2007 MERCEDES-BENZ SL65AMG trunk release

ContentsSafety and Security........................... 65
Occupant safety................................... 66
Air bags .......................................... 68
Occupant Classification System ..... 72
Seat belts ....................................... 77
Roll bar ........................................... 81
Children in the vehicle .................... 83
Panic alarm .......................................... 86
Activating ....................................... 86
Deactivating ................................... 86
Driving safety systems ......................... 87
ABS ................................................ 87
BAS ................................................ 89
ESP
®............................................... 89
Electro-hydraulic brake system ...... 92
Anti-theft systems................................ 96
Immobilizer..................................... 96
Anti-theft alarm system .................. 96
Tow-away alarm ............................. 98
Controls in detail............................. 101
Locking and unlocking ....................... 102
SmartKey ..................................... 102
SmartKey with KEYLESS-GO* ...... 105
Opening the doors from the
inside ........................................... 111
Opening the trunk ........................ 111
Closing the trunk.......................... 113
Valet locking ................................ 117
Trunk lid emergency release ........ 117
Power closing assist for trunk lid . 118
Automatic central locking ............ 119
Locking and unlocking from the
inside ........................................... 119
Seats ................................................. 121
Moving the seats forward and
backward ..................................... 121
Lumbar support............................ 121
Multicontour backrest* ................ 122
Seat heating ................................. 123
Seat ventilation* .......................... 125
Memory function ............................... 126
Storing positions into memory ..... 127
Recalling positions from memory . 127 Lighting ............................................ 128
Exterior lamp switch .................... 128
Corner-illuminating front fog
lamps ........................................... 132
Combination switch ..................... 133
Hazard warning flasher ................ 133
Interior lighting ............................ 134
Courtesy lighting .......................... 135
Trunk lamp ................................... 135
Instrument cluster ............................. 136
Adjusting instrument cluster
illumination .................................. 136
Coolant temperature gauge ......... 137
Trip odometer .............................. 137
Tachometer.................................. 138
Outside temperature indicator ..... 138
Control system .................................. 139
Multifunction display.................... 139
Multifunction steering wheel........ 140
Menus .......................................... 142
Standard display menu ................ 145
AMG menu ................................... 146
AUDIO menu ................................ 149
NAV menu .................................... 151
Distronic* menu .......................... 151

97 Safety and Security
Anti-theft systems
The alarm system will also be triggered
when

someone attempts to raise the vehicle


unlocking and opening the driver’s
door with the mechanical key


someone opens a door from the inside


someone opens the trunk lid with the
emergency release buttonArming the alarm system
The alarm system is armed after locking
the vehicle with the SmartKey or
KEYLESS-GO*. The turn signal lamps flash
three times to indicate that the alarm sys-
tem is activated. The indicator lamp in the
central locking switch (
page 31) begins
to flash after arming the alarm system.
Disarming the alarm system
The alarm system is disarmed when you
unlock your vehicle with the SmartKey or
KEYLESS-GO*. The turn signal lamps flash
once to indicate that the alarm system is
disarmed.Canceling the alarm
To cancel the alarm:
With the SmartKey

Insert the SmartKey in the starter
switch.
or

Press theŒor‹button on the
SmartKey.
With KEYLESS-GO*

Grasp an outside door handle.
The SmartKey with KEYLESS-GO must
be within 3 ft. (1 m) of the vehicle.
or

Press the KEYLESS-GO start/stop but-
ton (
page 40).
The SmartKey with KEYLESS-GO must
be inside the vehicle.
i
If the alarm stays on for more than
30 seconds, a call to the Response Center is ini-
tiated automatically by the Tele Aid system
(
page 245) provided Tele Aid service was sub-
scribed to and properly activated, and that nec-
essary cellular service and GPS coverage are
available.
i
If the turn signal lamps do not flash three
times, a door or the trunk lid may not be properly
closed.
Close the respective element and lock the vehi-
cle again.
i
The alarm system will rearm automatically
again after approximately 40 seconds if no door
was opened.

113 Controls in detail
Locking and unlocking
Vehicles with trunk opening/closing
system*
1Remote trunk opening/closing* switch
2Indicator lamp
Pull and hold switch1 until the trunk
unlocks and begins to open.
Indicator lamp2 comes on and re-
mains lit until the trunk closed.

Release switch1.
To interrupt the opening procedure:

Press or pull switch1.
Closing the trunk Closing trunk from outside manually
1Handle

Lower trunk lid by pulling firmly on
handle1.

Close trunk lid with hands placed flat
on trunk lid.
The power closing assist automatically en-
sures that the lid is pulled closed com-
pletely (
page 118).
!
The trunk lid swings open upwards automat-
ically. Always make sure that there is sufficient
overhead clearance.
Warning!
G
Only drive with the trunk closed as, among
other dangers such as blocked visibility, ex-
haust fumes may enter the vehicle interior.i
When the hardtop is retracted, it must be
completely lowered in the trunk before the trunk
can be closed (
page 199).
i
Do not place the SmartKey in the open
trunk. You may lock yourself out.
i
If the vehicle was previously centrally
locked, the trunk will lock automatically after
closing it. All turn signal lamps flash three times
to confirm locking.
Vehicles with KEYLESS-GO*: To prevent a possi-
ble inadvertent lockout, the trunk will open auto-
matically if a SmartKey with KEYLESS-GO is
recognized inside the vehicle or in the trunk.
The vehicle is only locked when the turn signals
flash three times. If you are carrying a second
SmartKey with KEYLESS-GO with you, you can
still lock the vehicle.

114 Controls in detailLocking and unlocking
Closing trunk from inside
automatically*
In vehicles with trunk opening/closing
system* you can close the trunk from
the inside using the remote trunk
opening/ closing* switch.
1Remote trunk opening/closing* switch
(vehicles with trunk opening/closing
system*)
2Indicator lamp
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the trunk
lid opening when closing the trunk. Be espe-
cially careful when small children are
around.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.
Warning!
G
Maintain sight of trunk area while operating
door mounted switch. Monitor the closing
procedure carefully to make sure no one is
in danger of being injured.
To interrupt the closing procedure, release
the door mounted remote trunk open-
ing/closing* switch again.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the remote trunk
opening/closing* switch can be operated.
Therefore, do not leave children unattended
in the vehicle, or with access to an unlocked
vehicle. Unsupervised use of vehicle equip-
ment may cause an accident and/or serious
personal injury.
i
If the trunk lid comes into contact with an
object while closing (e.g. luggage that has been
piled too high) in the upper motion sequence, the
closing procedure is stopped and the trunk re-
opens slightly.

115 Controls in detail
Locking and unlocking

Press and hold switch1 until the
trunk is closed.
Indicator lamp2 in the switch goes
out when the trunk is closed.
To interrupt the closing procedure:

Release switch1.Closing trunk from outside
automatically*
In vehicles with trunk opening/closing sys-
tem* you can close the trunk separately
from the outside using the trunk closing
switch.
Warning!
G
Monitor the closing procedure carefully to
make sure no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the trunk lid opening when closing the trunk.
Be especially careful when small children
are around. To stop the closing procedure,
do one of the following:

Press button Š on the SmartKey or
SmartKey with KEYLESS-GO*.


Press the trunk opening/closing*
switch (on the driver’s door).


Press trunk closing switch.


Press the KEYLESS-GO locking/closing
switch*.


Pull the trunk lid handle.
Even with the SmartKey removed from the
starter switch, the trunk opening/closing*
switch can be operated. Therefore, do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and/or serious personal
injury.

117 Controls in detail
Locking and unlocking
Valet locking
The lock is located next to the handle
above the rear license plate recess.
1Neutral position
2Locked

Close the trunk (
page 113).

Pull the mechanical key out of the
SmartKey (
page 391).

Insert the mechanical key in the trunk
lid lock.

Turn the mechanical key clockwise to
position2 and remove the mechani-
cal key in that position to lock the
trunk.
The trunk remains locked even when the
vehicle is centrally unlocked.

Insert the mechanical key in the trunk
lid lock.

Turn the mechanical key counterclock-
wise to neutral position1 and remove
the mechanical key in that position to
unlock the trunk.
You can now open the trunk
(page 111).
Trunk lid emergency release
With the emergency release button, the
trunk can be opened from inside the trunk.
The emergency release button is located
on the left side of the trunk.
1Emergency release button
Briefly press emergency release
button1.
The trunk opens.
i
To deny any unauthorized person access to
the trunk, e.g. when you valet park the vehicle,
lock it separately with the mechanical key. Leave
only the SmartKey or SmartKey with
KEYLESS-GO* less its mechanical key with the
vehicle.
i
You can only cancel the separate trunk lock-
ing mode by means of the mechanical key.


118 Controls in detailLocking and unlockingIllumination of the emergency release but-
ton:

The button flashes for 30 minutes after
opening the trunk.


The button flashes for 60 minutes after
closing the trunk.
Power closing assist for trunk lid
It is not necessary to slam the trunk lid
closed. A electrical power-assisted mecha-
nism draws trunk lid closed quietly and au-
tomatically once trunk lid has been
latched. When the pneumatic power-as-
sisted mechanism has stopped, trunk can
be re-opened.Power closing assist for trunk lid

Press the trunk lid gently into its lock.
The trunk closes automatically.
i
The emergency release button unlocks and
opens the trunk while the vehicle is standing still
or in motion.
i
The emergency release button does not
open the trunk lid if the vehicle battery is dis-
charged or disconnected.
Warning!
G
To prevent possible personal injury, always
keep hands and fingers away from the trunk
lid opening when closing the trunk. Be espe-
cially careful when small children are
around.
In case of danger, pull the inside or outside
door handle, or press the trunk lid lock.
To prevent personal injury, never actuate
the closing assist mechanism by tampering
with the door or trunk lid latch.
Warning!
G
Only drive with the trunk closed as, among
other dangers such as blocked visibility, ex-
haust fumes may enter the vehicle interior.


199 Controls in detail
Retractable hardtop
Retractable hardtop
Opening and closing the retractable hardtop
For safety reasons, the retractable hardtop
can only be opened and closed when the
vehicle is standing still.Warning!
G
To prevent possible accidents, only drive the
vehicle with the retractable hardtop either
completely closed and locked, or fully low-
ered into its storage compartment.
If the retractable hardtop does not com-
pletely open or close, the roof hydraulics will
lose pressure and the retractable hardtop is
lowered

after approximately 7 minutes when the
ignition is switched on


after approximately 15 seconds when
the ignition is switched off
Shortly before the retractable hardtop is
lowered, a warning will sound and in the left
multifunction display you will see K, in
the right multifunction display you will see
the message
being lowered
.
Lock the retractable hardtop again before
driving any further (
page 202). Otherwise,
the unlocked hardtop could open while the
vehicle is in motion and cause you to lose
control of the vehicle. You or others could
be injured as a result.
Warning!
G
Before operating the retractable hardtop
switch, make sure there is no danger of any-
one being injured by the moving parts (re-
tractable roof, roof frame, and trunk lid) due
to inattention.
Hands must never be placed near the roof
frame, upper windshield area, hardtop, shelf
behind roll bars, or trunk lid while the re-
tractable hardtop is being raised or lowered.
Serious personal injury may occur.
If potential danger exists, release the re-
tractable hardtop switch. This immediately
interrupts the raising or lowering procedure.
You then can operate the retractable hard-
top switch to raise or lower the retractable
hardtop away from the danger zone.
