INSTRUMENT PANEL ASSEMBLY
IP-11
C
D
E
F
G
H
J
K
L
MA
B
IP
Revision: 2006 November2007 350Z
Removal and InstallationNIS00099
WORK STEP
When removing instrument panel, combination meter, audio and console assembly, take steps in the order
shown by the numbers below.
CAUTION:
Disconnect both battery cables in advance.
Disconnect air bag system line in advance.
Never tamper with or force air bag lid open, as this may adversely affect air bag performance.
Be careful not to scratch pad and other parts.
1. Instrument panel 2. Instrument side finisher (LH) 3. Instrument driver panel upper
4. Combination meter 5. Instrument driver panel lower 6. Steering column cover
7. Steering lock escutcheon 8. Fuse cover 9. Dash side finisher (LH)
10. Unified meter and A/C amp. 11. Foot rest plate 12. Foot rest
13. Center console 14. Console boot (M/T) 15. Cluster lid C lower
16. Console finisher (A/T) 17. Console finisher (A/T ring) 18. Dash side finisher (RH)
19. Instrument side panel (RH) 20. Instrument side panel (LH) 21. Audio unit
22. Instrument passenger panel lower 23. Knee protector (RH) 24. Cluster lid C
25. NAVI switch 26. Instrument center panel 27. Instrument finisher (LH/RH)
28. Pocket mat 29. Instrument passenger panel upper 30. Instrument side finisher (RH)
31. Knee protector (LH)
Pawl Clip Metal clip
PartsReference
pageInstrument
panelCombination
meterAudio Center console
(A) Kicking plate (RH / LH)EI-35
[ 1 ] [ 1 ]
(B) Foot restEI-43
[ 2 ] [ 2 ]
(C) Dash side finisher (RH / LH)EI-35
[ 3 ] [ 3 ]
(D) Instrument driver panel lowerIP-12
[ 4 ] [ 4 ]
(E) Steering column lower coverIP-12
[ 5 ] [ 5 ]
(F) Combination meterIP-12
[ 6 ] [ 6 ]
(G) Spiral cableSRS-42
[ 7 ]
(H) Console finisher (A/T Models)IP-13
[ 8 ] [ 1 ] [ 1 ]
(I) Cluster lid C lower (A/T Models)IP-13
[ 8 ] [ 1 ] [ 1 ]
(J) Console boot (M/T Models)IP-13
[ 8 ] [ 1 ] [ 1 ]
(K)
Center console *
1IP-13[10] [ 2 ]
(L) Instrument passenger panel lowerIP-13
[11]
(M) Instrument side panel (RH / LH)IP-13
[12]
(N) Unified meter and A/C amp.IP-13
[13] [ 2 ]
(O)Instrument center panel (with NAVI
models)IP-14
[14] [ 3 ]
(P) NAVI switch (with NAVI models)IP-14
[15] [ 4 ]
(Q)
Cluster lid C*
2IP-14[16] [ 5 ]
(R) Display unit (with NAVI models)IP-14
[17]
(S) Front pillar garnish (RH / LH)EI-36
[18]
(T) Instrument driver panel upperIP-14
[19]
(U) Instrument passenger panel upperIP-14
[20]
(V) Instrument side finisher (RH)IP-14
[21]
(V) Instrument panel IP-15
[22]
IP-14
INSTRUMENT PANEL ASSEMBLY
Revision: 2006 November2007 350Z
(O) Instrument Center Panel
Insert a screwdriver wrapped with tape into the gap and then remove
instrument center panel.
(P) NAVI Switch (With NAVI Models)
Remove NAVI switch. Refer to AV- 9 9 , "Removal and Installation of NAVI Switch" .
(Q) Cluster Lid C
1. Lift upward while disengaging the pawls, and pull backward to
remove the pocket mat. (Without NAVI)
2. Pull backward to remove the instrument finisher (left/right).
(Without NAVI)
3. Disengage the metal clip with the upper center pawls.
4. Remove the harness connector of the triple meter and audio unit
by pulling backward, and then remove cluster lid C.
CAUTION:
Unit is heavy, so be careful not to pinch your fingers when
working.
5. After remove cluster lid C and then remove triple meter, instru-
ment upper box and audio unit. Refer to IP-17, "
CLUSTER LID
C" .
(R) Display Unit (With NAVI Models)
Remove display unit. Refer to AV- 9 9 , "Removal and Installation of Display Unit" .
(S) Front Pillar Garnish
Pull to inside of vehicle, disconnect metal clips and remove front pillar garnish. Refer to EI-35, "BODY SIDE
TRIM" .
(T) Instrument Driver Panel Upper
1. Remove screws.
2. Disconnect metal clips, then remove instrument driver panel upper.
(U) Instrument Passenger Panel Upper
1. Remove screws.
2. Disconnect metal clips, then remove instrument passenger panel upper.
(V) Instrument Side Finisher (RH)
Using a screwdriver wrapped with tape, pry up and remove instrument side finisher.
Disconnect from metal clip and pull toward you.
PIIB7182E
PIIB7176E
PIIB7177E
