2007 INFINITI FX35 ECO mode

AT-40
ON BOARD DIAGNOSTIC (OBD) SYSTEM
Revision: 2006 July 2007 FX35/FX45
ON BOARD DIAGNOSTIC (OBD) SYSTEMPFP:00028
IntroductionNCS001B7
The A/T system has two self-diagnostic systems.
The first is the emission-related on board diagnostic system (OBD-II) performed by the TCM in combination
with the ECM. The malfunction is indicated by the MIL (malfunction indicator lamp) and is stored as a DTC in
the ECM memory but not the TCM memory.
The second is the TCM original self-diagnosis indicated by the A/T CHECK indicator lamp. The malfunction is
stored in the TCM memory. The detected items are overlapped with OBD-II self-diagnostic items. For detail,
refer to AT- 9 2 , "
Display Items List" .
OBD-II Function for A/T SystemNCS001B8
The ECM provides emission-related on board diagnostic (OBD-II) functions for the A/T system. One function
is to receive a signal from the TCM used with OBD-related parts of the A/T system. The signal is sent to the
ECM when a malfunction occurs in the corresponding OBD-related part. The other function is to indicate a
diagnostic result by means of the MIL (malfunction indicator lamp) on the instrument panel. Sensors, switches
and solenoid valves are used as sensing elements.
The MIL automatically illuminates in “One or Two Trip Detection Logic” when a malfunction is sensed in rela-
tion to A/T system parts.
One or Two Trip Detection Logic of OBD-IINCS001B9
ONE TRIP DETECTION LOGIC
If a malfunction is sensed during the first test drive, the MIL will illuminate and the malfunction will be stored in
the ECM memory as a DTC. The TCM is not provided with such a memory function.
TWO TRIP DETECTION LOGIC
When a malfunction is sensed during the first test drive, it is stored in the ECM memory as a 1st trip DTC
(diagnostic trouble code) or 1st trip freeze frame data. At this point, the MIL will not illuminate. — 1st trip
If the same malfunction as that experienced during the first test drive is sensed during the second test drive,
the MIL will illuminate. — 2nd trip
The “Trip” in the “One or Two Trip Detection Logic” means a driving mode in which self-diagnosis is performed
during vehicle operation.
OBD-II Diagnostic Trouble Code (DTC)NCS001BA
HOW TO READ DTC AND 1ST TRIP DTC
DTC and 1st trip DTC can be read by the following methods.
( with CONSULT-II or GST) CONSULT-II or GST (Generic Scan Tool) Examples: P0705, P0720 etc.
These DTC are prescribed by SAE J2012.
(CONSULT-II also displays the malfunctioning component or system.)

1st trip DTC No. is the same as DTC No.

Output of the diagnostic trouble code indicates that the indicated circuit has a malfunction. How-
ever, in case of the Mode II and GST, they do not indicate whether the malfunction is still occurring
or occurred in the past and returned to normal.
CONSULT-II can identify them as shown below, therefore, CONSULT-II (if available) is recom-
mended.
A sample of CONSULT-II display for DTC and 1st trip DTC is shown
on the next page. DTC or 1st trip DTC of a malfunction is displayed
in SELF-DIAGNOSTIC RESULTS mode for “ENGINE” with CON-
SULT-II. Time data indicates how many times the vehicle was driven
after the last detection of a DTC.
BCIA0030E

ON BOARD DIAGNOSTIC (OBD) SYSTEM AT-43
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 July 2007 FX35/FX45
HOW TO ERASE DTC (WITH GST)
1. If the ignition switch stays ON after repair work, be sure to turn ignition switch OFF once. Wait at least 10
seconds and then turn it ON (engine stopped) again.
2. Perform “TCM SELF-DIAGNOSTIC PROCEDURE (No Tools)”. Refer to AT- 1 0 2 , "
TCM SELF-DIAGNOS-
TIC PROCEDURE (NO TOOLS)" . (The engine warm-up step can be skipped when performing the diag-
nosis only to erase the DTC.)
3. Select Mode 4 with Generic Scan Tool (GST). For details, refer to EC-129, "
Generic Scan Tool (GST)
Function" (for VQ35DE) or EC-793, "Generic Scan Tool (GST) Function" (for VK45DE).
HOW TO ERASE DTC (NO TOOLS)
The A/T CHECK indicator lamp is located on the instrument panel.
1. If the ignition switch stays ON after repair work, be sure to turn ignition switch OFF once. Wait at least 10 seconds and then turn it ON (engine stopped) again.
2. Perform “TCM SELF-DIAGNOSTIC PROCEDURE (No Tools)”. Refer to AT- 1 0 2 , "
TCM SELF-DIAGNOS-
TIC PROCEDURE (NO TOOLS)" . (The engine warm-up step can be skipped when performing the diag-
nosis only to erase the DTC.)
3. Perform “OBD-II SELF-DIAGNOSTIC PROCEDURE (No tools)”. Refer to EC-66, "
How to Erase DTC"
(for VQ35DE) or EC-728, "How to Erase DTC" (for VK45DE).
Malfunction Indicator Lamp (MIL)NCS001BB
DESCRIPTION
The MIL is located on the instrument panel.
1. The MIL will light up when the ignition switch is turned ON with- out the engine running. This is a bulb check.

If the MIL does not light up, refer to DI-38, "WARNING LAMPS" ,
or see EC-673, "
MIL AND DATA LINK CONNECTOR" (for
VQ35DE) or EC-1364, "
MIL AND DATA LINK CONNECTOR"
(for VK45DE).
2. When the engine is started, the MIL should go off. If the MIL remains on, the on board diagnostic system has
detected an engine system malfunction.
SEF217U

AT-44
TROUBLE DIAGNOSIS
Revision: 2006 July 2007 FX35/FX45
TROUBLE DIAGNOSISPFP:00004
DTC Inspection Priority ChartNCS001BC
If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.
NOTE:
If “DTC U1000” is displayed with other DTCs, first perform the trouble diagnosis for “DTC U1000 CAN
COMMUNICATION”. Refer to AT- 1 0 4
.
Fail-safeNCS001BD
The TCM has an electrical fail-safe mode. This mode makes it possible to operate even if there is a an error in
a main electronic control input/output signal circuit.
In fail-safe mode, even if the selector lever is “D” or “M” mode, the transmission is fixed in 2nd, 4th or 5th
(depending on the breakdown position), so the customer should feel “slipping” or “poor acceleration”.
Even when the electronic circuits are normal, under special conditions (for example, when slamming on the
brake with the wheels spinning drastically and stopping the tire rotation), the transmission can go into fail-safe
mode. If this happens, switch OFF the ignition switch for 10 seconds, then switch it ON again to return to the
normal shift pattern. Therefore, the customer's vehicle has returned to normal, so handle according to the
“WORK FLOW” (Refer to AT- 4 6
).
FAIL-SAFE FUNCTION
If any malfunction occurs in a sensor or solenoid, this function controls the A/T to mark driving possible.
Vehicle Speed Sensor
Signals are input from two systems - from vehicle speed sensor A/T (revolution sensor) installed on the trans-
mission and from combination meter so normal driving is possible even if there is a malfunction in one of the
systems. And if vehicle speed sensor A/T (revolution sensor) has unusual cases, 5th gear and manual mode
are prohibited.
Accelerator Pedal Position Sensor
If there is a malfunction in one of the systems, the accelerator opening angle is controlled by ECM according
to a pre-determined accelerator angle to make driving possible. And if there are malfunctions in tow systems,
the engine speed is fixed by ECM to a pre-determined engine speed to make driving possible.
Throttle Position Sensor
If there is a malfunction in one of the systems, the accelerator opening angle is controlled by ECM according
to a pre-determined accelerator angle to make driving possible. And if there are malfunctions in tow systems,
the accelerator opening angle is controlled by the idle signal sent from the ECM which is based on input indi-
cating either idle condition or off-idle condition (pre-determined accelerator opening) in order to make driving
possible.
PNP Switch
In the unlikely event that a malfunction signal enters the TCM, the position indicator is switched OFF, the
starter relay is switched OFF (starter starting is disabled), the back-up lamp relay switched OFF (back-up lamp
is OFF) and the position is fixed to the “D” position to make driving possible.
Starter Relay
The starter relay is switched OFF. (Starter starting is disabled.)
Priority Detected items (DTC)
1 U1000 CAN communication line
2 Except above

TROUBLE DIAGNOSIS AT-57
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 July 2007 FX35/FX45
Check Before Engine Is StartedNCS001BI
1. CHECK A/T CHECK INDICATOR LAMP
1. Park vehicle on level surface.
2. Move selector lever to “P” position.
3. Turn ignition switch OFF and wait at least 10 seconds.
4. Turn ignition switch ON. (Do not start engine.)
Does A/T CHECK indicator lamp light up for about 2 seconds?
YES >> 1. Turn ignition switch OFF. 2. Perform self-diagnostics and record all NG items on the AT- 4 7 , "
DIAGNOSTIC WORKSHEET"
. Refer to AT- 9 2 , "SELF-DIAGNOSTIC RESULT MODE" , AT- 1 0 2 , "Diagnostic Procedure with-
out CONSULT-II" .
3. Go to AT- 5 7 , "
Check at Idle" .
NO >> Stop the road test and go to AT- 1 8 9 , "
A/T CHECK Indicator Lamp Does Not Come On" .
Check at IdleNCS001BJ
1. CHECK STARTING THE ENGINE
1. Park vehicle on level surface.
2. Move selector lever to “P” or “N” position.
3. Turn ignition switch OFF.
4. Start engine.
Does the engine start?
YES >> GO TO 2.
NO >> Stop the road test and go to AT- 1 9 0 , "
Engine Cannot Be Started in “P” or “N” Position" .
2. CHECK STARTING THE ENGINE
1. Turn ignition switch ON. (Do not start engine.)
2. Move selector lever to “D”, “M” or “R” position.
3. Start engine.
Does the engine start in either position?
YES >> Stop the road test and go to AT- 1 9 0 , "Engine Cannot Be Started in “P” or “N” Position" .
NO >> GO TO 3.
3. CHECK “P” POSITION FUNCTIONS
1. Move selector lever to “P” position.
2. Turn ignition switch OFF.
3. Disengage the parking brake.
4. Push the vehicle forward or backward.
5. Engage the parking brake.
When you push the vehicle with disengaging the parking brake, does it move?
YES >> Enter a check mark at AT- 1 9 1 , "In “P” Position, Vehicle Moves When Pushed" on the AT- 4 7 ,
"DIAGNOSTIC WORKSHEET" , then continue the road test.
NO >> GO TO 4.

AT-58
TROUBLE DIAGNOSIS
Revision: 2006 July 2007 FX35/FX45
4. CHECK “N” POSITION FUNCTIONS
1. Start engine.
2. Move selector lever to “N” position.
3. Release the parking brake.
Does vehicle move forward or backward?
YES >> Enter a check mark at AT- 1 9 2 , "In “N” Position, Vehicle Moves" on the AT- 4 7 , "DIAGNOSTIC
WORKSHEET" , then continue the road test.
NO >> GO TO 5.
5. CHECK SHIFT SHOCK
1. Engage the brake.
2. Move selector lever to “D” position.
When the transmission is shifted from
“N” to “D”, is there an excessive shock?
YES >> Enter a check mark at AT- 1 9 3 , "Large Shock (“N” to “D” Position)" on the AT- 4 7 , "DIAGNOSTIC
WORKSHEET" , then continue the road test.
NO >> GO TO 6.
6. CHECK “R” POSITION FUNCTIONS
1. Engage the brake.
2. Move selector lever to “R” position.
3. Release the brake for 4 to 5 seconds.
Does the vehicle creep backward?
YES >> GO TO 7.
NO >> Enter a check mark at AT- 1 9 6 , "
Vehicle Does Not Creep Backward in “R” Position" on the AT- 4 7 ,
"DIAGNOSTIC WORKSHEET" , then continue the road test.
7. CHECK “D” POSITION FUNCTIONS
Inspect whether the vehicle creep forward when the A/T is put into the “D” position.
Does the vehicle creep forward in the
“D” position?
YES >> Go to AT- 5 8 , "Cruise Test - Part 1" , AT- 6 0 , "Cruise Test - Part 2" , and AT- 6 1 , "Cruise Test - Part
3" .
NO >> Enter a check mark at AT- 1 9 9 , "
Vehicle Does Not Creep Forward in “D” Position" on the AT- 4 7 ,
"DIAGNOSTIC WORKSHEET" , then continue the road test.
Cruise Test - Part 1NCS001BK
1. CHECK STARTING OUT FROM D1
1. Drive the vehicle for about 10 minutes to warm up the engine oil and ATF. Appropriate temperature for the ATF: 50 to 80 °C (122 to 176 °F)
2. Park the vehicle on a level surface.
3. Move selector lever to “P” position.
4. Start the engine.
5. Move selector lever to “D” position.
6. Press the accelerator pedal about half-way down to accelerate the vehicle.
With CONSULT-II
Read the gear positions. Refer to AT- 9 5 , "
DATA MONITOR MODE" .
Starts from D1?
YES >> GO TO 2.
NO >> Enter a check mark at AT- 2 0 1 , "
Vehicle Cannot Be Started From D1" on the AT- 4 7 , "DIAGNOS-
TIC WORKSHEET" , then continue the road test.

AT-92
TROUBLE DIAGNOSIS
Revision: 2006 July 2007 FX35/FX45
CONSULT-II SETTING PROCEDURE
Refer to GI-38, "CONSULT-II Start Procedure" .
SELF-DIAGNOSTIC RESULT MODE
After performing AT- 9 2 , "SELF-DIAGNOSTIC RESULT MODE" , place check marks for results on the AT- 4 7 ,
"DIAGNOSTIC WORKSHEET" . Reference pages are provided following the items.
Operation Procedure
Touch “SELF-DIAG RESULTS” on “SELECT DIAG MODE” screen.
Display shows malfunction experienced since the last erasing opera-
tion.
Display Items List
X: Applicable, —: Not applicable
BCIA0031E
Items (CONSULT-II
screen terms) Malfunction is detected when... TCM self-
diagnosis OBD-II
(DTC)
Reference page
“A/T” with
CONSULT-
II MIL indica-
tor lamp(*1) ,
“ENGINE”
with CON-
SULT-II or GST
CAN COMM CIR-
CUIT

When TCM is not transmitting or receiving CAN communication
signal for 2 seconds or more U1000 U1000
AT-104
STARTER RELAY/
CIRC

If this signal is ON other than in “P” or “N” position, this is judged
to be a malfunction.
(And if it is OFF in “P” or “N” position, this too is judged to be a
malfunction.) P0615 —
AT-107
TCM
TCM is malfunctioning P0700 P0700 AT- 111
PNP SW/CIRC

PNP switch 1-4 signals input with impossible pattern

“P” position is detected from “N” position without any other posi-
tion being detected in between. P0705 P0705
AT- 11 2
TURBINE REV S/
CIRC
TCM does not receive the proper voltage signal from the sensor.

TCM detects an irregularity only at position of 4th gear for turbine
revolution sensor 2. P0717 P0717
AT- 11 6
VEH SPD SEN/CIR
AT

Signal from vehicle speed sensor A/T (Revolution sensor) not
input due to cut line or the like

Unexpected signal input during running

After ignition switch is turned ON, unexpected signal input from
vehicle speed sensor MTR before the vehicle starts moving P0720 P0720
AT- 11 8
ENGINE SPEED
SIG
TCM does not receive the CAN communication signal from the
ECM. P0725 —
AT-123
TCC SOLENOID/
CIRC
Normal voltage not applied to solenoid due to cut line, short, or
the like P0740 P0740
AT-125
A/T TCC S/V
FNCTN
A/T cannot perform lock-up even if electrical circuit is good.

TCM detects as irregular by comparing difference value with slip
rotation. P0744
P0744(*2)AT-127

TROUBLE DIAGNOSIS AT-95
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 July 2007 FX35/FX45
*2: These malfunctions cannot be displayed MIL if another malfunction is assigned to MIL.
How to Erase Self-Diagnostic Results
1. Touch “SELF-DIAG RESULTS” on “SELECT DIAG MODE”
screen.
2. Touch ”ERASE”. (The self-diagnostic results will be erased.)
DATA MONITOR MODE
Operation Procedure
Touch “DATA MONITOR” on “SELECT DIAG MODE” screen.
NOTE:
When malfunctions detected, CONSULT-II performs “REAL-
TIME DIAGNOSIS”. Also, any malfunction detected while in this
mode will be displayed at real time.
Display Items List
X: Standard, —: Not applicable, : Option
BCIA0031E
PCIA0061E
BCIA0031E
Monitored item (Unit) Select Monitor Item
Remarks
ECU
INPUT
SIGNALS MAIN SIG-
NALS SELEC-
TION
FROM
MENU
VHCL/S SE-A/T (km/h) X X Revolution sensor
VHCL/S SE-MTR (km/h) X —
ACCELE POSI (0.0/8) X — Accelerator pedal position signal
THROTTLE POSI (0.0/8) X X Degree of opening for accelerator recognized by
the TCM
For fail-safe operation, the specific value used
for control is displayed.
CLSD THL POS (ON/OFF) X — Signal input with CAN communications
W/O THL POS (ON/OFF) X —

AT-96
TROUBLE DIAGNOSIS
Revision: 2006 July 2007 FX35/FX45
BRAKE SW (ON/OFF) X — Stop lamp switch
GEAR — X Gear position recognized by the TCM updated
after gear-shifting
ENGINE SPEED (rpm) X X
TURBINE REV (rpm) X X
OUTPUT REV (rpm) X X
GEAR RATIO — X
TC SLIP SPEED (rpm) — X Difference between engine speed and torque
converter input shaft speed
F SUN GR REV (rpm) — —
F CARR GR REV (rpm) — —
ATF TEMP SE 1 (V) X —
ATF TEMP SE 2 (V) X —
ATF TEMP 1 ( °C) — X
ATF TEMP 2 ( °C) — X
BATTERY VOLT (V) X —
ATF PRES SW 1 (ON/OFF) X X (for FR/B solenoid)
ATF PRES SW 2 (ON/OFF) X X (for LC/B solenoid)
ATF PRES SW 3 (ON/OFF) X X (for I/C solenoid)
ATF PRES SW 5 (ON/OFF) X X (for D/C solenoid)
ATF PRES SW 6 (ON/OFF) X X (for HLR/C solenoid)
PNP SW 1 (ON/OFF) X —
PNP SW 2 (ON/OFF) X —
PNP SW 3 (ON/OFF) X —
PNP SW 4 (ON/OFF) X —
1 POSITION SW (ON/OFF) X —
SLCT LVR POSI — X Selector lever position is recognized by the
TCM.
For fail-safe operation, the specific value used
for control is displayed.
OD CONT SW (ON/OFF) X —
Not mounted but displayed.
POWERSHIFT SW (ON/OFF) X —
HOLD SW (ON/OFF) X —
MANU MODE SW (ON/OFF) X —
NON M-MODE SW (ON/OFF) X —
UP SW LEVER (ON/OFF) X —
DOWN SW LEVER (ON/OFF) X — Monitored item (Unit)
Select Monitor Item
Remarks
ECU
INPUT
SIGNALS MAIN SIG-
NALS SELEC-
TION
FROM
MENU
