ContentsSafety and Security........................... 69
Occupant safety................................... 70
Air bags .......................................... 71
Seat belts ....................................... 77
Active head restraint ...................... 80
Rear head restraints ....................... 81
Children in the vehicle .................... 82
Blocking of rear door
window operation ........................... 93
Panic alarm .......................................... 95
Activating ....................................... 95
Deactivating ................................... 95
Driving safety systems ......................... 96
ABS ................................................ 96
BAS ................................................ 97
ESP
®............................................... 98
EBP............................................... 101
4-ETS ............................................ 102
Anti-theft systems.............................. 103
Immobilizer................................... 103
Anti-theft alarm system ................ 103
Controls in detail ............................. 107
Locking and unlocking ....................... 108
SmartKey ..................................... 108
SmartKey with KEYLESS-GO* ...... 112
Opening the doors
from the inside ............................. 118
Opening the tailgate ..................... 119
Closing the tailgate ...................... 121
Automatic central locking ............ 126
Locking and unlocking
from the inside ............................. 126
Seats ................................................. 128
Front seat active head restraints . 128
Rear seat head restraints ............. 128
Lumbar support............................ 130
Multicontour seat* ....................... 130
Seat heating* ............................... 131
Seat ventilation* .......................... 132Memory function* ............................. 134
Storing positions into memory ..... 135
Recalling positions from memory. 135
Lighting ............................................. 136
Exterior lamp switch .................... 136
Combination switch ..................... 140
Corner-illuminating
front fog lamps*........................... 140
Hazard warning flasher ................ 142
Interior lighting ............................ 142
Door entry lamps ......................... 144
Cargo compartment lamp ............ 144
Instrument cluster ............................. 145
Adjusting instrument
cluster illumination ...................... 145
Resetting trip odometer ............... 146
Tachometer.................................. 146
Outside temperature indicator ..... 146

136 Controls in detailLightingFor information on how to switch on the
headlamps and use the turn signals, see
“Switching on headlamps” (
page 59)
and “Turn signals” (
page 60).
Exterior lamp switchExterior lamp switchMOff
Daytime running lamp mode
(
page 138)
UAutomatic headlamp mode
Daytime running lamp mode
(page 137)
CParking lamps (also tail lamps,
license plate lamps, side marker
lamps, instrument panel lamps)BLow beam headlamps or high beam
headlamps when the combination
switch is pushed forward. The tail
lamps, license plate lamps, side
marker lamps, parking lamps and
instrument panel lamps also come
on.
ˆStanding lamps, right
(turn left one stop)
‚Standing lamps, left
(turn left two stops)
‡Indicator lamp for front fog lamps
†Indicator lamp for rear fog lamp
i
If you drive in countries where vehicles drive
on the other side of the road than the country in
which the vehicle is registered, you must have
the headlamps modified for symmetrical low
beams. Relevant information can be obtained at
any authorized Mercedes-Benz Light Truck
Center.
i
Vehicles equipped with active Bi-Xenon*
headlamps:
The active Bi-Xenon* headlamps monitor the
vehicles steering angle and vehicle speed, then
automatically shift their beams to either side to
better follow the curvature of the road ahead,
increasing usable illumination over conventional
headlamps.
i
If you hear a warning signal you have
forgotten to switch off the headlamps before
opening the driver’s door.
In addition the message
Switch off lights

appears in the multifunction display.
Switch off the headlamps.

137 Controls in detail
Lighting
Manual headlamp mode
The low beam headlamps and the parking
lamps can be switched on and off with the
exterior lamp switch.
Turn the exterior lamp switch to
positionB.
Automatic headlamp mode
The following lamps switch on and off au-
tomatically depending on the brightness of
the ambient light:


Low beam headlamps


Tail and parking lamps


License plate lamps


Side marker lamps

Turn the exterior lamp switch to
positionU.
With the SmartKey in starter switch
position1 or the KEYLESS-GO*
start/stop button pressed once, only
the parking lamps and the side marker
lamps will switch on and off automati-
cally.
When the engine is running, the low
beam headlamps, the tail and parking
lamps, the license plate lamps, and the
side marker lamps will switch on and
off automatically.
Warning!
G
If the exterior lamp switch is set toU,

the headlamps may switch off unexpect-
edly when the system senses bright
ambient light, for example light from
oncoming traffic


the headlamps will not be automatically
switched on under foggy conditions
To minimize risk to you and to others,
activate headlamps by turning exterior lamp
switch toB when driving or when traffic
and/or ambient lighting conditions require
you to do so.
In low ambient lighting conditions, only
switch from positionU toB with the
vehicle at a standstill in a safe location.
Switching fromUtoB will briefly
switch off the headlamps. Doing so while
driving in low ambient lighting conditions
may result in an accident.
The automatic headlamp feature is only an
aid to the driver. The driver is responsible for
the operation of the vehicle’s lights at all
times.

139 Controls in detail
Lighting
Locator lighting and night security
illumination
The locator lighting and the night security
illumination are described in the “Control
system” section, see “Setting locator light-
ing” (
page 172) and “Setting night secu-
rity illumination” (
page 172).
Fog lampsFront fog lamps

Switch on the low beam
headlampsB (
page 136).

Pull out the exterior lamp switch to first
stop.
The front fog lamps switch on.
The green indicator lamp‡ in the
exterior lamp switch comes on
(page 136).

Push in the exterior lamp switch.
The front fog lamps switch off.
The green indicator lamp‡ in the
exterior lamp switch goes out.
Rear fog lamp (driver’s side only)

Switch on the low beam
headlampsB (
page 136).

Pull out the exterior lamp switch to
second stop.
The rear fog lamp switches on.
The yellow indicator lamp† in the
exterior lamp switch comes on
(page 136).

Push in the exterior lamp switch to first
stop.
The rear fog lamp switches off.
The yellow indicator lamp† in the
exterior lamp switch goes out.
The front fog lamps remain lit.
Warning!
G
In low ambient lighting or foggy conditions,
only switch from positionU toB with
the vehicle at a standstill in a safe location.
Switching fromU toB will briefly
switch off the headlamps. Doing so while
driving in low ambient lighting conditions
may result in an accident.i
Fog lamps will operate with the parking
lamps and/or the low beam headlamps on. Fog
lamps should only be used in conjunction with
low beam headlamps. Consult your State or
Province Motor Vehicle Regulations regarding
permissible lamp operation.
i
Fog lamps cannot be switched on with the
exterior lamp switch in positionU.
To switch on the fog lamps, turn the exterior
lamp switch to positionB first.

140 Controls in detailLightingCombination switch
1High beam
2High beam flasher
High beam
Canada only: Turn the exterior lamp
switch to positionB (
page 136).
or

USA only: Turn the exterior lamp switch
to positionB orU
(page 136).

Push the combination switch in
direction of arrow1 to switch on the
high beam.
The high beam headlamp indicator
lampA in the instrument cluster
comes on (
page 26).

Pull the combination switch in direction
of arrow2 to its original position to
switch off the high beam.
The high beam headlamp indicator
lampA in the instrument cluster
goes out.
High beam flasher

Pull the combination switch briefly in
direction of arrow2.
Corner-illuminating front fog lamps*
The corner-illuminating front fog lamps im-
prove illumination of the area in the direc-
tion into which you are turning.
The corner-illuminating front fog lamps will
operate with the engine running and with

the exterior lamp switch in
positionB (
page 136)
or


the exterior lamp switch in
positionU (
page 136)
or


the daytime running lamp mode
activated (
page 138)
i
The corner-illuminating front fog lamps will
only come on in low ambient lighting conditions.
If you are driving faster than 25 mph (40 km/h)
or have the front fog lamps switched on, the
corner-illuminating function is not available.

141 Controls in detail
Lighting
Driving forward
Switching on corner-illuminating front
fog lamps
Switch on the left or right turn signal
(page 60), depending on whether
you are turning left or right.
The respective front fog lamp comes on
and illuminates the area in the direc-
tion into which you are turning.
or

Turn steering wheel in desired direc-
tion.
The front fog lamp on the side of your
steering direction comes on.Switching off corner-illuminating front
fog lamps
The combination switch for the turn signal
resets automatically after major steering
wheel movements. This will switch off the
corner-illuminating front fog lamps if they
were activated by switching on the left or
right turn signal.
If the turn signal should stay on after
making the turn, the turn signal and the
corner-illuminating front fog lamps can be
switched off by returning the combination
switch to its original position.Driving rearward
Switching on corner-illuminating front
fog lamps

Shift the automatic transmission to
reverse gearR (
page 187).
The corner-illuminating front fog lamp
opposite to your steering direction
comes on.
Switching off corner-illuminating front
fog lamps

Shift the automatic transmission to a
gear other than reverse gearR
(page 187).
The respective corner-illuminating
front fog lamp goes out.
i
The corner-illuminating front fog lamps
temporarily come on on both sides of the vehicle
if you turn the steering wheel in one direction
and then again in the other direction shortly
thereafter.
i
The corner-illuminating front fog lamps will
come on automatically depending on the steer-
ing angle and vehicle speed, even if you did not
switch on either turn signal. If the
corner-illuminating front fog lamps came on
automatically, they will also go out automatically
depending on the steering angle and vehicle
speed.
i
There may be a brief delay before the
corner-illuminating front fog lamps switch off.

172 Controls in detailControl systemSetting locator lighting
With the locator lighting feature activated,
the exterior lamp switch in positionU
(page 136) and the interior lighting in
automatic mode (
page 143), the follow-
ing lamps will switch on during darkness
when the vehicle is unlocked using
buttonΠon the SmartKey or SmartKey
with KEYLESS-GO:


Parking lamps


Tail lamps


License plate lamps


Side marker lamps


Front fog lamps*
The locator lighting switches off when the
driver’s door is opened.
If you do not open a door after unlocking
the vehicle with the SmartKey, the lamps
will switch off automatically after
approximately 40 seconds.

Move the selection marker with
buttonæ orç to the
Lighting

submenu.

Press buttonj ork repeatedly
until the message
Function Surround
lighting
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to switch
the locator lighting function
On or
Off
.

Turn the exterior lamp switch to
positionU when exiting the vehicle.
The locator lighting feature is
activated.Setting night security illumination
(Headlamps delayed shut-off)
Use this function to set whether you would
like the exterior lamps to remain on for
15 seconds during darkness after exiting
the vehicle and closing all doors.
With the headlamps delayed shut-off
feature activated and the exterior lamp
switch in positionU before the engine
is turned off, the following lamps will
switch on when the engine is turned off:


Parking lamps


Tail lamps


License plate lamps


Side marker lamps


Front fog lamps*
If after turning off the engine you do not
open a door or do not close an opened
door, the lamps will automatically switch
off after 60 seconds.

216 Controls in detailClimate controlAir conditioning
The air conditioning is operational while
the engine is running and cools the interior
air to the temperature set by the operator.
In addition, the air conditioning dehumidi-
fies the interior air at outside temperatures
above 41°F (5° C) and helps prevent
window fogging.Deactivating
It is possible to deactivate the air condi-
tioning (cooling) function of the climate
control system. The air in the vehicle will
then no longer be cooled or dehumidified.

Press button9 (
page 208).
The indicator lamp on the button goes
out.
Activating
Moist air can fog up the windows. You can
dehumidify the air with the air condition-
ing.

Press button9 (
page 208) again.
The indicator lamp on the button
comes on.
The air conditioning uses the refrigerant
R134a. This refrigerant is free of CFCs
which are harmful to the ozone layer.
Residual heat and ventilation
With the engine switched off, it is possible
to continue to heat or ventilate the interior
for up to 30 minutes. This feature makes
use of the residual heat produced by the
engine.
i
Condensation may drip out from underneath
the vehicle. This is normal and not an indication
of a malfunction.Warning!
G
If you turn off the cooling function, the
interior air is not dried. The windows can fog
up more quickly. Window fogging may
impair visibility and endanger you and
others.
!
If the air conditioning cannot be turned on
again, this indicates that the air conditioning is
losing refrigerant. The compressor has turned
off.
Have the air conditioning checked at the nearest
authorized Mercedes-Benz Light Truck Center.
i
How long the system will provide heating
depends on


the coolant temperature


the battery voltage
Regardless of the temperature and air volume
set on the climate control panel, the interior tem-
perature is set to 72°F (22°C) and the blower
runs on low speed to protect the vehicle battery.
