2007 DODGE MAGNUM Owners Manual

LIGHT BULBS — Exterior Bulb Number
Low Beam Headlight.....................9006
High Beam Headlight.....................9005
Front Park/Turn Light...................3457A
Front Fog Light—If Equipped. . . 9145/H10 (Serviced at
Dealer)
Front Sidemarker........194NA (Serviced at Dealer)
Tail/Stop/Turn Light...............3157KP27/7W
Rear Sidemarker.................3757APY27/7W
Backup Light......................921/W16W
Center High Mount Stop Light (CHMSL)....... LED
License.............................. W5W
BULB REPLACEMENT
Low Beam Headlight, High Beam Headlight, and
Park/Turn Light
1. Open the hood.
NOTE:Removal of the air cleaner filter housing may be
necessary prior to replacing bulbs in the headlight assem-
bly on the driver side of the vehicle.2. Twist the appropriate bulb and socket assembly
counter-clockwise and then pull it out of the headlight
assembly.
3. Pull the bulb out of the socket assembly.
4. Push the replacement bulb into the socket assembly.
5. Reinstall the bulb and socket assembly into the head-
light assembly, and then turn it clockwise.
1 — Low Beam Headlight Bulb
2 — High Beam Headlight BulbMAINTAINING YOUR VEHICLE 345
7

CAUTION!
Do not touch the new bulb with your fingers. Oil
contamination will severely shorten bulb life. If the
bulb comes in contact with an oily surface, clean the
bulb with rubbing alcohol.
Tail/Stop, Turn Signal Light, and Backup Light
1. Open the liftgate.
2. Remove tail light access cover.
3 — Park/Turn Light Bulb
346 MAINTAINING YOUR VEHICLE

3. Push the electrical connector locking tab to the side.
4. Disconnect the electrical connector.
5. Remove 1 wing nut from the back of the tail light
assembly.
6. Remove 2 push pin fasteners under the liftgate with a
flat blade tool.7. Pull tail light assembly clear from vehicle to access
bulbs.
8. Turn the appropriate bulb and socket assembly
counter-clockwise to remove it from the tail light assem-
bly.
1 — Tail/Stop Light BulbMAINTAINING YOUR VEHICLE 347
7

9. Pull the bulb out of the socket assembly.
10. Push the replacement bulb into the socket assembly.
11. Reinstall the bulb and socket assembly into the tail
light assembly, and then turn it clockwise.
12. Reinstall the tail light assembly, fasteners, and elec-
trical connector.
13. Close the liftgate.
2 — Turn Signal Light Bulb3 — Backup Light Bulb 348 MAINTAINING YOUR VEHICLE

License Light
1. Remove the screws securing the light to the rear fascia.
2. Remove the bulb and socket assembly.
3. Pull the bulb out of the socket assembly.4. Push the replacement bulb into the socket assembly.
5. Reinstall the bulb and socket assembly.
6. Reattach the light to the rear fascia, and then install the
screws.
1 — License Light Bulb
2 — SocketMAINTAINING YOUR VEHICLE 349
7

FLUIDS AND CAPACITIES
U.S. Metric
Fuel (approximate)
2.7 Liter Engine 18 gallons 68 liters
3.5 Liter Engine without All Wheel Drive 18 gallons 68 liters
3.5 Liter Engine with All Wheel Drive 19 gallons 72 liters
5.7 Liter Engine 19 gallons 72 liters
Engine Oil-With Filter
2.7 Liter Engine (SAE 5W-20, API Certified) 6.0 qts. 5.7 liters
3.5 Liter Engine (SAE 10W-30, API Certified) 6.0 qts. 5.7 liters
5.7 Liter Engine (SAE 5W-20, API Certified) 7.0 qts. 6.6 liters
Cooling System *
2.7 Liter Engine (MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula)
or equivalent.9.9 qts 9.4 liters
3.5 Liter Engine without All Wheel Drive (MoparAntifreeze/Coolant 5
Year/100,000 Mile Formula) or equivalent.11.1 qts 10.5 liters
3.5 Liter Engine with All Wheel Drive (MoparAntifreeze/Coolant 5 Year/
100,000 Mile Formula) or equivalent.11.4 qts 10.8 liters
5.7 Liter Engine without Severe Duty II Cooling System (Mopar
Antifreeze/Coolant 5 Year/100,000 Mile Formula) or equivalent.14.7 qts 13.9 liters
5.7 Liter Engine with Severe Duty II Cooling System (MoparAntifreeze/
Coolant 5 Year/100,000 Mile Formula) or equivalent.15.1 qts 14.3 liters
* Includes heater and coolant recovery bottle filled to MAX level.
350 MAINTAINING YOUR VEHICLE

FLUIDS, LUBRICANTS, AND GENUINE PARTS
Engine
Component Fluids, Lubricants, and Genuine Parts
Engine Coolant MoparAntifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or-
ganic Additive Technology) or equivalent
Engine Oil (2.7 Liter) Use API Certified engine oil. SAE 5W-20 is recommended. Refer to the en-
gine oil fill cap for the correct SAE grade meeting DaimlerChrysler Material
Standard MS-6395.
Engine Oil (3.5 Liter) Use API Certified engine oil. SAE 10W-30 is recommended. Refer to the en-
gine oil viscosity chart for the correct SAE grade meeting DaimlerChrysler
Material Standard MS-6395.
Engine Oil (5.7 Liter) Use API Certified engine oil. SAE 5W-20 is recommended. Refer to the en-
gine oil fill cap for the correct SAE grade meeting DaimlerChrysler Material
Standard MS-6395.
Oil Filter (2.7 Liter) Mopar05281090 or equivalent.
Oil Filter (3.5 Liter) Mopar05281090 or equivalent.
Oil Filter (5.7 Liter) Mopar05281090 or equivalent.
Spark Plugs Refer to the Vehicle Emission Control Information label in the engine com-
partment.
Fuel Selection (2.7 Liter) 87 Octane
Fuel Selection (3.5 Liter) 87 to 89 Octane
Fuel Selection (5.7 Liter) 87 to 89 Octane
MAINTAINING YOUR VEHICLE 351
7

Chassis
Component Fluids, Lubricants, and Genuine Parts
Automatic Transmission MoparATF+4 Automatic Transmission Fluid.
Brake Master Cylinder MoparDOT 3, SAE J1703 should be used. If DOT 3, SAE J1703 brake
fluid is not available, then DOT 4 is acceptable. Use only recommended
brake fluids.
Front Axle API Certified GL-5 SAE 75W90 Synthetic Gear Lubricant or equivalent.
Power Steering Reservoir MoparPower Steering Fluid + 4, MoparATF+4 Automatic Transmission
Fluid.
Rear Axle API Certified GL-5 SAE 75W140 Synthetic Gear Lubricant or equivalent.
Transfer Case MoparTransfer Case Lubricant LX, P/N 05170055AA, or equivalent.
352 MAINTAINING YOUR VEHICLE
