2007 NISSAN MURANO warning

REMOTE KEYLESS ENTRY SYSTEM
LOCK DOORS Press the LPD0150 button to lock all doors.
UNLOCK DOORS Press the
lpd0151
button once to unlock the driver’s door only. Press the button again within 5 seconds to unlock all doors.
USING THE PANIC ALARM Press and hold the button for longer than 0.5 seconds. The panic alarm will sound and headlights will stay on for 25 seconds. The panic alarm stops when it has run for 25 seconds or when any button is pressed on the keyfob.
HORN BEEP FEATURE The horn beep feature can be deactivated. Refer to the “Display screen, heater, air conditioner and audio systems” section in your Owner’s Manual for the procedure.
INTELLIGENT K EY SYSTEM
The Intelligent Key System allows you to lock or unlock your vehicle and start the engine.
NOTE: It is important to make sure the Intelligent Key is with you (that is, in your pocket or purse).
 The operating range of the door and trunk lock/unlock function is approximately 31 in (0.8 m).
 Locking the vehicle - Push any door handle Request Switch 01 once.
 Unlocking the vehicle - Push any door handle Request Switch 01 once. The corresponding door will unlock. Push the door handle Request Switch 01 again within 1 minute; all other doors will unlock.
STARTING THE ENGINE
 Push the ignition knob in.
 Confirm the Intelligent Key warning light is illuminated green.
 Turn the ignition knob to start the engine.
TURNING THE ENGINE OFF
 Shift transmission into P (Park).
 Turn ignition knob to LOCK position.
 An audible warning chime will sound when exiting the vehicle if the ignition knob is not completely turned to the OFF position.
01
XTRONIC CONTINUOUSL Y VARIABLE
T RANSMISSION
(CVT) ™
 The Xtronic CVT™ does not produce a gear change
sensation like traditional automatic transmissions.
 The transmission in your Murano requires a special fluid available only at your NISSAN dealer. No other fluid will
meet the exact requirements of the new Xtronic CVT™.

CONTROL PANEL DISPLAY WITH
N AVIGATION S YSTEM (if so equipped)
TRIP BUTTON
When the TRIP button is pressed, the following
modes will display on the screen:
 Warning messages (if there are any)
 TRIP 1 (Elapsed Time, Driving Distance,
Average Speed)
 TRIP 2 (Elapsed Time, Driving Distance, Average Speed)
 FUEL ECONOMY (Average Fuel Economy, Distance to Empty)
 MAINTENANCE (Engine Oil, Tire Rotation)
 OFF
MAINTENANCE ITEMS
You can set the engine oil and the tire rotation interval. To display the setting of the
maintenance interval, select the ENGINE O IL or TIRE R OTATION key using the joystick
and press the ENTER button.
To set the maintenance interval, select the MAINTENANCE SCHEDULE key by
using the joystick and pushing the joystick to the right or left. To reset the maintenance
interval, select the RESET key using the joystick and press the ENTER button.
CLOCK/SE T ADJUSTMENT

The clock on the display screen can be adjusted using the joystick and the following
procedure.

 Press the SETTING button, then select SYSTEM SETTINGS from the menu on
the display screen.
 Next select CLOCK to enter the CLOCK SETTINGS mode.
 Then select the HOURS or MINUTES key and hold the joystick left or right to adjust
the time. After the desired time is shown on the display screen, press the BACK
button to store.
Refer to both the Navigation System Owner’s Manual and your Owner’s Manual for
additional information.
MANUAL SHIFT MODE (if so equipped)
 When the shift selector lever is shifted from D (Drive) to the manual shift gate, the
transmission enters the manual shift mode.
 In the manual shift mode, shift range is displayed on the position indicator in the meter.
 When shifting up, move the shift selector lever to the + (up) side. (Shifts to higher range.)
 When shifting down, move the shift selector lever to the - (down) side. (Shifts to lower
range.)
 In manual shift mode, the transmission automatically shifts down to M1 (first) before
the vehicle comes to a stop. When accelerating again, it is necessary to shift up to the
desired range.
 When canceling the manual shift mode, return the shift selector lever to the D (Drive)
position. The transmission returns to the normal driving mode.

SEAT BELT WARNING LIGHT AND CHIME
 The light and chime remind you to fasten your seat belts. The
light illuminates whenever the ignition key is turned to the ON
or START position and remains illuminated until the driver’s seat
belt is fastened. At the same time, the chime sounds for about 6
seconds unless the driver’s seat belt is securely fastened.
 The seat belt warning light may also illuminate if the front passenger’s seat belt is
not fastened when the front passenger’s seat is occupied. For 5 seconds after the
ignition switch is in the ON position, the system does not activate the warning light
for the front passenger.
Refer to the Owner’s Manual for detailed information regarding seat belt usage.
FRONT-PASSENGER AIR BAG STATUS LIGHT
This vehicle is equipped with the Nissan Advanced Air Bag system. Under some conditions, depending on the type of occupant or object detected in the front passenger seat by the occupant classification sensor, the front-passenger air bag is designed to automatically turn OFF. When the front-passenger air bag is OFF, the front-passenger air bag status light will illuminate*. For example:
 When the system detects that the front-passenger’s seat is occupied by a small adult, child or child restraint as outlined in the Owner’s Manual, the will illuminate to indicate that the front-passenger air bag is OFF and will not inflate in a crash.
 When the front-passenger’s seat is occupied and the passenger meets the conditions outlined in the Owner’s Manual, the will not illuminate to indicate that the front-passenger air bag is operational.
*When the system detects that the front-passenger’s seat is unoccupied, the passenger air bag status light will not illuminate even though the front-passenger air bag is OFF.
Refer to the Owner’s Manual for detailed information regarding the Nissan Advanced Air Bag System.
TIRE PRESSURE MONITORING SYSTEM (if so equipped)
This system monitors tire pressure. Please remember, this system does not detect a sudden drop in tire pressure (for example, a blowout while driving). It also does not monitor the air pressure in the spare tire.
Tire pressure is affected by temperature. Low outside temperature causes lower tire pressure. This may cause the low tire pressure warning light to illuminate.
If the low tire pressure warning light comes on, check the tire pressure in all four tires.
Adjust the low tire pressure to the recommended COLD tire pressure shown on the Tire and Loading Information label to turn the low tire pressure warning light off.
If TPMS is not functioning properly, the low tire pressure warning light will flash for approximately 60 seconds when the key is turned on. The light will remain on after the 60 seconds. Have the system checked by a NISSAN dealer.

This easy-to-use Quick Reference Guide is intended to help you more fully appreciate some of the unique features and functions of your new vehicle. However, it is not intended to replace your Owner’s Manual. The Owner’s Manual contains more detailed information to help you better understand the important safety warnings, features, operation, and maintenance of your vehicle.
