SHIFT CONTROL
MT-13
D
E
F
G
H
I
J
K
L
MA
B
MT
Revision: 2006 November2007 350Z
REMOVAL
1. Remove the shift knob with the following procedure.
a. Release metal clips on console boot from center console. Refer
to IP-11, "
Removal and Installation" .
b. Lift console boot, and push down control lever boot B and con-
trol lever boot A. Set water pump pliers and others to control
lever assembly.
CAUTION:
Put waste cloth between water pump pliers and control
lever assembly to avoid damaging control lever assembly.
c. Set monkey wrench to shift knob.
CAUTION:
Put waste cloth between shift knob and monkey wrench to
avoid damaging shift knob.
d. Keeping control lever assembly in place with water pump pliers,
turn monkey wrench counterclockwise to loosen shift knob.
NOTE:
Remove shift knob from control lever assembly keeping water
pump pliers in place because a certain power to turn shift knob
is still necessary even after adhesive is peeled.
e. Remove shift knob from control lever assembly.
2. Remove insulator and seat from control lever assembly.
3. Remove console boot.
4. Remove center console assembly. Refer to IP-11, "
Removal and
Installation" .
5. Remove felt.
PCIB0596E
PCIB0222E
PCIB0246E
PCIB0247E
