Engine Compartment
The engine compartment of the Altima Hybrid houses an aluminum alloy 2.5 liter gasoline engine, the high
voltage harnesses, fuse/fusible link box, fuse block, inverter unit, transaxle and electricair conditioning
compressor.
Engine compartment components and locations
1.Fuse/Fusible link box2.Fuse block3.Inverter unit
4.High voltage harness (orange)5.Transaxle6.Electricair conditioning
compressor
7.Gasoline engineA.HV electrical connector:Vehicle front
- 19-
AlternativeHigh Voltage SystemShut Down Procedure
NOTE:
If the service disconnect procedure cannot be performed, the following alternative shut down procedure is
acceptable.
A.Locate the fuse/fusible link box (1) under the hood near the driver
side strut tower (2).
