3. CHECK REAR SEAT CONTROL UNIT HARNESS
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R (heated seat relay) and rear seat control unit connector.
3. Check continuity between IPDM E/R (heated seat relay) con-
nector and rear seat control unit connector.
4. Check continuity between rear seat control unit connector and
ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness between rear seat control unit and IPDM E/R (heated seat relay).
4. CHECK REAR SEAT CONTROL UNIT GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect rear seat control unit connector.
3. Check continuity between rear seat control unit connector and
ground.
OK or NG
OK >> Rear seat control unit power supply and ground circuit is OK.
NG >> Repair or replace harness between rear seat control unit and ground.
AB
Continuity
Rear seat control
unit connectorTerminalIPDM E/R
(heated seat relay)
connectorTerminal
B303 (LH)
4E6 12
Ye s
B353 (RH) E5 9
A
GroundContinuity
Rear seat control unit connector Terminal
B303 (LH)
B353 (RH)4No
PIIB5999E
Terminal
Continuity
Rear seat control
unit connectorTerminal
Ground B303 (LH)
B353 (RH)8
Ye s
B304 (LH)
B354 (RH)13
PIIB6000E

SE-158
HEATED SEAT
Revision: 2007 April2007 M35/M45
Check Rear Heated Seat Indicator Power Supply CircuitNIS0028A
1. CHECK REAR HEATED SEAT INDICATOR POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect rear heated seat switch connector.
3. Check voltage between rear heated seat switch connector and
ground.
OK or NG
OK >> GO TO 3.
NG >> GO TO 2.
2. CHECK REAR HEATED SEAT INDICATOR HARNESS
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R (heated seat relay) connector.
3. Check continuity between IPDM E/R (heated seat relay) con-
nector and rear heated seat switch connector.
4. Check continuity between rear heated seat switch connector
and ground.
OK or NG
OK >> Check the condition of the harness and connector.
NG >> Replace or replace harness between IPDM E/R (heated seat relay) and rear heated seat switch.
Terminal
ConditionVoltage (V)
(Approx.) (+)
(–) Rear heated
seat switch
connectorTerminal
B507 (LH)
B558 (RH)6GroundIgnition
switchON Battery voltage
OFF 0
PIIB6005E
AB
Continuity
Rear heated seat
switch connectorTe r m i n a lIPDM E/R
(heated seat relay)
connectorTerminal
B507 (LH)
6E6 12
Ye s
B558 (RH) E5 9
A
GroundContinuity
Rear heated seat
switch connectorTerminal
B507 (LH)
B558 (RH)6No
PIIB6006E

STC-2Revision: 2007 April2007 M35/M45 Inspection 3: RAS Motor Output Malfunction ......... 37
Inspection 4: Vehicle Speed Signal ........................ 38
Inspection 5: Steering Angle Signal Malfunction .... 39
Inspection 6: Rear Main Signal and Rear Sub Signal
Malfunction ............................................................. 40
Inspection 7: VDC Malfunction ............................... 43
Inspection 8: Engine Speed Signal Malfunction ..... 44
Inspection 9: CAN Communication System Mal-
function ................................................................... 44Inspection 10: Stop Lamp Switch Harness ............. 45
Inspection 11: RAS Warning Lamp Harness ........... 46
Diagnosis Chart by Symptom 1 .............................. 47
Diagnosis Chart by Symptom 2 .............................. 47
Check RAS Static/Dynamic Characteristics ............ 49
Component Inspection ............................................ 50
RAS MOTOR RELAY ........................................... 50
RAS MOTOR ....................................................... 50
REAR WHEEL STEERING ANGLE SENSOR .... 50

TROUBLE DIAGNOSIS
STC-19
[RAS]
C
D
E
F
H
I
J
K
L
MA
B
STC
Revision: 2007 April2007 M35/M45
Component Parts LocationNGS000EC
A. RAS warning lamp B. Steering angle sensor C. RAS control unit
D. RAS motor relay E. RAS motor F. Rear wheel steering angle sensor
G. Noise suppressor
SGIA1053J

TROUBLE DIAGNOSIS
STC-27
[RAS]
C
D
E
F
H
I
J
K
L
MA
B
STC
Revision: 2007 April2007 M35/M45
STANDARD BY CONSULT-II
CAUTION:
The output signal indicates the RAS control unit calculation data. The normal values will be displayed
even in the event that the output circuit (harness) is open.
CONSULT-II Function (RAS/HICAS)NGS000EG
FUNCTION
CONSULT-II can display each self-diagnostic item using the diagnostic test modes shown following.
Monitor item Condition Reference values
VHCL SPEED SE [km/h] or [mph] Ignition switch ON or engine running Almost in accordance with the speedome-
ter display. It is not a malfunction, through
it might not be corresponding just after
ignition switch is turned ON.
STEERING ANG [°]Turning steering wheel clockwise or coun-
terclockwise.Displays the angle when the steering
wheel turns from the neutral position
ENGINE SPEED [rpm] Engine runningAlmost in accordance with tachometer dis-
play
POWER STR SOL [A]Accelerate the vehicle from 0 to 100 km/h
(0 to 62 MPH)0 km/h (0 MPH): Approx. 1.10 A
100 km/h (62 MPH): Approx. 0.54 A
RR ST ANG-MAI [V]
Perform the ACTIVE TEST and stroke the
actuator (with tires off the ground)Neutral: Approx. 2.4 V
Turn steering wheel to right for full stroke:
Approx. 4.4 V
Turn steering wheel to left for full stroke:
Approx. 0.4 V RR ST ANG-SUB [V]
RR ST ANG-VOL [V]
Ignition switch ON or engine runningApprox. 5 V
C/U VOLTAGE [V]Battery voltage (Approx. 12 V)
MOTOR VOLTAGE [V] Battery voltage (Approx. 12V)
MOTOR CURRENT [A]Perform the ACTIVE TEST and stroke the
actuator.It is normal when there is the current out-
put at stroke
MTR CRNT OPE [A]Turning steering wheel clockwise or coun-
terclockwise while ignition switch is ON or
running the engineNeutral (Steering force is zero and straight-
ahead position): Approx. 0 A
The value is changed according to steering
left or right
RR ANGLE OPE [°]RAS actuator assembly turned full right Approx. 1°
RAS actuator assembly neutral Approx. 0°
RAS actuator assembly turned full left Approx. - 1°
STOP LAMP SW [ON/OFF] Depressing or releasing brake pedalBrake pedal depressed: ON
Brake pedal not depressed: OFF
HICAS RELAY [ON/OFF]
Ignition switch ON or engine runningIgnition switch ON: ON
FAIL SAFE [ON/OFF] Not activated
WARNING LAMP (ON/OFF)RAS warning lamp ON: ON
RAS warning lamp OFF: OFF
Diagnostic test mode Function Reference page
SELF-DIAG RESULTSReceives self-diagnosis results from RAS control unit and
indicates DTCs.STC-28, "
SELF-DIAG
RESULT MODE"
DATA MONITORReceives input/output signals from RAS control unit and
indicates and stores them to facilitate locating cause of mal-
functions.STC-30, "DATA MONI-
TOR MODE"
CAN DIAG SUPPORT MNTRMonitors transmitting/receiving status of CAN communica-
tion.LAN-44, "CAN Diagnos-
tic Support Monitor"
ACTIVE TESTSends command to RAS actuator to change output signals
and check operation of output system.STC-30, "ACTIVE TEST
MODE"
ECU PART NUMBER Displays RAS control unit part number.STC-30, "RAS CONTROL
UNIT PART NUMBER"

STC-28
[RAS]
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
CONSULT-II SETTING PROCEDURE
Refer to GI-38, "CONSULT-II Start Procedure" .
SELF-DIAG RESULT MODE
Operation Procedure
1. Perform “CONSULT-II Start Procedure”. Refer to GI-38, "CONSULT-II Start Procedure" .
2. Touch “PRINT” to print out the self-diagnostic results if necessary. Check RAS warning lamp if “NO FAIL-
URE” is displayed.
3. Perform the appropriate inspection from the display item list, and repair or replace the malfunctioning
component. Refer to STC-28, "
Display Item List" .
Display Item List
CAUTION:
When malfunctions are detected in several systems, including the “CAN COMM [U1000]” and “CON-
TROL UNIT (CAN) [U1010]”, inspect the CAN communication system.
DTC Diagnostic item Diagnostic item is detected when... Check items
C1923 STEERING ANGLE SEN [NO CHANGE]While driving at 60 km/h (37 MPH)
or more, steering angle does not
change for a while.STC-39
C1924 STEERING ANGLE SEN [NO NEUT STATE]When driving some distance, no
neutral signal (ON signal) is input.STC-39
C1915 RR ST ANGLE SENSOR [MAIN SIGNAL]The main sensor input signal is
malfunctioning for some time
against the sensor power supply
value.STC-40
C1916 RR ST ANGLE SENSOR [SUB SIGNAL]When the main sensor input signal
is 2.4 - 2.6 V, the sub sensor input
signal is malfunctioning for some
time compared to the sensor power
supply value.STC-40
C1917 RR ST ANGLE SENSOR [OFFSET SIG1] An excessive difference has
occurred in the input values of main
sensor and sub sensor.STC-40
C1918 RR ST ANGLE SENSOR [OFFSET SIG2]
C1914 RR ST ANGLE SENSOR [ABNORMAL VOL]Higher or lower value compared to
the standard voltage.STC-40
C1921 MOTOR OUTPUTNo engine speed is input for a cer-
tain time.STC-44
C1911 MOTOR VOLTAGE [LOW VOLTAGE]The motor power supply voltage is
lower than ignition power supply
voltage with RAS motor relay ON.STC-35
C1912 MOTOR VOLTAGE [BAD OBSTRCT]The motor power supply voltage is
inputting for some time with motor
power supply OFF by RAS control
unit.STC-35
C1913 MOTOR OUTPUT [ABNORMAL SIG]When the motor current value is 10
A or more, actual output is exces-
sively low and the condition contin-
ues for some time.STC-37
C1902 MOTOR OUTPUT [REV CURRENT]The current flows in the opposite
direction when the motor current is
output. STC-37
C1903 MOTOR OUTPUT [NO CURRENT]The current flows when the motor
current is not output. STC-37
C1904 MOTOR OUTPUT [OVERCURRENT]The excessive high current flows
when the motor current is output.STC-37

STC-30
[RAS]
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
DATA MONITOR MODE
Operation Procedure
1. Perform “CONSULT-II Start Procedure”. Refer to GI-38, "CONSULT-II Start Procedure" .
2. Touch “DATA MONITOR”.
3. Select from “SELECT MONITOR ITEM”, screen of data monitor is displayed.
NOTE:
When malfunction is detected, CONSULT-II performs REAL-TIME DIAGNOSIS. Also, any malfunction
detected while in this mode will be displayed in real time.
Display Item List
ACTIVE TEST MODE
Operation Procedure
1. Perform “CONSULT-II Start Procedure”. Refer to GI-38, "CONSULT-II Start Procedure" .
2. When turning the steering wheel right or left, the rear wheel turns in the same direction. If the steering
wheel is not turned, the rear wheel turns left and right 5 times.
RAS CONTROL UNIT PART NUMBER
1. Perform “CONSULT-II Start Procedure”. Refer to GI-38, "CONSULT-II Start Procedure" .
2. The part number described on RAS control unit sticker is displayed.
Item [Display or Unit] Remarks
VHCL SPEED SE [km/h] or [mph] Vehicle speed received via CAN communication is displayed.
STEERING ANG [°] Steering angle received via CAN communication is displayed.
ENGINE SPEED [rpm] Engine speed received via CAN communication is displayed.
POWER STR SOL [A]Power steering solenoid controlling current that RAS control unit
outputs is displayed.
RR ST ANG-MAI [V]Rear wheel steering angle main sensor output voltage is dis-
played.
RR ST ANG-SUB [V] Rear wheel steering angle sub sensor output voltage is displayed.
RR ST ANG VOL [V]Voltage supplied from RAS control unit to rear wheel steering
angle sensor is displayed.
C/U VOLTAGE [V] Voltage supplied to RAS control unit is displayed.
MOTOR VOLTAGE [V] Voltage supplied from RAS control unit to RAS motor is displayed.
MOTOR CURRENT [A]RAS motor relay controlling current that RAS control unit outputs
is displayed.
MOTOR CRNT OPE [A] Current commanded value to RAS motor is displayed.
RR ANG OPE [°]Angle commanded value to rear wheel steering angle sensor is
displayed.
STOP LAMP SW [ON/OFF] Condition of stop lamp switch ON/OFF is displayed.
HICAS RELAY [ON/OFF] RAS motor relay ON/OFF condition is displayed.
FAILSAFE [ON/OFF] Fail-safe ON/OFF condition is displayed.
WARNING LAMP [ON/OFF] RAS warning lamp operating condition is displayed.
STEERING ANG RR ST ANG MAI RR ST ANG SUB MOTOR CURRENT
0° (Neutral) 2.4 V 2.4 V No output (Approx. 0 A)
R 90°Approx. 4.4 V Approx. 4.4 V
Output (change)
L 90°Approx. 0.4 V Approx. 0.4 V

STC-36
[RAS]
TROUBLE DIAGNOSIS
Revision: 2007 April2007 M35/M45
2. CHECK RAS MOTOR RELAY BATTERY CIRCUIT
1. Turn ignition switch OFF, and disconnect RAS motor relay harness connector B480.
2. Check voltage between RAS motor relay harness connector
B480 and ground.
OK or NG
OK >> GO TO 3.
NG >> RAS motor relay power supply circuit open or shorted.
Repair or replace power supply circuit and fuse.
3. CHECK RAS MOTOR RELAY HARNESS
1. Disconnect RAS motor relay harness connector B480 and RAS control unit harness connector B476.
2. Check continuity between RAS motor relay harness connector
B480 and RAS control unit harness connector B476.
3. Check continuity between RAS motor relay harness connector
B480 and ground.
OK or NG
OK >> GO TO 4.
NG >> RAS motor relay harness open or shorted. Repair or replace applicable malfunctioning harness.
4. CHECK RAS MOTOR RELAY RESISTANCE
Check the resistance between RAS motor relay connector.
OK or NG
OK >> GO TO 5.
NG >> RAS motor relay malfunction (replacement)Terminal 3 – Ground : Battery voltage (Approx. 12 V)
SGIA1246E
Terminal 5 – 37 : Continuity should exist.
Terminal 1 – 25 : Continuity should exist.
2 – Ground : Continuity should exist.
SGIA1265E
Terminal 1 – 2 : Approx. 74 Ω
SGIA1266E
