182TECHNICAL SPECIFICATIONS
TRANSMISSION
CLUTCH
Hydraulic, self-adjusting external
control.
GEARBOX
Five forward gears and reverse with
synchromesh for front gear engage-
ment.
Cyclical gear reduction and differen-
tial assembly incorporated in the gear-
box.
Drive transmission to the front
wheels by means of drive shafts con-
nected to the differential assembly and
the wheels with CV joints.
BRAKES
SERVICE AND
EMERGENCY BRAKES
Front:
– disc, floating shoe, self-ventilated.
Rear:
– drum, self-centring callipers.
Crossed hydraulic circuit control.
Vacuum brake booster.
ABS system with four sensors and
EBD.
Automatic take-up of friction liner
wear.
Lacking the ABS, there is the brake
force distributor that acts on rear
brake circuit according to load on rear
axle
HANDBRAKE
Controlled by a lever, it works me-
chanically on the rear brake shoes.
SUSPENSIONS
FRONT
Independent wheel, McPherson sus-
pension with steel wishbones an-
chored to an auxiliary crossmember.
Coil springs and sway bar.
Double acting telescopic hydraulic
shock absorbers.
REAR
Stiff axle with wishbones.
Double acting telescopic hydraulic
shock absorbers.
Sway bar in Fiat Doblò Passengers
Transport versions.
Page 184 of 218
183TECHNICAL SPECIFICATIONS
STEERING
Volante ad assorbimento di energia.
Energy-absorbing jointed steering
wheel.
Permanently lubricated rack and pin-
ion.
Permanent lubrication joints.
Minimum steering circle: 10.5 metres
(average between versions).; 11.8 m
for Long wheelbase versions,
STRUCTURE
Self-supporting chassis, three or five
doors, high-resistance, multiple thick-
ness structural elements for progres-
sive energy absorption in impacts.
Side bars in doors for side impact
protection and stiffening the passen-
ger compartment in the event of front
impacts.
The front and rear ends of the un-
derbody crumple to reduce repair
costs following low speed impacts.
WHEELS
RIMS AND TYRES
High resistance printed steel rims of
alloy rims.
Tubeless tyres with radial carcass.
The homologated tyres are listed in
the log book.
IMPORTANT In the event of dis-
crepancies between the information
provided in this Owner Handbook and
the Log Book, consider the specifica-
tions shown in the Log Book only.
To ensure safety of the vehicle in
movement, it must be fitted with tyres
of specified size and of the same make
and type on all wheels.IMPORTANT Do not use inner
tubes with tubeless tyres.
Do not fasten alloy wheels with the
steel wheel bolts and vice versa. For
details on the compatibility between
rims and bolts, see “If a tyre is punc-
tured” in section “In an emergency”.
SPARE WHEEL
Pressed steel rim.
Tubeless tyre.
SNOW CHAINS
Only use low profile chains, see
“Snow chains”.
WHEEL GEOMETRY
Front wheel toe-in measured from
rim to rim: 0 ± 1 mm.
The values refer to the vehicle in run-
ning order.
Page 185 of 218
184TECHNICAL SPECIFICATIONS
UNDERSTANDING TYRE
MARKING
The following are the necessary in-
dications to understand the meaning
of the markings on the tyre.Maximum speed rating
Q= up to 160 km/h.
R= up to 170 km/h.
S= up to 180 km/h.
T= up to 190 km/h.
U= up to 200 km/h.
H= up to 210 km/h.
V= up to 240 km/h.
Maximum speed rating for
snow tyres
Q M+S= up to 160 km/h
T M+S= up to 190 km/h
H M+S= up to 240 km/hUNDERSTANDING RIM
MARKINGS
The following are the necessary in-
dications to understand the meaning
of the markings on the rim.
Example: 185/65 R 15 88 T
185= Nominal width (S, distance
between sidewalls in mm).
65= Height/width ratio (H/S, as a
percentage).
R= Radial tyre.
15= Rim nominal diameter in inch-
es (Ø).
88= Load rating.
T= Maximum speed rating.Example: 5
1/2J x 15 H2
51/2= rim width in inches (1)
J= rim drop centre outline (side
projection where the tyre
bead rests) (2)
15= rim nominal diameter in inch-
es (corresponds to diameter of
the tyre to be mounted) (3 =
Ø)
H2= “hump” shape and number
(relief on the circumference
holding the tubeless tyre bead
on the rim)
fig. 6
F0A0257b
Page 186 of 218
185TECHNICAL SPECIFICATIONS
COLD INFLATION PRESSURES (bar)
Versions Size Medium load Full load
Front Rear Front Rear
Passenger Transportation 185/65 R15 88T 2.3 (*) 2.3 (*) 2.3 2.7
Family (7 seater) 185/65 R15 92T 2.3 2.7 2.3 2.7
Cargo standard capacity/Combi N1185/65 R15 92T 2.3 2.7 2.3 2.7
Cargo extra capacity/Long wheelbase 175/75 R14 C99/98T 3.0 3.5 3.0 3.5
Combi N1 exra capacity 175/75 R14 C99/98T 2.8 3.0 3.0 3.5
Passenger Transportation Natural Power 175/70 R14 C95/93S 2.6 3.0 2.6 3.0
Cargo Natural Power 175/70 R14 C95/93S 2.8 3.5 2.8 3.5
With warm tyres the pressure should be +0.3 bar in relation to the prescribed value. Check again the correct pressure when the tyres are cold.
(*) Up to 3 people + 50 kg. Versions Steel Alloy Factory-fitted Alternative Tyre Space-saver
rim rim tyre min. sizes that (*)spare wheel
can be adopted (**)
Passenger Transportation 5,5 J x 15H2-ET32 5,5 J x 15H2-ET32 185/65 R15 88T 185/65 R15 88T185/65 R15 88Q (M+S)125/80 R15 95M
Family (7 seater) 5,5 J x 15H2-ET32 5,5 J x 15H2-ET32185/65 R15 92T 185/65 R15 88T185/65 R15 88Q (M+S) –
Cargo 5,5 J x 15H2-ET32 5,5 J x 15H2-ET32 185/65 R15 92T 175/75 R14 C99/98T185/65 R15 92Q (M+S) –
standard capacity/ (or EXTRA LOAD 175/70 R14 C95/93T
Combi N1or Reinforced)
Cargo 5,5 J x 14H2-ET32 5,5 J x 14H2-ET32 175/75 R14 C99/98T 175/75 R14 95S 175/75 R14 C99/98 Q (M+S) –
exra capacity/175/70 R14 95S
Long wheelbase/
Combi N1(where fitted)
Passenger Transportation 5,5 J x 14H2-ET32 5,5 J x 14H2-ET32 175/70 R14 C95/93S 175/70 R14 88T 175/70 R14 88 Q (M+S) –
Natural Power
Cargo Natural Power 5,5 J x 14H2-ET32 5,5 J x 14H2-ET32 175/70 R14 C95/93S – – –
(*) Tyres with load and speed index equal to or higher than the specified values are admitted
(**) When replacing tyres, you are however recommended to adopt tyres with load and speed ratings equal to or higher than those of the factory-fitted tyres.
Page 187 of 218
186TECHNICAL SPECIFICATIONS
PERFORMANCE
Top admitted speed after running-in,
in km/h:
1.4 .................................................... 148
1.4 high roof................................ 145
1.4 7 plae ...................................... 145
1.3 Multijet 75 HP.................. 146
1.3 Multijet 85 HP.................. 153
1.3 Multijet 85 HP
high roof...................................... 150
1.3 Multijet 85 HP 7 place.... 150
1.9 Multijet 100/105 HP........ 168
1.9 Multijet 120 HP................ 175
1.9 Multijet 120 HP
high roof .................................... 172
1.9 Multijet 120 HP 7 place.. 172
DIMENSIONS
fig. 6
F0A0721b
Dimensions are expressed in mm.
Height is intended on an unladen ve-
hicle
Unladen boot volume (Fiat Doblò
Cargo versions): 3,2 m
3.Unladen boot volume (Fiat Doblò
Passengers Transport versions):
– standard conditions 750 dm
3;
– with rear table seat tilted 3000 dm
3.
Page 188 of 218
A
B
C
D
E
F (*)
G (*)
H
I
L
M
(*) Minor differences in dimensions may occur according to rims and/or versions.D
imensionsFiat Doblò
Combi
833
2583
837
4253
2332
1818
1514
1505
1722
454
2591
Fiat Doblò
Passengers Trans-
port High roof
833
2583
837
4253
–
2073
1514
1505
1722
454
2591
Fiat Doblò
Passengers
Transport
833
2583
837
4253
2332
1818
1514
1505
1722
454
2591 833
2963
837
4633
–
1817
1514
1505
1722
454
2591
Fiat Doblò Cargo
Long wheelbase Fiat Doblò Cargo
Short wheelbase
High roof Fiat Doblò
Cargo
Short wheelbase
833
2583
837
4253
–
2086
1514
1505
1722
454
2591 833
2583
837
4253
2345
1831
1514
1505
1722
454
2591
187TECHNICAL SPECIFICATIONS
Page 189 of 218
188TECHNICAL SPECIFICATIONS
WEIGHTS
Weights (kg) - Fiat Doblò Cargo versions - Short wheelbase
(*) If special equipment is fitted (wing window, tow hitch, etc.), the unladen vehicle weight increases, thus reducing the specified payload.
(**) Loads not to be exceeded. The driver is responsible for arranging the loads so that they comply with these limits.
▼For specific markets, where applicable.
1.4 8V
1190
730
1010
1150
1920
1000
500
100
601.3
75HPMultijet
1270
730
1010
1150
2000
1200
500
100
601.9 100▼/105HPMultijet
1280
730
1010
1150
2010
1300
500
100
601.3 85HPMultijet
1290
730
1010
1150
2020
1300
500
100
601.9 120HPMultijet
1300
730
1010
1150
2030
1300
500
100
60
Weight empty
(including fluids, 90% fuel in the
tank and no optional)
Payload including driver (*):
Maximum admitted loads (**)
– front axle:
– rear axle:
– total:
Towable weight:
– trailer with brakes
– trailer without brakes
Maximum load on roof
Maximum load on ball coupling
(trailer with brakes)
Page 190 of 218
Weights (kg) - Fiat Doblò Cargo versions - Short wheelbase - Extra capacity
(*) If special equipment is fitted (wing window, tow hitch, etc.), the unladen vehicle weight increases, thus reducing the specified payload.
(**) Loads not to be exceeded. The driver is responsible for arranging the loads so that they comply with these limits.
▼For specific markets, where applicable
1.4 8V
1190
850
1010
1270
2040
1000
500
100
601.3
75HPMultijet
1270
850
1010
1270
2120
1200
500
100
601.9 100▼/105HPMultijet
1280
850
1010
1270
2130
1300
500
100
60
189TECHNICAL SPECIFICATIONS
Weight empty (including fluids, 90% fuel in the tank and no optional)
Payload including driver (*):
Maximum admitted loads (**)
– front axle:
– rear axle:
– total:
Towable weight:
– trailer with brakes
– trailer without brakes
Maximum load on roof
Maximum load on ball coupling (trailer with brakes)
