Contents
COMAND navigation system
(destination memory) ......................... 206
Saving a destination
in the destination memory ........... 206
Deleting a destination
from the destination memory ....... 208
Own address ................................ 209
COMAND navigation system
(last destinations) .............................. 213
Saving a destination permanently
in the destination memory ........... 213
Saving the vehicle position
in the list of last destinations ....... 213
Saving the crosshair position
in the list of last destinations ....... 213
Deleting one of
the last destinations ..................... 213
COMAND address book ..................... 214
General notes ............................... 214
Address book menu overview ...... 214
Calling up the address book ......... 215
Selecting an entry in
the main address book display ..... 215
Creating a new
address book entry ...................... 215
Deleting an entry .......................... 217Searching for an
address book entry ...................... 217
Displaying a complete
address book entry ...................... 219
Displaying of a complete phone
book entry in the mobile phone ... 220
Changing an entry ........................ 221
Calling a number
saved in an entry .......................... 222
Starting route guidance
to an entry.................................... 223
Voice entries ................................ 224
Saving a phone book entry from
mobile phone in the
COMAND address book ............... 225
Importing data from external
Bluetooth
® devices....................... 226
COMAND system settings ................. 227
Systems settings menu overview . 227
Display settings............................ 227
Time settings................................ 227
Voice Control settings .................. 229
Setting the system language ........ 231
Assigning the favorite button ....... 231
Bluetooth
® settings ...................... 232
Reset............................................ 234COMAND vehicle menu ..................... 235
Setting night security illumination 235
Locator lighting on/off................. 236
Exterior mirror
convenience settings ................... 237
Automatic locking on/off............. 238
Activating easy-entry/exit feature 239
Setting interior
ambient lighting ........................... 240
Setting interior
lighting delayed switch-off ........... 241
Extending or retracting
rear window sunshade ................. 242
Trunk opening-height
restriction* on/off ....................... 242
Switching the
tow-away alarm on/off ................ 243
COMAND automatic climate control . 244
Setting temperature ..................... 245
Adjusting air distribution .............. 246
Adjusting air volume .................... 246
Central climate control menu
via COMAND ................................ 247
ProCarManuals.com

19 Introduction
Symbols
Symbols
Trademarks:

Bluetooth® is a registered trademark of
of Bluetooth SIG Inc.

ESP® and PRE-SAFE® are registered
trademark of DaimlerChrysler.

HomeLink® is a registered trademark
of Prince, a Johnson Controls
Company.

LOGIC7® is a registered trademark of
Harman International Industries, Incor-
porated.

SIRIUS and related marks are trade-
marks of SIRIUS Satellite Radio Inc.The following symbols are found in this
Operator’s Manual:
* Optional equipment is identified
with an asterisk. Since standard
equipment varies between models,
the descriptions and illustrations in
this manual may differ slightly from
the actual equipment of your
vehicle.
This symbol points to instructions for
you to follow.
A number of these symbols appearing
in succession indicates a multiple-step
procedure.
 page This symbol tells you where to
look for further information on a
topic.
This continuation symbol marks
a warning which is continued on
the next page.
This continuation symbol marks
a procedure which is continued
on the next page.
-> This symbol is used to indicate
cross-references to term defini-
tions.
“Display” Words appearing in the multi-
function display and COMAND
display are printed in the type
shown here.
Warning!G
Warning notices draw your attention to
hazards that may endanger your health or
life, or the health or life of others.
!Highlights hazards that may result in
damage to your vehicle.
iHelpful hints or further information you may
find useful.
ProCarManuals.com

120 Control systems
COMAND telephone*
Safety precautions
General notes
Calls disconnected while the vehicle is
in motion
A call may be disconnected if:

there is insufficient network coverage

you move from one transmitter/receiv-
er area (cell) into another and no chan-
nels are free or the cell is fullOperating options
When the mobile phone is inserted in the
cradle, you can operate the telephone us-
ing the following devices:

mobile phone keypad

COMAND telephone keypad

buttonss andt on the multi-
function steering wheel (
page 257)

Voice Control (page 278)

Bluetooth® headset (page 136)
Warning!G
Some jurisdictions prohibit the driver from
using a cellular telephone while driving.
Whether or not prohibited by law, for safety
reasons, the driver should not use the cellu-
lar telephone while the vehicle is in motion.
Stop the vehicle in a safe location before
placing or answering a call.
If you nonetheless choose to use the mobile
phone
1 while driving, please use the hands-
free feature and be sure to pay attention to
the traffic situation at all times. Use the mo-
bile phone only when road, weather and traf-
fic conditions permit. Otherwise, you may
not be able to observe traffic conditions and
could endanger yourself and others.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approxima-
tely 14 m) every second.
1Observe all legal requirements.
Warning!G
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or
personal injury.
iThe components and operating principles of
COMAND can be found on (
page 81) and
(
page 89).
iVarious mobile phone cradles can be in-
stalled in the front center armrest, see separate
installation instructions for the mobile phone
cradle. These mobile phone cradles can be ob-
tained from an authorized Mercedes-Benz Cen-
ter. For more information about telephone
(
page 479).
ProCarManuals.com

121 Control systems
COMAND telephone*
Please note that these functions are only
available with Mercedes-Benz approved
mobile phones. Please contact an autho-
rized Mercedes-Benz Center for informa-
tion on features available for your mobile
phone of choice.
You can control other functions of the mo-
bile phone via the COMAND, instrument
cluster control system (
page 265) or
Voice Control.
The descriptions in this section assume
that the mobile phone is inserted in the
cradle. Exceptions to this are clearly stat-
ed.
Unless otherwise indicated, the descrip-
tions and illustrations in this section refer
to COMAND and the telephone keypad.Operation using the mobile phone and
Bluetooth
® headset is described in the re-
spective separate Operating Instructions.
Caller ID
COMAND can display the telephone num-
ber and the name of the caller, e.g. for an
incoming call and also in other menus or
displays.
For the telephone number to be displayed,
the caller must transmit their telephone
number.
This is also the case for name displays. For
this, the telephone number and the name
of the caller must also be saved in the mo-
bile phone book.Functional restrictions
You will not be able to use the telephone,
or you may have to wait a while, in the fol-
lowing situations:

If the telephone has not yet logged into
the network.
The telephone automatically tries to
log into a network. If no network is
available, you will also not be able to
make a “911” emergency call.
If you attempt to make an outgoing call,
the “No Service” message will appear
for a short while.

If the mobile phone is not inserted in
the cradle.

SIM card is not inserted in GSM type
phone
iIn order for the functions described in this
section to work correctly, the Bluetooth® head-
set must be linked to COMAND (
page 232).
Please make sure any Bluetooth® headset linked
with the mobile phone is switched off or that the
headset is linked with COMAND before you in-
sert the mobile phone in the cradle (
page 479)
and use the telephone functions with COMAND.
ProCarManuals.com

131 Control systems
COMAND telephone*
Use the Bluetooth® headset
(see headset operating instructions).
If you have accepted the call using
COMAND, the telephone keypad, the mul-
tifunction steering wheel or the mobile
phone, the call will be conducted via the
hands-free system. The volume of the call
can be adjusted (
page 91).
If you have accepted the call using the
Bluetooth
® headset, the call will be con-
ducted via the headset.
Further operating functions can be found
in the “Functions during a single-call con-
nection” section (
page 133).
You can also accept a call if the
COMAND display is showing a screen oth-
er than the telephone mode screen. After
accepting the call, you will see the caller’s
data in a window.
Closing window: Slide qmr oromp
or press n.
Making an outgoing call
Entering the telephone number using
the COMAND controller
Switching screen to telephone
mode: Call up main telephone menu
(
page 127).
Entering digits: Select desired digits
by rotating ymz or sliding omp and
press n.
Deleting individual digits: Select )
and briefly press n.
Deleting an entire telephone num-
ber: Select ) and press and hold n
until the telephone number is deleted.
Connecting a call: Select “S”.Entering a telephone number using the
telephone keypad
Switching screen to telephone
mode: Call up main telephone menu
(
page 127).
Use telephone keypad to enter digits.
Connecting a call: Press s.
iThe use of a Bluetooth® headset requires
Bluetooth® to be activated and the Bluetooth®
headset to be authorized (
page 232).
iIf you place an outgoing call and receive a
busy signal, the telephone automatically starts
to redial as long as the provider and the mobile
phone support this function (see mobile phone
operating instructions).
While the call is connecting, you can also send
character strings (
page 134).iA detailed description of how to enter digits
using the telephone keypad can be found on
(
page 84).
ProCarManuals.com

136 Control systems
COMAND telephone*
Transferring a call
From the hands-free system to the
Bluetooth
® headset
The call transfer is controlled by pressing
the PTT button on the Bluetooth
® headset
(see headset operating instructions). Nor-
mally, it is sufficient to press the PTT but-
ton once, but under certain circumstances
you may have to press it a second time.
Once the call has been transferred to the
Bluetooth
® headset, all the functions will
be available to you which are described in
the “Functions during a single-call connec-
tion” section (
page 133).
Exception: “Switching the hands-free mi-
crophone on or off” function (
page 134).From the Bluetooth
® headset to the
hands-free system
On most Bluetooth
® headsets, you press
the PTT button on the headset twice quick-
ly to transfer the call (see headset operat-
ing instructions).
From the hands-free system to the mo-
bile phone
If the mobile phone has a folding up-
per section: Flip upper section open.
Take mobile phone out of cradle.
The “No telephone inserted” message
appears on the COMAND display. Sub-
sequent operation is only possible us-
ing the mobile phone.From the mobile phone to the
hands-free system
Insert mobile phone into cradle.
Once the call has been transferred to
the hands-free feature, all the functions
will be available to you which are de-
scribed in the “Functions during a sin-
gle-call connection” section
(
page 133).
iThe use of a Bluetooth® headset requires
Bluetooth® to be activated and the Bluetooth®
headset to be authorized (
page 232).
ProCarManuals.com

226 Control systems
COMAND address book
After selecting an entry, press n.
COMAND saves the data if there are
fewer than four numbers assigned to
the selected entry in the selected num-
ber category. Otherwise, you will see a
prompt asking whether one of the ex-
isting numbers should be overwritten.
Select “Yes” or “No”.
If you select “Yes”, a selection list will
appear containing the four existing
numbers.
Select the number to be overwritten.
COMAND overwrites the selected num-
ber with the new data.Importing data from external
Bluetooth® devices
You can import vCards from external
Bluetooth
® devices into the address book.
Please keep the following in mind:

Bluetooth® is activated in COMAND
(
page 232) and in the device con-
cerned.

The external device must be able to
send vCards by Bluetooth®.

The external device is inside the vehi-
cle, switched on and authorized
(
page 232).
Importing: Start data transfer on the
external device (see operating instruc-
tions of the device concerned).
If there is no address book entry with
the same first name and last name,
COMAND imports the data.
If there is already an address book en-
try with the same first name and last
name, a prompt will appear asking
whether the existing data should be
overwritten.
Select “Yes” or “No”.
The existing address book entry will be
overwritten or not, depending on your
selection.
iThere is a detailed description of how to
search for an address book entry in the “Search-
ing for an address book entry” section
(
page 217).
ProCarManuals.com

227 Control systems
COMAND system settings
COMAND system settings
Systems settings menu overview
Display settings
Switching the display on or off
Switching off: Select “Vehicle”

“Display OFF”.
Switching back on: Rotate ymz or
slideqmr.Setting the display design
Select “Vehicle”
“System Settings”

“Display”.
Select “Day Mode”, “Night Mode” or
“Automatic”.
Time settings
Setting the time
Select “Vehicle”
“System Settings”

“Time”
“Time”.
iThe components and operating principles of
COMAND can be found on (
page 81).
Display
(
page 227)
Time
(
page 227)
Voice Control
(
page 229)
Language
(
page 231)
Favorite
(
page 231)
Services
(
page 232)
Reset
(
page 227)
Display settingsTime settingsVoice Control
settingsLanguage
settingsAssign favorite
buttonBluetooth®
settingsReset COMAND to
factory settings
iIn the “Automatic” setting, COMAND ana-
lyzes the automatic vehicle light sensor and
switches between the display design automati-
cally.
iThe correct time must be set for the follow-
ing navigation system functions to operate cor-
rectly:

Route guidance on routes with time-depen-
dent traffic guidance

Calculation of estimated arrival time

ProCarManuals.com
