2007 CADILLAC DTS Owners Manual

ENGINE OVERHEATED IDLE ENGINE
Notice:If you drive your vehicle while the
engine is overheating, severe engine damage
may occur. If an overheat warning appears
on the instrument panel cluster and/or
DIC, stop the vehicle as soon as possible.
Do not increase the engine speed above
normal idling speed. SeeEngine Overheating
on page 377for more information.
This message displays when the engine coolant
temperature is too hot. Stop and allow the vehicle
to idle until it cools down. SeeEngine Coolant
Temperature Warning Light on page 233.
SeeOverheated Engine Protection Operating
Mode on page 379for information on driving to
a safe place in an emergency.
ENGINE OVERHEATED STOP ENGINE
Notice:If you drive your vehicle while the
engine is overheating, severe engine damage
may occur. If an overheat warning appears
on the instrument panel cluster and/or
DIC, stop the vehicle as soon as possible.
SeeEngine Overheating on page 377for more
information.This message displays when the engine has
overheated. Immediately look for a safe place
to pull your vehicle over and turn the engine
off right away to avoid severe engine damage.
SeeEngine Overheating on page 377and
Overheated Engine Protection Operating Mode
on page 379. A chime also sounds when this
message is displayed.
ENGINE POWER REDUCED
This message displays when the engine power is
being reduced to protect the engine from damage.
There could be several malfunctions that might
cause this message. Reduced engine power
can affect the vehicle’s ability to accelerate.
If this message is on, but there is no reduction
in performance, proceed to your destination.
The performance may be reduced the next time
the vehicle is driven. The vehicle may be driven
at a reduced speed while this message is on, but
acceleration and speed may be reduced. Anytime
this message stays on, the vehicle should be taken
to your dealer for service as soon as possible.
249

FOLLOWING GAP
This symbol appears with this message.
If your vehicle has Adaptive Cruise Control (ACC),
this message displays to show the follow
distance that has been set. There are six follow
distances to choose from. Each follow distance
is shown on the DIC by displaying from one to
six bars between two car symbols. SeeAdaptive
Cruise Control on page 179for more information.
FUEL LEVEL LOW
This symbol appears
with this message.
This message displays when your vehicle is low
on fuel. Rell the fuel tank as soon as possible.
A single chime sounds when this message is
displayed. SeeFilling the Tank on page 358.
HEATED WASHER FLUID SYSTEM OFF
This message displays when you manually turn
off the heated washer uid system or when
the system automatically turns off. See “Heated
Washer Fluid” underWindshield Washer on
page 175for more information.
250

HEATING WASH (Washer) FLUID
WASH (Washer) WIPES PENDING
This message displays when you turn on the
heated washer uid system. See “Heated Washer
Fluid” underWindshield Washer on page 175
for more information.
HOOD OPEN
This symbol appears
with this message.
This message displays when the hood is not
closed completely. Make sure that the hood is
completely closed.
ICE POSSIBLE DRIVE WITH CARE
This message displays when the outside
temperature is cold enough to create icy road
conditions.
LEFT REAR DOOR OPEN
This symbol appears
with this message.
This message displays when the driver’s side rear
door is not closed completely. Make sure that
the door is closed completely.
NO CRUISE BRAKING GAS PEDAL
APPLIED
This message displays when the Adaptive Cruise
Control (ACC) is engaged and you are pressing
the accelerator pedal enough to disable ACC
automatic braking. SeeAdaptive Cruise Control
on page 179for more information.
251

OIL PRESSURE LOW STOP ENGINE
Notice:If you drive your vehicle while
the engine oil pressure is low, severe engine
damage may occur. If a low oil pressure
warning appears on the instrument panel
cluster and/or DIC, stop the vehicle as soon
as possible. Do not drive the vehicle until
the cause of the low oil pressure is corrected.
SeeEngine Oil on page 365for more
information.
This message displays when the vehicle’s engine
oil pressure is low. The oil pressure light also
appears on the instrument panel cluster.
SeeOil Pressure Light on page 237.
A multiple chime sounds when this message
is displayed. SeeEngine Oil on page 365for
more information.
Stop the vehicle immediately, as engine damage
can result from driving a vehicle with low oil
pressure. Have the vehicle serviced by your
dealer as soon as possible when this message
is displayed.
PARKING ASSIST OFF
If your vehicle has the Ultrasonic Front and Rear
Parking Assist (UFRPA) system, after the vehicle is
shifted out of PARK (P), this message displays to
remind the driver that the UFRPA system has
been turned off. Press the set/reset button to
acknowledge this message and clear it from the
DIC display. To turn the UFRPA system back on,
see “PARKING ASSIST” underDIC Controls and
Displays on page 240. SeeUltrasonic Front and
Rear Parking Assist (UFRPA) on page 202for more
information.
PASSENGER DOOR OPEN
This symbol appears
with this message.
This message displays when the passenger’s side
front door is not closed completely. Make sure
that the door is closed completely.
252

RADAR CRUISE NOT READY
This message displays when the Adaptive Cruise
Control (ACC) system will not activate due to a
temporary condition. Your vehicle does not require
service. If this message appears when you
attempt to activate the system, continue driving
for several minutes and then try activating
the system again. SeeAdaptive Cruise Control
on page 179for more information.
RAINSENSE WIPERS ACTIVE
If your vehicle has Rainsense™ II wipers, this
message displays while this feature is active.
SeeRainsense™ II Wipers on page 173for more
information.
REMOTE KEY LEARNING ACTIVE
This message displays while you are matching
a Remote Keyless Entry (RKE) transmitter to your
vehicle. See “Matching Transmitter(s) to Your
Vehicle” underRemote Keyless Entry (RKE)
System Operation on page 96andDIC Controls
and Displays on page 240for more information.
REPLACE BATTERY IN REMOTE KEY
This message displays when the battery in
the Remote Keyless Entry (RKE) transmitter
needs to be replaced. To replace the battery,
see “Battery Replacement” underRemote Keyless
Entry (RKE) System Operation on page 96.
RIGHT REAR DOOR OPEN
This symbol appears
with this message.
This message displays when the passenger’s side
rear door is not closed completely. Make sure
that the door is closed completely.
SERVICE AIR BAG
This message displays when there is a problem
with the airbag system. Have your vehicle serviced
by your dealer immediately. SeeAirbag Readiness
Light on page 226for more information.
253

SERVICE A/C SYSTEM
This message displays when the air delivery mode
door or the electronic sensors that control the air
conditioning and heating systems are no longer
working. Have the climate control system serviced
by your dealer if you notice a drop in heating and air
conditioning efficiency.
SERVICE BATTERY CHARGING
SYSTEM
This message displays when a problem with the
charging system has been detected. The charging
system light also displays on the instrument
panel cluster. SeeCharging System Light on
page 229for more information. Have your vehicle
serviced by your dealer.
SERVICE BRAKE ASSIST
This message displays if there is a problem with the
brake system. The brake system warning light and
the anti-lock brake system warning light may also
be displayed on the instrument panel cluster.
SeeBrake System Warning Light on page 229andAnti-Lock Brake System Warning Light on page 230
for more information. If this happens, stop as soon
as possible and turn off the vehicle. Restart the
vehicle and check for the message on the DIC
display. If the message is displayed or appears
again when you begin driving, the brake system
needs service. See your dealer as soon as
possible. SeeBrakes on page 387for more
information.
SERVICE BRAKE SYSTEM
This message displays if the ignition is on to
inform the driver that the brake uid level is low.
Have the brake system serviced by your dealer as
soon as possible.
SERVICE PARKING ASSIST
If your vehicle has the Ultrasonic Front and Rear
Parking Assist (UFRPA) system, this message
displays if there is a problem with the UFRPA
system. Do not use this system to help you park.
SeeUltrasonic Front and Rear Parking Assist
(UFRPA) on page 202for more information.
See your dealer for service.
254

SERVICE POWER STEERING
Your vehicle may have a speed variable assist
steering system. SeeSteering on page 312.
This message displays if a problem is detected
with the speed variable assist steering system.
When this message is displayed, you may notice
that the effort required to steer the vehicle
decreases or feels lighter, but you will still be
able to steer the vehicle.
SERVICE RADAR CRUISE
This message displays when the Adaptive Cruise
Control (ACC) system and the Forward Collision
Alert (FCA) system are disabled and need service.
See your dealer.
SERVICE STABILITRAK
Your vehicle may have a vehicle stability
enhancement system called StabiliTrak®.
SeeStabiliTrak®System on page 311.
This message displays if there has been a
problem detected with the StabiliTrak
®system.If this message comes on while you are driving,
pull off the road as soon as possible and stop
carefully. Try resetting the system by turning
the ignition off then back on. If this message
still stays on or comes back on again while you
are driving, your vehicle needs service. Have
the StabiliTrak
®system inspected by your dealer
as soon as possible.
SERVICE SUSPENSION SYS (System)
This message displays when the magnetic ride
control or automatic leveling control system is not
operating properly. Have your vehicle serviced by
your dealer.
SERVICE THEFT DETERRENT SYSTEM
This message displays when there is a problem
with the theft-deterrent system programmed in the
key. A fault has been detected in the system which
means that the system is disabled and it is not
protecting the vehicle. The vehicle usually restarts;
however, you may want to take the vehicle to
your dealer before turning off the engine. See
PASS-Key
®III+ Operation on page 115for more
information.
255

SERVICE TIRE MONITOR SYSTEM
This message displays if a part on the Tire
Pressure Monitor (TPM) system is not working
properly. If you drive your vehicle while any of
the four sensors are missing or inoperable,
the warning comes on in about 20 minutes.
A sensor would be missing, for example,
if you put different wheels on your vehicle
without transferring the sensors. If the warning
comes on and stays on, there may be a problem
with the TPM. See your dealer.
SERVICE TRACTION CONTROL
This message displays when there is a problem
with the Traction Control System (TCS). When
this message is displayed, the system will not limit
wheel spin. Adjust your driving accordingly. See
your dealer for service. SeeTraction Control
System (TCS) on page 309for more information.
SERVICE TRANSMISSION
This message displays when there is a problem
with the vehicle’s transaxle. Have your vehicle
serviced by your dealer.
SERVICE VEHICLE SOON
This message displays when a non-emissions
related malfunction occurs. Have your vehicle
serviced by your dealer as soon as possible.
SET SPD (Speed)
If your vehicle has Adaptive Cruise Control (ACC),
this message displays whenever the cruise control
is set. First, the “CRUISE SET TO XXX MPH
(km/h)” message appears. After a few seconds,
the “CRUISE SET TO XXX MPH (km/h)” message
clears and the message “SET SPD XX” displays
at the bottom of the DIC. See “CRUISE SET TO
XXX MPH (km/h)” earlier in this section and
Adaptive Cruise Control on page 179for more
information.
SPEED LIMITED TO XXX MPH (km/h)
This message displays when your vehicle speed
is limited to 80 mph (128 km/h) because the
vehicle detects a problem in the speed variable
assist steering, magnetic ride control, or automatic
leveling control systems. Have your vehicle
serviced by your dealer.
256
