2007 JEEP WRANGLER tow

To Set At A Desired Speed
When the vehicle has reached the desired speed, press
down on the lever and release. Release the accelerator
and the vehicle will operate at the selected speed.
NOTE:The vehicle should be traveling at a steady
speed and on level ground before pressing the SET lever.
To Deactivate
A soft tap on the brake pedal, pulling the speed control
lever towards you “CANCEL”, or normal brake or clutch
pressure while slowing the vehicle will deactivate speed
control without erasing the set speed memory. Pressing
the ON/OFF button or turning off the ignition switch
erases the set speed memory.
To Resume Speed
To resume a previously set speed, push the “RESUME
ACCEL” lever up and release. Resume can be used at any
speed above 20 mph (32 km/h).
To Vary The Speed Setting
When the speed control is ON, speed can be increased by
pushing up and holding “RESUME ACCEL”. Release the
lever when the desired speed is reached, and the new
speed will be set.
Tapping “RESUME ACCEL” once will result ina2mph
(3 km/h) speed increase. Each time the lever is tapped,
speed increases so that tapping the lever three times will
increase speed by 6 mph (10 km/h), etc.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105
3

2. Place one hand on the upper rear and one hand on the
front of the door frame.
3. Pull the frame towards you with your rearward hand
to remove the frame from the vehicle.
4. Screw the knobs back into the door frame and fold for
storage. Store in a secure location.
WARNING!
Never store the door frames in your vehicle. In an
event of an accident, a loose door frame many cause
personal injury. If removed, always store the door
frames outside of the vehicle.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133
3

3. Pull the frame towards you with your front hand to
remove the frame from the vehicle.
4. Unscrew and remove the remaining door frame at-
tachment knob on the rear door frame.5. Place one hand on the upper rear and one hand on the
upper front of the rear door frame. Pull the frame
towards you with your rear hand to remove the frame
from the vehicle.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137
3

NOTE:Clean side and rear windows before removal to
assist in preventing scratching during removal of the soft
top. If zippers are difficult to operate due to road dust,
etc., clean them with a mild soap solution and a small
brush. Cleaning products are available through your
authorized dealer.
1. If your vehicle has half doors, remove each half door
window by opening the door and lifting the half door
window out.
NOTE:Stow half doors carefully outside of the vehicle,
never inside to avoid scratches.
2. Insert finger behind the plastic retainer. Pull down and
roll the retainer out of the channel. Repeat this on the
opposite side.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145
3

•Unzip the rear window starting at the right lower
corner of the window. Pull the zipper up, across the
top and down to the left lower corner.Zipper pulls
will stay on the rear window.Pull down on the rear
window to disengage from the zipper on the top
cover. Stow the windows carefully to avoid scratch-
ing.7. Undo the Velcrothat runs along the top and rear
edge of the side window.
8. Beginning from the rear lower corner, completely
unzip the window.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147
3

12. The swing gate brackets do not need to be removed
unless the hard top is being installed. To remove the
swing gate brackets, pull the front of the bracket forward
while rolling the entire bracket back in towards the
vehicle to disengage.13. Completely release the latches from the loops on the
windshield frame.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149
3

14. Grasp the side bow behind the header, lift the top,
and fold toward the rear of the vehicle.
15. Tuck the fabric and the check straps between the
bows and as far inward as possible. This will keep any
portion of the top from flapping outside of the vehicle.When the top is completely down, position the drip rails
so they make a “v-shape”, this prevents damage to the
soft top material.
16. Close front header latches.
17. Remove door frames, if desired. Refer to “Door
Frame” in this section.
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

7. Move to the rear of the vehicle and gently pull the sail
panels over the rear roof bow.
8. Partially install the sail panel retainers into the body
side channel, leaving the last three (3) inches towards therear window loose (on both sides). Pulling down on the
rear roof bow (3 bow) will aid to reach the channel with
the retainers.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155
3
