2007 CADILLAC DTS ESP

This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
1. This device may not cause interference.
2. This device must accept any interference
received, including interference that may
cause undesired operation of the device.
Changes or modications to this system by other
than an authorized service facility could void
authorization to use this equipment.
Adaptive Cruise Control is an enhancement
to traditional cruise control. It allows you to
keep cruise control engaged in moderate traffic
conditions without having to constantly reset your
cruise control. Adaptive Cruise Control uses
radar to detect a vehicle directly ahead in your
path, within a distance of 330 ft (100 m), and
operates at speeds above 25 mph (40 km/h).
When it is engaged by the driver, the system
can apply limited braking or acceleration of the
vehicle automatically to maintain a selected follow
distance to the vehicle ahead. Braking is limited
to 0.25 g’s (2.45 m/sec2)of deceleration, which iscomparable to moderate application of the
vehicle’s brakes. To disengage Adaptive Cruise
Control, apply the brake. If no vehicle is in
your path, the vehicle will react like traditional
cruise control.
{CAUTION:
Adaptive Cruise Control will not apply
hard braking or bring the vehicle to a
complete stop. It will not respond to
stopped vehicles, pedestrians or animals.
When you are approaching a vehicle or
object, Adaptive Cruise Control may not
have time to slow your vehicle enough to
avoid a collision. Your complete attention
is always required while driving and you
should be ready to take action and apply
the brakes. For more information, see
Defensive Driving on page 302.
180

Approaching and Following a Vehicle
The Vehicle Ahead
symbol is located on the
top of the instrument
panel to the right of the
driver.
The Vehicle Ahead symbol will only appear when
a vehicle is detected in your path.
If this symbol does not appear, or disappears
briey, Adaptive Cruise Control will not respond to
vehicles you may see ahead.{CAUTION:
When the Adaptive Cruise Control radar is
blocked by snow, ice, or dirt, it may not
detect a vehicle ahead. Adaptive Cruise
Control may not have time to slow your
vehicle enough to avoid a collision. Do
not use Adaptive Cruise Control when
the radar is blocked by snow, ice, or dirt.
Keep your radar clean. See “Cleaning the
System” later in this section.
Adaptive Cruise Control will automatically slow
your vehicle down when approaching a slower
moving vehicle. It will then adjust your speed to
follow the vehicle in front at the selected follow
distance. Your speed will increase or decrease
to follow the vehicle in front of you but will
not exceed the set speed. It may apply limited
braking, if necessary. When braking is active,
your brake lights will come on. Braking may feel
or sound different than if you were applying
the brakes yourself. This is normal.
187

Passing a Vehicle/Adaptive Cruise Control
Override
If you need to increase speed to pass a vehicle,
use the accelerator pedal. While you are doing
this, the system will not automatically apply
the brakes. A message will appear on the DIC.
SeeDIC Warnings and Messages on page 246.
Once you remove your foot from the accelerator
pedal, Adaptive Cruise Control will return to normal
operation and be able to apply the brakes,
if needed.
{CAUTION:
If you rest your foot on the accelerator
pedal, the system will not automatically
apply the brakes. You could crash into a
vehicle ahead of you. Do not rest your
foot on the accelerator pedal when using
Adaptive Cruise Control.
Curves in the Road
{CAUTION:
Due to Adaptive Cruise Control limitations
in curves, it may respond to a vehicle in
another lane, or may not have time to react
to a vehicle in your lane. You could crash
into a vehicle ahead of you, or lose control
of your vehicle. Give extra attention in
curves and be ready to use the brakes if
necessary. Select an appropriate speed
while driving in curves.
Adaptive Cruise Control may operate differently in
a sharp curve. It may reduce your speed if the
curve is too sharp.
189

When following a vehicle and entering a curve,
Adaptive Cruise Control could lose track of
the vehicle in your lane and accelerate your
vehicle. When this happens the Vehicle Ahead
symbol will not appear.Adaptive Cruise Control may detect a vehicle that
is not in your lane and apply the brakes.
Adaptive Cruise Control may, occasionally,
provide a driver alert and/or braking that you
consider unnecessary. It could respond to signs,
guardrails, and other stationary objects when
entering or exiting a curve. This is normal
operation. Your vehicle does not need service.
190

Using Adaptive Cruise Control on Hills
and When Towing a Trailer
How well Adaptive Cruise Control will work on hills
and when towing a trailer depends on your vehicle’s
speed, vehicle load, traffic conditions and the
steepness of the hills. It may not detect a vehicle
in your lane while driving on hills. When going up
steep hills, you may want to use the accelerator
pedal to maintain your vehicle’s speed. When going
downhill, especially when towing a trailer, you may
want to brake to keep your speed down. Applying
the brake disengages the system. You may choose
not to use Adaptive Cruise Control on steep hills,
especially when towing a trailer.
Disengaging Adaptive Cruise Control
To turn off the system, apply the brake pedal,
press the cancel button, or press the Adaptive
Cruise Control button.
Erasing Set Speed Memory
When you press the Adaptive Cruise Control
button or turn the ignition off, the set speed
memory is erased.
Other Messages
There are three additional messages that may
appear on the DIC. They are SERVICE RADAR
CRUISE, RADAR CRUISE NOT READY and
CLEAN RADAR. These messages will appear
to indicate a problem with the Adaptive Cruise
Control. SeeDIC Warnings and Messages
on page 246for more information.
Cleaning the System
The radar can become blocked by snow, ice, or
dirt. If so, you may need to turn off the engine and
clean the lens. Remember, do not use Adaptive
Cruise Control in icy conditions, or when visibility
is low, such as in fog, rain or snow.
The emblem/lens is located in the center of
the grille.
To clean the emblem/lens, wipe the surface with a
soft cloth. After cleaning the emblem/lens, try to
engage the Adaptive Cruise Control. If you
are unable to do so, see your dealer.
192

Wiper Activated Headlamps
This feature activates the headlamps and parking
lamps after the windshield wipers are turned
on and have completed eight wipe cycles within
four minutes.
When the ignition is turned to OFF, the
wiper-activated headlamps immediately turn off.
The wiper-activated headlamps also turn off if the
windshield wipers are turned off.
Headlamps on Reminder
A warning chime will sound if the exterior lamp
control is left on in either the headlamp or parking
lamp position and the driver’s door is opened
with the ignition off.
Daytime Running Lamps (DRL)
Daytime Running Lamps (DRL) can make it easier
for others to see the front of your vehicle during
the day. DRL can be helpful in many different
driving conditions, but they can be especially
helpful in the short periods after dawn and before
sunset. Fully functional daytime running lamps
are required on all vehicles rst sold in Canada.
The DRL system will make the turn signal lamps
come on when the following conditions are met:
It is still daylight and the ignition is on.
The exterior lamp control is in the off position.
The transaxle is not in PARK (P)
(United States only).
The light sensor is covered or not detecting
light. See “Sensors” underDual Climate Control
System on page 210.
When DRL are on, no other exterior lamps such as
the parking lamps, taillamps, etc. will be on when
the DRL are being used. Your instrument panel will
not be lit up either.
197

DISPLAY LANGUAGE
This feature allows you to select the language in
which the DIC messages will appear.
Press the customization button until the DISPLAY
LANGUAGE screen appears on the DIC display.
Press the set/reset button to access the settings
for this feature. Then press the menu up/down
button to scroll through the following settings:
ENGLISH (default):All messages will appear in
English.
DEUTSCH:All messages will appear in German.
FRANCAIS:All messages will appear in
French.
ESPANOL:All messages will appear in Spanish.
JAPANESE:All messages will appear in
Japanese.
ARABIC:All messages will appear in Arabic.
NO CHANGE:No change will be made to
this feature. The current setting will remain.
Choose one of the available settings and press
the set/reset button while it is displayed on the DIC
to select it.
AUTO DOOR LOCK
This feature allows you to select when the
vehicle’s doors will automatically lock. See
Programmable Automatic Door Locks on page 104
for more information.
Press the customization button until AUTO DOOR
LOCK appears on the DIC display. Press the
set/reset button to access the settings for this
feature. Then press the menu up/down button to
scroll through the following settings:
SHIFT OUT OF PARK (default):The vehicle’s
doors automatically lock when the doors are
closed and the vehicle is shifted out of PARK (P).
AT VEHICLE SPEED:The vehicle’s doors
automatically lock when the vehicle speed is
above 5 mph (8 km/h) for three seconds.
NO CHANGE:No change will be made to this
feature. The current setting will remain.
Choose one of the available settings and press
the set/reset button while it is displayed on the DIC
to select it.
260

Radio Reception
You may experience frequency interference
and static during normal radio reception if items
such as cellphone chargers, vehicle convenience
accessories, and external electronic devices
are plugged into the accessory power outlet.
If there is interference or static, unplug the item
from the accessory power outlet.
AM
The range for most AM stations is greater than
for FM, especially at night. The longer range can
cause station frequencies to interfere with each
other. For better radio reception, most AM
radio stations will boost the power levels during
the day, and then reduce these levels during
the night. Static can also occur when things
like storms and power lines interfere with radio
reception. When this happens, try reducing
the treble on your radio.
FM Stereo
FM stereo will give the best sound, but FM signals
will reach only about 10 to 40 miles (16 to 65 km).
Tall buildings or hills can interfere with FM
signals, causing the sound to fade in and out.
XM™ Satellite Radio Service
XM™ Satellite Radio Service gives digital radio
reception from coast-to-coast in the 48 contiguous
United States, and in Canada. Just as with FM,
tall buildings or hills can interfere with satellite
radio signals, causing the sound to fade in and out.
In addition, traveling or standing under heavy
foliage, bridges, garages, or tunnels may cause
loss of XM signal for a period of time. The
radio may display NO XM SIGNAL to indicate
interference.
298
