Page 17 of 22
16
TRASMISSION
Six speeds plus reverse
Gearbox with electronically-controlled
hydraulic system
ClutchSingle dry plate with hydraulic engagement
Drive Front
PERFORMANCE
For top speeds, see “Performance” in the “Technical Data” section of the Owner Handbook.
Page 18 of 22
17
Specified fuels
Recommended products
TUTELA CAR CS SPEED -
Specific fluid with“ATF DEXRON
III” additive
TUTELA TOP4
Synthetic fluid FMVSS n° 116 DOT
4, ISO 4925 SAE JI704, CUNA NC
956-01
CAPACITIES
COMFORT-MATIC
gearbox hydraulic operating system
Clutch hydraulic operating system
litres
0.7
0.050kg
0.59
–
Page 19 of 22
18
FUEL CONSUMPTION AND CO2EMISSIONS
Fuel consumption according to Directive 1999/100/EC (litres x 100 km)
CO
2emissions according to 1999/100/CE Directive (g/km).
Payload Fuel consumption CO2emissions
Urban Extraurban Combined Combined
Short wheelbase Ducato 9.2 6.9 7.7 204
Medium wheelbase Ducato 9.6 7.2 8.1 213
Ducato MAXI 10.0 7.6 8.5 224 Combi versions (*)
Payload Fuel consumption CO2emissions
Urban Extraurban Combined Combined
Ducato all types 10.0 7.6 8.5 224 Panorama versions (*)
Page 20 of 22
19
Payload Fuel consumption CO2emissions
Urban Extraurban Combined Combined
Ducato: Van CH1-MH1/Truck CH1
MH1-MLH1-LH1 – Chassis cabs 10.3 7.7 8.7 229
and without drive cabs(**)
Ducato: Van MH2-LH2-LH3/
Truck XLH1-Crew cab MH1-LH1
10.6 8.0 9.0 237
Chassis cabs and without
drive cab (**)
Ducato MAXI: Truck MH1 – Chassis
10.5 7.9 8.9 233
chassis cabs and without drive cab (**)
Ducato MAXI: Van MH1-MH2
LH2-LH3/Truck MLH1-LH1-XLH1
10.9 8.2 9.2 242
Crew cab MH1-LH1 – Chassis
cabs and without drive cabs (**)
Ducato MAXI: Van XLH2-XLH3/
Crew cab truck XLH1 – Chassis 10.9 8.2 9.2 242
cabs and without drive cabs (**)
(*) Fuel consumption figures recorded in AUTO mode
(**) Fuel consumption figures apply to pre-conversion vehicles Goods transport versions (*)
Page 21 of 22
Fiat Group Automobiles S.p.A.
Servizi al Cliente - Assistenza Tecnica - Ingegneria Assistenziale
Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia)
Print n. 603.83.789 - 10/2007 - 1
stedition
Page 22 of 22
