2007 MERCEDES-BENZ E63AMG Owner's Manual

176 Controls in detailControl systemYou can temporarily deactivate the de-
layed shut-off feature:
Before exiting the vehicle, turn the
SmartKey in the starter switch to
position0.

Then turn it to position2 and back to
position0.
The delayed shut-off feature is deacti-
vated. It will reactivate as soon as you
reinsert the SmartKey in the starter
switch.
Vehicles with KEYLESS-GO*:

Press the KEYLESS-GO start/stop but-
ton on the gear selector lever
(page 39).Setting interior lighting delayed shut-off
Use this function to set whether you would
like the interior lighting to remain on for
10 seconds during darkness after you have
removed the SmartKey from the starter
switch.

Move the selection marker with
buttonæ orç to the
Lighting
submenu.

Press buttonj ork repeatedly
until the message
Interior lighting
delayed shut-off appears in the mul-
tifunction display.
The selection marker is on the current
setting.

Press buttonæ orç to switch Interior lighting delayed shut-off

On or
Off
. Vehicle submenu
Access the
Vehicle
submenu via the
Set-
tings
menu. Use the
Vehicle
submenu to
make general vehicle settings. The follow-
ing function is available:
Setting automatic locking
Use this function to activate or deactivate
the automatic central locking. With the au-
tomatic central locking system activated,
the vehicle is centrally locked at vehicle
speeds of approximately 9 mph
(15 km/h).

Move the selection marker with
buttonæ orç to the
Vehicle
submenu.
Function
Page
Setting automatic locking
176
Audio search function
177


177 Controls in detail
Control system

Press buttonj ork repeatedly
until the message
Automatic door
locking
appears in the multifunction
display.
The selection marker is on the current
setting.

Press buttonæ orç to switch Automatic door locking
On or
Off
.Setting station selection mode
Use the
Audio search function
to select
the manual or memory station selection
mode for the radio (
page 161).

Move the selection marker with
buttonæ orç to the
Vehicle

submenu.

Press buttonj ork repeatedly
until the message
Audio search func-
tion
appears in the multifunction dis-
play.
The selection marker is on the current
setting.

Press buttonæ orç to select
the desired station selection mode.
You can select:

frequenc
.


memory
selects next stored station

178 Controls in detailControl systemConvenience submenu
Access the
Convenience
submenu via the
Settings
menu. Use the
Convenience
sub-
menu to change the settings for a number
of convenience features. The following
functions are available:
Activating easy-entry/exit feature
Use this function to activate and deacti-
vate the easy-entry/exit feature
(
page 46).

Move the selection marker with
buttonæ orç to
the
Convenience
submenu.

Press buttonj ork repeatedly
until the message
Easy-entry func-
tion
appears in the multifunction dis-
play.
The selection marker is on the current
setting.

Press buttonæ orç to switch Easy-entry function
On or
Off
.
Function
Page
Activating easy-entry/exit fea-
ture
178
Setting parking position for exte-
rior rear view mirror
1
1If equipped.
179
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel when the easy-entry/exit feature is
activated.
To stop steering wheel movement, do one of
the following:

Move steering column stalk
(page 45).


Press one of the memory position but-
tons (
page 135).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.

179 Controls in detail
Control system
Setting parking position for exterior rear
view mirror
Depending on production date, your vehi-
cle may not be equipped with this function.
Use the
Mirror adjust. parking aid

function to select whether the passenger-
side exterior rear view mirror should be
turned downward during parking maneu-
vers when reverse gear R is engaged. For
additional information, see “Activating ex-
terior rear view mirror parking position”
(
page 200).

Move the selection marker with
buttonæ orç to
the
Convenience
submenu.

Press buttonj ork repeatedly
until the message
Mirror adjust.
parking aid
appears in the multifunc-
tion display.
The selection marker is on the current
setting.

Press buttonæ orç to switch Mirror adjust. parking aid
On or
Off
.
Trip computer menu
Use the trip computer menu to call up sta-
tistical data on your vehicle. The following
information is available:Function
Page
Fuel consumption statistics
since start
180
Fuel consumption statistics
since last reset
180
Resetting fuel consumption
statistics
180
Distance to empty
181

180 Controls in detailControl systemFuel consumption statistics since start
Press buttonÿ orè repeatedly
until you see the first function of the
trip computer menu.

Press buttonj ork repeatedly
until the message
From start
appears
in the multifunction display.
1Distance driven since start
2Time elapsed since start
3Average speed since start
4Average fuel consumption since startFuel consumption since last reset

Press buttonÿ orè repeatedly
until you see the first function of the
trip computer menu.

Press buttonj ork repeatedly
until the message
Since reset
appears
in the multifunction display:
1Distance driven since last reset
2Time elapsed since last reset
3Average speed since last reset
4Average fuel consumption since last re-
setResetting fuel consumption statistics

Press buttonÿ orè repeatedly
until you see the first function of the
trip computer menu.

Press buttonj ork repeatedly
until you see the reading that you want
to reset in the multifunction display.

Press and hold the reset button in the
instrument cluster (
page 26) until
the value is reset to 0.
i
All statistics stored since the last engine
start will be reset approximately 4 hours after
the SmartKey in the starter switch is turned to
position0 or removed from the starter switch.
Resetting will not occur if you turn the SmartKey
back to position1 or2 within this time period.

181 Controls in detail
Control system
Distance to empty
Press buttonÿ orè repeatedly
until you see the first function of the
trip computer menu.

Press buttonj ork repeatedly
until the message
Range:
appears in
the multifunction display.
The calculated remaining driving range
based on the current fuel tank level ap-
pears in the multifunction display.
TEL* menu
You can use the functions in the
Tel
menu
to operate your telephone, provided it is
connected to a hands-free system and
switched on.

Switch on the telephone and COMAND.

Press buttonÿ orè on the
steering wheel repeatedly until the
Tel

menu appears in the multifunction dis-
play.
Which messages will appear in the multi-
function display depends on whether your
telephone is switched on or off:


If the telephone is off, the message in
the multifunction display is:
TEL off
.
i
If only very little fuel is left in the tank, a ve-
hicle at the fuel pump is shown instead of the
range.
Warning!
G
A driver’s attention to the road must always
be his/her primary focus when driving. For
your safety and the safety of others, we rec-
ommend that you pull over to a safe location
and stop before placing or taking a tele-
phone call. If you choose to use the tele-
phone while driving, please use the
hands-free device and only use the tele-
phone when weather, road and traffic condi-
tions permit.
Some jurisdictions prohibit the driver from
using a cellular telephone while driving a ve-
hicle.
Bear in mind that at a speed of just 30 mph
(approximately 50 km / h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or
personal injury.

182 Controls in detailControl system

If the telephone is on:
The telephone will then search for a
network. During this time the multi-
function display is empty.
As soon as the telephone has found a
network,
READY
appears in the multi-
function display.
This standby message indicates that your
telephone is ready for use and you can op-
erate it using the control system.Answering a call
When your telephone is ready to receive
calls, you can answer a call at any time. In
the multifunction display you will then see
the message, or if available, the caller ID
(number and name):

Press buttons.
You have answered the call. In the mul-
tifunction display you see the length of
the call.Ending a call or rejecting an incoming
call

Press buttont.
Dialing a number from the phone book
If your telephone is ready to receive calls,
you may select and dial a number from the
phone book at any time.

Press buttonÿ orè repeatedly
until you see the
Tel
menu in the mul-
tifunction display.

183 Controls in detail
Control system

Press buttonj ork.
The control system reads the phone
book which is stored in the telephone.
This may take several minutes. In the
multifunction display you will see the
message
Please wait
.
When the message
Please wait
disap-
pears, the phone book has been load-
ed.

Press buttonj ork repeatedly
until the desired name appears in the
multifunction display.
The stored names are displayed in as-
cending or descending alphabetical or-
der.

Press buttons.
The system dials the selected phone
number.

If the connection is successful, the
name of the party you are calling
and the duration of the call will ap-
pear in the multifunction display.


If no connection is made, the con-
trol system stores the dialed num-
ber in the redial memory.Redialing
The control system stores the most recent-
ly dialed phone numbers. This eliminates
the need to search through your entire
phone book.

Press buttonÿ orè repeatedly
until you see the
Tel
menu in the mul-
tifunction display.

Press buttons.
In the multifunction display you see the
first number in the redial memory.

Press buttonj ork repeatedly
until the desired name appears in the
multifunction display.

Press buttons.
The control system dials the selected
phone number.
i
If you press and hold buttonj ork
for longer than 1 second, the system scrolls rap-
idly through the list of names until you release
the button again.
Cancel the quick search mode by pressing
buttont.
