2007 NISSAN 350Z c1123

BRC-20
[ABS]
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
DISPLAY ITEM LIST
Display item Malfunction detecting condition Check item
RR RH SENSOR-1
[C1101]When the circuit in the rear RH wheel sensor is open.
BRC-25, "
Wheel
Sensor System"
(Note 1) RR LH SENSOR-1
[C1102]When the circuit in the rear LH wheel sensor is open.
FR RH SENSOR-1
[C1103]When the circuit in the front RH wheel sensor is open.
FR LH SENSOR-1
[C1104]When the circuit in the front LH wheel sensor is open.
RR RH SENSOR-2
[C1105]When the circuit in the rear RH wheel sensor is short-circuited. Or when the
sensor power voltage is outside the standard. When the distance between the
wheel sensor and sensor rotor is too large and the sensor pulse cannot be
recognized by the control unit.
RR LH SENSOR-2
[C1106]When the circuit in the rear LH wheel sensor is short-circuited. Or when the
sensor power voltage is outside the standard. When the distance between the
wheel sensor and sensor rotor is too large and the sensor pulse cannot be
recognized by the control unit.
FR RH SENSOR-2
[C1107]When the circuit in the front RH wheel sensor is short-circuited. Or when the
sensor power voltage is outside the standard. When the distance between the
wheel sensor and sensor rotor is too large and the sensor pulse cannot be
recognized by the control unit.
FR LH SENSOR-2
[C1108]When the circuit in the front LH wheel sensor is short-circuited. Or when the
sensor power voltage is outside the standard. When the distance between the
wheel sensor and sensor rotor is too large and the sensor pulse cannot be
recognized by the control unit.
BATTERY VOLTAGE
[ABNORMAL]
[C1109]When the ABS actuator and electric unit (control unit) power supply voltage is
lower than normal.BRC-27, "
ABS Actua-
tor and Electric Unit
(Control Unit) Power
and Ground Sys-
tems"
CONTROLLER FAILURE
[ C 111 0 ]When there is an internal malfunction in the ABS actuator and electric unit
(control unit).BRC-27, "ABS Actua-
tor and Electric Unit
(Control Unit)"
MAIN RELAY
[ C 111 4 ]When the control unit detects an error in the actuator relay system.BRC-29, "
ABS Actua-
tor Relay or ABS
Motor Relay Power
System"
STOP LAMP SW
[ C 111 6 ]When a stop lamp switch open-circuit is detected.BRC-30, "Stop Lamp
Switch System"
FR LH IN ABS SOL
[C1120]When the control unit detects an error in the front left inlet solenoid system.
BRC-29, "
ABS Actua-
tor Relay or ABS
Motor Relay Power
System"
FR LH OUT ABS SOL
[C1121]When the control unit detects an error in the front left outlet solenoid system.
FR RH IN ABS SOL
[C1122]When the control unit detects an error in the front right inlet solenoid system.
FR RH OUT ABS SOL
[C1123]When the control unit detects an error in the front right outlet solenoid system.
RR LH IN ABS SOL
[C1124]When the control unit detects an error in the rear left inlet solenoid system.
RR LH OUT ABS SOL
[C1125]When the control unit detects an error in the rear left outlet solenoid system.
RR RH IN ABS SOL
[C1126]When the control unit detects an error in the rear right inlet solenoid system.
RR RH OUT ABS SOL
[C1127]When the control unit detects an error in the rear right outlet solenoid system.

BRC-54
[TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
Note 1: After completing repairs of the shorted sensor circuit, when ignition switch is turned ON, ABS warning lamp turns on. Check that
ABS warning lamp turns off while driving the vehicle at approximately 30 km/h (19 MPH) or more for approximately 1 minute according
to self-diagnosis procedure. In addition, if wheel sensor 2 is displayed for the wheels, check the wheel sensor circuit and also check the
control unit power voltage.
Note 2: When errors are detected in several systems, including the CAN communication system [U1000], troubleshoot the CAN commu-
nication system.STOP LAMP SW
[ C 111 6 ]When a stop lamp switch open-circuit is detected.BRC-66, "
Stop Lamp
Switch System"
FR LH IN ABS SOL
[C1120]When the control unit detects an error in the front left inlet solenoid system.
BRC-65, "
ABS Actuator
Relay or ABS Motor
Relay Power System"
FR LH OUT ABS SOL
[C1121]When the control unit detects an error in the front left outlet solenoid system.
FR RH IN ABS SOL
[C1122]When the control unit detects an error in the front right inlet solenoid system.
FR RH OUT ABS SOL
[C1123]When the control unit detects an error in the front right outlet solenoid system.
RR LH IN ABS SOL
[C1124]When the control unit detects an error in the rear left inlet solenoid system.
RR LH OUT ABS SOL
[C1125]When the control unit detects an error in the rear left outlet solenoid system.
RR RH IN ABS SOL
[C1126]When the control unit detects an error in the rear right inlet solenoid system.
RR RH OUT ABS SOL
[C1127]When the control unit detects an error in the rear right outlet solenoid system.
EMERGENCY BRAKE
[C1153]When the ABS actuator and electric unit (control unit) malfunctions (pressure
increase is too much or too little).BRC-67, "
ABS Actuator
and Electric Unit (Con-
trol Unit) 2"
ENGINE SIGNAL 1
[C1130]
Major engine components are malfunctioning.BRC-63, "
Engine Sys-
tem"
ENGINE SIGNAL 2
[C1131]
ENGINE SIGNAL 3
[C1132]
ENGINE SIGNAL 4
[C1133]
ENGINE SIGNAL 5
[C1134]
ENGINE SIGNAL 6
[C1136]
CAN COMM CIRCUIT
[U1000]When ABS actuator and electric unit (control unit) is not transmitting or receiv-
ing CAN communication signal for 2 seconds or more.BRC-67, "
CAN Commu-
nication System"
(Note 2) Display item Malfunction detecting condition Check item

TROUBLE DIAGNOSIS
BRC-97
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 November2007 350Z
DISPLAY ITEM LIST
Display item Malfunction detecting condition Check item
RR RH SENSOR -1
[C1101]When the circuit in the rear RH wheel sensor is open.
BRC-105, "
Wheel Sen-
sor System"
(Note 1) RR LH SENSOR - 1
[C1102]When the circuit in the rear LH wheel sensor is open.
FR RH SENSOR - 1
[C1103]When the circuit in the front RH wheel sensor is open.
FR LH SENSOR - 1
[C1104]When the circuit in the front LH wheel sensor is open.
RR RH SENSOR -2
[C1105]When the circuit in the rear RH wheel sensor is short-circuited. Or
when the sensor power voltage is outside the standard. When the
distance between the wheel sensor and sensor rotor is too large
and the sensor pulse cannot be recognized by the control unit.
RR LH SENSOR - 2
[C1106]When the circuit in the rear LH wheel sensor is short-circuited. Or
when the sensor power voltage is outside the standard. When the
distance between the wheel sensor and sensor rotor is too large
and the sensor pulse cannot be recognized by the control unit.
FR RH SENSOR -2
[C1107]When the circuit in the front RH wheel sensor is short-circuited. Or
when the sensor power voltage is outside the standard. When the
distance between the wheel sensor and sensor rotor is too large
and the sensor pulse cannot be recognized by the control unit.
FR LH SENSOR - 2
[C1108]When the circuit in the front LH wheel sensor is short-circuited. Or
when the sensor power voltage is outside the standard. When the
distance between the wheel sensor and sensor rotor is too large
and the sensor pulse cannot be recognized by the control unit.
BATTERY VOLTAGE
[ABNORMAL]
[C1109]When the VDC/TCS/ABS power voltage is lower than normal. BRC-120, "
VDC/TCS/
ABS Control Unit Power
and Ground Systems"
CONTROLLER FAILURE
[C1110]When there is an internal error in the VDC/TCS/ABS control unit.BRC-107, "VDC/TCS/
ABS Control Unit 1"
PUMP MOTOR
[ C 1111 ]When the control unit detects an error in the motor or motor relay.BRC-116, "ABS Motor
and Motor Relay System"
MAIN RELAY
[C1114]When the control unit detects an error in the actuator relay system.BRC-118, "Actuator
Relay System"
ABS SENSOR
[ABNORMAL SIGNAL]
[C1115]When wheel sensor input is malfunction.BRC-105, "Wheel Sen-
sor System"
(Note 1)
STOP LAMP SW
[C1116]When a stop lamp switch open-circuit is detected.BRC-119, "
Stop Lamp
Switch System"
FR LH IN ABS SOL
[C1120]When the VDC/TCS/ABS control unit detects an error in the front
left inlet solenoid system.
BRC-113, "
Solenoid and
VDC Change-Over Valve
System"
FR LH OUT ABS SOL
[C1121]When the VDC/TCS/ABS control unit detects an error in the front
left outlet solenoid system.
FR RH IN ABS SOL
[C1122]When the VDC/TCS/ABS control unit detects an error in the front
right inlet solenoid system.
FR RH OUT ABS SOL
[C1123]When the VDC/TCS/ABS control unit detects an error in the front
right outlet solenoid system.
RR LH IN ABS SOL
[C1124]When the VDC/TCS/ABS control unit detects an error in the rear
left inlet solenoid system.
RR LH OUT ABS SOL
[C1125]When the VDC/TCS/ABS control unit detects an error in the rear
left outlet solenoid system.
RR RH IN ABS SOL
[C1126]When the VDC/TCS/ABS control unit detects an error in the rear
left inlet solenoid system.
RR RH OUT ABS SOL
[C1127]When the VDC/TCS/ABS control unit detects an error in the rear
right outlet solenoid system.
