2007 BMW MOTORRAD K 1200 S spark plugs

1 Extending tool holderAdapters to accommodate all
tools
Removing and installing spark
plugs
2 1/4" bits 5x Torx, for example for remov-
ing and installing rear wheel
2x cross-head bits
1x plain screwdriver bit
3 3/8" adapter for socket-
head screws, w/f 22 Removing and installing front
axle 4 Electric torch
LED bulb
5 Socket 3x open-ended spanner, for
example for connecting and
disconnecting leads to battery
terminals
6 Adapter Adapter for 1/4" bits
9x12 mm and 3/8" swivel ad-
apters
Engine oilChecking engine oil level
The engine can seize if the
oil level is low, and this can
lead to accidents.
Always make sure that the oil
level is correct.
Oil can collect in the sump
if the motorcycle is out of
use for an extended period of
time; this oil has to be pumped into the oil tank before the level
is read. The engine oil must be
at operating temperature to do
this. Checking the oil level with
the engine cold or after no more
than a short ride will lead to mis-
interpretation; this in turn, means
that the engine will be operated
with the incorrect quantity of oil.
In order to ensure that the en-
gine oil level is read correctly,
check the oil level only after a
lengthy trip.
Make sure the engine is at op-
erating temperature and hold
the motorcycle upright.
with OA Centre stand:
Check that the engine is at op-
erating temperature, make sure
the ground is level and firm
and place the motorcycle on its
centre stand.
Allow the engine to idle for one
minute.
897zMaintenance

Tyre pressure
Tyre pressure, front 2.5 bar, one-up, tyre cold2.5 bar, two-up and/or with luggage, tyre cold
Tyre pressure, rear 2.9 bar, one-up, tyre cold 2.9 bar, two-up and/or with luggage, tyre coldElectricsElectrical rating of on-board socketmax 5 A
Fuses All circuits are electronically protected, so plug-
in fuses are no longer necessary. If an electronic
fuse trips and de-energises a circuit, the circuit is
active as soon as the ignition is switched on after
the fault has been rectified.
Battery
Battery, manufacturer and designation Yuasa YTX 14 BS
Battery type AGM (Absorptive Glass Mat) battery
Battery rated voltage 12 V
Battery rated capacity 14 Ah
Technical data
Spark plugs, manufacturer and designation NGK KR9CI
Electrode gap of spark plug 0.8 mm, When new
10144zTechnical data

K
Keys, 42
L
Laying up, 134
LightsHeadlight flasher, 15, 52
High-beam headlight, 15, 52
Low-beam headlight, 52
Parking light, 52
Side light, 52
Luggage Correct loading, 89
Luggage loops, 66
M
Maintenance General instructions, 96
Mirrors Adjusting, 58
Motorcycle General view, left side, 11
General view, right side, 13
Laying up, 134
Restoring to use, 134 Multifunction display, 17
Overview, 20
O
Odometer and tripmeters Resetting, 46
Selecting readings, 45
On-board computer Ambient temperature, 48
Average consumption, 49
Average speed, 48
Oil level, 50
Range, 50
Selecting readings, 47
P
Power socket, 11
Pre-ride check, 71
R
Rear-wheel drive Technical data, 141
Rear-wheel stand, 114
Refuelling, 77 Reserve
Warning, 24
Residual range, 47
Restoring to use, 134
Rev. counter, 17
Rims Test, 105
Running gear Technical data, 141
Running in, 73
S
Seat Installation, 64
Lock, 11
Removal, 63
Service, 150 Status indicators on the
display, 20
Service Card, 150
Side stand For starting, 70
Spark plugs, 144
Speedometer, 17
12161zIndex

Spring preloadAdjusting, 11, 58
Starter, 16
Steering lock Locking, 43
T
Technical data Battery, 144
Brakes, 142
Bulbs, 145
Clutch, 140
Electrics, 144
Engine, 138
Engine oil, 139
Frame, 145
Fuel, 139
Rear-wheel drive, 141
Running gear, 141
Spark plugs, 144
Standards, 7
Transmission, 140
Wheels and tyres, 142
Telltale lights, 17 Toolkit, 14
Service kit, 96
Standard kit, 96
Torques, 135
Transmission For starting, 70
Technical data, 140
Troubleshooting chart, 136
Turn indicators Left, 15, 53
Right, 16, 53
Switching off, 16, 53
Tyre pressure monitoring RDC Label on wheel rim, 105
Operation, 51
Status indicators, 51
Warning, 33
Tyres Checking inflation pressure, 62
Measuring tread depth, 104
Recommended tyres, 105
Running in, 73
Technical data, 142 V
Vehicle identification number, 13
W
Warning lights, 17
Warnings
Mode of presentation, 22
Warnings, overview, 23, 28, 30, 32, 35, 39
Wheels Installing front wheel, 107
Installing rear wheel, 111
Remove the front wheel, 106
Removing rear wheel, 109
Technical data, 142
12162zIndex
