2007 MERCEDES-BENZ SLK CLASS Owners Manual

96 Controls in detail
Locking and unlocking
Factory settingGlobal unlocking
Press buttonŒ.

All turn signal lamps flash once.

An acoustic warning sounds once
(if equipped and feature activated).
For more information, see “Factory
setting” (
page 96).

The locking knobs in the doors
move up.

The anti-theft alarm system is
disarmed.
The vehicle will lock again automatically
and rearm the anti-theft alarm system
within approximately 40 seconds of un-
locking if:

neither door nor trunk is opened

the SmartKey is not inserted in the
starter switch

the central locking switch is not
activatedGlobal locking
Press button‹.
With all doors and the trunk closed:

All turn signal lamps flash three
times.

An acoustic warning sounds three
times (if equipped and feature
activated). For more information,
see “Factory setting” (
page 96).

The locking knobs in the doors
move down.

The anti-theft alarm system is
armed.
iYour vehicle may be equipped with an
acoustic lock and unlock confirmation signal
feature. If your vehicle is equipped with this
feature and the feature is activated, an acoustic
signal will sound when the vehicle is locked or
unlocked using the SmartKey.
To determine whether or not your vehicle is
equipped with this feature, contact an
authorized Mercedes-Benz Center. If equipped
and you wish to activate or deactivate, or adjust
its signal volume, also contact an authorized
Mercedes-Benz Center.

97 Controls in detail
Locking and unlocking
Selective setting
If you frequently travel alone, you may wish
to reprogram the SmartKey so that press-
ing buttonŒ only unlocks the driver’s
door, the storage/telephone* compart-
ment under the armrest, the glove box, and
the fuel filler flap.
Press and hold buttonsŒand‹
simultaneously for about 5 seconds
until battery check lamp5
(
page 94) flashes twice.
The SmartKey will then function as fol-
lows:Unlocking driver’s door and fuel filler
flap
Press buttonΠonce.

All turn signal lamps flash once.

An acoustic warning sounds once
(if equipped and feature activated).
For more information, see “Factory
setting” (
page 96).

The locking knob in the driver’s
door moves up.

The anti-theft alarm system is
disarmed.Global unlocking
Press buttonΠtwice.

All turn signal lamps flash once.

An acoustic warning sounds once
(if equipped and feature activated).
For more information, see “Factory
setting” (
page 96).

The locking knobs in the doors
move up.

The anti-theft alarm system is
disarmed.

98 Controls in detail
Locking and unlocking
Global locking
Press button‹.
With all doors and the trunk closed:

All turn signal lamps flash three
times.

An acoustic warning sounds three
times (if equipped and feature acti-
vated). For more information, see
“Factory setting” (
page 96).

The locking knobs in the doors
move down.

The anti-theft alarm system is
armed.Restoring to factory setting
Press and hold buttonsŒand‹
simultaneously for about 5 seconds
until battery check lamp5
(
page 94) flashes twice.
Checking the batteries
Press button‹orŒ.
The battery check lamp (
page 94)
comes on briefly to indicate that the
SmartKey batteries are in order.Loss of SmartKey or mechanical key
If you lose a SmartKey or mechanical key,
you should do the following:
Have the SmartKey deactivated by an
authorized Mercedes-Benz Center.
Report the loss of the SmartKey or the
mechanical key to your car insurance
company immediately.
If necessary have the mechanical lock
replaced.
Your authorized Mercedes-Benz Center
will be glad to supply you with a replace-
ment.
iIf the battery check lamp (page 94) does
not come on briefly during check, the SmartKey
batteries are discharged.

Replace the batteries (page 391).
You can obtain the required batteries at any
authorized Mercedes-Benz Center.
iIf the batteries are checked within signal
range of the vehicle, pressing
button‹orŒ will lock or unlock the
vehicle accordingly.

99 Controls in detail
Locking and unlocking
Opening the doors from the inside
You can open a locked door from the in-
side. Open door only when conditions are
safe to do so.
1Inside door handle
2Locking knob
Pull on door handle1 on the respec-
tive door.
If the door was locked, locking knob2
will move up.
iIf you hear a warning signal, you have forgot-
ten to switch off the headlamps before opening
the driver’s door.
In addition, the message
Turn off lights
appears in the multifunction display.
Switch off the headlamps.
!Failure to switch off the headlamps when
leaving the vehicle may result in a discharged
battery.
iIf the vehicle has previously been centrally
locked with the SmartKey, opening a door from
the inside will trigger the anti-theft alarm system.
To cancel the alarm, do one of the following:

Press buttonŒor‹on the
SmartKey.

Insert the SmartKey in the starter switch.
!Opening a door causes the windows on that
side of the car to open slightly. They will return to
the up position when the door is closed.
The side windows will not open or close if the
battery is discharged or the windows are imped-
ed by ice. As a result, you may no longer be able
to properly close the door. Do not attempt to
force the door shut. Doing so may damage the
door or the side window. Correct the condition
that prevents the windows from operating before
attempting to close the door.

100 Controls in detail
Locking and unlocking
Opening the trunk
You can open the trunk when if vehicle is
stationary.
A minimum height clearance of 5.78 ft
(1.76 m) is required to open the trunk lid.Press and hold buttonŠ on the
SmartKey.
The trunk is unlocked.
Pull on the handle.
Lift the trunk lid.
The trunk lid can also be opened from the
inside in an emergency, see “Trunk lid
emergency release” (
page 101).
Closing the trunk
1Handle
Warning!G
Make sure the trunk is closed when the
engine is running and while driving.
Among other dangers, deadly carbon
monoxide (CO) gases may enter vehicle
interior resulting in unconsciousness and
death.
!When the trunk lid is lifted slightly, it swings
open upwards automatically. Always make sure
there is sufficient overhead clearance.
iThe vehicle or trunk must be unlocked
before the trunk lid can be opened.
The trunk lid can only be opened when the vehi-
cle is not in motion and the retractable hardtop
is fully opened or closed.
Warning!G
Make sure the trunk is closed when the
engine is running and while driving.
Among other dangers, deadly carbon
monoxide (CO) gases may enter vehicle
interior resulting in unconsciousness and
death.
iDo not place the SmartKey in the open
trunk. You may lock yourself out.

101 Controls in detail
Locking and unlocking
Lower the trunk lid using handle1.
Close the trunk lid with hands placed
flat on the trunk lid.
Trunk lid emergency release
With the emergency release button, the
trunk can be opened from inside the trunk.
1Emergency release button
Briefly press emergency release
button1.
The trunk lid unlocks and opens
slightly.
Push up the trunk lid to fully open.
iIf the vehicle was previously centrally
locked, the trunk lid will lock automatically when
closed. The turn signal lamps will flash three
times to confirm locking.
Warning!G
To prevent possible personal injury, always
keep hands and fingers away from the trunk
lid opening when closing the trunk lid.
Be especially careful when small children
are around.
Warning!G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s
unsupervised access to a vehicle could
result in an accident and/or serious
personal injury.

102 Controls in detail
Locking and unlocking
Illumination of the emergency release
button:

The button flashes for 30 minutes after
opening the trunk.

The button flashes for 60 minutes after
closing the trunk.
Automatic central locking
The doors and the trunk automatically lock
when the vehicle is set into motion.
You can deactivate the automatic locking
using the control system, see “Setting
automatic locking” (
page 146).
Locking and unlocking from the inside
You can lock or unlock the doors and the
trunk from the inside using the central
locking or unlocking switch. This can be
useful, for example, if you want to lock the
vehicle before starting to drive.
The fuel filler flap will not be locked or
unlocked with the central locking or
unlocking switch, respectively.iThe emergency release button unlocks
the trunk while the vehicle is standing still or
in motion.
iThe emergency release button does not un-
lock the trunk if the vehicle battery is discharged
or disconnected.
iIf the vehicle has previously been centrally
locked with the SmartKey, opening the trunk
from the inside will trigger the anti-theft alarm
system.
To cancel the alarm, do one of the following:

Press buttonŒor‹on the
SmartKey.

Insert the SmartKey in the starter switch.
iYou can open a locked door from the inside.
Open door only when conditions are safe to do
so.
iThe doors unlock automatically after an
accident if the force of the impact exceeds a
preset threshold.
The vehicle locks automatically when the ignition
is switched on and the wheels are turning at a
vehicle speed of approximately 9 mph (15 km/h)
or more. You could therefore lock yourself out
when the vehicle

is pushed or towed

is on a test stand
Warning!G
When leaving the vehicle, always remove the
SmartKey from the starter switch, take it
with you, and lock the vehicle. Do not leave
children unattended in the vehicle, or with
access to an unlocked vehicle. A child’s
unsupervised access to a vehicle could
result in an accident and/or serious
personal injury.

103 Controls in detail
Locking and unlocking
1Central locking switch
2Central unlocking switchLocking
Press central locking switch1.
If all doors are closed, the vehicle
locks.
Unlocking
Press central unlocking switch2.
The vehicle unlocks.
iYou can open a locked door from the inside.
Open door only when conditions are safe to do
so.
If the vehicle was previously centrally locked
using the SmartKey, it will not unlock using the
central unlocking switch.
If the vehicle was previously locked with the
central locking switch

and the SmartKey is set to factory settings,
the complete vehicle is unlocked when a
door is opened from the inside

and the SmartKey is set to selective settings,
only the door opened from inside is unlocked
