2007 JEEP LIBERTY Owners Manual

VEHICLE MODIFICATIONS / ALTERATIONS
WARNING!
Any modifications or alterations to this vehicle
could seriously affect its roadworthiness and safety
and may lead to an accident resulting in serious
injury or death.
INTRODUCTION 9
1

THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
CONTENTS

A Word About Your Keys..................14
▫Ignition Key Removal...................14
▫Key-In-Ignition Reminder................16

Steering Wheel Lock — If Equipped..........16
▫To Manually Lock The Steering Wheel.......16
▫To Release The Steering Wheel Lock.........16

Sentry Key Immobilizer System..............16
▫Important Note About Service.............18
▫Replacement Keys......................18▫Customer Key Programming..............18
▫General Information....................19

Security Alarm System — If Equipped.........19
▫ToSetTheAlarm ......................20
▫To Disarm The System...................20

Illuminated Entry........................21

Remote Keyless Entry.....................21
▫To Unlock The Doors...................21
▫To Lock The Doors.....................22
2

▫To Unlatch The Swing Gate Flip-Up Window . .23
▫Panic Alarm..........................24
▫To Use The Panic Alarm.................24
▫To Program Additional Transmitters.........24
▫General Information....................25
▫Transmitter Battery Service...............26

Door Locks............................26
▫Manual Door Locks.....................28
▫Power Door Locks — If Equipped..........29
▫Automatic Door Locks — If Equipped.......29
▫Child Protection Door Lock...............30

Windows.............................31
▫Power Front Windows...................31▫Power Rear Windows...................32
▫Wind Buffeting........................32

Rear Swing Gate........................33

Occupant Restraints......................36
▫Lap/Shoulder Belts.....................37
▫Lap/Shoulder Belt Operating Instructions.....39
▫Rear Center Lap/Shoulder Belt
Retractor Lock-Out.....................43
▫Adjustable Upper Shoulder Belt Anchorage....43
▫Automatic Locking Mode — If Equipped.....44
▫Energy Management Feature..............45
▫Seat Belt Pretensioners...................46
▫Enhanced Seat Belt Use Reminder System
(BeltAlert)...........................47
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

▫Seat Belts And Pregnant Women............48
▫Seat Belt Extender......................48
▫Driver And Front Passenger Supplemental
Restraint Systems (SRS) — Airbags..........49
▫Child Restraint........................64

Engine Break-In Recommendations...........74
SafetyTips ............................74
▫Exhaust Gas..........................74
▫Safety Checks You Should Make Inside
TheVehicle ..........................75
▫Safety Checks You Should Make Outside
TheVehicle ..........................76
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13
2

A WORD ABOUT YOUR KEYS
The keys for your new vehicle are enclosed in a plastic
bag with the key code number on it. If you received your
keys without the bag, ask your dealer to give you the
number. The key code can also be obtained by the dealer
from your vehicle invoice.
Ignition Key Removal
Manual Transmission
To remove the ignition key, depress and hold the key
release button, turn the ignition key to LOCK and remove
the key.
Ignition KeyIgnition Key Release Button
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Automatic Transmission — If Equipped
To remove the ignition key, place the gearshift lever in P
(Park), turn the ignition key to LOCK and remove the
key.WARNING!
Leaving children in a vehicle unattended is danger-
ous for a number of reasons. A child or others could
be injured. Children should be warned not to touch
the parking brake, brake pedal, or the gear selector
lever. Do not leave the keys in the ignition. A child
could operate power windows, other controls, or
move the vehicle.
CAUTION!
An unlocked vehicle is an invitation to thieves.
Always remove the key from the ignition, and lock
all doors when leaving the vehicle unattended.
Ignition Key Positions
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15
2

Key-In-Ignition Reminder
If you open the driver’s door and the key is fully inserted
in the ignition switch, a chime will sound to remind you
to remove the key.
STEERING WHEEL LOCK — IF EQUIPPED
Your vehicle may be equipped with a passive steering
wheel lock (manual transmission only). This lock pre-
vents steering the vehicle without the ignition key. If the
steering wheel is moved a half turn in either direction
and the key is not in the ignition, the steering wheel will
lock.
To Manually Lock the Steering Wheel
With the engine running, rotate the steering wheel 1/2
revolution from straight ahead position, turn off the
engine and remove the key. Rotate the steering wheel
slightly in both directions until the lock engages.
To Release the Steering Wheel Lock
Insert the key in the ignition and turn the wheel slightly
to the right or left to disengage the lock.
NOTE:If you turned the wheel to the right to engage
the lock, you must turn the wheel slightly to the right to
disengage it. If you turned the wheel to the left to engage
the lock, turn the wheel slightly to the left to disengage it.
SENTRY KEY IMMOBILIZER SYSTEM
The Sentry Key Immobilizer System (SKIM) prevents
unauthorized operation of the vehicle by disabling the
engine. The system will shut the engine down after 2
seconds of running if an invalid key is used to start the
vehicle. This system utilizes ignition keys which have an
electronic chip (transponder) embedded into them. Only
keys that have been programmed to the vehicle can be
used to start and operate the vehicle for longer than the
2 second validation time period.
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
