2007 NISSAN 350Z check engine

EC-520
DTC P0850 PNP SWITCH
Revision: 2006 November2007 350Z
DTC P0850 PNP SWITCHPFP:23006
Component DescriptionNBS000GB
When the shift position is P or N (A/T), Neutral (M/T), park/neutral position (PNP) switch is ON.
ECM detects the position because the continuity of the line (the ON signal) exists.
CONSULT-III Reference Value in Data Monitor ModeNBS000GC
Specification data are reference values.
On Board Diagnosis LogicNBS000GD
DTC Confirmation ProcedureNBS000GE
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
WITH CONSULT-III
1. Turn ignition switch ON.
2. Select “P/N POSI SW” in “DATA MONITOR” mode with CONSULT-III. Then check the “P/N POSI SW” sig-
nal under the following conditions.
If NG, go to EC-525, "
Diagnostic Procedure" .
If OK, go to following steps.
3. Select “DATA MONITOR” mode with CONSULT-III.
4. Start engine and warm it up to normal operating temperature.
5. Maintain the following conditions for at least 60 consecutive seconds.
6. Check 1st trip DTC.
7. If 1st trip DTC is detected, go to EC-525, "
Diagnostic Procedure" .
Overall Function CheckNBS000GF
Use this procedure to check the overall function of the park/neutral position (PNP) switch circuit. During this
check, a 1st trip DTC might not be confirmed.
MONITOR ITEM CONDITION SPECIFICATION
P/N POSI SW

Ignition switch: ONShift lever: P or N (A/T), Neutral (M/T)
positionON
Shift lever: Except above position OFF
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0850
0850Park/neutral position
switchThe signal of the park/neutral position (PNP)
switch is not changed in the process of engine
starting and driving.

Harness or connectors
[The park/neutral position (PNP) switch
circuit is open or shorted.]

Park/neutral position (PNP) switch

TCM (A/T models)
Position (Shift lever) Known-good signal
N or P position (A/T)
Neutral position (M/T)ON
Except above position OFF
ENG SPEED 1,400 - 6375 rpm
COOLAN TEMP/S More than 70°C (158°F)
B/FUEL SCHDL 2.0 - 31.8 msec
VHCL SPEED SE More than 64 km/h (40 MPH)
Shift lever Suitable position

DTC P1078 P1084 EVT CONTROL POSITION SENSOR
EC-529
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 November2007 350Z
DTC Confirmation ProcedureNBS000BM
NOTE:
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
WITH CONSULT-III
1. Start engine and let it idle for 10 seconds.
2. Check 1st trip DTC.
3. If 1st trip DTC is detected, go to EC-534, "
Diagnostic Procedure" .
WITH GST
Follow the procedure WITH CONSULT-III above.
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1078
1078
(Bank 1)
Exhaust valve timing con-
trol position sensor circuitAn excessively high or low voltage from the
sensor is sent to ECM.

Harness or connectors
[Exhaust valve timing control position
sensor (bank 1) circuit is open or
shorted)

Exhaust valve timing control position
sensor (bank 1)

Crankshaft position sensor (POS)

Camshaft position sensor (PHASE)
(bank 1)

Accumulation of debris to the signal
pick-up portion of the camshaft
P1084
1084
(Bank 2)

Harness or connectors
[EVT control position sensor (bank 2)
circuit is shorted.]
[CKP sensor (POS) circuit is shorted.]
[CMP sensor (PHASE) (bank 2) circuit
is open or shorted.]
(APP sensor 2 circuit is shorted.)
(EVAP control system pressure sensor
circuit is shorted.)
(Refrigerant pressure sensor circuit is
shorted.)

Exhaust valve timing control position
sensor (bank 2)

Crankshaft position sensor (POS)

Camshaft position sensor (PHASE)
(bank 2)

Accelerator pedal position sensor

EVAP control system pressure sensor

Refrigerant pressure sensor

Accumulation of debris to the signal
pick-up portion of the camshaft

DTC P1211 TCS CONTROL UNIT
EC-541
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 November2007 350Z
DTC P1211 TCS CONTROL UNITPFP:47850
DescriptionNBS000D6
The malfunction information related to TCS is transferred through the CAN communication line from VDC/
TCS/ABS control unit (with VDC models) or “ABS actuator and electric unit (control unit)” (without VDC mod-
els) to ECM.
Be sure to erase the malfunction information such as DTC not only for VDC/TCS/ABS control unit
(with VDC models) or “ABS actuator and electric unit (control unit)” (without VDC models) but also for
ECM after TCS related repair.
On Board Diagnosis LogicNBS000D7

Freeze frame data is not stored in the ECM for this self-diagnosis.

The MIL will not light up for this self-diagnosis.
DTC Confirmation ProcedureNBS000D8
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 10.5V at idle.
WITH CONSULT-III
1. Start engine and let it idle for at least 60 seconds.
2. Check 1st trip DTC.
3. If 1st trip DTC is detected, go to EC-541, "
Diagnostic Procedure" .
WITH GST
Follow the procedure “WITH CONSULT-III” above.
Diagnostic ProcedureNBS000D9
Go to BRC-82, "TROUBLE DIAGNOSIS" (With VDC models) or BRC-42, "TROUBLE DIAGNOSIS" (Without
VDC models).
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1211
1211TCS control unitECM receives a malfunction information from
VDC/TCS/ABS control unit (with VDC models)
or “ABS actuator and electric unit (control unit)”
(without VDC models).

VDC/TCS/ABS control unit
(with VDC models)

ABS actuator and electric unit (control
unit) (without VDC models)

TCS related parts

EC-542
DTC P1212 TCS COMMUNICATION LINE
Revision: 2006 November2007 350Z
DTC P1212 TCS COMMUNICATION LINEPFP:47850
DescriptionNBS000DA
NOTE:

If DTC P1212 is displayed with DTC U1000 or U1001, first perform the trouble diagnosis for DTC
U1000, U1001. Refer to EC-151, "
DTC U1000, U1001 CAN COMMUNICATION LINE" .

If DTC P1212 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010.
Refer to EC-154, "
DTC U1010 CAN COMMUNICATION" .
This CAN communication line is used to control the smooth engine operation during the TCS operation. Pulse
signals are exchanged between ECM and VDC/TCS/ABS control unit (with VDC models) or “ABS actuator
and electric unit (control unit)” (without VDC models).
Be sure to erase the malfunction information such as DTC not only for VDC/TCS/ABS control unit
(with VDC models) or “ABS actuator and electric unit (control unit)” (without VDC models) but also for
ECM after TCS related repair.
On Board Diagnosis LogicNBS000DB

Freeze frame data is not stored in the ECM for this self-diagnosis.

The MIL will not light up for this self-diagnosis.
DTC Confirmation ProcedureNBS000DC
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 10.5V at idle.
WITH CONSULT-III
1. Start engine and let it idle for at least 10 seconds.
2. Check 1st trip DTC.
3. If 1st trip DTC is detected, go to EC-542, "
Diagnostic Procedure" .
WITH GST
Follow the procedure “WITH CONSULT-III” above.
Diagnostic ProcedureNBS000DD
Go to BRC-82, "TROUBLE DIAGNOSIS" (With VDC models) or BRC-42, "TROUBLE DIAGNOSIS" (Without
VDC models).
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P1212
1212TCS communication
lineECM can not receive the information
from VDC/TCS/ABS control unit (with
VDC models) or “ABS actuator and elec-
tric unit (control unit)” (without VDC mod-
els) continuously.

Harness or connectors
(The CAN communication line is open or
shorted.)

VDC/TCS/ABS control unit (with VDC models)

ABS actuator and electric unit (control unit)
(without VDC models)

Dead (Weak) battery

DTC P1217 ENGINE OVER TEMPERATURE
EC-545
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 November2007 350Z
CAUTION:
When a malfunction is indicated, be sure to replace the coolant. Refer to CO-10, "
Changing Engine
Coolant" . Also, replace the engine oil. Refer to LU-7, "Changing Engine Oil" .
1. Fill radiator with coolant up to specified level with a filling speed of 2 liters per minute. Be sure to
use coolant with the proper mixture ratio. Refer to MA-12, "
ANTI-FREEZE COOLANT MIXTURE
RATIO" .
2. After refilling coolant, run engine to ensure that no water-flow noise is emitted.
Overall Function CheckNBS000DH
Use this procedure to check the overall function of the cooling fan. During this check, a DTC might not be con-
firmed.
WARNING:
Never remove the radiator cap when the engine is hot. Serious burns could be caused by high pres-
sure fluid escaping from the radiator.
Wrap a thick cloth around cap. Carefully remove the cap by turning it a quarter turn to allow built-up
pressure to escape. Then turn the cap all the way off.
WITH CONSULT-III
1. Check the coolant level in the reservoir tank and radiator.
NOTE:
Allow engine to cool before checking coolant level.
If the coolant level in the reservoir tank and/or radiator is below
the proper range, skip the following steps and go to EC-549,
"Diagnostic Procedure" .
2. Confirm whether customer filled the coolant or not. If customer
filled the coolant, skip the following steps and go to EC-549,
"Diagnostic Procedure" .
3. Turn ignition switch ON.
4. Perform “COOLING FAN” in “ACTIVE TEST” mode with CON-
SULT-III.
5. If the results are NG, go to EC-549, "
Diagnostic Procedure" .
WITH GST
1. Check the coolant level in the reservoir tank and radiator.
NOTE:
Allow engine to cool before checking coolant level.
If the coolant level in the reservoir tank and/or radiator is below
the proper range, skip the following steps and go to EC-549,
"Diagnostic Procedure" .
2. Confirm whether customer filled the coolant or not. If customer
filled the coolant, skip the following steps and go to EC-549,
"Diagnostic Procedure" .
3. Start engine.
CAUTION:
Be careful not to overheat engine.
4. Turn air conditioner switch ON.
5. Turn blower fan switch ON.
SEF621W
SEF621W

DTC P1217 ENGINE OVER TEMPERATURE
EC-549
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 November2007 350Z
Diagnostic ProcedureNBS000DJ
1. INSPECTION START
Do you have CONSULT-III?
Ye s o r N o
Ye s > > G O T O 2 .
No >> GO TO 4.
2. CHECK COOLING FAN LOW SPEED OPERATION
With CONSULT-III
1. Start engine and let it idle.
2. Select “COOLING FAN” in “ACTIVE TEST” mode with CONSULT-III and touch “LOW” on the CONSULT-
III screen.
3. Make sure that cooling fans-1 and -2 operate at low speed.
OK or NG
OK >> GO TO 3.
NG >> Check cooling fan low speed control circuit. (Go to EC-551, "
PROCEDURE A" .)
3. CHECK COOLING FAN HIGH SPEED OPERATION
With CONSULT-III
1. Touch “HIGH” on the CONSULT-III screen.
2. Make sure that cooling fans-1 and -2 operate at higher speed than low speed.
OK or NG
OK >> GO TO 6.
NG >> Check cooling fan high speed control circuit. (Go to EC-554, "
PROCEDURE B" .)
4. CHECK COOLING FAN LOW SPEED OPERATION
Without CONSULT-III
1. Start engine and let it idle.
2. Turn air conditioner switch ON.
3. Turn blower fan switch ON.
4. Make sure that cooling fans-1 and -2 operate at low speed.
OK or NG
OK >> GO TO 5.
NG >> Check cooling fan low speed control circuit. (Go to EC-
551, "PROCEDURE A" .)
SEC163BA

EC-550
DTC P1217 ENGINE OVER TEMPERATURE
Revision: 2006 November2007 350Z
5. CHECK COOLING FAN HIGH SPEED OPERATION
Without CONSULT-III
1. Turn ignition switch OFF.
2. Turn air conditioner switch and blower fan switch OFF.
3. Disconnect engine coolant temperature sensor harness connector.
4. Connect 150Ω resistor to engine coolant temperature sensor harness connector.
5. Restart engine and make sure that cooling fans-1 and -2 oper-
ate at higher speed than low speed.
OK or NG
OK >> GO TO 6.
NG >> Check cooling fan high speed control circuit. (Go to EC-
554, "PROCEDURE B" .)
6. CHECK COOLING SYSTEM FOR LEAK
Refer to CO-10, "
LEAK CHECK" .
OK or NG
OK >> GO TO 7.
NG >> Check the following for leak.

Hose

Radiator

Water pump
7. CHECK RADIATOR CAP
Refer to CO-15, "
Checking Radiator Cap" .
OK or NG
OK >> GO TO 8.
NG >> Replace radiator cap.
8. CHECK THERMOSTAT
Refer to CO-26, "
WATER INLET AND THERMOSTAT ASSEMBLY" .
OK or NG
OK >> GO TO 9.
NG >> Replace thermostat
9. CHECK ENGINE COOLANT TEMPERATURE SENSOR
Refer to EC-228, "
Component Inspection" .
OK or NG
OK >> GO TO 10.
NG >> Replace engine coolant temperature sensor.
10. CHECK MAIN 12 CAUSES
If the cause cannot be isolated, go to EC-555, "
Main 12 Causes of Overheating" .
>>INSPECTION END
MEC475B

DTC P1217 ENGINE OVER TEMPERATURE
EC-551
C
D
E
F
G
H
I
J
K
L
MA
EC
Revision: 2006 November2007 350Z
PROCEDURE A
1. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R harness connector E6.
3. Check voltage between IPDM E/R terminals 15, 16 and ground
with CONSULT-III or tester.
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2. DETECT MALFUNCTIONING PART
Check the following.

40A fusible links

Harness for open or short between IPDM E/R and battery
>> Repair open circuit or short to ground or short to power in harness or connectors. Voltage: Battery voltage
PBIB1924E
