2007 DODGE MAGNUM Owners Manual

REAR WINDOW FEATURES
Rear Wiper Operation
The rear wiper is operated by the rear wiper/
washer switch. The switch is located near the top
center of the instrument panel. An indicator in the switch
illuminates when the rear wiper is on.
To use the rear wiper, push the left side of the rear
wiper/washer switch in and release.The rear wiper system is intermittent, and is not adjust-
able. The delay is approximately 8 to 9 seconds between
cycles.
CAUTION!
Turn the rear wiper off when driving through an
automatic car wash. Damage to the rear wiper may
result if the wiper switch is left in any position other
than OFF.
Rear Washer Operation
The rear washer is operated by the rear wiper/
washer switch. The switch is located near the top
center of the instrument panel.
To use the rear washer, push the right side of the rear
wiper/washer switch in and hold while spray is desired
(maximum spray of 10 seconds). The rear wiper operates
for 2 wipe cycles after the switch is released.
Rear Wiper/Washer Switch
UNDERSTANDING YOUR INSTRUMENT PANEL 201
4

Adding Washer Fluid
The windshield washer and rear window washer share
the same fluid reservoir. The reservoir is located in the
front of the engine compartment on the passenger side of
the vehicle. Be sure to check the fluid level at regular
intervals. Fill the reservoir with windshield washer sol-
vent (not radiator antifreeze) and operate the system for
a few seconds to flush out the residual water.The washer fluid reservoir will hold a full gallon of fluid
when the message “Low Washer Fluid” appears in the
Electronic Vehicle Information Center (EVIC) — if
equipped.
WARNING!
Commercially available windshield washer solvents
are flammable. They could ignite and burn you. Care
must be exercised when filling or working around
the washer solution.
Electric Rear Window Defroster
The electric Rear Window Defroster Control is
located on the climate control. Press this button to
turn on the rear window defroster and the heated side
mirrors (if equipped). An LED in the button will illumi-
nate when the rear window defroster is ON. The de-
froster automatically turns off after approximately 10
minutes of operation for the first push of the button, and
will turn off after approximately 5 minutes for the second
push of the button.
202 UNDERSTANDING YOUR INSTRUMENT PANEL

CAUTION!
To avoid damaging the electrical conductors of the
rear window defroster, do not use scrapers, sharp
instruments, or abrasive window cleaners on the
interior surface of the window.
Labels can be peeled off after soaking with warm
water.
UNDERSTANDING YOUR INSTRUMENT PANEL 203
4

STARTING AND OPERATING
CONTENTS

Starting Procedures....................208
▫Automatic Transmission................209
▫Normal Starting......................209
▫Extremely Cold Weather (Below
20°F
Or
29°C)..........................209
▫If Engine Fails To Start.................209
▫After Starting........................210

Engine Block Heater — If Equipped........211

Automatic Transmission.................211
▫Automatic Transmission — General
Information.........................212
▫Brake/Transmission Shift Interlock System . . . 213▫4 Speed Automatic Transmission..........214
▫5 Speed Automatic Transmission..........219

AutoStick— If Equipped...............223
▫AutoStickOperation..................223

All Wheel Drive — If Equipped...........223

Driving On Slippery Surfaces.............224
▫Acceleration.........................224
▫Traction............................224

Parking Brake.........................225

Brake System.........................226
▫Anti-Lock Brake System — If Equipped.....226
5

Power Steering........................229

Multi Displacement System (MDS) - 5.7L
Engine Only
..........................230

Traction Control System (TCS) — If
Equipped
............................230

Brake Assist System (BAS) — If Equipped....232

Electronic Stability Program (ESP) — If
Equipped
............................233
▫Synchronizing ESP....................235
▫ESP/BAS Malfunction Indicator And ESP/TCS
Indicator Lights......................235

Tire Safety Information..................236
▫Tire Markings........................236
▫Tire Identification Number (TIN)..........239
▫Tire Loading And Tire Pressure...........240

Tires — General Information..............244
▫Tire Pressure.........................244▫Tire Inflation Pressures.................245
▫Radial-Ply Tires......................247
▫Compact Spare Tire — If Equipped.........247
▫Limited Use Spare — If Equipped.........248
▫Tire Spinning........................248
▫Tread Wear Indicators..................249
▫LifeOfTire .........................250
▫Replacement Tires.....................250
▫Alignment And Balance.................251

Self–Sealing Tires — If Equipped..........252

Tire Chains...........................252

Snow Tires...........................253

Tire Rotation Recommendations...........253

Tire Pressure Monitor System (TPMS) — If
Equipped
............................254
▫Base System — If Equipped..............256
206 STARTING AND OPERATING

▫Premium System — If Equipped..........258
▫General Information...................261

Fuel Requirements.....................261
▫2.7L Engine.........................261
▫3.5L And 5.7L Engines..................261
▫Reformulated Gasoline.................262
▫Gasoline/Oxygenate Blends..............262
▫MMT In Gasoline.....................263
▫Materials Added To Fuel................263
▫Fuel System Cautions..................263
▫Carbon Monoxide Warnings..............264

Adding Fuel..........................265
▫Fuel Filler Cap (Gas Cap)...............265
▫Loose Fuel Filler Cap Message............267

Vehicle Loading.......................267
▫Vehicle Certification Label...............267▫Gross Vehicle Weight Rating (GVWR).......268
▫Gross Axle Weight Rating (GAWR).........268
▫Overloading.........................268
▫Loading............................268

Trailer Towing........................270
▫Common Towing Definitions.............270
▫Trailer Hitch Classification...............273
▫Trailer Towing Weights (Maximum Trailer Weight
Ratings)............................273
▫Trailer And Tongue Weight..............275
▫Towing Requirements..................276
▫TowingTips .........................280

Recreational Towing
(Behind Motorhome, Etc.)
................282
▫Towing This Vehicle Behind Another Vehicle
(Flat Towing With All Four Wheels On The
Ground)............................282
STARTING AND OPERATING 207
5

STARTING PROCEDURES
Before starting your vehicle, adjust your seat, adjust the
inside and outside mirrors, fasten your seat belt, and if
present, instruct all other occupants to buckle their seat
belts.WARNING!
•Never leave children alone in a vehicle. Leaving
children in a vehicle unattended is dangerous for
a number of reasons. A child or others could be
seriously or fatally injured. Don’t leave the keys
in the ignition. A child could operate power
windows, other controls, or move the vehicle.
•Do not leave animals or children inside parked
vehicles in hot weather; interior heat build up
may cause serious injury or death.
•Be sure to turn off the engine if you want to rest or
sleep in your car. Accidents can be caused by
inadvertently moving the gear selection lever or
by pressing the accelerator pedal. This may cause
excessive heat in the exhaust system, resulting in
overheating and vehicle fire, which may cause
serious or fatal injuries.
208 STARTING AND OPERATING
