2007 Acura RL sensor

Theclimatecontrolsystemhastwo
sensors. A sunlight sensor is in the
top of the dashboard, and a
temperature sensor is next to the
steering column. Do not cover the
sensors or spill any liquid on them. Sunlight and T emperature
Sensors
Climat e Cont rol Sensors
206
SUNLIGHT SENSORTEMPERATURE SENSOR
——
y

y
(y

y

The radar sensor for ACC is shared
with the collision mitigation brake
system (CMBS). For more
information on the radar sensor, see
page . For more information on
CMBS, see page .
Adaptive cruise control (ACC)
consists of a radar sensor in the
f ront grille, the ACC buttons on the
steering wheel, and the ACC
f unctions of the multi-inf ormation
display.
355
356
If equipped
A CC Components
A daptive Cruise Control (A CC)
278
ACC INDICATOR
MULTI-INFORMATION
DISPLAY
RES/ACCEL
BUTTON
ACC BUTTON
DISTANCE BUTTON
CANCEL BUTTON SET/DECEL
BUTTON
——
y

y
(yy

Adaptive cruise control (ACC) allows
you to maintain a set speed and keep
the vehicle ahead of you and your
vehicle at a safe distance without
having to use the accelerator pedal
or the brake pedal. If
the vehicle ahead of you slows
down suddenly or another vehicle
cu ts in front of your vehicle, ACC
al erts you by sounding a beeper and
displaying a message on the multi-
information display.
TheACCradarsensorinthefront
grille can detect and monitor the
distance of a vehic le up to 328 feet
(100 meters) ahead of your vehicle.
For more inf ormation on the radar
sensor, see page . Do not use ACC under these
conditions:
In poor visibility.
In heavy traffic.
When you must slow down and
speed up repeatedly.
On winding roads.
When you enter a toll gate,
interchange, service area, parking
area, etc. In these areas, there is
no vehicle ahead of you, but ACC
would still try to accelerate to your
set speed.
In bad weather (rain, f og, snow,
etc.)
On a slippery road (f or example a
road covered with ice or snow).
As with any system, there are limits
to ACC. Inappropriate use of ACC
can result in a serious accident. Use
the brake pedal whenever necessary,
and always keep a safe distance
between your vehicle and other
vehicles.
When the vehicle ahead of you slows
down or speeds up, ACC senses the
change in distance and compensates
by accelerating or braking your
vehicle to reach the cruising speed
you previously set. The distance
between vehicles is based on your
speed: the f aster you go, the longer
the distance will be; the slower you
go, the shorter it will be.
356
CONT INUED
Overview
Important Saf ety Precautions
A daptive Cruise Control (A CC)
Features
279
——
y

y
(yy

This indicator normally comes on for
a few seconds when you turn the
ignition switch to the ON (II)
position. If it comes on at any other
time, there is a problem in the ACC
system. If this happens, take the
vehicle to your dealer to have it
checked.
The ACC system cannot be used
while this indicator is on.
When
ACC is automatically
cancelled, the beeper sounds three
times, and an ACC OFF message
appears on the multi-info rmation
display for 3 seconds.
Any of these conditions may cause
ACC to cancel:
The vehic le speed decreases
below22mph(35km/h). Driving
on a mountainous road, or
driving off road for extended
periods.
When the VSA indicator comes on.
When
the ABS or VSA is activated.
Abrupt
steering wheel movement.
If ACC is cancelled by any these
conditions, wait until the condition
improves, then press the RES/
ACCEL button to restore ACC.
When you do this, the vehicle will
resume its set cruising speed.
If you turn the ignition switch to the
ACCESSORY (I) or LOCK (0)
position af ter ACC was automatically
cancelled, the set speed is erased,
and you must enter it again (see
page ).
Poor weather (rain, f og, snow, etc.)
When the radar sensor in the front
grille gets dirty.
The vehicle ahead of you cannot
be detected.
An abnormal tire condition is
detected, or the tires are skidding.
283
Automatic ACC Cancellation
ACC Indicator
A daptive Cruise Control (A CC)
Features
289
ACC INDICATOR
——
y
y
(yy

MessageMessage
Description Description
ACC detects a vehicle ahead of you.
You will hear a beep when the vehicle
moves out of the ACC radar sensor’s
range.
ACC does not detect a vehicle ahead
of you.
You will hear a beep when ACC
detects a vehicle ahead of you.
ACC has automatically cancelled
because its radar sensor in the f ront
grill is dirty.
You will hear three beeps. ACC has automatically cancelled
because of bad weather or other
conditions.
You will hear three beeps.
Apply the brakes immediately.
Your vehicle is too close to the vehicle
ahead of it.
You will hear a continuous beep.
ACC needs to be checked.
Have your vehicle checked by a
dealer.
A daptive Cruise Control (A CC)
Features
291
U.S.
U.S.
CANADA
CANADA
——
y
y
(yy

The CMBS does not activate if the
speed difference between your
ve hicles is less than 10 mph (15
km/h). CMBS may also not
activate if you turn the steering
wheel to avoid the collision.
When the CMBS activates, the brake
lights also come on.
The
collision mitigation brake
system (CMBS) can assist you when
there is a possibility of your vehicle
hitting the vehicle in front of you. It
is designed to reduce the speed of
your vehicle before an unavoidable
collision occu rs and, if possible, to
alert you to a poten tial collision while
thereistimetopreventit.Hereisa
brief description of what the CMBS
can do:
When your speed is above 10 mph
(15 km/h), the CMBS radar
sensor in the front grille can sense
a vehicle ahead of you. When your
vehicle gets too close to the
ve hicle ahead of you, the system
mayactivateawarningbeep,
causing automatic application of
the brakes, and causing the
e-pretensioners to tighten the
f ront seat belts (see page ). The CMBS consists of a radar
sensor in the f ront grille, a brake
actuator in the engine compartment,
an indicator on the instrument panel,
seat belt e-pretensioners on the f ront
seats,andanon/off switchonthe
dashboard.
24
If equipped
Collision Mitigation Brake System (CMBS)
Overview
Driving
355
RADAR SENSOR
BRAKE ACTUATOR SEAT BELT
E-PRETENS
IONER
——
y
y
(yy

The radar sensor is located behind
the Acura emblem in the f ront grille.
If the emblem is covered with mud,
dirt, dead leaves, wet snow, etc., or if
you put a sticker on it, the CMBS will
automatically shut off, and the
CMBS indicator on the instrument
panel will come on. You will also see
a CHECK CMBS RADAR SENSOR
message on the multi-inf ormation
display f or about 5 seconds.Always keep the emblem clean. If it
gets dirty, clean it with water or a
mild detergent. Never use chemical
solvents or polishing powder.Do not allow anything to impact the
radar sensor or the emblem. If either
of these parts receives a strong
impact, turn off the system by
pressing the CMBS of f switch, and
have your vehicle checked by a
dealer. If the f ront grille ever needs
to be repaired, consult a dealer f irst.
There are three bolts on the sides of
the radar sensor. Do not tamper with
these bolts, or you may cause the
system to malf unction. If the f ront emblem or the radar
sensor ever needs to be removed,
take your vehicle to a dealer.
Collision Mitigation Brake System (CMBS)
Radar Sensor
356
EMBLEM
BOLTS
(Do not tamper)
——
y
y
(y
y

When the CMBS is on, the radar
sensor constantly scans for vehicles
ahead of you. This means that
driving on a ro ad with a few or no
vehicles could cause a CHECK
CMBS RADAR SENSOR message to
appear on the multi-information
display. This is normal and not a
cause for concern. The
radar sensor may not always
scan as intended. Here are two
examples:
Thetiresarenotcorrectly
maintained. Always make sure the
tire pressures are correct (see
page ), and that the tires are
the correct size and in good
condition (see Tires on page ).
Your
vehicle is tilted because of a
heavy load in the rear or from
modifications to the suspension.
Do not overload your vehicle (see
Carrying Cargo on page ), and
do not make any modifi cations to
the suspension (see Accessories
and Modifications on page ).
335
333
415 415
Collision Mitigation Brake System (CMBS)
Driving
357
——
