TroubleshootingNKS004F4

The electronic compass is highly protected from changes in most magnetic fields. However, some large
changes in magnetic fields can affect it. Some examples are (but not limited to): high tension power lines,
large steel buildings, subways, steel bridges, automatic car washes, large piles of scrap metal, etc. While
this does not happen very often, it is possible.

During normal operation, the Compass Mirror will continuously update the compass calibration to adjust
for gradual changes in the vehicle's magnetic “remnant” field. If the vehicle is subjected to high magnetic
influences, the compass may appear to indicate false headings, become locked, or appear that it is
unable to be calibrated. If this occurs, perform the calibration procedure.

If at any time the compass continually displays the incorrect direction or the reading is erratic or locked,
verify the correct zone variance.
Troubleshooting Chart
Symptom Cause Solution / Reference
The compass display reads “C”.

Compass is not calibrated.

Incorrect zone variance setting.

Large change in magnetic field (Steel
bridges, subways, concentrations of
metal, carwashes, etc.)

Compass was calibrated incorrectly or in
the presence of a strong magnetic field.Perform Calibration.
Refer to DI-104, "
Calibration Procedure" . Compass shows the wrong direction.
Compass does not change direction –
appears “Locked”.
Compass does not show all the directions,
one or more is missing.
The compass was calibrated but it “loses”
calibration.
On long trips the compass shows the
wrong direction.Perform Zone Variation Setting if correct
reading is desired in that location.
Refer to DI-104, "
Zone Variation Setting
Procedure" .
Compass does not work – No direction is
displayed.Compass not turned ON.Check for green LED indicator (inside mir-
ror switch).
No power to inside mirror. Check power supply circuit.

DI-104
COMPASS
Revision: 2007 April2007 M35/M45
Zone Variation Setting ProcedureNKS004F5
NOTE:
The zone setting is factory preset (“default” setting) to zone 8.
1. Press and hold the compass switch for 3 – 9 seconds.
2. The current zone setting appears on the compass display.
3. Find the current geographical location number in the Zone Varia-
tion Chart.
4. Select the new zone number. (Press the compass switch until
the new zone number appears on the compass display.)
5. After select the new zone number, the compass display will
automatically shows a direction within a few seconds.
6. Preform the following Calibration Procedure for more accurate
indications.
Calibration ProcedureNKS004F6
NOTE:
The compass calibrates itself under normal driving conditions. However, occasional circumstances may cause
the compass to operate inaccurately. Example: Driving from rural (wide open) areas to crowded city areas, or
if an aftermarket (i.e., non original equipment) antenna with a magnetic base is attached to the vehicle. Cali-
brate the mirror compass if the display shows only one direction or a limited number of directions.
NOTE:

If “magnetic hats” are used in the dealership for vehicle identification, remove the hat from the vehicle
before performing the following steps. Do NOT put the hat back on the vehicle after the procedure is com-
pleted.

Drive the vehicle to an open level area; away from large metallic objects, structures, and overhead power
lines.

Turn off “non-essential” electrical accessories (rear window defrost, heater/air conditioning, wipers) and
close the doors.
1. Verify the correct compass zone setting for the geographical location. Refer to DI-104, "
Zone Variation
Setting Procedure" .
2. Press and hold the compass switch for more than 9 seconds.
3. “C” is displayed on the compass display, when calibration starts.
4. Drive slowly [less than 8 km/h (5 mph)] in a circle until the “C / CAL” is replaced with primary headings (N,
NE, E, SE, S, SW, W, or NW).
NOTE:
This will require driving at least 2 complete 360 degree circles; 3 complete circles may be required.
5. The compass calibration procedure is now complete. The compass should operate normally.
NOTE:
If at any time the compass continually displays the incorrect direction or the reading is erratic or locked,
repeat the calibration procedure.
SEL168Y

DI-106
COMPASS
Revision: 2007 April2007 M35/M45
Removal and Installation of CompassNKS003W7
Refer to GW-69, "INSIDE MIRROR" .

DOOR OUTSIDE MOLDING
EI-29
C
D
E
F
G
H
J
K
L
MA
B
EI
Revision: 2007 April2007 M35/M45
DOOR OUTSIDE MOLDING PFP:82820
Removal and InstallationNIS0024Q
FRONT DOOR OUTSIDE MOLDING
Removal
1. Fully open door window.
2. Remove door trim. Refer to EI-34, "
DOOR FINISHER" .
3. Remove front door sash cover inner. Refer to EI-36, "
FRONT DOOR SASH COVER INNER" .
4. Disconnect harness connector for tweeter (only for models with tweeter). Refer to AV- 2 7 8 , "
Tw e e t e r" .
5. Remove door mirror. Refer to GW-118, "
Removal and Installation" .
6. Disengage pawls by inserting a screwdriver to front and rear of
pawl inter grated with cap.
7. Remove door outside molding while pulling up molding using plastic spatula after disengaging.
1. Door outside molding (front) 2. Door outside molding (rear) 3. Door mirror
4. Front door outer 5. Rear door outer
PIIB2754J
PIIB4192J

EI-36
DOOR FINISHER
Revision: 2007 April2007 M35/M45
FRONT DOOR SASH COVER INNER
Removal
1. Remove front door finisher.
2. Disconnect harness connector for door mirror and tweeter.
3. Remove clips of front door sash cover inner.
4. Remove front door sash cover inner.
Installation
Install in the reverse order of removal.
REAR DOOR SASH COVER INNER
Removal
1. Remove rear door finisher.
2. Remove clip of rear door sash cover inner.
3. Remove rear door sash cover inner.
Installation
Install in the reverse order of removal.
PIIB4934E
PIIB4935E

HEADLINING
EI-53
C
D
E
F
G
H
J
K
L
MA
B
EI
Revision: 2007 April2007 M35/M45
REMOVAL
1. Remove front pillar garnish (LH/RH). Refer to EI-37, "BODY SIDE TRIM" .
2. Remove roof harness and antenna feeder securing clip using a clip clamp remover after removing front
pillar garnish (LH/RH), and then disconnect roof harness and antenna feeder connectors.
3. Remove rear seat cushion and seatback. Refer to SE-173, "
REAR SEAT" .
4. Remove front kicking plate inner, center pillar lower garnish, center pillar upper garnish, front body side
welt, rear kicking plate inner, rear wheelhouse garnish, rear pillar finisher, rear body side welt. Refer to EI-
37, "BODY SIDE TRIM" .
5. Disconnect antenna feeder connectors of antenna amplifier and
sub-antenna feeder after removing rear pillar finisher (LH), and
then remove antenna feeder securing clip using a remover.
6. Models with sunroof: Remove mounting plastic clips of front
assistance grip (LH/RH) and rear assistance grip (LH/RH), and
then remove bolts.
Models with standard roof: Remove mounting plastic clips of
front assistance grip (LH) and rear assistance grip (LH/RH).
CAUTION:

Always use SST, and attach a cloth to protect from dam-
age.

Assistance grip is crimped from back of headlining.
Remove it by disengaging the crimping area of back of
lamp after removing headlining from the vehicle.
7. Remove screws on personal lamp (in coat hanger hook).
8. Remove rear display unit. (models with mobile entertainment system) Refer to AV- 2 8 3 , "
Rear Display
Unit" .
9. Remove sun visor bracket cover and mounting screws, and then remove sun visors (LH/RH).
NOTE:
Disconnect vanity mirror illumination harness connector when removing sun visor.
10. Remove screws of dual-visor, and then remove dual-visor (LH/RH).
11. Insert a screwdriver into the sun visor holder cutout and rotate
90 degrees to remove sun visor holder (LH/RH).
12. Remove map lamp assembly. (models with LDW system)
13. Remove passenger seat assembly. Refer to SE-164, "
FRONT SEAT" .
14. Using a removal tool, remove body side mounting plastic clip from rear side of headlining.
