Moving the front seat forcibly
back against cargo on the seat or
floor behind it.
Hanging heavy items on the front
passenger seat, or placing heavy
items in the seat-back pocket.
When
the airbag is turned off, a
‘‘passenger airbag off’’ indicator in
the center of the dashboard comes
on (see page ).
To ensure that the passenger’s
advanced front airbag system will
work properly,
This includes:
A rear passenger pushing or
pulling on the back of the front
passenger’s seat. Also,makesurethefloormatbehind
the
front passenger’s seat is hooked
to the floor mat anchor (see page ). If it is not, the mat may
interf ere with the proper operation
of the sensors and operation of the
seat.
If the weight sensors detect there is
no passenger in the f ront seat, the
airbag will be off. However, the
passenger airbag of f indicator will
not come on.
If you ever have a moderate to
severe side impact, sensors will
detect rapid acceleration and signal
the control unit to instantly inf late
either the driver’s or the passenger’s
side airbag and activate the seat belt
tensioner on the af f ected side.
35
412
Additional Inf ormation About Your Airbags
How Your Side A irbags Work
do not do anyt hing
t hat would increase or decrease t he weight on the f ront passenger’s seat.
32
——
y
y
(yy

There will be some delay between
the moment the passenger moves
into or out of the airbag deployment
pathandwhentheindicatorcomes
on or goes off.
A front seat passenger should not
use a cushion or other object as a
backrest. It may prevent the cutoff
system from working properly.
Only
one airbag will deploy during a
side impact. If the impact is on the
passenger’s side, the passenger’s
side airbag will deploy even if there
is no passenger.
To get the best protection from the
side airbags, front seat occupa nts
should wear their seat belts and sit
upright and well back in their seats. If the side airbag of f indicator comes
on (see page ), have the
passenger sit upright. Once the
passenger is out of the airbag’s
deployment path, the system will
turn the airbag back on, and the
indicator will go out.
Your vehicle has a side airbag cutof f
system designed primarily to protect
a child riding in the f ront passenger’s
seat.
Although Acura does not encourage
children to ride in f ront, if the
sensors in the seat detect a child has
leaned into the side airbag’s
deployment path, the airbag will shut
off.
Thesideairbagmayalsoshutoff if a
short adult leans sideways, or a
larger adult slouches and leans
sideways into the airbag’s
deployment path.
Objects placed on the f ront
passenger seat can also cause the
side airbag to be shut of f . 35
Additional Inf ormation About Your Airbags
Side A irbag Cut of f Syst em
Driver and Passenger Saf ety
33
——
y

y
(yy

If the impact is on the passenger’s
side, the passenger’s side curtain
airbag will inflate even if there are no
occupants on that side of the vehicle.
To get the best protection f rom the
side curtain airbags, occupants
should wear their seat belts and sit
upright and well back in their seats.If the indicator comes on or
flashesonandoff whileyoudrive. If the indicator stays on after the
engine starts. If the SRS indicator does not come
on after you turn the ignition
switch to the ON (II) position.The SRS indicator alerts
you to a potential problem
with your airbags, seat belt
tensioners, and, on models with
CMBS, seat belt e-pretensioners.
If the indicator comes on at any
other time, or does not come on at all,
you should have the system checked
by your dealer. For example:
In a moderate to severe side impact,
sensors will detect rapid acceleration
and signal the control unit to
instantly inflate the side curtain
airbag and activate the seat belt
tensioner on the driver’s or the
passenger’s side of the vehicle. When you turn the ignition switch to
the ON (II) position, this indicator
comes on brief ly then goes of f . This
tells you the system is working
properly.
How Your Side Curtain A irbags
Work
How the SRS Indicator Works
Additional Inf ormation About Your Airbags
34
SIDE CURTAIN AIRBAG
——
y
y
(yy

CONTINUED
You will also see a ‘‘CHECK
AIRBAG SYSTEM’’ message on the
multi-info rmation display (see page
). This indicator alerts
you that the
passenger’s side airbag has been
automatically shut off. It does
mean there is a problem with your
side airbags.
If
you see any of these indications,
the airbags and seat belt tensioners
may not work properly when you
need them.
When you turn the ignition switch to
the ON (II) position, the indicator
should come on briefly and go out
(see page ). If it does not come on,
stays on, or comes on while driving
wi thout a passenger in the front seat,
you will also see a ‘‘PASSENGER
SIDE AIRBAG OFF’’ message on the
multi-information display. Have the
system checked (see page ). This indicator alerts you that the
passenger’s f ront airbag has been
shut of f because weight sensors
detectabout65lbs(29kg)orless
(the weight of an inf ant or small
child) on the f ront passenger’s seat.
It does there is a problem
with the airbag.
78
6379
Additional Inf ormation About Your Airbags
How the Passenger Airbag Of f
Indicator Works
How the Side Airbag Of f
Indicator Works
not
not mean
Driver and Passenger Saf ety
35
PASSENGER AIRBAG OFF INDICATOR
Canada
U.S.
Canada
U.S.
Ignoring the SRS indicator can
result in serious injury or death
if the airbag systems or
tensioners do not work properly.
Have your vehicle checked by a
dealer as soon as possible if
the SRS indicator alerts you to
a possible problem.
——
y
y
(yy

Be aware that objects placed on the
f ront seat can cause the indicator to
come on.
If no weight is detected on the f ront
seat, the airbag will be automatically
shut of f . However, the indicator will
not come on.
The passenger airbag of f indicator
maycomeonandoff repeatedlyif
the total weight on the seat is near
the airbag cutof f threshold.
If an adult or teenage passenger is
riding in f ront, move the seat as f ar
to the rear as possible, and have the
passenger sit upright and wear the
seat belt properly.If the indicator comes on with no
f ront seat passenger and no objects
on the seat, or with an adult riding
there, something may be interf ering
with the weight sensors. Look f or
and remove:
Any items under the f ront
passenger’s seat.
Any object hanging on the seat or
in the seat-back pocket.
Any object touching the rear of
the seat-back. Your airbag systems are virtually
maintenance f ree, and there are no
parts you can saf ely service.
However, you must have your
vehicle serviced if:
Any airbag
that has deployed must be
replaced along with the control
unit and other related parts. Any
seat belt tensioner that activates
must also be replaced.
Do not try to remove or replace
anyairbagbyyourself.Thismust
be done by an authorized dealer or
a knowledgeable body shop.
If no obstructions are f ound, have
your vehicle checked by a dealer as
soon as possible.
Additional Inf ormation About Your Airbags
Airbag Service
An airbag ever inf lates.
36
——
y
y
(y
y

Improperly replacing
or covering f ront seat-back covers
can prevent your side airbags f rom
inf lating during a side impact.
If water or
another liquid soaks into the seat-
back, it can prevent the side airbag
cutoff system from working
properly.
Together, airbags and
seat belts provide the best
protection.
Tampering could cause
the airbags to deploy, possibly
causing very serious injury.
This could make the
driver’s seat position sensor or the
f ront passenger’s weight sensors
inef f ective. If it is necessary to
remove or modif y a f ront seat to
accommodate a person with
disabilities, f irst contact Acura
Client Services at 800-382-2238.
Take your vehicle to an
authorized dealer as soon as
possible. If you ignore this
indication, your airbags may not
operate properly.
Even if your
airbags do not inflate, your dealer
should inspect the driver’s seat
position sensor, the f ront
passenger’s weight sensors, the
f ront seat belt tensioners, and all
seat belts worn during the crash to
make sure they are operating
properly.
Additional Inf ormation About Your Airbags
Do not cover or replace f ront seat -
back covers wit hout consult ingyour dealer.
Do not expose the f ront passenger’sseat-back to liquid.
Donotattempttodeactivateyour
airbags.
Do not t amper wit h airbagcomponent s or wiring f or anyreason.
Do not remove or modif y a f rontseat without consulting yourdealer.
T he SRS indicat or alert s you t o a
problem.
If your vehicle has a moderat e t osevere impact .Additional Saf ety Precautions
Driver and Passenger Saf ety
37
——
y
y
(yy

This indicator has two functions:
Itcomesonwhenyouturnthe
ignition switch to the ON (II)
position. It is a reminder to check
the parking brake. Driving with
the parking brake not fully
released can damage the rear
brakes, axles, and tires.
If you drive without releasing the
parking brake, a beeper will sound,
and you will also see a ‘‘RELEASE
PARKING BRAKE’’ message on
the multi-information display (see
page ).
If it stays on after you have fully
released the parking brake while
the engine is running, or if it
comes on while driving, it can
indicate a problem in the brake system.
You will also see a
‘‘BRAKE FLUID LOW’’ or
‘‘CHECK BRAKE SYSTEM’’
message on the multi-information
display. For more information, see
page .
This indicator comes on when you
turn the ignition switch to the ON
(II) position. If it comes on at any
other time, it indicates that the
passenger’s side airbag has
au tomatically shut off. You will also
see a ‘‘PASSENGER SIDE AIRBAG
OFF’’ message on the multi-
information display (see page ).
For more information, see page .This
indicator comes on briefly when
you turn the ignition switch to the
ON (II) position. If it comes on at
any other time, it indicates a
poten tial problem with your front
airbags. This indica tor will also alert
you to a poten tial problem with your
side airbags, passenger’s side airbag
automatic cutoff system, side curtain
airbags, automatic seat belt
tensioners driver’s seat position
sensor, the front passenger’s weight
sensors, or, on models with ACC,
seat belt e-pretensioners. You will
also see a ‘‘CHECK AIRBAG
SYSTEM’’ message on the multi-
inf ormation display (see page ).
For more inf ormation, see page .
1.
2.
78
3578
35
445
79
Instrument Panel Indicators
Parking Brake and Brake System
Indicator Supplemental Restraint
System Indicator
Side Airbag Of f Indicator
Inst rument s and Cont rols
63
U.S. Canada U.S. Canada
——
y
y
(yy

This indicator comes on when the
security system is set. For more
info rmation, see page .
This
indicator normally comes on for
a few seconds when you turn the
ignition switch to the ON (II)
position.
Itcomesonasareminderthatyou
have turned off the adaptive front
lighting system (AFS).
This indicator blinks when there is a
problem with the AFS syste m; you
will also see a ‘‘CHECK ADAPTIVE
FRONT LIGHTING SYSTEM’’
message on the multi-information
display (see page ). If this
happens, stop the vehicle in a safe
place, turn the ignition switch to the
ACCESSORY (I) or the LOCK (0)
position, and restart the engine. If
the indicator does not go off or
blinks again, take your vehicle to a
dealer to have it checked. For more
info rmation, see page . This
indicator normally comes on for
a few seconds when you turn the
ignition switch to the ON (II)
position. It also comes on as a reminder
that you have turned off
the collision mitigation brake system
(CMBS).
The CMBS indicator also comes on
if dirt or other debris blocks the
radar sensor in the front grille. You
will also see a ‘‘CHECK CMBS
RADAR SENSOR’’ message on the
multi-information display. When you
clean the radar sensor, the indicator
should go off the next time you turn
the ignition switch to the ON (II)
position.
If the indicator comes on at any
other time, there is a problem with
the CMBS. You will also see a
‘‘CHECK CMBS SYSTEM’’ message
on the multi-information display. If
this happens, take your vehicle to a
dealer, and have it checked. For
more information, see page .
When this indicator is on, the CMBS
is not working.
78
143 274
359
If equipped
If equipped
A daptive Front L ighting
System (A FS) IndicatorSecurity System Indicator
Collision Mitigation
Brake System (CMBS)
Indicator
Instrument Panel Indicators
Inst rument s and Cont rols
69
SECURITY SYSTEM INDICATOR
——
y
y
(yy
