2007 BUICK LUCERNE Owner's Manual

Removing the Spare Tire and Tools
The equipment you will need is located in the
trunk.
1. If your vehicle has a
center retainer, turn
it counterclockwise
to remove it.
2. Lift and remove the compact spare tire cover.3. Remove the washer and retainer that holds
down the jack and wheel wrench.
4. Remove the jack container with the jack and
the wheel wrench.
5. Remove the spare tire from the vehicle. See
Compact Spare Tire on page 418for more
information.
409

The tools you will be using include the jack (A)
and the wheel wrench (B).
Removing the Flat Tire and
Installing the Spare Tire
1. Place the wheel wrench securely over the
wheel nut. Turn the wheel wrench
counterclockwise to loosen all the wheel nuts,
but do no remove them yet.
410

2. Turn the jack handle clockwise to raise the
jack lift head.
{CAUTION:
Raising your vehicle with the jack
improperly positioned can damage the
vehicle and even make the vehicle fall. To
help avoid personal injury and vehicle
damage, be sure to t the jack lift head
into the proper location before raising the
vehicle.
3. Put the jack into the ange in the frame which
is located near each wheel well. The anges
are accessible through openings in the
plastic trim at the bottom of the vehicle. The
front opening is about 8 inches (20 cm)
back from the front wheel well. The rear
opening is about 3 inches (8 cm) forward from
the rear wheel well.
411

4. Position the jack and raise the jack head
until it ts rmly on the ridge in the vehicle’s
frame nearest the at tire. Do not raise
the vehicle yet.
5. Put the compact spare tire near the at tire.
{CAUTION:
Getting under a vehicle when it is jacked
up is dangerous. If the vehicle slips off
the jack you could be badly injured or
killed. Never get under a vehicle when it is
supported only by a jack.6. Raise the vehicle by turning the jack handle
clockwise. Raise the vehicle far enough off
the ground for the compact spare tire to
t under the vehicle.
412

7. Remove all wheel
nuts and take off the
at tire.
{CAUTION:
Rust or dirt on the wheel, or on the parts
to which it is fastened, can make the
wheel nuts become loose after time. The
wheel could come off and cause an
accident. When you change a wheel,
CAUTION: (Continued)
CAUTION: (Continued)
remove any rust or dirt from the places
where the wheel attaches to the vehicle. In
an emergency, you can use a cloth or a
paper towel to do this; but be sure to use
a scraper or wire brush later, if needed, to
get all the rust or dirt off.
8. Remove any rust or
dirt from the wheel
bolts, mounting
surfaces and spare
wheel.
413

9. Install the compact spare tire.
{CAUTION:
Never use oil or grease on studs or nuts.
If you do, the nuts might come loose.
Your wheel could fall off, causing a
serious accident.
10. Put the wheel nuts back on with the rounded
end of the nuts toward the wheel. Tighten
each nut by hand until the wheel is held
against the hub.11. Lower the vehicle by turning the jack handle
counterclockwise. Lower the jack completely.
414

{CAUTION:
Incorrect wheel nuts or improperly
tightened wheel nuts can cause the wheel
to come loose and even come off. This
could lead to an accident. Be sure to use
the correct wheel nuts. If you have to
replace them, be sure to get new GM
original equipment wheel nuts. Stop
somewhere as soon as you can and have
the nuts tightened with a torque wrench to
the proper torque specication. See
Capacities and Specifications on page 436
for wheel nut torque specication.
Notice:Improperly tightened wheel nuts can
lead to brake pulsation and rotor damage.
To avoid expensive brake repairs, evenly
tighten the wheel nuts in the proper sequence
and to the proper torque specication. See
Capacities and Specifications on page 436for
the wheel nut torque specication.12. Tighten the wheel
nuts rmly in a
crisscross sequence
as shown.
Notice:Wheel covers will not t on your
compact spare. If you try to put a wheel cover
on the compact spare, you could damage
the cover or the spare.
Do not try to put the wheel cover on the compact
spare tire. It will not t. Store the wheel cover
in the trunk until you have the at tire repaired or
replaced.
415

Storing a Flat or Spare Tire
and Tools
{CAUTION:
Storing a jack, a tire, or other equipment
in the passenger compartment of the
vehicle could cause injury. In a sudden
stop or collision, loose equipment could
strike someone. Store all these in the
proper place.
After you have put the compact spare tire on your
vehicle, you need to store the at tire in your
trunk. Store the at tire as far forward in the trunk
as possible.
To store the compact spare tire and tools, do the
following:
416
