469 Practical hints
Where will I find ...?
Where will I find ...?
First aid kit
The first aid kit is located on the driver’s
side in the cargo compartment behind the
cover.
1Cover in left side trim panel
2Lock
Turn lock2 90°.

Fold down cover1.
The first aid kit can be removed.
Vehicle tool kit
The vehicle tool kit is stored under the
cargo compartment floor.
The vehicle tool kit includes:

Towing eye bolt


Wheel wrench


Alignment bolt


Vehicle jack


Fuse chart


Spare fuses


Fuse extractor


Collapsible wheel chock


Wheel bolts for spare wheel1Cargo compartment floor, lowered
2Handle cover

Open the tailgate (
page 119).

Push in handle cover2 and pull han-
dle in direction of arrow.

Lift cargo compartment floor1.
i
Check expiration dates and contents for
completeness at least once a year and replace
missing/expired items.


470 Practical hintsWhere will I find ...?3Securing hook
Release securing hook3 (located be-
low the floor handle) from holder.3Securing hook
4Cargo compartment floor, raised
5Upper cargo compartment lip

Engage securing hook3 on upper
cargo compartment lip5.

Remove the Minispare wheel
(page 473).
orML 63 AMG:

Remove the collapsible tire
(page 474).
You can now access the vehicle tool kit.
6Wheel bolt wrench
7Vehicle jack
8Collapsible wheel chock
9Spare fuses, fuse chart, fuse extractor
aTowing eye bolt
bAlignment bolt
cSpare wheel bolts
!
With the cargo compartment cover blind
installed behind the rear seats (
page 286),
disengage cargo compartment cover blind and
flip it forward. Otherwise the strap of the
securing hook could damage the cargo compart-
ment cover blind.


473 Practical hints
Where will I find ...?
Minispare wheel (except ML 63 AMG)The Minispare wheel is located underneath
the cargo compartment floor
(
page 469).
Removing Minispare wheel
1Minispare wheel
2Towing eye bolt
3Alignment bolt
4Retaining screw
5Wheel bolt wrenchFor access the minispare wheel, see “Vehi-
cle tool kit” (
page 469).

Loosen retaining screw2 by turning it
counterclockwise.

Remove Minispare wheel1.
Warning!
G
The dimensions of the Minispare wheel are
different from those of the road wheels. As
a result, the vehicle handling characteristics
change when driving with a Minispare wheel
mounted. Adapt your driving style accord-
ingly.
The Minispare wheel is for temporary use
only. When driving with a Minispare wheel
mounted, ensure proper tire inflation
pressure and do not exceed a vehicle speed
of 50 mph (80 km/h).
Drive to the nearest Mercedes-Benz Light
Truck Center as soon as possible to have the
Minispare wheel replaced with a regular
road wheel.
Never operate the vehicle with more than
one spare wheel mounted.
Do not switch off the ESP
® when a
Minispare wheel is mounted.
i
For information on how to mount the
Minispare wheel, see “Mounting the spare
wheel” (
page 498).
i
Remove Minispare wheel to gain access to
remaining tools in the vehicle tool kit
(
page 469).

474 Practical hintsWhere will I find ...?Collapsible tire (ML 63 AMG only)The collapsible tire is located underneath
the cargo compartment floor
(
page 469).
Removing the collapsible tire
1Electric air pump
2Collapsible tire
3Vehicle tool kit storage well casing
4Alignment bolt
5Towing eye bolt
6Wheel bolt wrenchFor access the collapsible tire, see “Vehi-
cle tool kit” (
page 469).

Remove the vehicle tool kit storage
well casing3.
7Retaining screw

Loosen retaining screw7 by turning it
counterclockwise.

Remove collapsible tire2.
Warning!
G
The dimensions of the collapsible tire are
different from those of the road wheels. As
a result, the vehicle handling characteristics
change when driving with a collapsible tire
mounted. Adapt your driving style accord-
ingly.
The collapsible tire is for temporary use
only. When driving with a collapsible tire
mounted, ensure proper tire inflation
pressure and do not exceed a vehicle speed
of 50 mph (80 km/h).
Drive to the nearest Mercedes-Benz Light
Truck Center as soon as possible to have the
collapsible tire replaced with a regular road
wheel.
Never operate the vehicle with more than
one collapsible tire mounted.
Do not switch off the ESP
® when a
collapsible tire is mounted.
i
For information on how to mount the
collapsible tire, see “Mounting the spare wheel”
(
page 498).
i
Remove collapsible tire to gain access to
remaining tools in the vehicle tool kit
(
page 469).

500 Practical hintsFlat tire
Position jack3 under the take-up
bracket2 so that it is always vertical
(plumb-line) as seen from the side,
even if the vehicle is parked on an in-
cline.

Turn crank4 clockwise until jack3
is fully seated in take-up bracket2
and the jack base evenly meets the
ground.

Continue to turn crank4 until the
wheel is a maximum of 1.2 in (3 cm)
from the ground.Removing the wheel
1Alignment bolt

Unscrew upper-most wheel bolt and
remove it.

Replace this wheel bolt with alignment
bolt1 supplied with the tool kit
(page 469).

Remove the remaining bolts.

Remove the wheel.
Warning!
G
The jack is intended only for lifting the
vehicle briefly for wheel changes. It is not
suited for performing maintenance work
under the vehicle.

Never start the engine when the vehicle
is raised.


Never lie down under the raised vehicle.
!
Do not place wheel bolts in sand or dirt. This
could result in damage to the bolts and wheel
hub threads.


501 Practical hints
Flat tire
Mounting the new wheel
1Wheel bolt for 18", 19" and 20" light
alloy wheels and collapsible tire (AMG
vehicles)
2Wheel bolt for 17" light alloy wheels or
Minispare wheel (located in vehicle tool
kit (
page 469))

Clean contact surfaces of wheel and
wheel hub.

Guide spare wheel onto the alignment
bolt and push it on the wheel hub.

Insert wheel bolts and tighten them
slightly.

Unscrew the alignment bolt.

Insert the remaining wheel bolt and
tighten it slightly.
!
Wheel bolts2 must be used when mount-
ing 17" light alloy rims or the Minispare wheel.
The use of any wheel bolts other than wheel
bolts2 for 17" light alloy rims or the Minispare
wheel will damage the vehicle’s brakes.
!
To avoid paint damage, place wheel flat
against hub and hold it there while installing first
wheel bolt.
Warning!
G
Always replace wheel bolts that are
damaged or rusted.
Never apply oil or grease to wheel bolts.
Damaged wheel hub threads should be
repaired immediately. Do not continue to
drive under these circumstances! Contact
an authorized Mercedes-Benz Light Truck
Center or call Roadside Assistance.
Incorrect wheel bolts or improperly tight-
ened wheel bolts can cause the wheel to
come off. This could cause an accident.
Make sure to use the correct wheel bolts.

521 Practical hints
Towing the vehicle
Installing towing eye bolt
Take the towing eye bolt and wheel bolt
wrench from the vehicle tool kit
(page 469).

Screw towing eye bolt in clockwise to
its stop and tighten with wheel wrench.
Removing towing eye bolt

Loosen towing eye bolt counterclock-
wise with wheel wrench.

Unscrew towing eye bolt.

Store the towing eye bolt and wheel
bolt wrench back into the vehicle tool
kit (
page 469).
Installing cover

Engage cover1 at top and press at
bottom.
Stranded vehicle
Freeing a stranded vehicle, on which the
wheels are dug into sand or mud, should
be done with the greatest of care, especial-
ly if the vehicle is heavily loaded.
Avoid pulling the vehicle abruptly or diago-
nally, since it could result in damage to the
chassis alignment.
Never try to free a vehicle that is still cou-
pled to a trailer.
If possible, a vehicle equipped with trailer
hitch receiver should be pulled backward
in its own previously made tracks.
