2007 HUMMER H2 ECO mode

Another feature of this system is the Traction
Control 2 (TC2) mode. TC2 should be selected for
improved traction and system performance
when the vehicle is on loose surfaces such as
deep sand or mud.
To enter this mode,
press the TC2 button
located on the
instrument panel to the
right of the steering
wheel.
TC2 only operates in the following transfer case
modes:
Four-Wheel-High Lock
Four-Wheel-Low Lock
Four-Wheel-Low Lock and Rear Axle Lock
SeeLocking Rear Axle on page 311for more
information on the rear axle lock.It will not operate in Four-Wheel-High. If the
TC2 button is pressed while in Four-Wheel High,
the light will ash for about 15 seconds and
then go out. The light should also come on briey
when you turn the ignition key to RUN; if it
doesn’t see your dealer for service.
If you restart your engine, the system reverts to
the standard TCS mode.
The traction off light will
come on when a
Traction Control System
or Anti-Lock Brake
System problem has
been detected and the
vehicle needs service.
SeeTraction Off Light on page 212.
When the traction off light is on, adjust your
driving accordingly.
The traction control system, as delivered from the
factory, will automatically come on whenever
you start your vehicle.
Adding non-GM accessories can affect your
vehicle’s performance. SeeAccessories and
Modications on page 392for more information.
310

Locking Rear Axle
The locking rear axle can give your vehicle
additional traction from the rear wheels when
traveling in off-road situations such as mud, snow,
sand, steep hills and uneven terrain.
The button used to turn
this feature on or off is
located above the
transfer case buttons
to the right of the
steering wheel.
To lock the rear axle, do the following:
1. Place the transfer case in the Four-Wheel-Low
Lock mode. This is the only mode which will
allow the rear axle to lock. SeeFull-Time
Four-Wheel Drive on page 128for more
information regarding the transfer case and
Four-Wheel-Low-Lock mode.
2. Press the button with the vehicle stopped or
moving less than 2 mph (3 km/h).You must wait for the light in the button to stop
ashing and remain illuminated before the
rear axle is locked.
Notice:If you try to lock the rear axle while
your vehicle is stuck and the tires are spinning,
you could damage your vehicle’s drivetrain.
The repairs would not be covered by your
warranty. Always lock the rear axle before
attempting situations and/or navigating terrain
which could possibly cause the vehicle to
become stuck.
The locking rear axle will be disengaged when the
vehicle’s speed is greater than 20 mph (32 km/h), if
the vehicle’s battery is low and/or the transfer case
is shifted out of Four-Wheel-Low-Lock mode.
Notice:If you lock the rear axle while driving
on pavement, you could damage your
vehicle’s drivetrain. The repairs would not be
covered by your warranty. Do not use the
locking rear axle on pavement. If you need
four-wheel drive when traveling on pavement,
use only 4HI.
311

You may also hear the release of air similar to a
hissing sound during suspension operation.
This is normal.
Load leveling will not function normally with the
inator hose attached to the inator outlet.
Remove the inater hose from the outlet when
it is not in use. SeeAccessory Inator on
page 466.
Overload and Overheat Protection
Overload protection is designed to protect the air
suspension system and is an indication to the
driver that the vehicle is overloaded.
If the rear suspension remains at a low height, the
rear axle load has exceeded GAWR (Gross Axle
Weight Rating). When the overload protection
mode is activated, the compressor operates forabout 30 seconds to one minute without raising the
vehicle depending on the amount of overload.
This will continue each time the ignition is turned on
until the rear axle load is reduced below GAWR.
If the total rear GAWR (Gross Axle Weight Rating)
is reached, the suspension may be slightly less
than level. This is normal and does not mean there
is a problem with the air suspension.
If the system overheats due to normal operation,
the SERVICE AIR SUSPENSION message
will not be displayed on the DIC, but the system
will shut down and stop all leveling functions until it
cools down. If the system overheats and sets
the SERVICE AIR SUSPENSION message in the
DIC, then there is a fault. SeeDIC Warnings
and Messages on page 226for more information.
373

Tow/Haul Mode
Tow/haul mode is used when using your vehicle to
pull a large or heavy load or trailer. Tow/haul is
also useful while pulling a load in rolling terrain, in
stop-and-go traffic, or when you need improved
low-speed control, such as when parking.
The purpose of the tow/haul mode is to do the
following:
Reduce the frequency and improve the
predictability of transmission shifts when
pulling a heavy trailer or a large or heavy load.
Provide the same solid shift feel when pulling a
heavy trailer or a large or heavy load as when
the vehicle is unloaded.
Improve control of vehicle speed while requiring
less accelerator pedal activity when pulling a
heavy trailer or a large or heavy load.
Tow/haul mode is most effective when the vehicle
and trailer combined weight is at least 75 percent of
the vehicle’s Gross Combination Weight Rating
(GCWR). See “Weight of the Trailer” later in this
section.Press the button on the
instrument panel to the
right of the steering
wheel to enable
the tow/haul mode.
A light on the instrument
panel will illuminate to
indicate that tow/haul
mode has been
selected.
Press the button again to turn off tow/haul mode.
The indicator light on the instrument panel will
turn off. The vehicle will automatically turn
off tow/haul mode every time it is started.
Driving with tow/haul mode activated without a
heavy load or with no trailer will cause reduced
fuel economy and unpleasant engine and
transmission driving characteristics, but will not
cause damage.
376

Intended Outboard Sidewall:The side of an
asymmetrical tire, that must always face outward
when mounted on a vehicle.
Kilopascal (kPa):The metric unit for air pressure.
Light Truck (LT-Metric) Tire:A tire used on
light duty trucks and some multipurpose passenger
vehicles.
Load Index:An assigned number ranging from
1 to 279 that corresponds to the load carrying
capacity of a tire.
Maximum Ination Pressure:The maximum air
pressure to which a cold tire may be inated.
The maximum air pressure is molded onto
the sidewall.
Maximum Load Rating:The load rating for a tire
at the maximum permissible ination pressure
for that tire.
Maximum Loaded Vehicle Weight:The sum of
curb weight, accessory weight, vehicle capacity
weight, and production options weight.Normal Occupant Weight:The number of
occupants a vehicle is designed to seat multiplied
by 150 lbs (68 kg). SeeLoading Your Vehicle
on page 362.
Occupant Distribution:Designated seating
positions.
Outward Facing Sidewall:The side of an
asymmetrical tire that has a particular side that
faces outward when mounted on a vehicle.
The side of the tire that contains a whitewall, bears
white lettering, or bears manufacturer, brand,
and/or model name molding that is higher
or deeper than the same moldings on the other
sidewall of the tire.
Passenger (P-Metric) Tire:A tire used on
passenger cars and some light duty trucks and
multipurpose vehicles.
Recommended Ination Pressure:Vehicle
manufacturer’s recommended tire ination
pressure as shown on the tire placard. See
Ination - Tire Pressure on page 456andLoading
Your Vehicle on page 362.
454

Trip Routing:A Roadside Assistance
Representative can provide specic information
regarding this feature.
Trip Interruption Expense Benets:
A Roadside Assistance Representative can
provide specic information regarding this
feature.
In many instances, mechanical failures are
covered under HUMMER’s Bumper-to-Bumper
warranty for U.S. customers and the Total warranty
for Canadian customers. However, when other
services are utilized, our Roadside Assistance
Representatives will explain any payment
obligations you might incur.
For prompt and efficient assistance when calling,
please provide the following to the Roadside
Assistance Representative:
Your name, home address, and home
telephone number.
Telephone number of your location.
Location of the vehicle.
Model, year, color, and license plate number
of the vehicle.
Odometer reading, Vehicle Identication
Number (VIN) and delivery date of the vehicle.
Description of the problem.
While we hope you never have the occasion to
use our service, it is added security while traveling
for you and your family. Remember, we are
only a phone call away. In the U.S., call HUMMER
Roadside Assistance:1-866-HUMMER6
(486-6376), text telephone (TTY) users, call
1-888-889-2438. In Canada, call1-800-268-6800.
HUMMER and GM of Canada Limited reserve
the right to limit services or reimbursement to an
owner or driver when, in their sole discretion,
the claims become excessive in frequency or type
of occurrence.
Roadside Assistance is not part of or included
in the coverage provided by the New Vehicle
Limited Warranty. HUMMER and GM of Canada
Limited reserve the right to make any changes
or discontinue the Roadside Assistance program
at any time without notication.
543

Vehicle Data Collection and Event
Data Recorders
Your vehicle, like other modern motor vehicles, has
a number of sophisticated computer systems that
monitor and control several aspects of the vehicle’s
performance. Your vehicle uses on-board vehicle
computers to monitor emission control components
to optimize fuel economy, to monitor conditions for
airbag deployment and, if so equipped, to provide
anti-lock braking and to help the driver control the
vehicle in difficult driving situations. Some
information may be stored during regular operations
to facilitate repair of detected malfunctions; other
information is stored only in a crash event by
computer systems, such as those commonly called
Event Data Recorders (EDR).
In a crash event, computer systems, such as the
airbag Sensing and Diagnostic Module (SDM)
in your vehicle may record information about the
condition of the vehicle and how it was operated,
such as data related to engine speed, brake
application, throttle position, vehicle speed, safety
belt usage, airbag readiness, airbag performance,
and the severity of a collision. If your vehicle is
equipped with StabiliTrak
®, steering performance,including yaw rate, steering wheel angle, and
lateral acceleration, is also recorded. This
information has been used to improve vehicle
crash performance and may be used to improve
crash performance of future vehicles and
driving safety. Unlike the data recorders on many
airplanes, these on-board systems do not
record sounds, such as conversation of vehicle
occupants.
To read this information, special equipment is
needed and access to the vehicle or the device
that stores the data is required. GM will not access
information about a crash event or share it with
others other than:
with the consent of the vehicle owner or,
if the vehicle is leased, with the consent of
the lessee,
in response to an official request of police or
similar government office,
as part of GM’s defense of litigation through
the discovery process, or
as required by law.
546

Electrical System (cont.)
Underhood Fuse Block............................. 507
Windshield Wiper Fuses........................... 503
Electronically Controlled Air Suspension
System.................................................... 372
Engine
Air Cleaner/Filter...................................... 409
Battery..................................................... 431
Check and Service Engine Soon Light........ 215
Coolant.................................................... 415
Coolant Heater......................................... 123
Coolant Temperature Gage...................... 213
Drive Belt Routing.................................... 531
Engine Compartment Overview................ 402
Exhaust................................................... 137
Oil ........................................................... 404
Oil Life System........................................ 407
Overheated Protection Operating Mode...... 420
Overheating............................................. 418
Starting.................................................... 121
Entry/Exit Lighting....................................... 191
Event Data Recorders (EDR)...................... 546
Extender, Safety Belt..................................... 45
Exterior Lamps............................................ 186F
Filter
Engine Air Cleaner................................... 409
Finish Damage............................................ 499
First Aid Kit................................................. 360
Fixed Mast Antenna.................................... 300
Flashers, Hazard Warning........................... 176
Flash-to-Pass.............................................. 180
Flat Tire...................................................... 468
Flat Tire, Changing...................................... 468
Flat Tire, Storing.................................485, 488
Fluid
Automatic Transmission............................ 412
Power Steering........................................ 425
Windshield Washer.................................. 426
Four-Wheel Drive........................................ 438
Four-Wheel Drive, Full-Time........................ 128
Front Axle................................................... 440
Front Mounted Receiver.............................. 360
Fuel............................................................ 394
Additives.................................................. 395
California Fuel.......................................... 395
Filling a Portable Fuel Container.............. 399
560
