrumentpanelgoesoutwhenthetirepressurehasbeencorrected.
Systemlearning
TheTirePressureMonitoringbeginsto“learn”thewheelsafterawheelchange,wheeltransmitterreplacementorupdateofthetiresettings.During
thisprocess,theTirePressureMonitoringrecog-nizesthetiresandtheirlocations.Theon-boardcomputerdisplayesthemessage“TPCinactive-systemlearning”.
TheTirePressureMonitoringrequiresacertainamountoftimetolearnthewheels.Duringthistime,thecurrenttirepressuresarenotavailableontheon-board-computer:
–ThedisplayoftheTirepressurefunctionoftheon-boardcomputershowslines.
–Therequiredpressuresforcoldtiresat68°F(20°C)areindicatedintheInfopressuredisplayintheTirepressuremenu.
–Tirepressurewarningsareissuedwithouttirepressureandpositioninformation(gure)assoonasthevehicle’sownwheelshavebeendetectedandthetirepressurewarninglighthasgoneout.
PositionandpressureinformationisdisplayedassoonastheTirePressureMonitoringhasassignedthewheelsidentifiedasbelongingtothevehicletothecorrectwheelpositions.
Thewheellearningprocesstakesplaceexclusivelywhenthevehicleisbeingdriven.
Manuallycheckthetirepressureatallwheelsandcorrectthetirepressuretotherequiredvalue.
Changingawheelandreplacingtires
Newwheelsmustbefittedwithradiotransmit-tersfortheTirePressureMonitoring.Beforetiresarechanged,thebatterychargestateofthewheeltransmittersshouldbecheckedatanauthorizedPorschedealer.
Switchtheignitionoffwhenchangingawheel.
Thetiresettingsontheon-boardcomputermustbeupdatedafterchangingawheel.
Amessageappearsifthecharacteristicsofthenewtiresdonotagreewiththeon-boardcomputersettings.
Updatetheon-boardcomputersettingswhenthevehicleisstationarythenexttime.
Warninglight
Thewarninglightinthespeedometerlightsup:
–Whenalossinpressurehasbeendetected
–IftheTirePressureMonitoringisfaulty
–Whenlearningnewlymountedwheels/wheelsensors,aslongasthevehicle’sownwheelshavenotyetbeenrecognized.
Thetirepressurewarninglightintheinstrumentpanelgoesoutonlywhenthecauseofthefaulthasbeenrectified.
128Controls,Instruments

InstrumentpanelOn-boardcomputerTextdisplayonon-boardcomputerMeaning/measure
ParkinglightonLeft/rightparkinglighton.
Checkleft/rightdippedbeam(lowbeam)alsoappliesto:frontsidelights,directionindicator,highbeam,foglights,sideindicatorlight,brakelight,taillight,rearfoglight,reversinglight,raisedbrakelight,sidemarker
Thereportedlightisfaulty.Checkbulb.HavethefaultremediedatanauthorizedPorschedealer.
DaytimedrivinglightsoffDaytimedrivinglightsswitchoffwhentheengineisshutoff.Switchonlightsifnecessary.
HeadlightbeamadjustmentfaultyHavethefaultremediedatanauthorizedPorschedealer.
FrontlidnotclosedCloseluggagecompartmentlidproperly.
RearlidnotclosedCloseenginecompartmentlidproperly.
RainsensorfaultyHavethefaultremediedatanauthorizedPorschedealer.
Refillwasherfluid
Controls,Instruments139

WindshieldWiper/WasherLever
Generalinformationtothewindshield
wipers
Warning!
Dangerofinjurywhenthewindshieldwipersoperateunintentionally.Riskofdamagetothewindshieldandwipersystem.
Avoidrunningthewiperbladesoveradrywindshieldtopreventscratchingtheglass.Spraywasherfluidonthewindshieldfirst.Ascratchedwindshieldwillreducevisibility.
Alwaysloosenwiperbladesfromfrozenglassbeforeoperatingwiperstopreventdamagetothewipermotororblades.
Alwaysswitchoffwindshieldwipersincarwashtopreventthemwipingunintentionally(intermittentorsensoroperation).
Alwaysswitchoffwindshieldwipersbeforecleaningthewindshieldtoavoidunintentionaloperation(intermittentorsensoroperation).
Donotoperatetheheadlightwasherincarwashes.
Donotoperateheadlightwasherwhenitisfrozen.
Frontwindshieldwipersandheadlight
washersystem
0–Windshieldwipersoff
1–Intermittent/rainsensoroperationforfrontwindshieldwipers
Movewiperleverupwardstothefirstclick.
Pleaseobservethechapter”RAINSENSOR”onpage151.
2–Windshieldwipersslow
Movewiperleverupwardstothesecondclick.
3–Windshieldwipersfast
Movewiperleverupwardstothethirdclick.
4–Frontwindshieldwiper-one-touchopera-tion:
Movewiperleverdownwards.Thewindshieldwiperswipeonce.
5–Windshieldwipersandwashersystem:
Pullwiperlevertowardsthesteeringwheel.Thewashersystemspraysandwipeswhiletheleverispulledtowardsthesteeringwheel.Whenthewiperleverisreleased,afewdryingwipesareexecuted.
A-Headlightwasher(Vehicleswith
Bi-Xenonheadlights):
Thewasherspraysonlywhilelowbeamorhighbeamisswitchedon.
BrieflypushbuttonAtooperateheadlightwashersystem.
Ifheavilysoiled,repeatwash.
Theheadlightwashersystemautomaticallyspraysonceforeverytentimesthefrontwindshieldwashersystemisoperated.
Note
Thewindshieldwashernozzlesareheatedwhentheignitionison,asaprecautionagainstfreezing.
150Controls,Instruments

Wipeintervalcontrol
Function
Onvehicleswithoutarainsensor,thewipingintervalscanbeadjustedinfoursteps.
Decreasingintervals
AdjustswitchAupwards.Thesettingisconfirmedbyonewipeofthewindshield.
Increasingintervals
AdjustswitchAdownwards.
Rainsensor
Invehicleswitharainsensortheamountofrainfall(snowfalltoo)whichhassettledonthewindshieldismeasured.Wiperspeedisautomaticallyadjustedaccordingly.
Switchingon
Movewiperleverupwardstothefirstclick.
Switchingoff
Movewiperlevertoposition0.
Therainsensorremainsswitchedoffifthewiperleverisalreadyinposition1whentheignitionisswitchedon.
Toswitchtherainsensoronagain:
Movewiperlevertoposition0andthentoposition1or
Operatewindshieldwashersystem5or
Changethesensitivityoftherainsensorwithfour-stageswitchA.
Switch-onisconfirmedbyonewipeofthewind-shield.
OnvehicleswiththeSportChronoPlusPackage,furtherrainsensorfunctionscanbeselectedviathePCM.
Pleaseobservethechapter“IndividualMemory”intheseparatePCMoperatinginstructions.
Changingthesensitivityoftherainsensor
SensitivitycanbesetwithswitchAin4stages:
AdjustswitchAupwards-highsensitivity.Thesettingisconfirmedbyonewipeofthewindshield.
AdjustswitchAdownwards-lowsensitivity.
Maintenancenote
Periodicallycleanthewiperbladeswithawin-dowcleaner,especiallyafterthevehiclehasbeenwashedinacarwash.WerecommendPorschewindowcleaner.Iftheyareverydirty(e.g.withinsectremains),theycanbecleanedwithaspongeorcloth.
Ifthewiperbladesruborsqueak,thismaybeasaresultofthefollowing:
Ifthevehicleiswashedinanautomaticcarwash,waxresiduesmaybeadheringtothewindshield.Thesewaxresiduescanberemovedusingawindowcleanerconcentrate.
Pleaseobservethechapter”WASHERFLUID”onpage223.
PleasecontactyourauthorizedPorschedealerforfurtherinformation.
Thewiperbladesmaybedamaged.
Replacedamagedwiperbladesassoonaspossible.
