A/T CONTROL SYSTEM
AT-29
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
TCM FunctionNCS0001M
The function of the TCM is to:

Receive input signals sent from various switches and sensors.

Determine required line pressure, shifting point, lock-up operation, and engine brake operation.

Send required output signals to the respective solenoids.
CONTROL SYSTEM OUTLINE
The A/T senses vehicle operating conditions through various sensors or signals. It always controls the opti-
mum shift position and reduces shifting and lock-up shocks.
CONTROL SYSTEM DIAGRAM
SENSORS (or SIGNALS)

TCM

ACTUATORS
PNP switch
Accelerator pedal position signal
Closed throttle position signal
Wide open throttle position signal
Engine speed signal
A/T fluid temperature sensor
Revolution sensor
Vehicle speed signal
Manual mode switch signal
Stop lamp switch signal
Turbine revolution sensor
ATF pressure switchShift control
Line pressure control
Lock-up control
Engine brake control
Timing control
Fail-safe control
Self-diagnosis
CONSULT-III communication line
Duet-EA control
CAN systemInput clutch solenoid valve
Direct clutch solenoid valve
Front brake solenoid valve
High and low reverse clutch
solenoid valve
Low coast brake solenoid valve
Torque converter clutch sole-
noid valve
Line pressure solenoid valve
A/T CHECK indicator lamp
Starter relay
Back-up lamp relay
SCIA8327E

AT-30
A/T CONTROL SYSTEM
Revision: 2006 November2007 350Z
CAN CommunicationNCS0001N
SYSTEM DESCRIPTION
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only. For details, refer to LAN-48,
"CAN System Specification Chart" .
Input/Output Signal of TCMNCS0001O

*1: Spare for vehicle speed sensor A/T (revolution sensor)

*2: Spare for accelerator pedal position signal

*3: If these input and output signals are different, the TCM triggers the fail-safe function.

*4: Used as a condition for starting self-diagnostics; if self-diagnostics are not started, it is judged that there is some kind of error.

*5: Input by CAN communications

*6: Output by CAN communicationsControl itemLine
pressure
controlVehicle
speed
controlShift
controlLock-up
controlEngine
brake
controlFail-safe
function
(*3)
Self-diag-
nostics
function
InputAccelerator pedal position signal
(*5)XXXXX X X
Vehicle speed sensor A/T
(revolution sensor)XXXXX X X
Vehicle speed sensor MTR
(*1)(*5)X
Closed throttle position signal
(*5)X(*2)XX X
X(*4)
Wide open throttle position signal(*5)X
X(*4)
Turbine revolution sensor 1 X X X X X
Turbine revolution sensor 2
(for 4th speed only)XXXXX
Engine speed signals
(*5)XXXXX X X
Stop lamp switch signal
(*5)XXX
X(*4)
A/T fluid temperature sensors 1, 2 X X X X X X
ASCDOperation signal
(*5)XXX
Overdrive cancel sig-
nal
(*5)X
OutputDirect clutch solenoid X X X X
Input clutch solenoid X X X X
High and low reverse clutch solenoid X X X X
Front brake solenoid X X X X
Low coast brake solenoid
(ATF pressure switch 2)XX X X X
Line pressure solenoid X X X X X X X
TCC solenoid X X X
Self-diagnostics table
(*6)X
Starter relayXX

TROUBLE DIAGNOSIS
AT-41
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
A/T Interlock

If there is an A/T interlock judgment malfunction, the transmission is fixed in 2nd gear to make driving pos-
sible.
NOTE:
When the vehicle is driven fixed in 2nd gear a turbine revolution sensor malfunction is displayed,
but this is not a turbine revolution sensor malfunction.

When interlock is detected at the 3rd gear or more, it is locked at the 2nd gear.
A/T 1st Engine Braking
When there is an A/T first gear engine brake judgment malfunction, the low coast brake solenoid is switched
OFF to avoid the engine brake operation.
Line Pressure Solenoid
The solenoid is switched OFF and the line pressure is set to the maximum hydraulic pressure to make driving
possible.
Torque Converter Clutch Solenoid
The solenoid is switched OFF to release the lock-up.
Low Coast Brake Solenoid
When a malfunction (electrical or functional) occurs, in order to make driving possible, if the solenoid is ON,
the A/T is held in 2nd gear; if the solenoid is OFF, the A/T is held in 4th gear. (Engine brake is not applied in
1st and 2nd gear.)
Input Clutch Solenoid
If a malfunction (electrical or functional) occurs with the solenoid either ON or OFF, the A/T is held in 4th gear
to make driving possible.
Direct Clutch Solenoid
If a malfunction (electrical or functional) occurs with the solenoid either ON or OFF, the A/T is held in 4th gear
to make driving possible.
Front Brake Solenoid
If a malfunction (electrical or functional) occurs with the solenoid ON, in order to make driving possible, the A/
T is held in 5th gear; if the solenoid is OFF, 4th gear.
High and Low Reverse Clutch Solenoid
If a malfunction (electrical or functional) occurs with the solenoid either ON or OFF, the A/T is held in 4th gear
to make driving possible.
Turbine Revolution Sensor 1 or 2
The control is the same as if there were no turbine revolution sensors, 5th gear and manual mode are prohib-
ited.

TROUBLE DIAGNOSIS
AT-45
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
4❏ Perform all road tests and enter checks in required inspection items.AT- 5 2
4-1.Check before engine is started AT- 5 3
❏ AT- 1 7 2 , "A/T Check Indicator Lamp Does Not Come On"
❏ Perform self-diagnostics. Enter checks for detected items. AT- 8 6 , AT- 9 2
❏ AT-94, "DTC U1000 CAN COMMUNICATION LINE"
❏ AT-97, "DTC P0615 START SIGNAL CIRCUIT"
❏ AT-101, "DTC P0700 TCM"
❏ AT-102, "DTC P0705 PARK/NEUTRAL POSITION SWITCH"
❏ AT-106, "DTC P0717 TURBINE REVOLUTION SENSOR"
❏ AT-108, "DTC P0720 VEHICLE SPEED SENSOR A/T (REVOLUTION SENSOR)"
❏ AT-113, "DTC P0725 ENGINE SPEED SIGNAL"
❏ AT-115, "DTC P0731 A/T 1ST GEAR FUNCTION"
❏ AT-117, "DTC P0732 A/T 2ND GEAR FUNCTION"
❏ AT-119, "DTC P0733 A/T 3RD GEAR FUNCTION"
❏ AT-121, "DTC P0734 A/T 4TH GEAR FUNCTION"
❏ AT-123, "DTC P0735 A/T 5TH GEAR FUNCTION"
❏ AT-125, "DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE"
❏ AT-127, "DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)"
❏ AT-129, "DTC P0745 LINE PRESSURE SOLENOID VALVE"
❏ AT-131, "DTC P1705 THROTTLE POSITION SENSOR"
❏ AT-134, "DTC P1710 A/T FLUID TEMPERATURE SENSOR CIRCUIT"
❏ AT-139, "DTC P1721 VEHICLE SPEED SENSOR MTR"
❏ AT-141, "DTC P1730 A/T INTERLOCK"
❏ AT-143, "DTC P1731 A/T 1ST ENGINE BRAKING"
❏ AT-145, "DTC P1752 INPUT CLUTCH SOLENOID VALVE"
❏ AT-147, "DTC P1757 FRONT BRAKE SOLENOID VALVE"
❏ AT-149, "DTC P1762 DIRECT CLUTCH SOLENOID VALVE"
❏ AT-151, "DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE"
❏ AT-153, "DTC P1772 LOW COAST BRAKE SOLENOID VALVE"
❏ AT-155, "DTC P1774 LOW COAST BRAKE SOLENOID VALVE FUNCTION"
❏ AT-157, "DTC P1815 MANUAL MODE SWITCH"
4-2.Check at IdleAT- 5 3
❏ AT- 1 7 3 , "Engine Cannot Be Started in “P” or “N” Position"
❏ AT- 1 7 3 , "In “P” Position, Vehicle Moves When Pushed"
❏ AT- 1 7 4 , "In “N” Position, Vehicle Moves"
❏ AT- 1 7 5 , "Large Shock (“N” to “D” Position)"
❏ AT- 1 7 7 , "Vehicle Does Not Creep Backward in “R” Position"
❏ AT- 1 7 9 , "Vehicle Does Not Creep Forward in “D” Position"
4-3.Cruise testAT- 5 5
Part 1
❏ AT- 1 8 1 , "
Vehicle Cannot Be Started from D1"
❏ AT- 1 8 3 , "A/T Does Not Shift: D1 → D2"
❏ AT- 1 8 5 , "A/T Does Not Shift: D2 → D3"
❏ AT- 1 8 7 , "A/T Does Not Shift: D3 → D4"
❏ AT- 1 8 9 , "A/T Does Not Shift: D4 → D5"
❏ AT- 1 9 1 , "A/T Does Not Lock-up"
❏ AT- 1 9 3 , "A/T Does Not Hold Lock-up Condition"
❏ AT- 1 9 4 , "Lock-up Is Not Released"
❏ AT- 1 9 5 , "Engine Speed Does Not Return to Idle"

AT-46
TROUBLE DIAGNOSIS
Revision: 2006 November2007 350Z
44-3.Part 2AT- 5 7
❏ AT-181, "Vehicle Cannot Be Started from D1"
❏ AT-183, "A/T Does Not Shift: D1 → D2"
❏ AT-185, "A/T Does Not Shift: D2 → D3"
❏ AT-187, "A/T Does Not Shift: D3 → D4"
Part 3AT- 5 8
❏ AT-196, "Cannot Be Changed to Manual Mode"
❏ AT-196, "A/T Does Not Shift: 5th Gear → 4th Gear"
❏ AT-198, "A/T Does Not Shift: 4th Gear → 3rd Gear"
❏ AT-199, "A/T Does Not Shift: 3rd Gear → 2nd Gear"
❏ AT-201, "A/T Does Not Shift: 2nd Gear → 1st Gear"
❏ AT-202, "Vehicle Does Not Decelerate by Engine Brake"
❏ Perform self-diagnostics. Enter checks for detected items. AT- 8 6 , AT- 9 2
❏ AT- 9 4 , "DTC U1000 CAN COMMUNICATION LINE"
❏ AT- 9 7 , "DTC P0615 START SIGNAL CIRCUIT"
❏ AT-101, "DTC P0700 TCM"
❏ AT-102, "DTC P0705 PARK/NEUTRAL POSITION SWITCH"
❏ AT-106, "DTC P0717 TURBINE REVOLUTION SENSOR"
❏ AT-108, "DTC P0720 VEHICLE SPEED SENSOR A/T (REVOLUTION SENSOR)"
❏ AT- 11 3 , "DTC P0725 ENGINE SPEED SIGNAL"
❏ AT- 11 5 , "DTC P0731 A/T 1ST GEAR FUNCTION"
❏ AT- 11 7 , "DTC P0732 A/T 2ND GEAR FUNCTION"
❏ AT- 11 9 , "DTC P0733 A/T 3RD GEAR FUNCTION"
❏ AT-121, "DTC P0734 A/T 4TH GEAR FUNCTION"
❏ AT-123, "DTC P0735 A/T 5TH GEAR FUNCTION"
❏ AT-125, "DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE"
❏ AT-127, "DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)"
❏ AT-129, "DTC P0745 LINE PRESSURE SOLENOID VALVE"
❏ AT-131, "DTC P1705 THROTTLE POSITION SENSOR"
❏ AT-134, "DTC P1710 A/T FLUID TEMPERATURE SENSOR CIRCUIT"
❏ AT-139, "DTC P1721 VEHICLE SPEED SENSOR MTR"
❏ AT-141, "DTC P1730 A/T INTERLOCK"
❏ AT-143, "DTC P1731 A/T 1ST ENGINE BRAKING"
❏ AT-145, "DTC P1752 INPUT CLUTCH SOLENOID VALVE"
❏ AT-147, "DTC P1757 FRONT BRAKE SOLENOID VALVE"
❏ AT-149, "DTC P1762 DIRECT CLUTCH SOLENOID VALVE"
❏ AT-151, "DTC P1767 HIGH AND LOW REVERSE CLUTCH SOLENOID VALVE"
❏ AT-153, "DTC P1772 LOW COAST BRAKE SOLENOID VALVE"
❏ AT-155, "DTC P1774 LOW COAST BRAKE SOLENOID VALVE FUNCTION"
❏ AT-157, "DTC P1815 MANUAL MODE SWITCH"
5❏ Inspect each system for items found to be NG in the self-diagnostics and repair or replace the malfunctioning parts.
6❏ Perform all road tests and enter the checks again for the required items.AT- 5 2
7❏ For any remaining NG items, perform the “diagnostics procedure” and repair or replace the malfunctioning
parts. See the chart for diagnostics by symptoms. (This chart also contains other symptoms and inspection pro-
cedures.)AT- 5 9
8❏ Erase the results of the self-diagnostics from TCM and ECM.AT- 9 3,
AT- 3 8

TROUBLE DIAGNOSIS
AT-59
D
E
F
G
H
I
J
K
L
MA
B
AT
Revision: 2006 November2007 350Z
Symptom ChartNCS0002C

The diagnostics item numbers show the sequence for inspection. Inspect in order from item 1.

Overhaul and inspect inside the A/T only if A/T fluid condition is NG. Refer to AT- 4 9 , "A/T Fluid Con-
dition Check".
No. Items Symptom Condition Diagnostic ItemReference
page
1
Shift
ShockLarge shock. (“N” → “
D” position)
Refer to AT-175,
"Large Shock (“N” to
“D” Position)" .ON vehicle1. Engine idle speedEC-76
2. Engine speed signalAT- 11 3
3. Accelerator pedal position sensorAT-131
4. A/T positionAT-206
5. A/T fluid temperature sensorAT-134
6. Front brake solenoid valveAT-147
7. CAN communication lineAT- 9 4
8. A/T fluid level and stateAT- 4 9
9. Line pressure testAT- 5 0
10. Control valve with TCMAT-215
OFF vehicle11. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to AT-17,
"Cross-sectional View" .)AT-255
2Shock is too large
when changing D1 →
D
2 or M1 → M2 .ON vehicle1. Accelerator pedal position sensorAT-131
2. A/T positionAT-206
3. Direct clutch solenoid valveAT-149
4. CAN communication lineAT- 9 4
5. Engine speed signalAT- 11 3
6. Turbine revolution sensorAT-106
7. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-108,
AT-139
8. A/T fluid level and stateAT- 4 9
9. Control valve with TCMAT-215
OFF vehicle 10. Direct clutchAT-288
3Shock is too large
when changing D2 →
D
3 or M2 → M3 .ON vehicle1. Accelerator pedal position sensorAT-131
2. A/T positionAT-206
3. High and low reverse clutch solenoid valveAT-151
4. CAN communication lineAT- 9 4
5. Engine speed signalAT- 11 3
6. Turbine revolution sensorAT-106
7. Vehicle speed sensor A/T and vehicle speed sensor MTRAT-108,
AT-139
8. A/T fluid level and stateAT- 4 9
9. Control valve with TCMAT-215
OFF vehicle 10. High and low reverse clutchAT-286
