2007 MERCEDES-BENZ CL-CLASS bluetooth

232 Control systems
COMAND system settings
Bluetooth® settings
General information about Bluetooth
®
Bluetooth® technology is the standard for
short-range wireless technologies, suitable
for transmitting voice and data. It is possi-
ble to connect Bluetooth
® devices wire-
lessly. Bluetooth® can be used to
exchange vCards or make calls using a
headset.
Bluetooth
® technology uses the freely
available ISM (Industrial Scientific Medi-
cal) wireless network that works at
2.45 GHz. Ranges of up to ten meters are
possible with Bluetooth
®.
Activate or deactivate Bluetooth
®
Select “Vehicle”
“System Settings”

“Services”
“Deactivate Blue-
tooth”.
You have activated or deactivated
Bluetooth
®. A checkmark appears
when Bluetooth® is deactivated.Connecting Bluetooth
® devices
It is possible to establish a Bluetooth
® con-
nection between COMAND and the follow-
ing types of device:

Mobile phone (only for transferring
business cards)

Headset

Laptop/PDA
You can connect up to twelve devices to
COMAND but only one device can be ac-
tive at a time.
The connection process includes search-
ing for the device and its subsequent au-
thorization.Calling up the Bluetooth
® device list
and searching for devices
Calling up the list: Select “Vehicle”

“System Settings”
“Services”

“Search for Bluetooth devices”.
When you call up the list for the first
time after switching on COMAND, the
search for devices in the reception
range starts automatically. You will see
a display to this effect.
The device list appears after a short
while.
Canceling search:
Select “Cancel”.
The second time you call up the list, and
each time thereafter, the device list ap-
pears immediately if COMAND has not
been switched off and on again in the
meantime.
Starting search manually:
select “Update”.
iTo connect a Bluetooth® device, the
Bluetooth® function must be activated in
COMAND and in the device concerned. The
Bluetooth
® device must also be set to “visible”
or “findable” in order for COMAND to find and
display it. For the setting procedures, please see
the operating instructions for the Bluetooth
®
device.
ProCarManuals.com

233 Control systems
COMAND system settings
The device list can contain the following
devices:

All detected devices, whether autho-
rized or not.

All authorized devices, whether detect-
ed or not.
1Authorized and detected device – de-
vice and padlock symbol are the same
color
2Device which was not detected, but
which has been authorized in the past
– device and padlock symbol are differ-
ent colors (the device may be switched
off or not in the vehicle, for example)
3Newly detected device - not yet autho-
rized (no symbol)Displaying details of a Bluetooth
® de-
vice
Call up Bluetooth® device list
(
page 232).
Select desired device.
Select “Details”.
The detailed display for this device ap-
pears.
Closing detailed display: Slide qmr
or press n.Authorizing a Bluetooth
® device
Call up Bluetooth® device list
(
page 232).
Select unauthorized device.
Select “Authorize”.
The input menu for the passkey ap-
pears.
iIf the device list already contains twelve au-
thorized devices, you must revoke authorization
for one of the authorized devices. Then you must
switch this device off and then restart the
search. Any new devices for which you would like
to search will otherwise not appear in the list.
iThe passkey is any one to sixteen-digit num-
ber which you can set yourself. You must enter
t he s ame n umb er in C OM AND an d als o in th e de-
vice to be authorized.
iOn devices which do not have an input key-
pad (e.g. headsets), the passkey is predeter-
mined. In this case, it is not necessary to enter
the number on the device itself. You will usually
find the passkey in the operating instructions for
the device.

ProCarManuals.com

234 Control systems
COMAND system settings
Entering passkey into COMAND:
Select the digits one by one.
Deleting digits: Select ) and briefly
press n.
Canceling entry into COMAND:
Select “Back”.
Confirming entry into COMAND:
Select?.
If necessary, enter the same passkey
into the Bluetooth® device (see the op-
erating instructions for the device).
The device is authorized.De-authorizing a Bluetooth
® device
Call up Bluetooth® device list
(
page 232).
Select authorized device.
Select “De-authorize”.
A prompt appears asking whether you
really want to de-authorize this device.
Select “Yes” or “No”.
If you select “Yes”, the device will be
de-authorized.
Reset
Select “Vehicle”
“System Settings”

“Reset”.
A prompt appears asking whether you
really want to reset.
Select “Yes” or “No”.
If you select “Yes” another prompt will
appear asking whether you really want
to reset.
Select “Yes” or “No”.
If you select “Yes”, COMAND will be re-
set and restarted.
iIf you de-authorize a device which has been
authorized in the past and which is not detected
in the search, this device will no longer be dis-
played in the device list.
Devices which have been authorized in the past
but which are not detected in the search are ei-
ther not switched on or not in the vehicle.
iYou can reset COMAND back to its factory
settings.
In this case, all personal data (e.g. address book
entries, entries in the destination memory and
the list of last destinations of the navigation sys-
tem), among other things, is deleted.

ProCarManuals.com

480 Controls in detail
Useful features
When the mobile phone is inserted in the
cradle, you can operate the telephone us-
ing the following devices:

mobile phone keypad

COMAND telephone keypad
(
page 122)

buttonss andt on the multi-
function steering wheel (
page 257)

Voice Control (page 278)

Bluetooth® headset (page 136)
Please note that these functions are only
available with Mercedes-Benz approved
mobile phones. Please contact an autho-
rized Mercedes-Benz Center for informa-
tion on features available for your mobile
phone of choice.
Open telephone compartment
(
page 470).Inserting mobile phone in mobile phone
cradle
Once the mobile phone has been inserted
in the mobile phone cradle, you have to
use the hands-free device or Bluetooth
headset to respond during phone calls.
If applicable, remove the cover for the
external antenna connection from the
back of the mobile phone and store it in
a s a f e p l a c e . B e s u r e t o c o m p l y w i t h t h e
mobile phone’s operating instructions,
as well.Example illustration
1Insert the mobile phone
2Connector contact
3Mobile phone cradle
Slide the lower end of the mobile phone
into connector contact 2 on
cradle3.
Push the top of the mobile phone in di-
rection of arrow 1, until the lug on the
mobile phone release button engages.
The mobile phone is connected to the
network via the external antenna.
!Do not try to remove the mobile phone along
with the cradle. You could otherwise damage the
mobile phone cradle.
ProCarManuals.com

695 Index
B
Backup lamps
Replacing bulbs 642
Bar 545
BAS 66
Batteries, SmartKey
Checking battery condition 332
Replacing 639
Batteries, SmartKey with KEYLESS-GO*
Checking battery condition 332
Replacing 639
Batteries, vehicle 655
Charging 658
Discharged, Jump starting 660
Disconnecting 657
For electrical consumers 655
For starter 655
Message in display 608
Reconnecting 659
Removing 658
Bead 545
Beverage holder see Cup holder
Bluetooth
®
Settings (COMAND) 232
Brake assist system (BAS Plus) 67
Brake assist system (BAS) 66Brake fluid 511, 685, 687
Brake lamp bulbs 642
Brake lamp, high mounted 642
Brake pads
Message in display 598
Brake warning lamp 31
Brakes 500
Warning lamp 31, 567
Break-in period 498
Bulbs, replacing 641
Additional turn signals 642
Brake lamps 642
Fog lamps 642
Front lamps 642
High beam 642
High mounted brake lamp 642
License plate lamps 642
Low beam 642
Parking and standing lamps 642
Rear fog lamp 642
Turn signal lamps 642C
California retail buyers and lessees,
important notice for 15
Can holder see Cup holder
Capacities and
recommended fuel/lubricants 684
Carpets, Cleaning and care of 564
Catalytic converter 507
CD
Ejecting (COMAND) 113
Loading (COMAND) 111
Menu overview (COMAND) 114
Playback options (COMAND) 119
Selecting a medium (COMAND) 117
Selecting a track (COMAND) 117
CD (COMAND) 107
Central locking
Automatic 334
Locking/unlocking from inside 335
Central locking/unlocking switches 335
Certification label 674
Change of address or ownership 16
ProCarManuals.com

712 Index
SRS 53
Indicator lamp 31, 575
Messages in display 626
Standing water, Driving through 505
Starter battery 657
Starter switch 336
Positions 336
Starting difficulties, Engine 380
Starting, Engine 378
Steering column 351
Steering wheel
Adjustment 351
Cleaning 563
Easy entry/exit feature 344
Heated steering wheel* 352
Power steering fluid 685
Steering wheel gearshift control
Automatic transmission 400
Stolen Vehicle Recovery services 490
Storage compartments 469
Cup holder 473
Front armrest 470
Parcel net 471
Rear armrest 472
Storage compartment
in front armrest 470Storage tray/telephone*
compartment in front armrest 470
Under the front seats 471
Storing tires 522
Summer opening feature 376
Sun visors 476
Sunroof see Power tilt/sliding sunroof
Sunshades
Extending or retracting rear window
sunshade (COMAND) 242
Suspension tuning
Setting (ABC) 429
Symbols used
in this operator’s manual 19
System settings (COMAND)
Bluetooth
® settings 232
Display 227
Favorite button 231
Menu overview 227
Reset 234
Setting the system language 231
Time settings 227
Voice Control settings
(COMAND) 229T
Tachometer 403
Overspeed range 403
Tail lamps
Cleaning lenses 558
Messages in display 621
Tar stains 555
Tele Aid 482
Automatic Maintenance Call 490
Call priority 488
Emergency calls 483
Hands-free microphone 37
Information 487
Information button 485
Initiating an
emergency call manually 485
Messages in display 628
Remote door lock 489
Remote door unlock 489
Roadside Assistance 486
Roadside Assistance button 485
SOS button 485
Stolen Vehicle
Recovery services 490
System self-check 483
