2007 MERCEDES-BENZ ML320CDI Keyless go

Contents
Introduction.......................................... 9
Product information ................................ 9
Operator’s Manual ............................... 10
Service and warranty information .. 10
Important notice for California
retail buyers and lessees of
Mercedes-Benz automobiles .......... 11
Maintenance .................................. 12
Roadside Assistance ...................... 12
Change of address or ownership.... 13
Operating your vehicle
outside the USA or Canada ............ 13
Where to find it .................................... 15
Symbols ............................................... 16
Operating safety .................................. 17
Proper use of the vehicle ............... 17
Problems with your vehicle .................. 18
Reporting safety defects...................... 19
Reporting safety defects ................ 19
Vehicle data recording ......................... 20
Information regarding electronic
recording devices ........................... 20
At a glance.......................................... 21
Exterior view ......................................... 22
Cockpit ................................................. 24
Instrument cluster ................................ 26
Instrument cluster ................................ 28
Multifunction steering wheel ................ 30
Center console ..................................... 31
Upper part ...................................... 31
Lower part ...................................... 32
Overhead control panel ........................ 33
Storage compartments ......................... 34
Door control panel................................ 36
Getting started................................... 37
Unlocking ............................................. 38
Unlocking with the SmartKey ......... 38
Unlocking with KEYLESS-GO*......... 39
Starter switch positions .................. 39
Adjusting .............................................. 43
Seats .............................................. 43
Steering wheel ................................ 46
Mirrors ............................................ 49
Driving .................................................. 51
Fastening the seat belts ................. 51
Starting the engine ......................... 54
Parking brake ................................. 57
Driving off ....................................... 58
Switching on headlamps ................. 59
Turn signals .................................... 60
Windshield wipers ........................... 60
Rear window wiper/washer ............ 62
Problems while driving.................... 63
Parking and locking .............................. 65
Parking brake ................................. 65
Switching off headlamps................. 66
Turning off the engine..................... 66
Releasing seat belts........................ 67
Locking ........................................... 68

ContentsSafety and Security........................... 69
Occupant safety................................... 70
Air bags .......................................... 71
Seat belts ....................................... 77
Active head restraint ...................... 80
Rear head restraints ....................... 81
Children in the vehicle .................... 82
Blocking of rear door
window operation ........................... 93
Panic alarm .......................................... 95
Activating ....................................... 95
Deactivating ................................... 95
Driving safety systems ......................... 96
ABS ................................................ 96
BAS ................................................ 97
ESP
®............................................... 98
EBP............................................... 101
4-ETS ............................................ 102
Anti-theft systems.............................. 103
Immobilizer................................... 103
Anti-theft alarm system ................ 103
Controls in detail ............................. 107
Locking and unlocking ....................... 108
SmartKey ..................................... 108
SmartKey with KEYLESS-GO* ...... 112
Opening the doors
from the inside ............................. 118
Opening the tailgate ..................... 119
Closing the tailgate ...................... 121
Automatic central locking ............ 126
Locking and unlocking
from the inside ............................. 126
Seats ................................................. 128
Front seat active head restraints . 128
Rear seat head restraints ............. 128
Lumbar support............................ 130
Multicontour seat* ....................... 130
Seat heating* ............................... 131
Seat ventilation* .......................... 132Memory function* ............................. 134
Storing positions into memory ..... 135
Recalling positions from memory. 135
Lighting ............................................. 136
Exterior lamp switch .................... 136
Combination switch ..................... 140
Corner-illuminating
front fog lamps*........................... 140
Hazard warning flasher ................ 142
Interior lighting ............................ 142
Door entry lamps ......................... 144
Cargo compartment lamp ............ 144
Instrument cluster ............................. 145
Adjusting instrument
cluster illumination ...................... 145
Resetting trip odometer ............... 146
Tachometer.................................. 146
Outside temperature indicator ..... 146

39 Getting started
Unlocking
Unlocking with KEYLESS-GO*
With the KEYLESS-GO function, you can
lock or unlock the vehicle without using
the remote control buttons on the
SmartKey and start the engine without in-
serting the SmartKey into the starter
switch.

Grasp an outside door handle or the
tailgate handle.
All turn signal lamps flash once. The ve-
hicle unlocks. The locking knobs in the
doors move up. The anti-theft alarm
system is disarmed. The locator light-
ing comes on if the feature is enabled
in the control system (
page 172).

Enter the vehicle.
For more information, see “SmartKey with
KEYLESS-GO*” (
page 112).
Starter switch positions
i
To unlock the vehicle, the SmartKey with
KEYLESS-GO must be outside the vehicle, no
further than approximately 3 feet (1 meter) away
from the respective door.Warning!
G
When leaving the vehicle, always take the
SmartKey with KEYLESS-GO* with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.
i
If the vehicle has been parked for more than
72 hours, you must pull an outside door handle
in order to activate the KEYLESS-GO function.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment may cause an accident
and/or serious personal injury.

41 Getting started
Unlocking
SmartKey with KEYLESS-GO*
Vehicles equipped with the KEYLESS-GO
feature are supplied with a SmartKey with
integrated KEYLESS-GO function and a
removable KEYLESS-GO start/stop
button.
With the KEYLESS-GO start/stop button
inserted and the SmartKey with
KEYLESS-GO present in the vehicle, press-
ing the KEYLESS-GO start/stop button

without the brake pedal depressed
corresponds to the various starter
switch positions (
page 42)


with the brake pedal firmly depressed
will start the engine (
page 54)
If you wish or should there be a need to
insert the SmartKey with KEYLESS-GO in
the starter switch, the KEYLESS-GO
start/stop button can be easily removed
by pulling it out of the starter switch.1KEYLESS-GO start/stop button
2Starter switch
KEYLESS-GO start/stop button3USA only
4Canada only
The SmartKey with KEYLESS-GO must be
located in the vehicle.
Insert KEYLESS-GO start/stop
button1 into starter switch2 (if not
inserted already).

Make sure the automatic transmission
is set toP (
page 187).

Do not depress the brake pedal.
i
The KEYLESS-GO start/stop button does
not need to be removed from the starter switch
when you leave the vehicle. However, always
take the SmartKey with KEYLESS-GO with you
when you leave the vehicle. As long as the
SmartKey with KEYLESS-GO is in the vehicle, the
vehicle’s electrical systems can be switched on
or the engine can be started using the
KEYLESS-GO start/stop button.

42 Getting startedUnlockingPosition 0
Before you press the KEYLESS-GO
start/stop button, the vehicle’s on-board
electronics have status0 (as with
SmartKey removed).
Position 1
Press the KEYLESS-GO start/stop
button once.
This supplies power for some electrical
consumers, such as seat adjustment.Ignition (or Position 2)

Press the KEYLESS-GO start/stop
button twice.
This supplies power for all electrical
consumers.
All lamps (except high beam headlamp
indicator lamp and turn signal indicator
lamps unless activated) in the instru-
ment cluster come on. If a lamp in the
instrument cluster fails to come on
when the ignition is switched on, have
it checked and replaced if necessary. If
a lamp in the instrument cluster re-
mains on after starting the engine or
comes on while driving, refer to “Lamps
in instrument cluster” (
page 414).For information on starting the engine
using the KEYLESS-GO start/stop button,
see “Starting with KEYLESS-GO*”
(
page 55).
For more information on KEYLESS-GO, see
“SmartKey with KEYLESS-GO*”
(page 112).
i
If you now press the KEYLESS-GO
start/stop button


once more, the ignition (position
2) is
switched on


twice more, the power supply is again
switched off
i
If you now press the KEYLESS-GO
start/stop button once more, the power supply
is again switched off.
i
When you switch on the ignition, the
indicator and warning lamps (except high beam
headlamp indicator lamp and turn signal indica-
tor lamps unless activated) in the instrument
cluster come on. The indicator and warning
lamps (except high beam headlamp indicator
lamp and turn signal indicator lamps if activated)
should go out when the engine is running. This
indicates that the respective systems are
operational.

43 Getting started
Adjusting
Adjusting
SeatsWarning!
G
All seat, head restraint, steering wheel, and
rear view mirror adjustments, as well as fas-
tening of seat belts, must be done before
the vehicle is put into motion.Warning!
G
Do not adjust the driver’s seat while driving.
Adjusting the seat while driving could cause
the driver to lose control of the vehicle.
Never ride in a moving vehicle with the seat
backrest in an excessively reclined position
as this can be dangerous. You could slide
under the seat belt in a collision. If you slide
under it, the belt would apply force at the ab-
domen or neck. That could cause serious or
fatal injuries. The seat backrest and seat
belts provide the best restraint when the
wearer is in a nearly upright position and
belts are properly positioned on the body.
Your seat must be adjusted so that you can
correctly fasten your seat belt (
page 51).
Never place hands under the seat or near
any moving parts while a seat is being
adjusted.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle.
Even with the SmartKey or the SmartKey
with KEYLESS-GO* removed from the
starter switch or the SmartKey with
KEYLESS-GO* removed from the vehicle,
the power seats can be operated when the
respective door is open.
Therefore, do not leave children unattended
i n t h e v e h i c l e , o r w i t h a c c e s s t o a n u n l o c k e d
vehicle. Unsupervised use of vehicle equip-
ment may cause an accident and/or serious
personal injury.
Warning!
G
According to accident statistics, children
are safer when properly restrained in the
rear seating positions than in the front seat-
ing position. Thus, we strongly recommend
that children be placed in the rear seats
whenever possible. Regardless of seating
position, children 12 years old and under
must be seated and properly secured in an
appropriate infant, or toddler restraint, or
booster seat recommended for the size and
weight of the child. For additional
information, see “Children in the vehicle”
(page 82).
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints
are not properly secured in the vehicle
and/or the child is not properly secured in
the child restraint.

46 Getting startedAdjustingHead restraint fore and aft adjustment
Manually adjust the angle of the head
restraint.
While seated, reach behind you with
both hands and find lower edge of the
head restraint.

Adjust the head restraint to the desired
position by pushing or pulling on the
lower edge of the head restraint cush-
ion.
For more information, see “Seats”
(
page 128).
Steering wheel
Easy-entry/exit feature*
This feature allows for easier entry into and
exit from the vehicle. When entering and
exiting the vehicle, the steering wheel is in
its uppermost position.
The easy-entry/exit feature can be
activated or deactivated in the
Comfort

submenu of the control system
(
page 177).With the easy-entry/exit feature activated,
the steering wheel will return to its last set
position when you:


close the driver’s door with the ignition
switched on
or


insert the SmartKey into the starter
switch or press the KEYLESS-GO*
start/stop button (
page 41) once
with the driver’s door closed
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel when the easy-entry/exit feature is
activated.
To stop steering wheel movement, do one of
the following:

Move steering wheel adjustment stalk*
(page 49).


Press one of the memory position
buttons or the memory buttonM*
(page 135).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.

47 Getting started
Adjusting
With the easy-entry/exit feature activated,
the steering wheel tilts upwards when you:

remove the SmartKey from the starter
switch,
or


open the driver’s door with the
SmartKey in starter switch position0
or1 or the KEYLESS-GO* start/stop
button in position1 (
page 41)Steering wheel adjustment, manualMake sure that


you can reach the steering wheel with
your arms slightly bent at the elbows


you can move your legs freely


all displays (including malfunction and
indicator lamps) on the instrument
cluster are clearly visible
The steering wheel adjustment release
handle is located on the lower left of the
steering column.
i
The last set steering wheel position is stored
when


the ignition is switched off (
page 39)


the position is stored in memory
(page 135)
i
If the current position for the steering wheel
is in the uppermost tilt position, the steering
wheel will no longer be able to move upward
when the easy-entry/exit feature is activated.
The adjustment procedure is briefly interrupted,
when the engine is started.
Warning!
G
Let the system complete the adjustment
procedure before setting the vehicle in mo-
tion. All steering wheel adjustment must be
completed before setting the vehicle in mo-
tion. Driving off with the steering wheel still
adjusting could cause the driver to lose con-
trol of the vehicle.Warning!
G
Only adjust the steering wheel with the vehi-
cle at a standstill and make sure the steer-
ing wheel is securely locked in place before
driving off.
Driving without the steering wheel adjust-
ment locked may cause an unexpected
steering wheel movement which could
cause the driver to lose control of the vehi-
cle. Make sure the steering wheel is secure-
ly locked by trying to move it up and down,
and in and out before driving off.
