INSTRUMENT CLUSTER DESCRIPTION
1. Speedometer
Indicates vehicle speed.
2. Brake Warning Light
The BRAKE warning light will come on when
the ignition is first turned on, and stay on
briefly as a bulb check. If the bulb does not
come on during starting, have the bulb re-
paired promptly. If the light stays on longer, it may be an
indication that the parking brake has not been released.
If the light remains on when the parking brake is off, it
indicates a possible brake hydraulic system malfunction
or low fluid level. In this case, the BRAKE warning light
will remain on until the cause is corrected. If a brake
malfunction is indicated, immediate repair is necessary
and continued operation of the vehicle in this condition is
dangerous.3. Turn Signal Indicator Light
The arrow will flash with the exterior turn signal
when the turn signal lever is operated.
If the vehicle electronics sense that the vehicle has
traveled about one mile with the turn signals on, a chime
will sound to alert you to turn the signals off. If either
indicator flashes at a rapid rate, check for a defective
outside light bulb.
4. High Beam Indicator Light
Indicates that headlights are on high beam.
5. Malfunction Indicator Light
This light is part of an onboard diagnostic system
called OBD II that monitors engine and auto-
matic transmission control systems. The light will
illuminate when the key is in the ON position before
172 UNDERSTANDING YOUR INSTRUMENT PANEL

²LIFTGATE/DOORS OPEN (with graphic)
²LIFTGLASS OPEN (with graphic)
²HOOD OPEN (with graphic)
²HOOD/DOOR OPEN (with graphic)
²HOOD/DOORS OPEN (with graphic)
²LIFTGATE/HOOD OPEN (with graphic)
²HOOD/GLASS/DOOR OPEN (with graphic)
²HOOD/GLASS/DOORS OPEN (with graphic)
²HOOD/GATE/DOOR OPEN (with graphic)
²HOOD/GATE/DOORS OPEN (with graphic)
²LIFTGLASS/DOOR OPEN (with graphic)
²LIFTGLASS/DOORS OPEN (with graphic)
²LIFTGLASS/HOOD OPEN (with graphic)
²WASHER FLUID LOW (with graphic)
²UPSHIFT (with graphic)
²CHECK GAUGES
²AUTO HIGHBEAM ON
²AUTO HIGHBEAM OFF
²PARK ASSIST DISABLED
²SERVICE PARK ASSIST SYSTEM
²TRANSMISSION OVER TEMP
²LOW BRAKE FLUID LEVEL
²WARNING! LIMIT SPEED
²CHECK GAS CAP
²ESP OFF
²MEMORY #1 POSITIONS SET
180 UNDERSTANDING YOUR INSTRUMENT PANEL

Towing Tips
Before setting out on a trip, practice turning, stopping
and backing the trailer in an area away from heavy
traffic.
Towing Tips Ð Automatic Transmission
The ªDº range can be selected when towing. However, if
frequent shifting occurs while in this range, the ª3º range
should be selected.
NOTE:Using the ª3º range while operating the vehicle
under heavy operating conditions will improve perfor-
mance and extend transmission life by reducing exces-
sive shifting and heat build up. This action will also
provide better engine braking.
The automatic transmission fluid and filter should be
changed if you REGULARLY tow a trailer for more than
45 minutes of continuous operation. See Schedule ªBº in
section 8 of this manual for transmission fluid change
intervals.
NOTE:Check the automatic transmission fluid level
before towing.
7- Pin Connector
288 STARTING AND OPERATING

NPower Steering Fluid Check..............314
NBody Lubrication.....................316
NWindshield Wiper Blades................316
NWindshield Washers Ð Front And Rear.....316
NExhaust System......................317
NCooling System.......................318
NHoses And Vacuum/Vapor Harnesses.......323
NBrake System........................324
NBrake Fluid Level Check................325
NFuel System Hoses....................327
NAutomatic Transmission................327
NFront And Rear Wheel Bearings...........329NAppearance Care And Protection From
Corrosion...........................329
mFuse Panel...........................333
NInterior Fuses........................333
NUnderhood Fuses
(Power Distribution Center)..............336
NUnderhood Fuses
(Integrated Power Module)..............338
mVehicle Storage........................339
mReplacement Bulbs......................340
mBulb Replacement......................341
NHead Light..........................341
NFront Turn Signal.....................342
298 MAINTAINING YOUR VEHICLE

CAUTION!
Do not use Automatic Transmission Fluid (ATF) or
other types of power steering fluids when servicing
the power steering system of this vehicle. Damage to
the power steering system can result from the use of
the wrong power steering fluid.
Checking the power steering fluid level at a defined
service interval is not required. The fluid should only be
checked if a leak is suspected, abnormal noises are
apparent, and/or the system is not functioning as antici-
pated. Coordinate inspection efforts through a certified
ªDaimlerChrysler Dealership.º
WARNING!
Fluid level should be checked on a level surface with
the engine off to prevent injury from moving parts,
and to insure accurate fluid level reading. Do not
overfill. Use only the manufacturer's recommended
fluid.
If necessary, add fluid to restore to the proper indicated
level. With a clean cloth, wipe any spilled fluid from all
surfaces. Refer to Fluids, Lubricants, and Genuine Parts
for correct fluid type.
NOTE:Upon initial start-up in cold weather, the power
steering pump may make noise for a short period of time.
This is due to the cold, thick fluid in the steering system.
This noise should be considered normal, and does not in
any way damage the steering system.
MAINTAINING YOUR VEHICLE 315
7

CAUTION!
Do not allow petroleum base fluid to contaminate
the brake fluid, all brake seal components could be
damaged causing partial or complete brake failure.
Fuel System Hoses
Electronic Fuel Injection high pressure fuel systems are
designed with hoses and quick connect fittings which
have unique material characteristics to provide adequate
sealing and resist attack by deteriorated gasoline.
You are urged to use only the manufacturer's specified
hoses with quick connect fittings, or their equivalent in
material and specification, in any fuel system servicing. It
is mandatory to replace any damaged hoses or quick
connect fittings that have been removed during service.Care should be taken in installing quick connect fittings
to insure they are properly installed and fully connected.
See your authorized dealer for service.
Automatic Transmission
Fluid Level Check
Regular automatic transmission fluid level checks are not
required. For this reason the dipstick is omitted.
If you notice fluid loss or gear shift malfunction, have
your authorized dealer check the transmission fluid level.
MAINTAINING YOUR VEHICLE 327
7

ABS (Anti-Lock Brake System)............173,245
Adding Engine Coolant (Antifreeze).......... 320
Adding Fuel........................... 274
Adding Washer Fluid..................... 165
Additives, Fuel......................... 272
Adjustable Pedals....................... 126
Air Conditioner Maintenance............... 313
Air Conditioning, Operating Tips............ 228
Air Conditioning Refrigerant............... 314
Air Pressure, Tires....................... 260
Airbag................................ 43
Airbag Deployment....................... 50
Airbag Light.......................52,66,173
Airbag Maintenance....................... 51
Alarm (Security Alarm).................18,174
Alarm System (Security Alarm)............... 18
Alignment and Balance................... 266
Alterations/Modifications, Vehicle............. 9
Antenna, Satellite Radio................... 218Antifreeze (Engine Coolant)..............319,346
Disposal............................ 321
Anti-Lock Brake System (ABS)............131,245
Anti-Lock Warning Light.................. 173
Anti-Theft System.....................18,174
Appearance Care........................ 329
Auto Down Power Windows................ 30
Automatic Dimming Mirror................. 74
Automatic Door Locks..................... 27
Automatic Headlights..................... 115
Automatic Temperature Control (ATC)......... 222
Automatic Transmission.............239,327,328
Adding Fluid......................... 328
Fluid and Filter Changes................. 328
Fluid Change......................... 328
Fluid Level Check...................... 327
Autostick............................. 241
Auxiliary Electrical Outlet (Power Outlet)...... 155
Auxiliary Power Outlet................... 155
378 INDEX

Battery............................... 312
Emergency Starting..................... 293
Keyless Transmitter Replacement (RKE)....... 23
Saving Feature (Protection)............... 114
Bearings.............................. 329
Belts, Drive............................ 309
Belts, Seat.............................. 35
Body Mechanism Lubrication............... 316
B-Pillar Location........................ 254
Brake Assist System...................... 132
Brake Control System, Electronic............. 131
Brake System........................... 324
Anti-Lock (ABS)....................131,245
Fluid Check.......................... 325
Hoses.............................. 324
Parking............................. 244
Warning Light........................ 172
Brake/Transmission Interlock............... 238
Break-In Recommendations, New Vehicle........ 64Bulb Replacement.....................340,341
Camera, Rear........................... 143
Capacities, Fluid........................ 346
Caps, Filler
Fuel................................ 274
Radiator (Coolant Pressure)............... 321
Car Washes............................ 330
Carbon Monoxide Warning............65,146,273
Cargo Area Cover....................... 159
Cargo Area Features...................... 158
Cargo Compartment...................... 158
Light............................... 158
Cargo Light............................ 158
Cargo Load Floor........................ 163
Cargo Tie-Downs........................ 161
Catalytic Converter...................... 310
Caution, Exhaust Gas..................... 146
CD (Compact Disc) Player................. 195
INDEX 379
