INSTRUMENT PANEL ASSEMBLY
IP-13
C
D
E
F
G
H
J
K
L
MA
B
IP
Revision: 2006 November2007 350Z
(H) Console Finisher (A/T Models)
1. Insert a thin flat-bladed screwdriver wrapped with tape from
behind console finisher, and remove metal clip on back. Then
pull up and back to disengage from front metal clip.
2. Disconnect harness connector, and remove console finisher.
NOTE:
A/C controller is assembled in the console finisher. Therefore, when
installing and removing be careful not to use excessive force, etc.
(I) Cluster lid C lower (A/T Models)
1. Disconnect harness connector.
2. Remove metal clips and pawls, and remove cluster lid C lower.
(J) Console Boot (M/T Models)
1. Remove metal clip.
2. Remove shift knob. Refer to MT-12, "
Removal and Installation" .
3. Disconnect harness connector, and remove console boot.
NOTE:
A/C controller is assembled in the console boot. Therefore, when
installing and removing be careful not to use excessive force, etc.
(K) Center Console
1. Remove coin holder and ashtray.
2. Remove screws.
3. Remove console sub-harness.
4. After removing, disassemble each parts. Refer to IP-16, "
CENTER CONSOLE" .
NOTE:
When removing console, be careful not to pull the harness.
(L) Instrument Passenger Panel Lower
1. Remove screws and bolt.
2. Pull panel horizontally toward you and disengage from metal clip.
(M) Instrument Side Panel (RH/LH)
1. Remove screws.
2. Pull to the side, disconnect metal clips, and remove instrument side panel.
(N) Unified Meter And A/C Amp.
Remove screws, and disconnect harness connector, and remove unified meter and A/C amp. Refer to AT C -
103, "AUTO AMP" .
PIIB7174J
PIIB7175J
PIIB7386J
IP-14
INSTRUMENT PANEL ASSEMBLY
Revision: 2006 November2007 350Z
(O) Instrument Center Panel
Insert a screwdriver wrapped with tape into the gap and then remove
instrument center panel.
(P) NAVI Switch (With NAVI Models)
Remove NAVI switch. Refer to AV- 9 9 , "Removal and Installation of NAVI Switch" .
(Q) Cluster Lid C
1. Lift upward while disengaging the pawls, and pull backward to
remove the pocket mat. (Without NAVI)
2. Pull backward to remove the instrument finisher (left/right).
(Without NAVI)
3. Disengage the metal clip with the upper center pawls.
4. Remove the harness connector of the triple meter and audio unit
by pulling backward, and then remove cluster lid C.
CAUTION:
Unit is heavy, so be careful not to pinch your fingers when
working.
5. After remove cluster lid C and then remove triple meter, instru-
ment upper box and audio unit. Refer to IP-17, "
CLUSTER LID
C" .
(R) Display Unit (With NAVI Models)
Remove display unit. Refer to AV- 9 9 , "Removal and Installation of Display Unit" .
(S) Front Pillar Garnish
Pull to inside of vehicle, disconnect metal clips and remove front pillar garnish. Refer to EI-35, "BODY SIDE
TRIM" .
(T) Instrument Driver Panel Upper
1. Remove screws.
2. Disconnect metal clips, then remove instrument driver panel upper.
(U) Instrument Passenger Panel Upper
1. Remove screws.
2. Disconnect metal clips, then remove instrument passenger panel upper.
(V) Instrument Side Finisher (RH)
Using a screwdriver wrapped with tape, pry up and remove instrument side finisher.
Disconnect from metal clip and pull toward you.
PIIB7182E
PIIB7176E
PIIB7177E
