434 Controls in detailAutomatic climate controlRear passenger compartment adjust-able air vents
Rear center console air vents
1Left center air vent, adjustable
2Right center air vent, adjustable
3Thumbwheel for right center air vents
4Thumbwheel for left center air vents
Opening/closing air vents:
Turn thumbwheel3 or 4.Rear passenger compartment climate
control*
Automatic climate control panel, rear
i
Vehicles without rear passenger compart-
ment climate control*:
The temperature at the air vents for rear passen-
ger compartment1 and2 will be approxi-
mately the same as at the dashboard center air
vents.
Warning!
G
Follow the recommended settings for heat-
ing and cooling as given in the instructions
for the front climate control (
page 424).
Otherwise the windows could fog up, impair-
ing visibility for the driver and endangering
you and others.
i
At low outside temperatures or if you have
switched off the cooling function, you cannot
cool the rear passenger compartment.
Item
1
Temperature control, left
2
Air distribution, left
(automatic, manual)
3
Air volume (automatic, manual)
4
Mode selector
5
Air distribution, right
(automatic, manual)
6
Temperature control, right

475 Controls in detail
Useful features
Infrared reflecting windshield
Your vehicle is equipped with infrared re-
flecting glass, which reduces the amount
of radiated heat entering the vehicle interi-
or through the windows.
The infrared reflecting glass also prevents
the transmission of signals through the
glass by in-vehicle electronic devices
(e.g. electronic toll collection devices).
To allow the use of these devices in the ve-
hicle, transparent areas 1 and 3 are
placed in the windshield.
You can see them from certain angles
when ambient light condition permit.
Vehicles without Night View Assist*1Transparent area (located left and right
to the cover of the rain light sensor)
2Cover of the rain light sensor
3Transparent area
Vehicles with Night View Assist*1Transparent area (located left to the
cover of the rain light sensor)
2Cover of the rain light sensor
3Transparent area

526 OperationTires and wheelsTire and loading terminology
Accessory weight
The combined weight (in excess of those
standard items which may be replaced) of
automatic transmission, power steering,
power brakes, power windows, power
seats, radio, and heater, to the extent that
these items are available as
factory-installed equipment (whether
installed or not).
Air pressure
The amount of air inside the tire pressing
outward on each square inch of the tire.
Air pressure is expressed in pounds per
square inch (psi), or kilopascal (kPa) or
bars.
Aspect ratio
Dimensional relationship between tire
section height and section width
expressed in percentage.Bar
Another metric unit for air pressure. There
are 14.5038 pounds per square inch (psi)
to 1 bar; there are 100 kilopascals (kPa)
to 1 bar.
Bead
The tire bead contains steel wires wrapped
by steel cords that hold the tire onto the
rim.
Cold tire inflation pressure
Tire inflation pressure when your vehicle
has been sitting for at least 3 hours or driv-
en no more than 1 mile (1.6 km).
Curb weight
The weight of a motor vehicle with stan-
dard equipment including the maximum
capacity of fuel, oil, and coolant, and, if so
equipped, air conditioning and additional
optional equipment, but without passen-
gers and cargo.DOT (D
epartment o
f T
ransportation)
A tire branding symbol which denotes the
tire meets requirements of the
U.S. Department of Transportation.
GAWR (G
ross A
xle W
eight R
ating)
The GAWR is the maximum permissible
axle weight. The gross vehicle weight on
each axle must never exceed the GAWR for
the front and rear axle indicated on the
Certification label located on the driver’s
door B-pillar.
GVW (G
ross V
ehicle W
eight)
The GVW comprises the weight of the
vehicle including fuel, tools, spare wheel,
installed accessories, passengers and
cargo and, if applicable, trailer tongue
load. The GVW must never exceed the
GVWR indicated on the Certification label
located on the driver’s door B-pillar.

534 OperationVehicle careCleaning and care of vehicle
While in operation, even while parked, your
vehicle is subjected to varying external in-
fluences which, if gone unchecked, can at-
tack the paintwork as well as the vehicle
underbody and cause lasting damage.Such damage is caused not only by ex-
treme and varying climatic conditions, but
also by:


Air pollution


Road salt


Tar


Gravel and stone chipping
To avoid paint damage, you should imme-
diately remove:


Grease and oil


Fuel


Coolant


Brake fluid


Bird droppings


Insects


Tree resins, etc.
Frequent washing reduces and/or elimi-
nates the aggressiveness and potency of
the above adverse influences.More frequent washings are necessary to
deal with unfavorable conditions:


near the ocean


in industrial areas (smoke, exhaust
emissions)


during winter operation
You should check your vehicle from time to
time for stone chipping or other damage.
Any damage should be repaired as soon as
possible to prevent corrosion.
In doing so, do not neglect the underbody
of the vehicle. A prerequisite for a thor-
ough check is a washing of the underbody
followed by a thorough inspection. Dam-
aged areas need to be re-undercoated.
Your vehicle has been treated at the facto-
ry with a wax-base rustproofing in the body
cavities which will last for the lifetime of
the vehicle. Post-production treatment is
neither necessary nor recommended by
Mercedes-Benz because of the possibility
of incompatibility between materials used
in the production process and others ap-
plied later.
Warning!
G
Many cleaning products can be hazardous.
Some are poisonous, others are flammable.
Always follow the instructions on the partic-
ular container. Always open your vehicle’s
doors or windows when cleaning the inside.
Never use fluids or solvents that are not de-
signed for cleaning your vehicle.
Always lock away cleaning products and
keep them out of reach of children.

540 OperationVehicle careCleaning the windows and the wiper
blades
Make sure the hood is fully closed.

Place wiper arms in vertical position
(page 627).

Make sure the vehicle’s on-board elec-
tronics have status 0 (
page 315).

Fold the wiper arms forward until they
snap into place.

Clean the wiper blade inserts with a
clean cloth and detergent solution.

Use a soft, clean cloth and a mild win-
dow cleaning solution on all outside
and inside glass surfaces.
An automotive glass cleaner is recom-
mended.
!
If the windshield wipers leave smears on the
windshield after the vehicle has been driven
through an automatic car wash, wax or other res-
idue is on the windshield. Clean the windshield
with washer fluid shortly after cleaning the car in
an automatic car wash (
page 352).
!
The windshield wipers must be in a vertical
position before folding them away from the wind-
shield. They could otherwise damage the hood.
Never open the hood when the wiper arms are
folded forward.
Warning!
G
For safety reasons, switch off wipers and re-
move SmartKey from starter switch (vehi-
cles with KEYLESS-GO*: Make sure the
vehicle’s on-board electronics have
status0) before cleaning the windshield
and/or the wiper blades. Otherwise, the
wiper motor could suddenly turn on and
cause injury.!
While doing so, only touch the wiper arm so
as not to damage the wiper blade inserts.
!
Fold the windshield wiper arms back onto
the windshield before turning the SmartKey in
the starter switch or pressing the KEYLESS-GO*
start/stop button (vehicles with KEYLESS-GO*).
Hold on to the wiper when folding the wiper arm
back. If released, the force of the impact from
the tensioning spring could crack the windshield.
!
To clean the window interior, do not use a
dry cloth, abrasives, solvents or cleaners con-
taining solvents. Do not touch the inside of the
front, rear or side windows with hard objects
such as an ice scraper or ring. Doing so may
damage the windows.

627 Practical hints
Replacing wiper blades
Replacing wiper blades
Placing wiper arms in vertical positionWiper blades in vertical positionVehicles with SmartKey
Turn SmartKey in starter switch
position1.

Turn combination switch to wiper
settingu (
page 351).

With wiper arm in vertical position, turn
the SmartKey in starter switch to
position0.
Warning!
G
For safety reasons, switch off wipers and re-
move SmartKey from starter switch (vehi-
cles with KEYLESS-GO*: Make sure the
vehicle’s on-board electronics have
status0) before replacing a wiper blade.
Otherwise, the wiper motor could suddenly
turn on and cause injury. Warning!
G
Wiper blades are components that are sub-
ject to wear and tear. Change the wiper
blades twice a year, preferably in the spring
and fall. Otherwise the windows will not be
properly wiped. As a result, you may not be
able to observe surrounding traffic condi-
tions and could cause an accident.
!
To avoid damage to the hood:


The wiper arms should only be folded for-
ward when in the vertical position.


Never open the hood when the wiper arm is
folded forward.
!
Hold on to the wiper when folding the wiper
arm back. If released, the force of the impact
from the tensioning spring could crack the wind-
shield.
Do not allow the wiper arms to contact the wind-
shield glass without a wiper blade inserted.
Make certain that the wiper blades are properly
installed. Improperly installed wiper blades may
cause windshield damage.
For your convenience, we recommend that you
have this work carried out by an authorized
Mercedes-Benz Center.

693 Index
Power folding exterior rear view
mirrors 333
Power outlet 458
Power tilt/sliding sunroof 441
Emergency operations 617
Opening/closing 441
Opening/closing in an
emergency 617
Synchronizing 442
Power train 676
Power washer 535
Power windows 353
Blocking of rear window operation 67
Cleaning 540
Opening/closing 353
Practical hints 557, 611
Premium unleaded gasoline 490, 662,
664
PRE-SAFE
®
60
Message in display 567
Messages in display 572
Preventive occupant safety see PRE-SAFE
®
Problems
While driving 362
With vehicle 20
Product information 13Production options weight 527
Program mode see Automatic transmis-
sion, Automatic shift program
Program mode selector switch 676
Automatic shift program 374
Proper use of the vehicle 19
PSI 527
Push-start see Tow-start
R
Radio
FM/AM operation (COMAND) 93
Saving stations, FM/AM
(COMAND) 96
Selecting satellite radio* channel (In-
strument cluster control
system) 248
Selecting stations 248
Submenu overview, FM/AM
(COMAND) 93
Switching wavebands, FM/AM
(COMAND) 94
Tuning in stations/channels 94
Voice Control* 282
Radio transmitters, control and
operation 486Range (distance to empty) 246
Reading lamps in the front 349
Reading lamps in the rear 350
Rear door window
Blocking operation 67
Rear fog lamp
Replacing bulbs 622
Rear lamps see Tail lamps
Rear passenger compartment
Adjustable air vents 434
Rear seats
Adjustment 318
Folding back and placing upright rear
head restraints 325
Head restraints 324
Heating* 322
Multicontour* 327
Setting front passenger seat position
from rear 321
Ventilation* 323
Rear view mirrors see Mirrors
Rear window defroster 430
Activating 430
Deactivating 430
Recommended inflation pressure 527,
676

696 IndexShelf below rear window, Cleaning and
care of 542
Shift program mode, Automatic
transmission 374
Shifting, Automatic transmission 367
Side impact air bags 49
Side marker lamps
Cleaning lenses 537
Messages in display 599
Side windows see Power windows
Sidewall 527, 677
Sirius satellite radio* (COMAND) 98
SmartKey see Key, SmartKey
SmartKey with KEYLESS-GO* see Key,
SmartKey with KEYLESS-GO*
SMS messages 137
Snow chains 531
Spare fuses 646
Spare wheel see Minispare wheel
Speed
Setting current 381
Setting to last stored speed in DIS-
TRONIC Plus* (“Resume”
function) 395Speed settings
Cruise control 383
DISTRONIC Plus* 393, 394
To last stored speed (“Resume” func-
tion) in Cruise control 384
Speedometer
Displays 387
SRS 57, 677
Indicator lamp 552
Messages in display 605
Standing water, Driving through 485
Starter battery 636
Starter switch 315
Positions 315
Starting difficulties, Engine 360
Starting, Engine 359
Steering column 330
Steering wheel
Adjustment 330
Cleaning 542
Easy entry/exit feature 328
Heated steering wheel* 331
Power steering fluid 661
Steering wheel gearshift control
Automatic transmission 375Stolen Vehicle Recovery services 469
Storage compartments 448
Cup holder 452
Front armrest 448
Parcel net 449
Rear armrest 450
Ruffled storage pockets 451
Storage compartment in front of
armrest 448
Under the front seats 449
Storing tires 502
Summer opening feature 355
Sun visors 455
Sunroof see Power tilt/sliding sunroof
Sunshades
Extending or retracting rear window
sunshade (COMAND) 227
Extending/retracting rear window
sunshade 456
Opening or closing rear side window
sunshades 355
Supplemental Restraint System see SRS
Suspension tuning
Setting (ABC*) 403
