2007 MERCEDES-BENZ S CLASS engine

629 Practical hints
Flat tire
Flat tire
Preparing the vehicle
Park the vehicle in a safe distance from
moving traffic on a hard, flat surface
when possible.

Turn on the hazard warning flashers.

Turn the steering wheel so that the
front wheels are in a straight ahead
position.

Shift the automatic transmission toP.

Turn off the engine (
page 365).

Remove the SmartKey from the starter
switch.
Vehicles with SmartKey with
KEYLESS-GO*:
Turn off the engine by pressing the
KEYLESS-GO* button once
(page 366).

Open the driver’s door (this puts
the starter switch in position0,
same as with the SmartKey re-
moved from the starter switch). The
driver’s door then can be closed
again.

Have any passenger exit the vehicle at
a safe distance from the roadway.
Mounting the Minispare wheel
i
Open the door only when conditions are safe
to do so.
Warning!
G
The dimensions of the Minispare wheel are
different from those of the road wheels. As
a result, the vehicle handling characteristics
change when driving with a Minispare wheel
mounted. Adapt your driving style accord-
ingly.
The Minispare wheel is for temporary use
only. When driving with Minispare wheel
mounted, ensure proper tire inflation
pressure and do not exceed a vehicle speed
of 50 mph (80 km/h).
Drive to the nearest Mercedes-Benz Center
as soon as possible to have the Minispare
wheel replaced with a regular road wheel.
Never operate the vehicle with more than
one Minispare wheel mounted.
Do not switch off the ESP
® when a Minis-
pare wheel is mounted.

631 Practical hints
Flat tire
1Jack take-up bracket
2Jack
3Crank
Place jack2 on firm ground.

Position jack2 under take-up
bracket1 so that it is always vertical
(plumb-line) as seen from the side,
even if the vehicle is parked on an
incline.

Jack up the vehicle until the wheel is a
maximum of 1.2 in (3 cm) from the
ground. Never start engine while
vehicle is raised.Removing the wheel
1Alignment bolt

Unscrew upper-most wheel bolt and re-
move.
Warning!
G
Position the jack only on the jack take-up
brackets designed for this purpose.
If the jack is not properly positioned, the ve-
hicle may slip off of the jack.
Warning!
G
The jack is intended only for lifting the
vehicle briefly for wheel changes. It is not
suited for performing maintenance work
under the vehicle.

Never start the engine when the vehicle
is raised.


Never lie down under the raised vehicle.


636 Practical hintsBatteries
Starter battery (example illustration from
S550)1Negative terminal
2Positive terminal
Disconnecting starter battery
Do not rub the battery with rags or cloths.
The battery could explode if touched due to
electrostatic charge or due to spark forma-
tion.!
Switch off the engine and switch off the ve-
hicle’s internal electrical functions (
page 637)
before you disconnect or remove the battery’s
terminal clamps. You could otherwise destroy
electronic assemblies such as the generator.
Have the battery checked regularly by an autho-
rized Mercedes-Benz Center. Refer to Mainte-
nance Booklet for maintenance intervals or
contact an authorized Mercedes-Benz Center for
further information.
!
Do not connect any consumers directly to
the starter battery. The starter battery will other-
wise be discharged.
i
Only replace a discharged battery with a bat-
tery recommended by Mercedes-Benz. The con-
sumer battery is installed in the trunk in such a
way that it is safeguarded as much as possible
against mechanical destruction in the event of
an accident.
i
Remove SmartKey from starter switch (vehi-
cles with KEYLESS-GO*: Make sure the vehicle’s
on-board electronics have status 0)
(
page 315) when you turn off the engine and
no longer require any electrical consumers. The
vehicle then uses very little power and the con-
sumer battery is spared.
i
If the consumer battery is discharged, you
must use the mechanical key to unlock the vehi-
cle (page 614). Since the vehicle has a sepa-
rate starter battery, however, you can still start
the vehicle.
!
Always disconnect the starter battery in the
order described below. You could otherwise
damage the vehicle’s electronics.
!
Switch off the vehicle’s internal electrical
functions before disconnecting the starter bat-
tery. If the vehicle is stationary for more than one
hour with the SmartKey removed, you do not
need to switch off the vehicle’s internal electrical
functions.


638 Practical hintsBatteriesStarter battery
Connect the switched-off charging de-
vice to the terminals of the starter bat-
tery. Observe the operating
instructions in the manual for the
charging device while doing so.
Reinstalling starter battery
Install starter battery in engine com-
partment.

Swing retaining bar down.
Reconnecting starter battery

Make sure that the consumer battery in
the trunk is correctly installed and con-
nected.

Turn SmartKey in starter switch to po-
sition 0 and remove.

Connect the positive lead and fasten its
cover2 (
page 636).

Connect negative lead1
(page 636).

Attach ventilation tube.

Switch on the ignition (
page 315).

Start the engine (
page 359).

Check vehicle functions.
!
Only use charging devices with a maximum
charging voltage of 14.8 V.
Warning!
G
During the charge procedure, there is a risk
of acid burns due to gases escaping from
the battery. Do not bend over the battery
during the charge procedure.
!
The battery and the battery ventilation hose
must always be securely installed when the vehi-
cle is in operation.
!
Always connect the starter battery in the or-
der described below. Otherwise, the vehicle’s
electronics could be damaged.
Warning!
G
Do not drive without a properly installed and
connected consumer battery.
Have any work on the consumer battery car-
ried out by an authorized Mercedes-Benz
Center.
!
Never invert the terminal connections.
!
Make sure that the battery has a plug where
the ventilation tube is attached to it.

639 Practical hints
Jump starting
Jump starting
If the starter battery is discharged, the en-
gine can be started with jumper cables and
the battery of another vehicle. Observe the
following:

Jump starting should only be performed
when the engine and catalytic convert-
er are cold.


Do not start the engine if the battery is
frozen. Let the battery thaw out first.


Only use 12-volt battery to jump start
y o ur ve h i c l e . J u m p s t a r t i n g w i t h a m o r e
powerful battery could damage the ve-
hicle’s electrical system, which will not
be covered by the Mercedes-Benz Lim-
ited Warranty.


Only use jumper cables with sufficient
cross-section and insulated terminal
clamps.


Always make sure that the jumper ca-
bles are not on or near pulleys, fans or
other parts that move when an engine
is started or running.
Warning!
G
Failure to follow these directions will cause
damage to the electronic components, and
can lead to a battery explosion and severe
injury or death.
Never lean over batteries while connecting
or jump starting, you might get injured.
Battery fluid contains sulfuric acid. Do not
allow this fluid to come in contact with eyes,
skin or clothing. In case it does, immediately
flush affected area with water, and seek
medical help if necessary.
A battery will also produce hydrogen gas,
which is flammable and very explosive. Keep
flames or sparks away from battery, avoid
improper connection of jumper cables,
smoking, etc.
Attempting to jump start a frozen battery
can result in it exploding, causing personal
injury.
Read all instructions before proceeding.
!
Do not tow-start the vehicle.
!
Jump starting should only be performed on
the starter battery installed in the engine com-
partment.
Avoid repeated and lengthy starting attempts.
Do not attempt to start the engine using a bat-
tery quick charge unit.
If engine does not run after several unsuccessful
starting attempts, have it checked at the nearest
authorized Mercedes-Benz Center.
Excessive unburned fuel generated by repeated
failed starting attempts may damage the catalyt-
ic converter and may present a fire risk.
Make sure the jumper cables do not have loose
or missing insulation.
Make sure the cable clamps do not touch any
other metal part while the other end is still at-
tached to a battery.

640 Practical hintsJump startingJump starting should only be performed on
the starter battery. The starter battery is
located in the engine compartment on the
passenger side (
page 634).

Make sure the two vehicles do not
touch.

Secure vehicle in place with electric
parking brake.

Shift the automatic transmission toP.

Turn off all electrical consumers, ex-
cept hazard warning flashers or work
lights.

Open the hood (
page 492).

Start the engine of the vehicle with the
charged battery and run at idle speed.1Positive terminal of your vehicle’s
battery
2Positive terminal of other vehicle’s
battery
3Negative terminal of other vehicle’s
battery
4Negative clamp
Warning!
G
Keep flames or sparks away from battery.
Do not smoke.
Observe all safety instructions and precau-
tions when handling automotive batteries
(page 634).
i
Vehicles with KEYLESS-GO: remove the
KEYLESS-GO button (
page 316) and use the
SmartKey with KEYLESS-GO like a normal
SmartKey.

641 Practical hints
Jump starting

Remove red cover from positive
terminal 1.

Connect positive terminal2 of the
charged battery with positive
terminal1 of the discharged battery
with the jumper cable. Clamp cable to
charged battery2 first.

Connect negative terminal3 of
charged battery to jumper cables and
attach other end4 to a suitable
ground point on the vehicle.

Get into vehicle and start engine within
30 seconds.
If the starting attempt does not suc-
ceed:
Turn the SmartKey in starter switch
to position 0.

Take out the SmartKey.

Turn off engine of donor vehicle, re-
start it and let it run at idle speed
for several minutes.

Disconnect the jumper cable during
this time.

Reconnect jumper cable as de-
scribed before.

Restart engine.

While the engine is running, switch off
several electrical consumers such as
the blower.

Disconnect jumper cables first from
ground point4 and negative
terminal3, then from positive
terminals1 and2.

Have the battery checked at the near-
est authorized Mercedes-Benz Center.
!
Never invert the terminal connections.

642 Practical hintsTowing the vehicleMercedes-Benz recommends that the vehi-
cle be transported with all wheels off the
ground using flatbed or appropriate wheel
lift/dolly equipment. This method is pref-
erable to other types of towing.
When circumstances do not permit the
recommended towing methods, the vehi-
cle may be towed with all wheels on the
ground or front wheels raised only so far as necessary to have the vehicle moved to a
safe location where the recommended
towing methods can be employed.!
Do not tow-start the vehicle.
!
Use flatbed or wheel lift/dolly equipment
with SmartKey in starter switch turned to posi-
tion 0.
Do not tow with sling-type equipment. Towing
with sling-type equipment over bumpy roads will
damage radiator and supports.
To prevent damage during transport, do not tie
down vehicle by its chassis or suspension parts.
Switch off the ESP
® (page 73), the tow-away
alarm (
page 76) and the automatic central
locking (page 313).
If the vehicle’s transmission is damaged, only
have it towed with the drive shaft disconnected.
!
Make sure that the electric parking brake is
released. If the electric parking brake is malfunc-
tioning, release it mechanically (
page 616).
!
In vehicles with KEYLESS-GO, insert the
SmartKey into the starter switch under the
KEYLESS-GO button and turn the SmartKey in
the starter switch to 0.
!
If the vehicle is towed with the front axle
raised, the engine must be shut off (SmartKey in
starter switch starter switch position 0 or 1).
Otherwise the ESP
®/ETS will immediately be en-
gaged and will apply the rear wheel brakes.
While towing, the battery must be connected and
charged. Otherwise:


you will not be able to switch on the ignition


you will not be able to engage the automatic
transmission in position N
When towing the vehicle with all wheels on the
ground, the automatic transmission must be
shifted to N and the SmartKey must be in starter
switch position2.
In vehicles with KEYLESS-GO*, you must use the
starter switch under the KEYLESS-GO* button
(
page 315).
When towing the vehicle with all wheels on the
ground or the front axle raised, the vehicle may
be towed only for distances up to 30 miles
(50 km) and at a speed not to exceed 30 mph
(50 km/h).
!
To be certain to avoid a possibility of dam-
age to the drivetrain, however, we recommend
the drive shaft be disconnected at the rear axle
drive flange for any towing beyond a short tow to
a nearby garage.
