2007 FIAT PANDA ECO mode

36
RADIO WITH
COMPACT DISC PLAYER
RADIO WITH
COMPACT DISC AND MP3 CD PLAYER
RADIO WITH
TAPES PLAYER
If the station does not broadcast in the PTY mode, the
wording “NO-PTY” is shown on the display for a few
seconds.
The list of the various subjects comprises:
NEWS News and magazine
AFFAIRS Politics and news
INFO Special information programmes
SPORT Sport programmes
EDUCATE Education
DRAMA Radio dramas and literature
CULTURE Culture
SCIENCE Science
VARIED Variety
POP M Pop music
ROCK M Rock music
EASY M Easy music
LIGHT M Light classic music
CLASSICS Classic music
OTHER M Other music
WEATHER Weather reportFINANCE Finance news
CHILDREN Child’s programmes
SOCIAL Social information
RELIGION Religion and philosophy
PHONE IN Listener’s calls (other than “Phone In”
function active only with handsfree kit
connection for cell phone)
TRAVEL Tourist’s information
LEISURE Free time and hobbies
JAZZ Jazz
COUNTRY Country music
NATION M National broadcasting
OLDIES Golden Oldies
FOLK M Folk music
DOCUMENT Special reports
001-050 ING 21-06-2007 15:48 Pagina 36

38
RADIO WITH
COMPACT DISC PLAYER
RADIO WITH
COMPACT DISC AND MP3 CD PLAYER
RADIO WITH
TAPES PLAYER
Scrolling transmissions
It is possible to receive different programmes in the
same network and scroll them (in FM band only).
To activate this function keep button 1 (AF-TA)
pressed to activate the AF function. The scrolling may
begin pressing button 9 (
˜) or 12 (÷).
IMPORTANT The station must have been received
previously at least once.
Stereophonic stations
If the signal received is weak, the device switches
automatically from Stereo to Mono.MENU
Functions of button 11 (MENU-PS)
To activate the menu function, briefly press button 11
(MENU-PS). The display shows the word “MENU”.
After about 2 seconds the display shows the wording
“MEN REG-ON”.
To scroll the menu functions use buttons 8 (
N) or 10
(
O). To turn on/off the function selected, use buttons
9 (
˜) or 12 (÷).
The display will show the current status of the
function selected.
The functions controlled by the menu are the
following:
❒REG (regional programmes);
❒CDC DISP (CD Changer data display, if installed);
❒SENS DX/LO (tuning sensitivity);
❒RM (Radio-Monitor);
❒PHONE (Telephone volume, if installed);
❒HICUT (Treble reduction);
❒IGN TIME (System power off mode).
To exit the menu function, press button 11 (MENU-
PS) again.
001-050 ING 21-06-2007 15:48 Pagina 38

56
RADIO WITH
COMPACT DISC AND MP3 CD PLAYER
RADIO WITH
TAPES PLAYER
RADIO WITH
COMPACT DISC PLAYER
GENERAL
The set possesses the following functions:
RADIO SECTION
❒PLL tuning with FM/AM/MW/LW frequency bands;
❒RDS (Radio Data System) with TA (traffic
information) - PTY (Program Type) - EON
(Enhanced Other Network) - REG (Regional
programmes);
❒AF: alternative frequency search selection in RDS
mode;
❒emergency alarm presetting;
❒automatic/manual station tuning;
❒manual storage of 36 stations: 18 in the FM band (6
in FM1, 6 in FM2, 6 in FMT), 6 in the MW band and
6 in the LW band and 6 PTY (only in FM);❒automatic storage (AUTOSTORE function) of 6
stations in FM band;
❒DX function (Distant: maximum sensitivity in
searching radio stations) and LO (Local) manual;
❒Scan function (scanning stored stations);
❒SVC function: automatic volume adjustment with
car speed;
❒automatic Stereo/Mono switching.
On multimedia CDs in addition to sound tracks also data tracks are recorded.
Playing one of these CDs may cause rustling and such a volume as to compromise road safety, as
well as causing damage to the final stages and speakers.
For installation and connection of the CD Changer apply only to Fiat Dealership.
051-098 ING 21-06-2007 15:49 Pagina 56

58
RADIO WITH
COMPACT DISC AND MP3 CD PLAYER
RADIO WITH
TAPES PLAYER
RADIO WITH
COMPACT DISC PLAYER
Entering the secret code
Turning the sound system on, if code is requested the
display will show“CODE” for about 2 seconds,
followed by four dashes “----”.
The secret code comprises four figures from 1 to 6,
each corresponding to one of the dashes.
To enter the first digit of the code, press the
corresponding key of the preset stations (from 1 to
6). Enter the other code digits in the same way.
If the four figures are not entered within 20 seconds,
the display shows the word “CODE” for 2 seconds
and then four dashes “----”. This is not to be
considered as an incorrect code entry.
After entering the fourth digit (within 20 seconds), the
radio starts working.If a wrong code is entered, the radio sounds a “beep”,
the display shows the word “CODE” for 2 seconds
and then four dashes “----” to warn the user that it is
necessary to enter the correct code.
Every time the user enters a wrong code, the waiting
time increases gradually (1 min, 2 min, 4 min, 8 min, 16
min, 30 min, 1h, 2h, 4h, 8h, 16h, 24h) until reaching a
maximum of 24 hours.
The waiting time will be shown on the display with the
word “WAIT”. When this goes off it is possible to
start the new code entry procedure.
CODE Card
This the document that certifies possession of the
radio. The Code Card contains the radio model, serial
number and secret code.
IMPORTANT Keep the Code Card carefully to be
able to give the related data to the competent
authorities in the event of theft.
051-098 ING 21-06-2007 15:49 Pagina 58

65
RADIO WITH
COMPACT DISC AND MP3 CD PLAYER
RADIO WITH
TAPES PLAYER
RADIO WITH
COMPACT DISC PLAYER
The functions that cannot be selected (e.g.: “CD”
when the compact disc is not inserted) are
automatically disabled. If CD is not inserted or the CD
Changer is not connected, pressing button 1
(SOURCE-SCAN) the display shows the message “NO
SOURCE AVAILABLE” for about 2.5 seconds; then
the radio will set automatically to “TUNER” (Radio).
Pause function
If while listening to a Compact Disc another function is
selected (e.g.: the radio), playing is stopped and when
the Compact Disc mode is resumed, it starts again
from the point in which it was stopped.
If while listening to the radio another function is
selected, when the Radio mode is resumed, it is tuned
to the last station selected.Volume adjustment
Volume level can be adjusted from min. (“VOLUME
0”) to max. (“VOLUME 66”).
Adjust volume through button/knob 18 (VOLUME
ON/OFF).
Turn the knob rightwards to increase volume and
leftwards to decrease it. Set volume is displayed for
about 4 seconds (e.g.: “VOLUME 23”).
If the volume level is changed during the broadcast of a
traffic bulletin or during use of the phone (if the voice
feature is installed), the new setting is maintained only
until the end of the bulletin or phone call.
Volume can be also adjusted during manual/automatic
tuning, AutoSTore, radio station scan or CD Changer
mode.
051-098 ING 21-06-2007 15:49 Pagina 65

66
RADIO WITH
COMPACT DISC AND MP3 CD PLAYER
RADIO WITH
TAPES PLAYER
RADIO WITH
COMPACT DISC PLAYER
SVC function
(volume changing with speed)
The SVC function makes it possible to automatically
adapt the volume level to the speed of the car,
increasing it as the speed increases to maintain the
ratio with the noise level in the passenger
compartment.
To activate the SVC function briefly press button 11
(MENU-PRESET SCAN), then use buttons 6 (
N) or
(
O) to scroll the menu stopping on the SVC function
and buttons 5 (
÷) or (˜) to switch the function
on or off selecting respectively “SVC SETTING ON”
or “SVC SETTING OFF”.
This function can be turned on or off in all the
operating modes of the device (Radio/Compact
Disc/CD Changer).
After about 4 seconds from the last adjustment the
display returns to the main radio screen.Mute function
(turning off the volume completely)
To switch on the Mute function, briefly press the
button/knob 18 (VOLUME ON/OFF). Volume will
gradually lower (Soft Mute function) and the display
will show the word “MUTE”.
To switch off the Mute function, briefly press the
button/knob 18 (VOLUME ON/OFF). Volume will
gradually become louder (Soft Mute function)
returning to the value set before switching on the
Mute function.
With the Mute function on:
❒all the other functions can be used;
❒turning the button/knob 18 (VOLUME ON/OFF)
the volume can be directly adjusted;
❒if an emergency alarm or a traffic bulletin arrives
with the TA function on, the message ignores the
Mute function;
❒an incoming call ignores the Mute function. The
Mute function will be resumed at the end of the call;
❒if with TA function on, the radio does not broadcast
traffic info, a warning beep will sound.
051-098 ING 21-06-2007 15:49 Pagina 66

70
RADIO WITH
COMPACT DISC AND MP3 CD PLAYER
RADIO WITH
TAPES PLAYER
RADIO WITH
COMPACT DISC PLAYER
Selecting the frequency band
If in the Radio mode, briefly and repeatedly press
button 12 (BAND-AUTOSTORE) to select the
required reception band.
Every time the button is pressed the following bands
are selected in sequence “FM1”, “FM2”, “FMT”,“MW”
and “LW” shown by the respective wording on the
display.
The last station selected in the respective frequency
band will be tuned specially if the station is not stored
on the presetting buttons.
If selected station is stored on one of the presetting
buttons, the display will show the presetting number
for few seconds; then the display will show again the
station frequency.
The FM band is divided into sections: FM1, FM2 and
FMT. The FMT reception band is reserved to the
stations stored automatically with the AutoSTore
function.
The radio is always ready to receive stations in the
RDS mode (Radio Data System).Presetting buttons
The buttons with symbols from 1 to 6 (“16”, “15”,
“13”, “10”, “7”, “9”) make it possible to set the
following presettings:
❒18 in the FM band (6 in FM1, 6 in FM2, 6 in FMT);
❒6 in the MW band;
❒6 in the LW band;
❒6 types of PTY programming (only in the FM mode
when PTY is selected).
To call a preset station, choose the required frequency
band and then press briefly the corresponding preset
button (from 1 to 6). For a few seconds the display
will show the number of the station preset and the
related frequency before showing the frequency band
and the name of the RDS station.
If the PI code (Program Index) can no longer receive at
the frequency allocated to a preset button, the radio
will start searching this PI on another frequency as
soon as the car leaves the area covered by the
previous frequency. The display will show “SEARCH”.
051-098 ING 21-06-2007 15:49 Pagina 70

79
RADIO WITH
COMPACT DISC AND MP3 CD PLAYER
RADIO WITH
TAPES PLAYER
RADIO WITH
COMPACT DISC PLAYER
IMPORTANT If the TA function is on and the station
tuned is not able to provide traffic information or it is
no longer able to provide this information, then, after
about 1 minute in which the radio is in these
conditions:
❒if listening to a Compact Disc another station is
sought that is enabled to transmit traffic
information;
❒if when listening to the radio a “beep” is given to
alert that it is not possible to receive traffic
information, to interrupt it, it is necessary to tune
to a station that can provide traffic information or
switch off the TA function.
The TA function is interrupted in the following cases:
❒in radio mode: press a preset button during a traffic
bulletin;
❒pressing button 1 (SOURCE-SCAN) during a traffic
bulletin;
❒by automatic/manual tuning or AutoSTore;
❒turning the Mute function on.Emergency alarm reception
In the RDS mode the radio is set to receive
emergency announcements in the case of exceptional
circumstances or events that may cause general danger
(earthquakes, floods, etc.), if they are broadcast by the
station tuned.
This function is activated automatically and cannot be
deactivated.
Program Type function (PTY)
(selecting a type of programme)
To turn on the PTY function, which makes it possible
to give top priority to PTY programmes, when
present, which may involve emergency messages or
various topics (e.g.: music, news bulletins), briefly press
button 17 (PTY) until the display shows “PTY” and the
subject of the last station heard (e.g.: “NEWS”).
After about 2 seconds the station name or frequency
is shown on the display.
IMPORTANT To turn on the PTY function, the radio
must be in the FM band.
If the station does not broadcast in the PTY mode, the
wording “NO PTY PROVIDED” is shown on the
display for a few seconds.
051-098 ING 21-06-2007 15:49 Pagina 79
