Trouble Diagnosis Symptom ChartNIS001NK
ALL FUNCTIONS OF THE INTELLIGENT KEY ARE NOT OPERATING
REMOTE CONTROL ENTRY FUNCTION MALFUNCTION
Symptom Diagnoses service procedure Refer to page
“KEY” and “P shift” warning lamps in combination
meter do not light up at all. 1.
Check Intelligent Key unit power supply and ground
circuit BL-124
2. Check CAN communication
BL-124
3. Replace Intelligent Key unitBL-146
“KEY” and “P shift” warning lamps in combination
meter turn on, but doors cannot be locked/
unlocked or the engine can not be started using
Intelligent Key. 1.
Use CONSULT-II to check if the Intelligent Key has
been registered Refer to
CONSULT-II Operation Manual
2. Use CONSULT-II setting change function to check if
Intelligent Key system has been cancelled BL-116
3. Intelligent Key battery inspection
BL-147
4. Replace Intelligent Key unitBL-146
Symptom Diagnoses service procedure Refer to page
Door lock/unlock does not operate (other func-
tions normal) when Intelligent Key remote con-
troller button is operated. 1. Check door lock/unlock setting
BL-116
2. Intelligent Key battery inspectionBL-147
3. Check door unlock sensorBL-131
4. Check door switchBL-129
5. Replace BCMBCS-14
6. Replace Intelligent Key unit BL-146
Driver side selective door unlock function does
not operate, when Intelligent Key remote control-
ler button is operated.
(All other remote control entry function is OK.) 1. Check selective door unlock setting
BL-116
2. Replace BCMBCS-14
3. Replace Intelligent Key unit BL-146
Panic alarm (horn and headlamp) do not acti-
vate, when panic alarm button is continuously
pressed.
(All other remote control entry function is OK.) 1. Check panic alarm mode
BL-116
2. Check headlamp functionBL-145
3. Check horn functionBL-145
4. Check IPDM E/R operationBL-145
5. Check key switch (Intelligent Key unit input)BL-125
6. Check ignition knob switchBL-127
7. Replace Intelligent Key unitBL-146
Hazard lamps do not flash during door lock oper-
ation using Intelligent Key remote controller but-
ton operated.
(Turn signal lamp operation is OK.)
(All other remote control entry function is OK.) 1. Check key reminder setting
BL-116
2. Replace BCMBCS-14
3. Replace Intelligent Key unit BL-146
Hazard lamps do not flash during door lock oper-
ation using Intelligent Key remote controller but-
ton operated.
(Turn signal lamps do not operate.) Check hazard function
BL-145
Intelligent Key warning buzzer does not sound
during door lock/unlock operation using Intelli-
gent Key remote controller button is operated.
(All other remote control entry function is OK.) 1.
Check if the operation confirmation Intelligent Key
warning buzzer was cancelled by the CONSULT-II set-
tings change function BL-116
2. Check Intelligent Key warning buzzer
BL-134
3. Replace Intelligent Key unitBL-146

BL-120
INTELLIGENT KEY SYSTEM
Revision: 2006 July 2007 FX35/FX45
DOOR LOCK FUNCTION MALFUNCTION
Before conducting the diagnosis in the following table, check all power door lock system function. Refer to BL-
21, "POWER DOOR LOCK SYSTEM" .
Symptom Diagnoses service procedure Refer to page
Door lock/unlock does not operate when door
request switch operation is used (power door
lock system is normal). 1. Check door lock/unlock setting
BL-116
2. Check outside key antennaBL-135
3. Intelligent Key battery inspectionBL-147
4. Replace Intelligent Key unitBL-146
Door lock/unlock do not operate using door
request switch operated (power door lock sys-
tem is normal). 1. Check door switch
BL-1292. Check key switch (Intelligent Key unit input)BL-125
3. Check ignition knob switchBL-127
4. Replace Intelligent Key unitBL-146
Driver side selective door unlock function does
not operate, when door request switch is oper-
ated.
(All other door lock function is OK.) 1. Check selective door unlock setting
BL-116
2. Replace BCMBCS-14
Passenger side selective door unlock function
does not operate, when door request switch is
operated.
(All other door lock function is OK.) 1. Check selective door unlock setting
BL-116
2. Check passenger side select unlock relayBL-144
3. Replace Intelligent Key unitBL-146
Hazard lamps do not flash during door lock
operation using door request switch operated.
(Turn signal lamp operation is normal.)
(All other door lock function is OK.) 1. Check key reminder setting
BL-116
2. Replace BCMBCS-14
3. Replace Intelligent Key unit BL-146
Hazard lamps do not flash during door lock
operation using door request switch operated.
(Turn signal lamps do not operate.) Check hazard function
BL-145

Intelligent Key warning buzzer does not sound
during door lock/unlock operation using Intelli-
gent Key (regardless of whether Intelligent Key
remote controller button or request switch oper-
ation is used). 1. Check if the operation confirmation Intelligent Key
warning buzzer was cancelled by the CONSULT-II
settings change function BL-116
2. Check Intelligent Key warning buzzer
BL-134
3. Replace Intelligent Key unitBL-146
Door lock/unlock operation confirmation Intelli-
gent Key warning buzzer sounds, but door lock
actuator does not operate. (And hazard lamps
do not flash.) 1. Check CAN communication
BL-124
2. Replace Intelligent Key unitBL-146

BL-184
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: 2006 July 2007 FX35/FX45

through back door closure motor terminal 8

through body grounds B15 and B45.
VEHICLE SECURITY SYSTEM ALARM OPERATION
The vehicle security system is triggered by

opening a door

opening the back door

opening the hood

detection of battery disconnect and connect.
The vehicle security system will be triggered once the system is in armed phase,
When BCM receives a ground signal at terminals 12 (passenger side door), 13 (rear RH door), 58 (back door),
62 (driver side door), 63 (rear LH door), or receives a signal from the IPDM E/R (hood switch).
When the vehicle security system is triggered,
ground is supplied intermittently from IPDM E/R terminals 38 and 60.
When headlamp high relay (with built-in IPDM E/R) and horn relay are energized and then power is supplied
to headlamps (LH and RH) and horns (HIGH and LOW).
The headlamps flash and the horn sounds intermittently.
The alarm automatically turns off after 50 seconds, but will reactivate if the vehicle is tampered with again.
VEHICLE SECURITY SYSTEM DEACTIVATION
To deactivate the vehicle security system, a door or the back door must be unlocked with the key, key fob or
Intelligent Key.
When the key is used to unlock a door, BCM terminal 22 receives signal

from terminal 14 of the power window main switch (door lock and unlock switch).
When the BCM receives either one of these signals or unlock signal from key cylinder switch, key fob or Intel-
ligent Key, the vehicle security system is deactivated. (Disarmed phase)
PANIC ALARM OPERATION
Remote keyless entry system may or may not operate vehicle security system (horn and headlamps) as
required.
When the remote keyless entry system is triggered, ground is supplied intermittently from IPDM E/R terminals
38 and 60.
When headlamp relay (which built-in IPDM E/R) and horn relay are energized and then power is supplied to
headlamps (LH and RH) and horns (HIGH and LOW).
The headlamp flashes and the horn sounds intermittently.
The alarm automatically turns off after 25 seconds or when BCM receives any signal from key fob or Intelligent
Key.
CAN Communication System DescriptionNIS001P4
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN Communication UnitNIS001P5
Refer to LAN-49, "CAN System Specification Chart" .

BL-194
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Revision: 2006 July 2007 FX35/FX45
Trouble DiagnosisNIS001PB
WORK FLOW

“POWER DOOR LOCK SYSTEM” Diagnosis; refer to BL-37, "Work Flow" .

“REMOTE CONTROL SYSTEM” Diagnosis; refer to BL-66, "Work Flow" .

“INTELLIGENT KEY SYSTEM” Diagnosis; refer to BL-115, "WORK FLOW" .
PIIA6909E

LT-2Revision: 2006 July 2007 FX35/FX45
Preliminary Check ...............................................
... 48
CHECK POWER SUPPLY AND GROUND CIR-
CUIT ................................................................. ... 48
INSPECTION PARKING BRAKE SWITCH CIR-
CUIT ................................................................. ... 49
CONSULT-II Functions (BCM) ............................. ... 50
CONSULT-II BASIC OPERATION .................... ... 50
DATA MONITOR ............................................... ... 50
ACTIVE TEST .................................................. ... 51
Daytime Light Control Does Not Operate Properly ... 52
Aiming Adjustment ............................................... ... 54
Bulb Replacement ............................................... ... 54
Removal and Installation ..................................... ... 54
Disassembly and Assembly ................................. ... 54
AUTO LIGHT SYSTEM .......................................... ... 55
Component Parts and Harness Connector Location ... 55
System Description .............................................. ... 55
OUTLINE .......................................................... ... 55
COMBINATION SWITCH READING FUNCTION ... 56
DELAY TIMER FUNCTION .............................. ... 56
CAN Communication System Description ........... ... 56
CAN Communication Unit .................................... ... 56
Major Components and Functions ....................... ... 56
Schematic ............................................................ ... 57
Wiring Diagram — AUTO/L — ............................. ... 58
Terminals and Reference Values for BCM ........... ... 61
Terminals and Reference Values for IPDM E/R ... ... 63
How to Proceed With Trouble Diagnosis ............. ... 63
Preliminary Check ............................................... ... 64
SETTING CHANGE FUNCTIONS .................... ... 64
CHECK POWER SUPPLY AND GROUND CIR-
CUIT ................................................................. ... 64
CONSULT-II Functions (BCM) ............................. ... 66
CONSULT-II BASIC OPERATION .................... ... 66
WORK SUPPORT ............................................ ... 66
DATA MONITOR ............................................... ... 66
ACTIVE TEST .................................................. ... 68
CONSULT-II Functions (IPDM E/R) ..................... ... 68
CONSULT-II BASIC OPERATION .................... ... 68
DATA MONITOR ............................................... ... 68
ACTIVE TEST .................................................. ... 69
Symptom Chart .................................................... ... 69
Lighting Switch Inspection ................................... ... 70
Optical sensor System Inspection ....................... ... 70
Removal and Installation of Optical Sensor ......... ... 72
REMOVAL ........................................................ ... 72
INSTALLATION ................................................. ... 72
HEADLAMP AIMING CONTROL ........................... ... 73
Schematic ............................................................ ... 73
Wiring Diagram — H/AIM — ................................ ... 74
Removal and Installation ..................................... ... 77
REMOVAL ........................................................ ... 77
INSTALLATION ................................................. ... 77
Switch Circuit Inspection ..................................... ... 77
FRONT FOG LAMP ............................................... ... 78
Component Parts and Harness Connector Location ... 78
System Description .............................................. ... 78
OUTLINE .......................................................... ... 78 FRONT FOG LAMP OPERATION ....................
... 79
COMBINATION SWITCH READING FUNCTION ... 79
EXTERIOR LAMP BATTERY SAVER CONTROL ... 79
CAN Communication System Description ........... ... 79
CAN Communication Unit .................................... ... 79
Wiring Diagram — F/FOG — ............................... ... 80
Terminals and Reference Values for BCM ........... ... 82
Terminals and Reference Values for IPDM E/R ... ... 83
How to Proceed With Trouble Diagnosis ............. ... 83
Preliminary Check ................................................ ... 83
CHECK POWER SUPPLY AND GROUND CIR-
CUIT .................................................................. ... 83
CONSULT-II Functions (BCM) ............................. ... 84
CONSULT-II Functions (IPDM E/R) ..................... ... 84
Front Fog Lamps Do Not Illuminate (Both Sides) ... 85
Front Fog Lamp Does Not Illuminate (One Side) . ... 87
Aiming Adjustment ............................................... ... 88
Bulb Replacement ................................................ ... 89
Removal and Installation ...................................... ... 89
REMOVAL ......................................................... ... 89
INSTALLATION ................................................. ... 89
TURN SIGNAL AND HAZARD WARNING LAMPS ... 90
Component Parts and Harness Connector Location ... 90
System Description .............................................. ... 90
OUTLINE .......................................................... ... 90
TURN SIGNAL OPERATION ............................ ... 91
HAZARD LAMP OPERATION .......................... ... 91
REMOTE CONTROL ENTRY SYSTEM OPER-
ATION ............................................................... ... 92
COMBINATION SWITCH READING FUNCTION ... 92
CAN Communication System Description ........... ... 92
CAN Communication Unit .................................... ... 92
Schematic ............................................................ ... 93
Wiring Diagram — TURN — ................................ ... 94
Terminals and Reference Values for BCM ........... ... 97
Terminals and Reference Value for Rear Combina-
tion Lamp Control Unit ......................................... ... 98
How to Proceed With Trouble Diagnosis ............. .100
Preliminary Check ................................................ .100
CHECK POWER SUPPLY AND GROUND CIR-
CUIT .................................................................. .100
CONSULT-II Functions (BCM) ............................. .102
CONSULT-II BASIC OPERATION .................... .102
DATA MONITOR ............................................... .102
ACTIVE TEST ................................................... .102
Turn Signal Lamps Do Not Operate ..................... .103
Rear Turn Signal Lamp Does Not Operate .......... .105
Hazard Warning Lamp Does Not Operate But Turn
Signal Lamp Operate ........................................... .106
Bulb Replacement (Front Turn Signal Lamp) ....... .108
Bulb Replacement (Rear Turn Signal Lamp) ....... .108
Removal and Installation of Front Turn Signal Lamp .108
Removal and Installation of Rear Turn Signal Lamp .108
Removal and Installation of Rear Combination
Lamp Control Unit ................................................ .108
REMOVAL ......................................................... .108
INSTALLATION ................................................. .108

LT-92
TURN SIGNAL AND HAZARD WARNING LAMPS
Revision: 2006 July 2007 FX35/FX45

through rear combination lamp control unit terminal 9

to rear combination lamp RH terminal 3,

through rear combination lamp RH terminal 4

to rear combination lamp control unit terminal 8.
And hazard switch is depressed, ground is supplied

to hazard switch terminal 2

through BCM terminal 29,

to grounds M35, M45 and M85

through hazard switch terminal 1.
BCM sends signal to the unified meter and A/C amp. through CAN communication, and turns ON turn signal
indicator lamp with combination meter.
When rear turn signal lamp (LED) does not turn ON, rear combination lamp control unit sends signal to combi-
nation meter. And then unified meter and A/C amp. ends turn LED burnout status signal to BCM through CAN
communication lines for speeding up turn signal blinking.
REMOTE CONTROL ENTRY SYSTEM OPERATION
When the remote control entry system is triggered by input from key fob, BCM output turn signal from BCM
terminals 45 and 46, interpreting it as turn signal is ON.
Connected from BCM terminals 45 and 46 to front combination lamp RH and LH terminals 4.
Turn signal lamp turns ON

through front combination lamp RH and LH terminals 8

to grounds E21, E50 and E51.
Connected form BCM terminals 45 and 46 to rear combination lamp control unit terminals 4 and 5.
Rear turn signal (LED) turns ON

through rear combination lamp control unit terminal 11

to rear combination lamp LH terminal 3,

through rear combination lamp LH terminal 4

to rear combination lamp control unit terminal 10,

through rear combination lamp control unit terminal 9

to rear combination lamp RH terminal 3,

through rear combination lamp RH terminal 4

to rear combination lamp control unit terminal 8.
BCM sends signal to the unified meter and A/C amp. through the CAN communication, and turns ON turn sig-
nal indicator lamp with combination meter.
With power and input supplied, BCM controls the flashing of hazard warning lamps when key fob is used to
activate remote control entry system.
COMBINATION SWITCH READING FUNCTION
Refer to BCS-3, "COMBINATION SWITCH READING FUNCTION" .
CAN Communication System DescriptionNKS002XE
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN H line, CAN L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN Communication UnitNKS002XF
Refer to LAN-49, "CAN System Specification Chart" .

LT-174
INTERIOR ROOM LAMP
Revision: 2006 July 2007 FX35/FX45
NOTE:

1: Vehicle with Intelligent Key system display this item.

2: Vehicle with remote keyless entry system display this item.
ACTIVE TEST (BATTERY SAVER)
Operation Procedure
1. Touch “BATTERY SAVER” on “SELECT TEST ITEM” screen.
2. Touch “ACTIVE TEST” on “SELECT DIAG MODE” screen.
3. Touch item to be tested and check operation of the selected item.
4. During the operation check, touching “OFF” deactivates the operation.
Display Item List
Interior Room Lamp Control Does Not OperateNKS002YU
1. CHECK EACH SWITCH
Select “BCM” on CONSULT-II. With “INT LAMP” data monitor to
make sure switches listed in display item list turn ON-OFF linked
with switch operation. Refer to LT- 1 7 2 , "
Display Item List" for
switches and their functions.
OK or NG
OK >> GO TO 2.
NG >> Inspect malfunctioning switch system.
2. ACTIVE TEST
1. Select “BCM” on CONSULT-II. Select “INT LAMP” active test.
2. When interior room lamp switch is in DOOR position, use active test to make sure interior room lamp operates.
OK or NG
OK >> Replace BCM. Refer to BCS-14, "Removal and Installa-
tion of BCM" .
NG >> GO TO 3.
I − KEY UNLOCK NOTE 1“ON/OFF” Displays “Unlocked (ON)/Other (OFF)” status, determined from unlock signal.
KEYLESS LOCK
NOTE 2“ON/OFF” Displays status (door is locked: ON/other: OFF) of remote keyless entry system lock signal
from the remote key less entry receiver signal.
KEYLESS UNLOCK
NOTE 2“ON/OFF” Displays status (door is unlocked: ON/other: OFF) of remote keyless entry system unlock
signal from the remote key less entry receiver signal.
Monitor item Contents
Test item Description
BATTERY SAVER Interior room lamp can be operated by ON −OFF operations.
PKIB3532E
PKIA7641E

ILLUMINATION LT-187
C
D E
F
G H
I
J
L
M A
B
LT
Revision: 2006 July 2007 FX35/FX45

to clock (illumination) terminal 3

to hazard switch (illumination) terminal 3

to heated seat switch (driver side) (illumination) terminal 5

to heated seat switch (passenger side) (illumination) terminal 5

to door mirror remote control switch (illumination) terminal 16

to LDW switch (illumination) terminal 5

to combination switch (spiral cable) terminal 26

to microphone terminal 2 (with telephone system)

to A/C and AV switch (illumination) terminal 3

to DVD player (illumination) terminal 12

to coin box illumination terminal 2 and

to rear power window switch LH and RH (illumination) terminals 6,

through combination switch (spiral cable) terminal 18

to audio steering switch (illumination)

to icc steering switch (illumination) (with icc) and

to ascd steering switch (illumination) (without icc)
Illumination control

through combination meter terminal 19

to A/T device (illumination) terminal 12

to snow mode switch (illumination) terminal 6

to VDC off switch (illumination) terminal 4

to clock (illumination) terminal 4

to hazard switch (illumination) terminal 4

to heated seat switch (driver side) (illumination) terminal 6

to heated seat switch (passenger side) (illumination) terminal 6

to door mirror remote control switch terminal 15

to LDW switch (illumination) terminal 4,

to combination switch (spiral cable) terminal 27

to A/C and AV switch (illumination) terminal 4 and

to DVD player (illumination) terminal 10,

through combination switch (spiral cable) terminal 21

to audio steering switch (illumination)

to icc steering switch (illumination) (with icc) and

to ascd steering switch (illumination) (without icc)
Ground is supplied at all times

to glove box lamp terminal 2 and

to coin box illumination terminal 3

through grounds M35, M45 and M85,

to rear power window switch LH and RH (illumination) terminals 7

through grounds B15 and B45.
With power and ground supplied, illumination lamps illuminate.
EXTERIOR LAMP BATTERY SAVER CONTROL
When the lighting switch is in the 1ST or 2ND position (or if auto light system is activated), and ignition switch
is turned from ON or ACC to OFF, battery saver control function is activated.
Under this condition, illumination lamps remain illuminated for 5 minutes, then illumination lamps are turned
off.
When the lighting switch is turned from OFF to 1ST or 2ND position (or if auto light system is activated) after
illumination lamps are turned off by battery saver control, and illumination lamps illuminate again.
Exterior lamp battery saver control mode can be changed by the function setting of CONSULT-II.
