11. Align the retaining clips on the back of the
headlamp with the rectangular holes in the
mounting panel.
12. Push rmly on both ends of the headlamp to
snap it into position.
13. Push the retaining clip down to its original
position.
14. Reinstall the wing stud.Taillamps, Turn Signal, and
Stoplamps
1. Open the liftgate. SeeLiftgate on page 118
for more information.
2. Remove the
two screws on
the inboard
taillamp panel.
3. Pull the lamp directly rearward from the
vehicle.
401

4. Turn the bulb socket one-quarter of a turn
counterclockwise.
5. Pull the bulb assembly out from the lamp
housing.
6. Unhook the electrical connector by lifting up
the tabs and separate the connector from the
bulb base.
7. Install the new bulb into the electrical
connector. Push the bulb rmly enough so
that the tabs hook over the tab on the bulb.
8. Reverse the steps to reinstall.
9. Reinstall the lamp to its pocket by lining up
the mounting pin and pushing forward to set
the position.
10. Reinstall the screws removed in Step 2.
11. Close the liftgate.Taillamps and Back-Up Lamps
This procedure is for the liftgate-mounted taillamps
and back-up lamps. To replace one of these bulbs,
do the following:
1. Open the liftgate. SeeLiftgate on page 118
for more information.
2. Remove the panel inside the liftgate by lifting
the tabs and pulling the panel off.
3. Remove the seven
wing nuts and the
four outboard nuts
(two at each end).
4. Gently lower the liftgate.
5. Pull the lamp assembly directly rearward from
the vehicle.
402

A. Outboard Taillamp
B. Center Taillamp
C. Inboard Back-Up Lamp
6. Turn the bulb socket counterclockwise
one-quarter of a turn.7. Pull the bulb assembly out from the lamp
housing.
8. Pull the bulb out of the base.
9. Install the new bulb into the electrical
connector. Push the bulb rmly enough so
that the tabs hook over the tab on the bulb.
10. Put the bulb assembly back into the lamp
housing and turn the bulb socket clockwise
one-quarter of a turn.
11. Reinstall the lamp assembly on the liftgate.
12. Gently lift the liftgate.
13. Reinstall the seven wing nuts and the four
outboard nuts.
14. Reinstall the panel inside the liftgate by
connecting the tabs.
15. Close the liftgate.
403

Replacement Bulbs
Exterior Lamp Bulb Number
Front Turn Signal/Parking Lamp 3457K
Headlamps
High-beam 9005
Low-beam 9006
Liftgate-Mounted
Back-up Lamp 921
Taillamp 161
Rear Outboard
Stoplamp/Taillamp/Turn
Signal Lamp3057K
Sidemarker Lamp 168
For replacement bulbs not listed here, contact
your dealer.
Windshield Replacement
Keep in mind that your windshield is part of the
Head-Up Display (HUD) system. If you ever have
to get your windshield replaced, be sure to get
one that is designed for HUD or your HUD image
may look blurred or out of focus.
Windshield Wiper Blade
Replacement
Windshield wiper blades should be inspected for
wear and cracking. SeeScheduled Maintenance
on page 475for more information.
Replacement blades come in different types and
are removed in different ways. For proper type and
length, seeNormal Maintenance Replacement
Parts on page 486.
404

To replace the windshield wiper blade assembly
do the following:
1. Lift the wiper arm away from the windshield.2. Push the release lever (B) to disengage the
hook and push the wiper arm (A) out of the
blade (C).
3. Push the new wiper blade securely on the
wiper arm until you hear the release lever
click into place.
To replace the rear wiper blade, follow the steps
listed above.
405

Tires
Your new vehicle comes with high-quality tires
made by a leading tire manufacturer. If you ever
have questions about your tire warranty and where
to obtain service, see your GM Warranty booklet for
details. For additional information refer to the tire
manufacturer’s booklet included with your vehicle.
{CAUTION:
Poorly maintained and improperly used
tires are dangerous.
Overloading your vehicle’s tires can
cause overheating as a result of too
much friction. You could have an
air-out and a serious accident. See
Loading Your Vehicle on page 332.
CAUTION: (Continued)
CAUTION: (Continued)

Underinated tires pose the same
danger as overloaded tires. The
resulting accident could cause serious
injury. Check all tires frequently to
maintain the recommended pressure.
Tire pressure should be checked when
your vehicle’s tires are cold. See
Inflation - Tire Pressure on page 413.
Overinated tires are more likely to be
cut, punctured, or broken by a sudden
impact — such as when you hit a
pothole. Keep tires at the
recommended pressure.
Worn, old tires can cause accidents.
If the tire’s tread is badly worn, or if
your vehicle’s tires have been
damaged, replace them.
406

Tire Sidewall Labeling
Useful information about a tire is molded into its
sidewall. The examples below show a typical
passenger vehicle tire and a compact spare tire
sidewall.(A) Tire Size:The tire size is a combination of
letters and numbers used to dene a particular
tire’s width, height, aspect ratio, construction type,
and service description. See the “Tire Size”
illustration later in this section for more detail.
(B) TPC Spec (Tire Performance Criteria
Specication):Original equipment tires designed
to GM’s specic tire performance criteria have a
TPC specication code molded onto the sidewall.
GM’s TPC specications meet or exceed all federal
safety guidelines.
(C) DOT (Department of Transportation):
The Department of Transportation (DOT) code
indicates that the tire is in compliance with the U.S.
Department of Transportation Motor Vehicle Safety
Standards.
(D) Tire Identication Number (TIN):The
letters and numbers following DOT (Department
of Transportation) code is the Tire Identication
Number (TIN). The TIN shows the manufacturer
and plant code, tire size, and date the tire was
manufactured. The TIN is molded onto both sides of
the tire, although only one side may have the date
of manufacture.
Passenger (P-Metric) Tire Example
407

(E) Tire Ply Material:The type of cord and
number of plies in the sidewall and under the
tread.
(F) Uniform Tire Quality Grading (UTQG):Tire
manufacturers are required to grade tires based on
three performance factors: treadwear, traction, and
temperature resistance. For more information see
Uniform Tire Quality Grading on page 420.
(G) Maximum Cold Ination Load Limit:
Maximum load that can be carried and the
maximum pressure needed to support that load.
(A) Temporary Use Only:The compact
spare tire or temporary use tire has a tread life of
approximately 3,000 miles (5 000 km) and should
not be driven at speeds over 65 mph (105 km/h).
The compact spare tire is for emergency use when
a regular road tire has lost air and gone at. If your
vehicle has a compact spare tire, seeCompact
Spare Tire on page 450andIf a Tire Goes Flat on
page 427.
Compact Spare Tire Example
408
