AT-56
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
5. CHECK SHIFT-UP D4 → D5
Press down the accelerator pedal about half-way and inspect if the vehicle shifts up (D4 → D5 ) at the appro-
priate speed. Refer to AT- 5 8 , "
Vehicle Speed at When Gears Shifting Occurs" .
With CONSULT-III
Read the gear position, throttle position, and vehicle speed. Refer to AT- 8 8 , "
DATA MONITOR MODE" .
Does the A/T shift-up D
4 → D5 at the correct speed?
YES >> GO TO 6.
NO >> Enter a check mark at AT- 1 8 9 , "
A/T Does Not Shift: D4 → D5" on the AT- 4 4 , "DIAGNOSTIC
WORKSHEET" , then continue the road test.
6. CHECK LOCK-UP
When releasing accelerator pedal (closed throttle position signal: OFF) from D
5 , check lock-up from D5 to L/
U. Refer to AT- 5 8 , "
Vehicle Speed at When Gears Shifting Occurs" .
With CONSULT-III
Select “TCC SOLENOID” with the “MAIN SIGNALS” mode for “A/T”. Refer to AT- 8 4 , "
CONSULT-III REFER-
ENCE VALUE" .
Does it lock-up?
YES >> GO TO 7.
NO >> Enter a check mark at AT- 1 9 1 , "
A/T Does Not Lock-up" on the AT- 4 4 , "DIAGNOSTIC WORK-
SHEET" , then continue the road test.
7. CHECK LOCK-UP HOLD
Check hold lock-up.
With CONSULT-III
Select “TCC SOLENOID” with the “MAIN SIGNALS” mode for “A/T”. Refer to AT- 8 4 , "
CONSULT-III REFER-
ENCE VALUE" .
Does it maintain lock-up status?
YES >> GO TO 8.
NO >> Enter a check mark at AT- 1 9 3 , "
A/T Does Not Hold Lock-up Condition" on the AT- 4 4 , "DIAGNOS-
TIC WORKSHEET" , then continue the road test.
8. CHECK LOCK-UP RELEASE
Check lock-up cancellation by depressing brake pedal lightly to decelerate.
With CONSULT-III
Select “TCC SOLENOID” with the “MAIN SIGNALS” mode for “A/T”. Refer to AT- 8 4 , "
CONSULT-III REFER-
ENCE VALUE" .
Does lock-up cancel?
YES >> GO TO 9.
NO >> Enter a check mark at AT- 1 9 4 , "
Lock-up Is Not Released" on the AT- 4 4 , "DIAGNOSTIC WORK-
SHEET" , then continue the road test.
9. CHECK SHIFT-DOWN D5 → D4
Decelerate by pressing lightly on the brake pedal.
With CONSULT-III
Read the gear position and engine speed. AT- 8 8 , "
DATA MONITOR MODE" .
When the A/T shift
-down D5 → D4 , does the engine speed drop smoothly back to idle?
YES >> 1. Stop the vehicle.
2. Go to AT- 5 7 , "
Cruise Test — Part 2" .
NO >> Enter a check mark at AT- 1 9 5 , "
Engine Speed Does Not Return to Idle" on the AT- 4 4 , "DIAG-
NOSTIC WORKSHEET" , then continue the road test. Go to AT- 5 7 , "Cruise Test — Part 2" .

TROUBLE DIAGNOSIS
AT-57
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
Cruise Test — Part 2NCS00028
1. CHECK STARTING FROM D1
1. Move selector lever into “D” position.
2. Accelerate at half throttle.
With CONSULT-III
Read the gear position. Refer to AT- 8 8 , "
DATA MONITOR MODE" .
Does it start from D1?
YES >> GO TO 2.
NO >> Enter a check mark at AT- 1 8 1 , "
Vehicle Cannot Be Started from D1" on the AT- 4 4 , "DIAGNOSTIC
WORKSHEET" , then continue the road test.
2. CHECK SHIFT-UP D1 → D2
Press the accelerator pedal down all the way and inspect whether or not the A/T shifts up (D1 → D2 ) at the
correct speed. Refer to AT- 5 8 , "
Vehicle Speed at When Gears Shifting Occurs" .
With CONSULT-III
Read the gear position, throttle position and vehicle speed. Refer to AT- 8 8 , "
DATA MONITOR MODE" .
Does the A/T shift-up D
1 → D2 at the correct speed?
YES >> GO TO 3.
NO >> Enter a check mark at AT- 1 8 3 , "
A/T Does Not Shift: D1 → D2" on the AT- 4 4 , "DIAGNOSTIC
WORKSHEET" , then continue the road test.
3. CHECK SHIFT UP D2 → D3
Press the accelerator pedal down all the way and inspect whether or not the A/T shifts up (D2 → D3 ) at the
correct speed. Refer to AT- 5 8 , "
Vehicle Speed at When Gears Shifting Occurs" .
With CONSULT-III
Read the gear position, throttle position and vehicle speed. Refer to AT- 8 8 , "
DATA MONITOR MODE" .
Does the A/T shift-up D
2 → D3 at the correct speed?
YES >> GO TO 4.
NO >> Enter a check mark at AT- 1 8 5 , "
A/T Does Not Shift: D2 → D3" on the AT- 4 4 , "DIAGNOSTIC
WORKSHEET" , then continue the road test.
4. CHECK SHIFT-UP D3 → D4 AND ENGINE BRAKE
When the A/T changes speed D
3 → D4 , return the accelerator pedal.
With CONSULT-III
Read the gear position. Refer to AT- 8 8 , "
DATA MONITOR MODE" .
Does the A/T shift
-up D3 → D4 and apply the engine brake?
YES >> 1. Stop the vehicle.
2. Go to AT- 5 8 , "
Cruise Test — Part 3" .
NO >> Enter a check mark at AT- 1 8 7 , "
A/T Does Not Shift: D3 → D4" on the AT- 4 4 , "DIAGNOSTIC
WORKSHEET" , then continue the road test. Go to AT- 5 8 , "Cruise Test — Part 3" .

AT-58
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
Cruise Test — Part 3NCS00029
1. MANUAL MODE FUNCTION
Move to manual mode from “D” position.
Does it switch to manual mode?
YES >> GO TO 2.
NO >> Continue road test and add check mark to AT- 1 9 6 , "
Cannot Be Changed to Manual Mode" on the
AT- 4 4 , "
DIAGNOSTIC WORKSHEET" .
2. CHECK SHIFT-DOWN
During manual mode driving, is downshift from M
5 → M4 → M3 → M2 → M1 performed?
With CONSULT-III
Read the gear position. Refer to AT- 8 8 , "
DATA MONITOR MODE" .
Is downshifting correctly performed?
YES >> GO TO 2.
NO >> Enter a check mark at “A/T Does Not Shift” at the corresponding position (5th → 4th, 4th → 3rd,
3rd → 2nd, 2nd → 1st) on the AT- 4 4 , "
DIAGNOSTIC WORKSHEET" , then continue the road test.
3. CHECK ENGINE BRAKE
Check engine brake.
Does engine braking effectively reduce speed in M
1 position?
YES >> 1. Stop the vehicle.
2. Perform self-diagnostics. Refer to AT- 8 6 , "
SELF-DIAGNOSTIC RESULT MODE" , AT- 9 2 ,
"Diagnostic Procedure Without CONSULT-III" .
NO >> Enter a check mark at AT- 2 0 2 , "
Vehicle Does Not Decelerate by Engine Brake" on the AT- 4 4 ,
"DIAGNOSTIC WORKSHEET" , then continue trouble diagnosis.
Vehicle Speed at When Gears Shifting OccursNCS0002A

At half throttle, the accelerator opening is 4/8 of the full opening.
Vehicle Speed at Which Lock-up Occurs/ReleasesNCS0002B

At closed throttle, the accelerator opening is less than 1/8 condition. (Closed throttle position signal: OFF)

At half throttle, the accelerator opening is 4/8 of the full opening.
Throttle positionVehicle speed km/h (MPH)
D1 →D2D2 →D3D3 →D4D4 →D5D5 →D4D4 →D3D3 →D2D2 →D1
Full throttle 50 – 54
(31 – 34)97 – 105
(60 – 65)154 – 164
(96 – 102)224 – 234
(139 – 145)220 – 230
(137 – 143)145 – 155
(90 – 96)86 – 94
(53 – 58)39 – 43
(24 – 27)
Half throttle 29 – 33
(18 – 21)63 – 69
(39 – 43)100 – 108
(62 – 67)136 – 144
(85 – 89)88 – 96
(55 – 60)64 – 72
(40 – 45)28 – 34
(17 – 21)9 – 13
(6 – 8)
Throttle positionVehicle speed km/h (MPH)
Lock-up ON Lock-up OFF
Closed throttle 62 – 70 (39 – 44) 59 – 67 (37 – 42)
Half throttle 136 – 144 (85 – 89) 88 – 96 (55 – 60)

TROUBLE DIAGNOSIS
AT-59
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
Symptom ChartNCS0002C

The diagnostics item numbers show the sequence for inspection. Inspect in order from item 1.

Overhaul and inspect inside the A/T only if A/T fluid condition is NG. Refer to AT- 4 9 , "A/T Fluid Con-
dition Check".
No. Items Symptom Condition Diagnostic ItemReference
page
1
Shift
ShockLarge shock. (“N” → “
D” position)
Refer to AT-175,
"Large Shock (“N” to
“D” Position)" .ON vehicle1. Engine idle speedEC-76
2. Engine speed signalAT- 11 3
3. Accelerator pedal position sensorAT-131
4. A/T positionAT-206
5. A/T fluid temperature sensorAT-134
6. Front brake solenoid valveAT-147
7. CAN communication lineAT- 9 4
8. A/T fluid level and stateAT- 4 9
9. Line pressure testAT- 5 0
10. Control valve with TCMAT-215
OFF vehicle11. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT-255
2Shock is too large
when changing D1 →
D
2 or M1 → M2 .ON vehicle1. Accelerator pedal position sensorAT-131
2. A/T positionAT-206
3. Direct clutch solenoid valveAT-149
4. CAN communication lineAT- 9 4
5. Engine speed signalAT- 11 3
6. Turbine revolution sensorAT-106
7. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-108,
AT-139
8. A/T fluid level and stateAT- 4 9
9. Control valve with TCMAT-215
OFF vehicle 10. Direct clutchAT-288
3Shock is too large
when changing D2 →
D
3 or M2 → M3 .ON vehicle1. Accelerator pedal position sensorAT-131
2. A/T positionAT-206
3. High and low reverse clutch solenoid valveAT-151
4. CAN communication lineAT- 9 4
5. Engine speed signalAT- 11 3
6. Turbine revolution sensorAT-106
7. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-108,
AT-139
8. A/T fluid level and stateAT- 4 9
9. Control valve with TCMAT-215
OFF vehicle 10. High and low reverse clutchAT-286

AT-84
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
CONSULT-III Function (TRANSMISSION)NCS0002E
CONSULT-III can display each diagnostic item using the diagnostic test mode shown following.
FUNCTION
CONSULT-III REFERENCE VALUE
NOTICE:
1. The CONSULT-III electrically displays shift timing and lock-up timing (that is, operation timing of each
solenoid).
Check for time difference between actual shift timing and the CONSULT-III display. If the difference is
noticeable, mechanical parts (except solenoids, sensors, etc.) may be malfunctioning. Check mechanical
parts using applicable diagnostic procedures.
2. Shift schedule (which implies gear position) displayed on CONSULT-III and that indicated in Service Man-
ual may differ slightly. This occurs because of the following reasons:
–Actual shift schedule has more or less tolerance or allowance,
–Shift schedule indicated in Service Manual refers to the point where shifts start, and
–Gear position displayed on CONSULT-III indicates the point where shifts are completed.
3. Display of solenoid valves on CONSULT-III changes at the start of shifting, while gear position is dis-
played upon completion of shifting (which is computed by TCM).
Diagnostic test mode Function
Work supportThis mode enables a technician to adjust some devices faster and more accurately by following the
indications on CONSULT-III.
Self-diagnostic results Self-diagnostic results can be read and erased quickly.
Data monitor Input/Output data in the ECU can be read.
CAN diagnostic support monitor The results of transmit/receive diagnosis of CAN communication can be read.
Function testPerformed by CONSULT-III instead of a technician to determine whether each system is “OK” or
“NG”.
DTC work support Select the operating condition to confirm Diagnosis Trouble Codes.
ECU part number TCM part number can be read.
Item name Condition Display value (Approx.)
ATF TEMP SE 1
0°C (32° F) – 20°C (68°F) – 80°C (176°F)3.3 – 2.7 – 0.9 V
ATF TEMP SE 23.3 – 2.5 – 0.7 V
ATF TEMP 1 Ignition switch ONMeasured ATF temperature is dis-
played.
TCC SOLENOID Lock-up is active 0.4 – 0.6 A
SLCT LVR POSISelector lever in “N” and “P” positions. N/P
Selector lever in “R” position. R
Selector lever in “D” position. D
VHCL/S SE-A/T During drivingApproximately matches the speed-
ometer reading.
VEHICLE SPEED During drivingApproximately matches the speed-
ometer reading.
ENGINE SPEED Engine runningClosely matches the tachometer
reading.
LINE PRES SOL During driving 0.2 – 0.6 A
TURBINE REV During driving (lock-up ON)Approximately matches the engine
speed.
VHCL/S SE-MTR During drivingApproximately matches the speed-
ometer reading.
ATF PRES SW 2Low coast brake engaged. Refer to AT- 1 9
.ON
Low coast brake disengaged. Refer to AT- 1 9
.OFF

AT-86
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
SELF-DIAGNOSTIC RESULT MODE
After performing self-diagnosis, place check marks for results on the AT- 4 4 , "DIAGNOSTIC WORKSHEET" .
Reference pages are provided following the items.
Display Items List
X: Applicable, —: Not applicable
Items (CONSULT-III
screen terms)Malfunction is detected when...TCM self-
diagnosisOBD-II (DTC)
Reference
page “TRANS-
MISSION”
with CON-
SULT-IIIMIL
*1 ,
“ENGINE” with
CONSULT-III
or GST
CAN COMM CIRCUITWhen TCM is not transmitting or receiving CAN communica-
tion signal for 2 seconds or more.U1000 U1000AT- 9 4
STARTER RELAY/
CIRCIf this signal is ON other than in “P” or “N” position, this is
judged to be a malfunction.
(And if it is OFF in “P” or “N” position, this too is judged to be
a malfunction.)P0615 —AT- 9 7
TCM TCM is malfunctioning P0700 P0700AT- 1 0 1
PNP SW/CIRC

PNP switch 1–4 signals input with impossible pattern.

“P” position is detected from “N” position without any other
position being detected in between.P0705 P0705AT- 1 0 2
TURBINE REV S/CIRC

TCM does not receive the proper voltage signal from the
sensor.

TCM detects an irregularity only at position of 4th gear for
turbine revolution sensor 2.P0717 P0717AT- 1 0 6
VEH SPD SEN/CIR AT

Signal from vehicle speed sensor A/T (Revolution sensor)
not input due to cut line or the like.

Unexpected signal input during running.

After ignition switch is turned ON, unexpected signal input
from vehicle speed sensor MTR before the vehicle starts
moving.P0720 P0720AT- 1 0 8
ENGINE SPEED SIGTCM does not receive the CAN communication signal from
the ECM.P0725 P0725AT- 11 3
A/T 1ST GR FNCTN A/T cannot shift to 1st gear P0731 P0731AT- 11 5
A/T 2ND GR FNCTN A/T cannot shift to 2nd gear P0732 P0732AT- 11 7
A/T 3RD GR FNCTN A/T cannot shift to 3rd gear P0733 P0733AT- 11 9
A/T 4TH GR FNCTN A/T cannot shift to 4th gear P0734 P0734AT- 1 2 1
A/T 5TH GR FNCTN A/T cannot shift to 5th gear P0735 P0735AT- 1 2 3
TCC SOLENOID/CIRCNormal voltage not applied to solenoid due to cut line, short,
or the like.P0740 P0740AT- 1 2 5
A/T TCC S/V FNCTN

A/T cannot perform lock-up even if electrical circuit is
good.

TCM detects as irregular by comparing difference value
with slip rotation.P0744
P0744*2AT- 1 2 7
L/PRESS SOL/CIRC

Normal voltage not applied to solenoid due to cut line,
short, or the like.

TCM detects as irregular by comparing target value with
monitor value.P0745 P0745AT- 1 2 9
TP SEN/CIRC A/TTCM does not receive the proper accelerator pedal position
signals (input by CAN communication) from ECM.P1705 P1705AT- 1 3 1
ATF TEMP SEN/CIRC During running, the A/T fluid temperature sensor signal volt-
age is excessively high or low.P1710 P0710AT- 1 3 4

AT-92
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
Diagnostic Procedure Without CONSULT-IIINCS0002F
OBD-II SELF-DIAGNOSTIC PROCEDURE (WITH GST)
Refer to EC-125, "Generic Scan Tool (GST) Function" .
OBD-II SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)
Refer to EC-62, "Malfunction Indicator Lamp (MIL)" .
TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)
Description
When the ignition switch is turned ON, the indicator lamp lights up 2 seconds. As a method for locating the
suspect circuit, when the self-diagnostics start signal is input, the memory for the malfunction location is output
and A/T CHECK indicator lamp flashes to display the corresponding DTC.
Diagnostic Procedure
1. CHECK A/T CHECK INDICATOR LAMP
1. Start the engine with selector lever in “P” position. Warm engine to normal operating temperature.
2. Turn ignition switch ON and OFF at least twice, then leave it in the OFF position.
3. Wait 10 seconds.
4. Turn ignition switch ON. (Do not start engine.)
Does A/T CHECK indicator lamp come on for about 2 seconds?
YES >> GO TO 2.
NO >> Go to AT- 1 7 2 , "
A/T Check Indicator Lamp Does Not Come On" .
2. JUDGMENT PROCEDURE
1. Turn ignition switch OFF.
2. Keep pressing shift lock release button.
3. Move selector lever from “P” to “D” position.
4. Release accelerator pedal. (Set the closed throttle position signal ON.)
5. Depress brake pedal. (Stop lamp switch signal ON.)
6. Turn ignition switch ON. (Do not start engine.)
7. Wait 3 seconds.
8. Move the selector lever to the manual shift gate side. (Manual mode switch ON.)
9. Release brake pedal. (Stop lamp switch signal OFF.)
10. Move the selector lever to “D” position. (Manual mode switch OFF.)
11. Depress brake pedal. (Stop lamp switch signal ON.)
12. Release brake pedal. (Stop lamp switch signal OFF.)
13. Depress accelerator pedal fully and release it.
>> GO TO 3.
3. CHECK SELF-DIAGNOSIS CODE
Check A/T CHECK indicator lamp. Refer to AT- 9 3 , "
Judgment Self-diagnosis Code" .
If the system does not go into self-diagnostics. Refer to AT- 1 0 2 , "
DTC P0705 PARK/NEUTRAL POSITION
SWITCH" , AT- 1 5 7 , "DTC P1815 MANUAL MODE SWITCH" , AT- 1 6 6 , "CLOSED THROTTLE POSITION AND
WIDE OPEN THROTTLE POSITION CIRCUIT" , AT- 1 6 7 , "BRAKE SIGNAL CIRCUIT" .
>>DIAGNOSIS END

AT-96
DTC U1000 CAN COMMUNICATION LINE
Revision: 2006 November2007 350Z
TCM terminals and data are reference value. Measured between each terminal and ground.
Diagnostic ProcedureNCS0002L
1. CHECK CAN COMMUNICATION CIRCUIT
With CONSULT-III
1. Turn ignition switch ON and start engine.
2. Select “SELF-DIAG RESULTS” mode for “TRANSMISSION” with CONSULT-III.
Is any malfunction of the
“CAN COMM CIRCUIT” indicated?
YES >> Print out CONSULT-III screen, GO TO LAN section. Refer to LAN-48, "CAN System Specification
Chart" .
NO >>INSPECTION END
TerminalWire
colorItem Condition Data (Approx.)
3 L CAN-H — —
8 P CAN-L — —
