WHEEL HUB
RAX-9
C
E
F
G
H
I
J
K
L
MA
B
RAX
Revision: 2006 November2007 350Z
INSPECTION AFTER ASSEMBLY
1. With wheel bearing pressed into axle housing, apply 49,033 N (5,000 kg, 11,000 lb) to wheel hub and
rotate both clockwise and counterclockwise 10 times to minimize resistance.
2. Attach spring balance in the position shown in illustration and
pull at a rate of 10 ± 2 rpm to measure rotating torque.
Rotating torque:
Less than 1.88 N·m (0.19 kg-m, 17 in-lb)
Spring balance reading:
Less than 18.5 N (1.89 kg, 4.16 lb)
SDIA1131E
