2007 MERCEDES-BENZ E63AMG WAGON CD player

155 Controls in detail
Control system
Control system
The control system is activated as soon as
the SmartKey in the starter switch is
turned to position1 or as soon as the
KEYLESS-GO start/stop button* is in
position1. The control system enables you
to:

call up information about your vehicle


change vehicle settings
For example, you can use the control sys-
tem to find out when your vehicle is next
due for service, to set the language for
messages in the instrument cluster dis-
play, and much more.
The control system relays information to
the multifunction display.
Multifunction display
1Outside temperature
2Trip odometer
3Automatic transmission program mode
4Main odometer
5Current gear selector lever position
Above illustration shows the standard dis-
play.
For more information on menus displayed
in the multifunction display, see “Menus”
(page 158).
i
The displays for the audio systems (radio,
CD player) will appear in English, regardless of
the language selected.
Warning!
G
A driver’s attention to the road and traffic
conditions must always be his / her primary
focus when driving.
For your safety and the safety of others, se-
lecting features through the multifunction
steering wheel should only be done by the
driver when traffic and road conditions per-
mit it to be done safely.
Bear in mind that at a speed of just 30 mph
(approximately 50 km / h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.

159 Controls in detail
Control system
Menus, submenus and functions
Menu1
Menu2
Menu3
Menu4
Menu5
Standard display
AMG
1
1AMG vehicles only.
AUDIO
NAV*
Distronic*
(page 161)
(page 161)
(page 165)
(page 167)
(page 167)
Commands/submenusDigital speedometer
Engine oil temperature
Selecting radio station
Show route guidance in-
structions, current direc-
tion traveled
Calling up settings
Calling up maintenance
system display
Vehicle supply voltage
Selecting satellite radio
station*
RACETIMER
Operating CD player
Overall analysisLap analysis

165 Controls in detail
Control system
AUDIO menu
The functions in the
AUDIO
menu operate
the audio equipment which you currently
have turned on.
If no audio equipment is currently turned
on, the message
AUDIO off
appears in the
multifunction display.
The following functions are available:Selecting radio station

Turn on COMAND and select radio. Re-
fer to separate COMAND operating in-
structions.

Press buttonè orÿ repeatedly
until you see the currently tuned sta-
tion in the multifunction display.
1Waveband setting
2Station frequency

Press buttonk orj repeatedly
until the desired station is found.Selecting satellite radio station*
(USA only)
The satellite radio is treated as a radio ap-
plication.

Select SAT radio with the correspond-
ing softkey in the radio menu.
1SAT mode and preset number
2Setting for station selection using
memory
3Channel name or number

Press buttonk orj repeatedly
until the desired channel is found.
Function
Page
Selecting radio station
165
Selecting satellite radio station*
165
Operating CD player
166
i
You can only store new stations using the
corresponding feature on the radio, see separate
operating instructions.
You can also operate the radio in the usual man-
ner.

166 Controls in detailControl systemOperating CD player
Selecting CD track
Turn on COMAND and select CD or
CD changer. Refer to separate
COMAND operating instructions.

Press buttonè orÿ repeatedly
until the settings for the CD currently
being played appear in the multifunc-
tion display.1Current CD (for CD changer)
2Current track

Press buttonk orj repeatedly
until the desired track is selected.
Selecting MP3-CD track

Turn on COMAND and select MP3-CD.
Refer to separate COMAND operating
instructions.

Press buttonè orÿ repeatedly
until the settings for the MP3-CD cur-
rently being played appear in the multi-
function display.1MP3 mode
2Current track

Press buttonk orj repeatedly
until the desired track is selected.
i
Additional optional satellite radio equipment
and a subscription to satellite radio service pro-
vider are required for satellite radio operation.
Contact an authorized Mercedes-Benz Center
for details and availability for your vehicle.
For more information, refer to separate
COMAND operating instructions.
i
The COMAND system and the CD changer
can play audio CDs as well as MP3-CDs.
For more information on operating the
CD changer refer to separate COMAND operat-
ing instructions.
i
To select a CD from the CD changer maga-
zine, press a number on the COMAND system
key pad located in the center console.
i
Level of information displayed will vary de-
pending on the information contained on the
MP3-CD insert in the single CD player of the
COMAND system.
To select a MP3-CD from the CD changer maga-
zine, press a number on the COMAND system
key pad located in the center console.

495 Index
A
ABS 97
Indicator lamp 378
Messages in display 396, 411
Accelerator position, automatic
transmission 191
Accessory weight 358
Accident 60
Active Bi-Xenon headlamps* see Head-
lamps
Active head restraints 87
Adaptive Damping System see ADS
ADS 261
Air bags 70
Children 71
Front, Driver 74
Front, Passenger 74
Safety guidelines 72
Side impact 75
Window curtain 75
Air conditioning refrigerant 489
Air conditioning system see Climate con-
trol system
Air conditioning, Cooling 218, 235
Air distribution 213, 230
Air pressure 358Air pressure see Tire inflation
pressure 341
Air pump, electric
Turning on 460
Air recirculation mode 216, 233
Air vents 213, 230
Air volume 214, 231
Airmatic DC (Dual Control)
Messages in display 428
Suspension tuning 262
Airmatic DC (Dual Control) 261
Vehicle level control 262
Alarm system see Anti-theft systems
Alignment bolt (vehicle tool kit) 430, 458
AMG menu 161
Anticorrosion/antifreeze 493
Antilock Brake System see ABS
Anti-theft systems 106
Anti-theft alarm system 106
Immobilizer 106
Aquaplaning see Hydroplaning 314
Ashtrays 285
Aspect ratio 358AUDIO menu 165
Operating CD player 166
Selecting radio station 165
Selecting satellite radio* station 165
Audio search function 180
Audio system
CD mode 166
Auto-dimming
Rear view mirrors 200
Automatic central locking, Control
system 180
Automatic headlamp mode 142
Automatic lighting control, Interior
lighting 149
Automatic locking when driving 180
Automatic shift program 193

497 Index
Cargo compartment
Closing the tailgate 123
Fuse box 472
Lamp 151
Message in display 428
Opening 121
Tie-down rings 270
Cargo compartment cover 276
Cargo management system* 271
Belt reel 272
Cargo tie-down ring 272
Mounting elements 271
Telescoping rod 273
Cargo net 275
Cargo tie-down rings 270
Carpets, cleaning 374
Catalytic converter 318
CD player 166
Center console
Lower part 30
PASS AIR BAG OFF indicator
lamp 391
Upper part 29
Central locking
Automatic 126, 180
Locking/unlocking from inside 127Central locking switch 127
Certification label 476
Checking
Oil level 326
Checking tire pressure electronically with
the Advanced Tire Pressure Monitoring
System (Advanced TPMS)*,
(Canada only) 344
Children in the vehicle 88
Air bags 71
Blocking of rear window operation 95
Indicator lamp, front passenger front
air bag 81
Infant and child restraint systems 89
LATCH-type child seat anchors 94
Cigarette lighter 286Climate control system
4-zone automatic climate
control 222
Air conditioning refrigerant 489
Air conditioning, Cooling 218, 235
Air distribution 213, 230
Air recirculation mode 216, 233
Air volume 214, 231
Automatic mode 211, 228
Control panel, Rear 220, 237
Deactivating system 211, 227
Dual-zone automatic climate
control 206
Front defroster 214, 231
Maximum cooling MAX COOL 216,
232
Rear climate control 237
Residual engine heat (REST) 219,
236
Clock 27, 174
Setting time 175
Cockpit 24
Cold tire inflation pressure 358
Collapsible tire 483
Collapsible wheel chock 434
