2007 Hyundai Getz key

1- 6 FEATURES OF YOUR HYUNDAI
B040B01A-EAT Locking and Unlocking Front Doors With a Key
o The door can be locked or unlocked
with a key.
o Lock the door by turning the key clockwise and unlock it by turning the key counterclockwise. LOCK
HTB056-D
UNLOCK
B880C02A-EAT Key Numbers The vehicle key number is recorded on a metal tag attached to the keys when the vehicle is first delivered to you.The key number should be recorded and kept in a safe place in case the need to order further keys arises. Newkeys are available from any Hyundai authorised repairer by quoting the rel- evant key number.In the interest of security, the metal tag attached to the keys which bears the key number should be removed fromthe key ring after you receive your new vehicle. In addition, key numbers cannot beprovided by Hyundai for security rea- sons.
AX10030A-1 If you need additional keys or if you should lose your keys, your Hyundai authorised repairer can make new keys.
B040A02Y-EAT DOOR LOCKS
!WARNING:
o Unlocked doors can be danger- ous. Before you drive away (espe- cially if there are children in the car), be sure that all the doors are securely closed and locked so that the doors cannot be inadvert- ently opened from the inside. Thishelps ensure that doors will not be opened accidentally. Also, when combined with the proper use ofseat belts, locking the doors helps keep occupants from being ejected from the car in case of an accident.
o Before opening the door, always look for and avoid oncoming traf-fic.
o In case of accident the door is unlocked automatically (Not allmodels).

FEATURES OF YOUR HYUNDAI 1- 7
o To help prevent theft, always re-
move the ignition key, close all windows, and lock all doors andhatchback door when leaving your vehicle unattended.
B040C01FC-GAT Locking From the Outside The doors can be locked without a key. To lock the doors from the outside, first push the inside lock switch to the"LOCK" position, so that the red mark on the switch is not visible, then close the door.The door will not lock if the key is left in the ignition switch when the front doors close. This is normal. (Not all models) NOTE:
o When locking the door this way,
be careful not to lock the door with the ignition key left in thevehicle.
HTB062-D SB040D1-F Locking from the Inside To lock the doors from inside, simply close the door and push the lock switchto the "LOCK" position. When this is done, the door cannot be opened using either the inside or theoutside door handle. NOTE: When the door is locked, the red mark on the switch is not visible andthe character "LOCK" on the switch is visible.
HTB057-D
UNLOCK
LOCK SB040F2-E CHILD-PROOF REAR DOOR LOCK The rear doors are fitted with child proof locks to prevent accidental opening of the doors using the inside door handle, whilst allowing access by means of the outside handle (such as is required in the event of an acccident for example) provided that the door lock button is at the unlocked position. Use of the child proof lock mechanism is recommended when children are carried in the vehicle. The child proof lock mechanism may be activated by opening the door and moving the lever located by the door latch to the "
" locked position. Move
the lever to the opposite direction of "
" unlocked position when normal
door operation is desired. HTB058-D

1- 8 FEATURES OF YOUR HYUNDAI
B070A01A-EAT ANTI-THEFT ALARM SYSTEM (Not all models) This system is designed to provide protection from unauthorized entry intothe car. This system is operated in three stages: the first is the "Armed" stage, the second is the "Alarm" stage,and the third is the "Disarmed" stage. If triggered, the system provides an au- dible alarm with blinking of the turnsignal lights. Park the car and stop the engine. Arm the system as described below.
1) Remove the ignition key from the
ignition switch.
2) Make sure that the engine bonnet ,
doors and hatchback door are closed.
3) Lock the doors using the transmitter
of the keyless entry system.
After completion of the steps above, the turn signal lights will blink once toindicate that the system is armed.
B070B01TB-D
B070B01O-EAT Armed Stage
o When the door is unlocked, the
red mark on the switch is visible and the character "LOCK" on theswitch is visible.
o The central door locking is oper-
ated by turning the key (with theft-alarm system: driver's door and passenger's door, without theft- alarm system: driver's door only)toward the front or rear of the vehicle.
o If the door is locked/unlocked mul- tiple times in rapid successionwith either the vehicle key or door lock switch, the system may stopoperating temporarily in order to protect the circuit and prevent damage to system components.
SB040G2-E CENTRAL DOOR LOCKING (Not all models)
HTB212-D
The central door locking is operated by pushing the driver's door lock switch toward the front or rear of the vehicle. Ifthe passenger and rear doors are open when the switch is pushed, the door will remain locked when closed. NOTE:
o When pushing the switch toward the rear, all doors and tail gate will unlock.When pushing the switch toward the front, all doors and tail gate will lock.

FEATURES OF YOUR HYUNDAI 1- 9
NOTE:
1) If any door, hatchback door or
engine bonnet remains open, the system will not be armed.
2) If this happens, rearm the system as described above.
! CAUTION:
Do not arm the system until all pas- sengers have left the car. If the sys- tem is armed while a passenger(s)remains in the car, the alarm may be activated when the remaining passenger(s) leaves the car.
HTB202
B070D02TB-EAT Disarmed Stage
B070C02FC-EATAlarm Stage The alarm will be activated if any of the following occurs while the car is parked and the system is armed.
1) A front or rear door is unlocked and opened without using the transmit- ter.
2) The hatchback door is opened with- out using the transmitter.
3) The engine bonnet is opened. The system will be disarmed when thedriver's or passenger's door is un-locked by depressing the button on the transmitter. After completion of the step above, the turn signal lights will blink twice to indicate that the system is disarmed.
The alarming horn will sound and the turn signal lights will blink continuously for approximately 27 seconds. To turnoff the system, unlock the door or hatchback door with the transmitter.
NOTE: When the vehicle is unlocked using the unlock button on the remote, but the doors, bonnet or boot are notopened within 30 seconds, the doors will relock and the system will re- arm.
!
CAUTION:
Only the transmitter can disarm the armed stage. If the transmitter does not disarm the system, it is neces- sary to take the following steps;
1. Unlock the door with the key, which will cause, the alarm to be activated.
2. Insert the key in the ignition key cylinder and turn the ignition keyto "ON" position.
3. Wait for 30 seconds. After completing the step above, the system will be disarmed.

1- 10 FEATURES OF YOUR HYUNDAI
HTB053
B070E01TB-EAT Replacing the battery When the transmitter's battery begins to get weak, it may take several pusheson the button to lock or unlock the doors, and the LED will not light. Re- place the battery as soon as possible. Battery type : CR1220 Replacement instructions:
1. Remove the screw with a (+) screw-
driver.
2. Separate the case with a (-) screw- driver as shown in the illustration.
- Other vehicles or objects may be
blocking the signal.
- The weather is extremely cold.
- The transmitter is close to a radio transmitter such as a radio stationor an airport which can interferewith normal operation of the trans- mitter.
When the transmitter does not workcorrectly, open and close the door with the ignition key. If you have aproblem with the transmitter, con- tact an authorized Hyundai Dealer. NOTE: Keep the transmitter away from wa- ter or any liquid. If the keyless entry system is inoperative due to expo-sure to water or liquids, it will not be covered by your manufacturer ve- hicle warranty.
B070F02TB-EAT Keyless Entry System (Not all models)Locking doors
1. Close all doors.
2. Push the button on the transmitter.
3. At the same time all doors lock, the
turn signal light will blink once to indicate that the system is armed.
Unlocking doors
1. Push the button on the transmitter.
2. At the same time all doors unlock, the turn signal light will blink twice to indicate that the system is disarmed.
NOTE: The transmitter will not work if any of following occur:
- The ignition key is in ignition switch.
- You exceed the operating distance limit (10 m).
- The battery in the transmitter is
weak.

FEATURES OF YOUR HYUNDAI 1- 11
!
HTB257-D
SB060A1-E MANUAL WINDOWS
The front door windows may be opened or closed by turning the window regula- tor handle. Ensure that when the win-dows are closed, nothing may become trapped between the glass and the door frame. HTB064-D
(1)
B060A02E-EAT POWER WINDOWS (Not all models)
The power windows operate when the ignition key is in the "ON" position. The main switches are located on the driver's armrest and control the front and rearwindows on both sides of the vehicle. The windows may be opened by de- pressing the appropriate window switchand closed by pulling up the switch. To open the window on the driver's side, press the switch(1) down. The windowmoves as long as the switch is oper- ated.
WARNING:
When opening or closing the win- dows, make sure your passenger's head, hair, arms and hands are safely out of the way.
3. Remove the four screws on the rear face of the built-in circuit. HTB054
HTB055
Battery
4. Before removing the battery note its position and ensure the new battery is fitted the same + side (positive) facing upwards, then insert it into the transmitter.

1- 12 FEATURES OF YOUR HYUNDAI
!
HTB024-D
B080A01FC-EAT SEAT ADJUSTMENT B080B02FC-EAT FRONT SEATS Front Seat Rake Adjustment
The front seat rake adjustment is per- formed by raising the lever at the frontof the seat base and sliding the seat to the desired position. At this position the lever should be released and the seatrocked to and fro to ensure that the mechanism has locked.
WARNING:
Front seat adjustments must not be undertaken whilst the vehicle is inmotion. Loss of control of the ve- hicle may result if seat adjustments are made whilst the vehicle is inmotion. WARNING:
1) Be careful that someone's head, hands and body are not trappedby a closing window.
2) Never try to operate the main switch on the driver's door andthe individual door window switchin opposing directions at the same time. If this is done, the window will stop and cannot be opened orclosed.
3) Always remove the ignition key
prior to exiting the car.
4) Do not leave children alone in the car.
!
!WARNING:
To ensure the seat is locked se- curely, attempt to move the seat for- ward or rearward without using thelever.
In order to prevent operation of the passenger front and rear windows, a window lock switch is provided on thearmrest of the driver's door. To disable the power windows, press the window lock switch.To revert to normal operation, press the window lock switch a second time. Auto-Down Window (Driver's Side) The Auto-Down window is moved to its fully open position by pushing the switch. To stop at the desired positionpush the switch again. HTB066-D

FEATURES OF YOUR HYUNDAI 1- 19
B100A01TB-EAT SEAT WARMER (Not all models) The seat warmer is provided to warm the front seats during cold weather. With the ignition key in the "ON" posi-tion, push either of the switches to warm the driver's seat or the passenger's seat.During mild weather or under conditions where the operation of the seat warmer is not needed, keep the switches in the"OFF" position. NOTE:
o The seat warmer will not operate if
ambient temperature is higher than 98.6°F (37°C).
o If the seat warmer doesn't work when ambient temperature islower than 82.4°F(28°C), it must bechecked at authoriseddealer.
HTB194
!WARNING:
Be very careful not to injure by low temperature burn or an attack of fe- ver on the occupants of the frontseats such as: children, elderly per- sons, persons under medication or under the influence of alcohol.
B140A01TB
B140A01B-GAT REAR SEAT WARNING For the safety of all passengers, lug- gage or other cargo should not be piled higher than the top of the seatback.
