2007 MERCEDES-BENZ CL600 Owner's Manual

136 Control systems
COMAND telephone*
Transferring a call
From the hands-free system to the
Bluetooth
® headset
The call transfer is controlled by pressing
the PTT button on the Bluetooth
® headset
(see headset operating instructions). Nor-
mally, it is sufficient to press the PTT but-
ton once, but under certain circumstances
you may have to press it a second time.
Once the call has been transferred to the
Bluetooth
® headset, all the functions will
be available to you which are described in
the “Functions during a single-call connec-
tion” section (
page 133).
Exception: “Switching the hands-free mi-
crophone on or off” function (
page 134).From the Bluetooth
® headset to the
hands-free system
On most Bluetooth
® headsets, you press
the PTT button on the headset twice quick-
ly to transfer the call (see headset operat-
ing instructions).
From the hands-free system to the mo-
bile phone
If the mobile phone has a folding up-
per section: Flip upper section open.
Take mobile phone out of cradle.
The “No telephone inserted” message
appears on the COMAND display. Sub-
sequent operation is only possible us-
ing the mobile phone.From the mobile phone to the
hands-free system
Insert mobile phone into cradle.
Once the call has been transferred to
the hands-free feature, all the functions
will be available to you which are de-
scribed in the “Functions during a sin-
gle-call connection” section
(
page 133).
iThe use of a Bluetooth® headset requires
Bluetooth® to be activated and the Bluetooth®
headset to be authorized (
page 232).

137 Control systems
COMAND telephone*
COMAND phone book
The COMAND phone book contains both
the COMAND address book entries and
mobile phone entries that have at least
one telephone number.
The COMAND address book entries are
permanently available even when a mobile
phone is not inserted in the cradle.
When the mobile phone is inserted in the
cradle, COMAND will read the phone book
entries in the mobile phone and compares
them with the COMAND address book en-
tries. If any of the telephone numbers of a phone
book entry in the mobile phone are the
same as an address book entry, COMAND
will only display the address book entry.
If the entries are not the same, the CO-
MAND phone book will show the phone
book entry in the mobile phone.
Calling up the COMAND phone book
Select “Telephone”
“Telephone”

“Telephone”
“Name”.
The COMAND phone book appears.Illustration: a phone book with name dis-
play and smart speller activated
1Category symbol
2Upper entry from address book (with-
out category symbol)
3Symbol + for several telephone num-
bers (subentries) under the main entry
4Symbol for summarized entries
from the mobile phone with the same
name but different telephone numbers
5Smart speller
6Voice entry symbol
7To close the phone book

138 Control systems
COMAND telephone*
Entries with category symbol 1 come
from the mobile phone. The following cate-
gory symbols are possible:

= symbol for “Mobile” category

= symbol for “Home” category

= symbol for “Work” category

= symbol for “Fax” category

= symbol for “Pager” category

= symbol for “Main” category or for
unknown category or for phone entries
that are saved on the SIM card of a
GSM mobile phone
Entries without a category symbol or with
the symbol come from the COMAND
address book.
Entries with the symbol contain a voice
entry. Voice entries can be added to the
address book (
page 224). This function
is available in vehicles with Voice Control.Switching between the smart speller
and the list
Switching from the smart speller to
the list: Slide mq repeatedly or press
n until the smart speller is hidden.
or
Rotate ymz or slide omp and
select?.
The smart speller is hidden.
Illustration: list of phone book entries with
name display and hidden smart speller
1Back to smart speller
2To switch phone book display (“123” or
“ABC”)
3Symbol + for several telephone num-
bers (subentries) under the main entry,
subentry list is closed
4To call up options
5Symbol / for open subentry list
6List of phone book entries
7Subentry list with category symbols
and telephone numbers

139 Control systems
COMAND telephone*
Switching from the list to the smart
speller: Select “Back” from the list.
or
Press back button L in the center
console (
page 82).
Changing phone book display in the
list: Select “123” or “ABC”.
The screen changes to telephone num-
ber or name display.Closing the COMAND phone book
In the smart speller, select “Back”.
or
Press back button L in the center
console (
page 82).
Selecting an entry in the COMAND
phone book
Selecting entries using the smart speller
Switch from the list to the smart speller
if necessary.
Changing smart speller language:
Select !.
Select desired language.
Changing smart speller character
set: Select #.
Depending on the previous setting, you
will change to letters with special char-
acters or to numbers with special char-
acters.
Entering characters: Select the char-
acters of the entry you are searching
for one by one.
Deleting individual characters: Se-
lect ) and briefly press n.
Each time you enter or delete a charac-
ter, the closest match will be displayed
at the top of the list.
Deleting an entire entry: Select )
and press and hold n until the entry is
deleted.
Canceling search: Switch from the
smart speller to the list.
The entry at the top of the list is auto-
matically highlighted.
Selecting using the list
If necessary, switch from the smart
speller to the list.
Rotate ymz or slide qmr until the de-
sired entry is highlighted.
iThe following options are available under
“Options” menu item 4:

Displaying details about an entry
(
page 140)

Creating a new entry in the address book
(
page 140)

Deleting an entry (page 142)

Saving a phone book entry from mobile
phone in the address book (
page 142)

Adding a telephone number to an address
book entry (
page 144)

140 Control systems
COMAND telephone*
Selecting subentries
Select an entry with the + symbol and
press n.
The + symbol changes to / and the
subentries are displayed.
Rotate ymz or slide qmr until the de-
sired subentry is highlighted.
Displaying details of an entry
COMAND can also show a shortened entry
in its entirety. For entries featuring suben-
tries, the detailed view is only available for
the subentries and not for the main entry.
Select entry (page 139).
Select “Options”
“Details”.
The detailed view appears.
Closing detailed view: Slide qmr or
omp or press n or back button L
in the center console (
page 82).Starting to dial the number of an entry
Select entry (page 139).
Press n.
or
Press s on the telephone keypad.
A list appears if the entry contains sub-
entries.
Select desired subentry.
Press n again.
or
Press s on the telephone key-
pad.Assigning a New Entry in the Address
Book
Select “Options”
“New Entry” in the
COMAND phone book list.
Selecting a number category:
Select a category, e.g. “Home”.
Selecting a telephone category:
Select a category, e.g. “Land Line”.
Confirming selection: Select “Save”.
The input menu appears with the data
fields.
iThis function is used to create a new entry in
the address book and to enter the data (first
name, last name and telephone number) manu-
ally.

141 Control systems
COMAND telephone*
1Data field
2Input mark (cursor)
3Input characters
Changing data field: Slide qmr re-
peatedly until desired data field is high-
lighted.
or
Select [ or ] repeatedly until de-
sired data field is highlighted.
Entering data into a field: Select all
characters one by one from the input
characters line 3.
Toggling upper and lower case for
the input characters: Select & or
(.
Changing language for the input
characters: Select !.
Select desired language.
Changing character set for the input
characters: Select #.
Depending on the previous setting, you
will change to letters with special char-
acters or to numbers with special char-
acters.
Displaying special characters as in-
put characters: Select !
“Sym-
bols”.
Returning input characters to nor-
mal characters: Select !
the
desired language.
Moving cursor in the data field:
SelectY or Z.
Deleting individual characters:
Select) and briefly press n.
The character to the left of the cursor is
deleted.
Deleting an entire entry: Select )
and press and hold n until the entry is
deleted.
Saving an entry: Select ?.
Canceling an entry: Select “Back”.
If one of the data fields contains data, a
prompt will appear asking whether you
want to save the entry.
Select “Yes” or “No”.
The entry will either be saved or
not, depending on your selection.

142 Control systems
COMAND telephone*
Deleting an entry
The deletion rules may vary, depending on
the entry selected:

Upper entry selected from the address
book:
the entry is deleted from the COMAND
phone book and also from the address
book, if the address book entry only
contains telephone numbers.

Subentry of an address book entry se-
lected:
the subentry is deleted from the
COMAND phone book and from the ad-
dress book.
Deleting: Select entry (page 139).
Select “Options”
“Delete”.
A prompt appears asking whether the
entry should be deleted.
Select “Yes” or “No”.
Once “Yes” has been selected, the en-
try will be deleted according to the
rules mentioned above.
Saving a phone book entry from the
mobile phone in the address book
Saving as a new address book entry
Select phone book entry from mobile
phone (
page 139).
Select “Options”
“Save”
“New En-
try”.
Selecting a number category:
Select a category, e.g. “Home”.
Selecting a telephone category:
Select a category, e.g. “Land Line”.
Confirming selection: Select “Save”.
The input menu appears with the data
fields. The data field for the telephone
number is filled in automatically. The
data field for the last name is also filled
when the entry to be saved contains a
name.
iIt is not possible to delete a phone book en-
try from the mobile phone using the COMAND
phone book.
iThis function is used to save an existing
phone book entry from the mobile phone in the
address book. The following options are avail-
able:

Saving as a new address book entry

Adding a telephone number to an existing
address book entry
iAll entries with the following category sym-
bols are phone book entries in the mobile phone.

= symbol for “Mobile” category

= symbol for “Home” category

= symbol for “Work” category

= symbol for “Fax” category

= symbol for “Pager” category

= symbol for “Main” category

143 Control systems
COMAND telephone*
1Data field
2Input mark (cursor)
3Input characters
Proceed as described in the “Changing
data field” paragraph in the “Assigning
a New Entry in the Address Book” sec-
tion (
page 140).Adding a telephone number to an exist-
ing address book entry
Select phone book entry from mobile
phone (
page 139).
Select “Options”
“Save”
“Add”.
Selecting a number category:
Select a category, e.g. “Home”.
Selecting a telephone category:
Select a category, e.g. “Land Line”.
Confirming selection: Select “Save”.
The search menu for address book en-
tries appears.
Search for desired entry using smart
speller function.
After selecting an entry, press n.
If there are fewer than four numbers
assigned to the selected entry in the
selected number category, COMAND
will save the data.
If four numbers are saved for the se-
lected entry, a prompt will appear ask-
ing whether you want to overwrite one
of the existing numbers.
Select “Yes” or “No”.
If you select “Yes”, a selection list will
appear containing the four existing
numbers.
Select number to be overwritten.
COMAND overwrites the selected num-
ber with the new data.
iAll entries with the following category sym-
bols are phone book entries in the mobile phone.

= symbol for “Mobile” category

= symbol for “Home” category

= symbol for “Work” category

= symbol for “Fax” category

= symbol for “Pager” category

= symbol for “Main” category
iThere is a detailed description of how to
search for an address book entry in the “Search-
ing for an address book entry” section
(
page 217).
