EC-686
FUEL INJECTOR
Revision: 2006 November2007 350Z
FUEL INJECTORPFP:16600
Component DescriptionNBS000HQ
The fuel injector is a small, precise solenoid valve. When the ECM
supplies a ground to the fuel injector circuit, the coil in the fuel injec-
tor is energized. The energized coil pulls the ball valve back and
allows fuel to flow through the fuel injector into the intake manifold.
The amount of fuel injected depends upon the fuel injection pulse
duration. Pulse duration is the length of time the fuel injector remains
open. The ECM controls the injection pulse duration based on
engine fuel needs.
CONSULT-III Reference Value in Data Monitor ModeNBS000HR
Specification data are reference values.
SEF375Z
MONITOR ITEM CONDITION SPECIFICATION
B/FUEL SCHDL See EC-132, "
TROUBLE DIAGNOSIS - SPECIFICATION VALUE" .
INJ PULSE-B1
INJ PULSE-B2
Engine: After warming up
Shift lever: P or N (A/T), Neutral
(M/T) position
Air conditioner switch: OFF
No loadIdle 2.0 - 3.0 msec
2,000 rpm 1.9 - 2.9 msec
EC-718
SERVICE DATA AND SPECIFICATIONS (SDS)
Revision: 2006 November2007 350Z
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Fuel PressureNBS000IJ
Idle Speed and Ignition TimingNBS000IK
*: Under the following conditions:
Air conditioner switch: OFF
Electric load: OFF (Lights, heater fan & rear window defogger)
Steering wheel: Kept in straight-ahead position
Calculated Load ValueNBS000IL
Mass Air Flow SensorNBS000IM
*: Engine is warmed up to normal operating temperature and running under no load.
Intake Air Temperature SensorNBS000IN
Engine Coolant Temperature SensorNBS000IO
Air Fuel Ratio (A/F) Sensor 1 HeaterNBS000IP
Heated Oxygen sensor 2 HeaterNBS000IQ
Crankshaft Position Sensor (POS)NBS000IR
Refer to EC-393, "Component Inspection" .
Camshaft Position Sensor (PHASE)NBS000IS
Refer to EC-405, "Component Inspection" .
Fuel pressure at idling kPa (kg/cm2 , psi)Approximately 350 (3.57, 51)
Target idle speedA/T No load* (in P or N position)
650 ± 50 rpm
M/T No load* (in Neutral position)
Air conditioner: ONA/T In P or N position 650 rpm or more
M/T In Neutral position 800 rpm or more
Ignition timingA/T In P or N position
15° ± 5° BTDC
M/T In Neutral position
Conditions Calculated load value % (Using CONSULT-III or GST)
At idle5 - 35
At 2,500 rpm5 - 35
Supply voltageBattery voltage (11 - 14V)
Output voltage at idle0.8 - 1.1V*
Mass air flow (Using CONSULT-III or GST)2.0 - 6.0 g·m/sec at idle*
7.0 - 20.0 g·m/sec at 2,500 rpm*
Temperature °C (°F) Resistance kΩ
25 (77)1.800 - 2.200
Temperature °C (°F) Resistance kΩ
20 (68)2.37 - 2.63
50 (122)0.68 - 1.00
90 (194)0.236 - 0.260
Resistance [at 25°C (77°F)] 1.8 - 2.44Ω
Resistance [at 25°C (77°F)] 3.4 - 4.4Ω
